Add an Oracle Integration Instance to an Environment

Before you can use the Integration build steps in a build job, you need to add Oracle Integration (OIC) instances to your VB Studio Environment definition. The way most users add these instances from your Identity domain is by selecting one from the list displayed in the table. To add OIC instances from another stripe, you can use the Oracle Integration Credentials option to add an OIC instance to an environment.

See Move Oracle Integration Artifacts, Packages, and Lookups Between Instances to learn about using Integration build steps to move integrations, packages, and lookups between instances.
To add an OIC instance to an environment:
  1. In the left navigator, click Environments Environments.
  2. Select an existing environment to add an Oracle Integration instance to or create a new one.
  3. In the Service Instances tab, click + Add Instance.
    Add Service Instances page, with Visual Builder and Oracle Integration instance type and Oracle Integration Credentials authentication method selected. The required fields (Base URL, Instance Name, Username, and Password) need to be filled out.
  4. In the Add Service Instance page, select Visual Builder and Oracle Integration under Instance Type and then, under Authentication Method, select Identity Domain or Oracle Integration Credentials:
    • Most of the time, you'll just select an instance from your Identity domain. To do this, click Identity Domain, select the instance from the list shown in the table, then click Add.

      To select an instance from a different region or compartment, click Edit Edit icon.
      Description of add-service-instance-panel.png follows
      Description of the illustration add-service-instance-panel.png

      The panel for editing the OCI account details is displayed.
      Description of add-service-instance-edit-oci-account-details.png follows
      Description of the illustration add-service-instance-edit-oci-account-details.png
      Note that the Root compartment is shown by default. Use the Region or Compartment selector to choose another region or compartment.

    • If you want to add OIC instances from another stripe, select the Oracle Integration Credentials option and VB Studio displays the Add Oracle Integration using Oracle Integration Credentials dialog shown above. Continue with the next step.
  5. In Base URL, enter the URL used to access the application instance.
  6. In Instance Name, enter the display name that will be used for the service instance within the environment.
  7. In Username, enter the username you use to log in to this application.
  8. In Password, enter the password associated with the username from the previous step.
  9. Click Add.

    The Service Instances tab displays the Oracle Integration instance you just added.

    Oracle Integration service instance details for OICINST_maindev in the Service Instances tab
