Specify Your Rule's Logic

Use a logic operator in your statement rule to enforce a relationship, such as Requires, Negates, Implies, and so on.

Consider this pseudocode:

If you select option a in the x configured item, then you must also select option y.

Note

You can propagate logic from operand x to operand y, or from operand y to operand x.
If your logic doesn't propagate the value for a relationship, then the rule doesn't modify the option's logic on the other side of the rule.
The term true means the configuration includes the option.
The term false means the configuration doesn't include the option.
We use the terms true and false here only to document how the rule works. You don't use true and false in your code.

Requires

If you select an option, then Oracle Configurator applies the same value to the other option.

If you:

Select option a, then Configurator also selects option b.
Deselect option a, then Configurator also deselects option b.
Select option b, then Configurator also selects option a.
Deselect option b, then Configurator also deselects option a.

Negates

If you select an option, then Configurator applies the opposite value to the other option.

If you:

Select option a, then Configurator deselects option b.
Deselect option a, then Configurator selects option b.
Select option b, then Configurator deselects option a.
Deselect option b, then Configurator selects option a.

Implies

Here's how an Implies rule works.

If you:

Select option a, then Configurator also selects option b.
Deselect option a, then Configurator deselects option b, and you can select or deselect option b.
Select option b, then Configurator deselects option a, and you can select or deselect option a.
Deselect option b, then Configurator also deselects option a.

Excludes

Here's how an Excludes rule works.

If you:

Select option a, then Configurator deselects option b and prevents you from selecting b because the rule excludes b from the configuration.
Deselect option a, then option b becomes available and you can select or deselect option b.
Select option b, then Configurator deselects option a and prevents you from selecting option a.
Deselect option b, then option a becomes available and you can select or deselect option a.

Logic States and Rule Variables

Configurator attempts to narrow the values that you can set for each model’s node at run time. You can specify the minimum value and the maximum value for each node. If you don't:

Select or exclude an option, then Configurator doesn't bind the variable.
Make a selection, enter a value, or click Finish and Review, then Configurator doesn't bind the variable.
Make a selection, or if Configurator hasn't excluded an option at run time, then the value of the SelectionState attribute and the DetailedSelectionState attribute is Selectable.
Configurator might also exclude an option through a default, search decision, or autocomplete.
