Example Instance of an Account Integration Object

This example shows an Account integration object in which the object has two component types: Account and Business Address (which is a child of Account). The hierarchy of component types, from the perspective of Oracle’s Siebel Tools, looks like that shown in the following figure.

Sample Account Integration Object. In this image, Account is connected by one-way arrow to Business Address.

The following figure shows an example instance of this object type, using the Integration Object Hierarchy representation. There are two Sample Account instances. The first object instance has an Account component and two Business Address child components. The second object instance has only an Account component with no child components.

Partial Instance of Sample Account Integration Object. This image is described in surrounding text.
