MTP2 Link Congestion Detection

To detect the congestion level, (Link TPS * 2 ) base is used for the base calculation.

If the sum of Link transmission buffer and MTP2 connection buffer queue utilization percentage is above configured threshold level, then the link is treated as congested.

The following figure describes the MTP2 Link Congestion:

MTP2 Congestion Detection
