cXML 1.2.008 Cancel Order Requests Out

There are two cXML 1.2.008 Cancel Order Request message definitions outlined in this section:

  • cXML-1-2-008-CancelOrderRequest-Out

  • OBN-cXML-1-2-008-CancelOrderRequest-Out

Data Mapping

Refer to Figure 1 in cXML 1.2.007 Order Requests for the structure of the payload received from the application.

This figure shows the structure of the payload that is sent to the supplier.

Payload structure for the cxml order request message definitions.

This table shows the data mapping for the predefined cXML message definitions for cancel order requests, cXML-1-2-008-CancelOrderRequest-Out and OBN-cXML-1-2-008-CancelOrderRequest-Out for the extensible purchase order data model.
Note: Only the header level information is mapped.

Procurement Source

Message Payload
Segment1 /cXML/Request/OrderRequest/OrderRequestHeader/@orderID
OrderDate /cXML/Request/OrderRequest/OrderRequestHeader/@orderDate
N/A /cXML/Request/OrderRequest/OrderRequestHeader/@orderType

Set to regular.
CollaborationEventName /cXML/Request/OrderRequest/OrderRequestHeader/@type
Note: For OrderRequest, the value is set to new. For ChangeOrderRequest, the value is set to update. For CancelOrderRequest, the value is set to delete.
RevisionNum /cXML/Request/OrderRequest/ OrderRequestHeader/@orderVersion
Note: This field is only applicable for OrderRequest or ChangeOrderRequest and the value is equal to RevisionNum + 1.
Attribute1...16 /cXML/Request/OrderRequest/OrderRequestHeader/ Extrinsic[@name="ATTRIBUTE1...16"]
CurrencyCode

There's a predefined DVM in use for this field.

 /cXML/Request/OrderRequest/ OrderRequestHeader/Total/Money/@Currency
Ordered /cXML/Request/OrderRequest/ OrderRequestHeader/Total/Money
PdfDraftPurchaseOrderLineVORow/PdfDraftPurchaseOrderLineLocationVORow/ShipToLocCountry /cXML/Request/OrderRequest/OrderRequestHeader/ ShipTo/Address/@isoCountryCode
Note: The ship-to fields from the first line location (schedule) are mapped to the cXML Fields at the header.There's a predefined DVM in use for this field.
PdfDraftPurchaseOrderLineVORow/PdfDraftPurchaseOrderLineLocationVORow/ShipToInternalLocationCode /cXML/Request/OrderRequest/OrderRequestHeader/ ShipTo/Address/@addressID
Note: The ship-to fields from the first line location (schedule) are mapped to the cXML Fields at the header.There's a predefined DVM in use for this field.
PdfDraftPurchaseOrderLineVORow/PdfDraftPurchaseOrderLineLocationVORow/LineLocShipToLocationName /cXML/Request/OrderRequest/OrderRequestHeader/ ShipTo/Address/Name
Note: The ship-to fields from the first line location (schedule) are mapped to the cXML Fields at the header.
PdfDraftPurchaseOrderLineVORow/PdfDraftPurchaseOrderLineLocationVORow/PdfDraftPurchaseOrderDistributionVORow/Requester /cXML/Request/OrderRequest/OrderRequestHeader/ ShipTo/Address/PostalAddress/DeliverTo
Note: The ship-to fields from the first line location (schedule) are mapped to the cXML Fields at the header.
PdfDraftPurchaseOrderLineVORow/PdfDraftPurchaseOrderLineLocationVORow/ShipToLocAddressLine1 /cXML/Request/OrderRequest/OrderRequestHeader/ ShipTo/Address/PostalAddress/Street
Note: The ship-to fields from the first line location (schedule) are mapped to the cXML Fields at the header.
PdfDraftPurchaseOrderLineVORow/PdfDraftPurchaseOrderLineLocationVORow/ShipToLocAddressLine2 /cXML/Request/OrderRequest/OrderRequestHeader/ ShipTo/Address/PostalAddress/Street
Note: The ship-to fields from the first line location (schedule) are mapped to the cXML Fields at the header.
PdfDraftPurchaseOrderLineVORow/PdfDraftPurchaseOrderLineLocationVORow/ShipToLocAddressLine3 /cXML/Request/OrderRequest/OrderRequestHeader/ ShipTo/Address/PostalAddress/Street
Note: The ship-to fields from the first line location (schedule) are mapped to the cXML Fields at the header.
PdfDraftPurchaseOrderLineVORow/PdfDraftPurchaseOrderLineLocationVORow/ShipToLocTownOrCity /cXML/Request/OrderRequest/OrderRequestHeader/ ShipTo/Address/PostalAddress/City
Note: The ship-to fields from the first line location (schedule) are mapped to the cXML Fields at the header.
PdfDraftPurchaseOrderLineVORow/PdfDraftPurchaseOrderLineLocationVORow/ShipToLocStateProvn /cXML/Request/OrderRequest/OrderRequestHeader/ ShipTo/Address/PostalAddress/State
Note: The ship-to fields from the first line location (schedule) are mapped to the cXML Fields at the header.There's a predefined DVM in use for this field.
PdfDraftPurchaseOrderLineVORow/PdfDraftPurchaseOrderLineLocationVORow/ShipToLocPostalCode /cXML/Request/OrderRequest/OrderRequestHeader/ ShipTo/Address/PostalAddress/PostalCode
Note: The ship-to fields from the first line location (schedule) are mapped to the cXML Fields at the header.
PdfDraftPurchaseOrderLineVORow/PdfDraftPurchaseOrderLineLocationVORow/ShipToLocCountry /cXML/Request/OrderRequest/OrderRequestHeader/ ShipTo/Address/PostalAddress/Country/@isoCountryCode
Note: The ship-to fields from the first line location (schedule) are mapped to the cXML Fields at the header.There's a predefined DVM in use for this field.
PdfDraftPurchaseOrderLineVORow/PdfDraftPurchaseOrderLineLocationVORow/ShipToLocCountry /cXML/Request/OrderRequest/OrderRequestHeader/ ShipTo/Address/PostalAddress/Country
Note: The ship-to fields from the first line location (schedule) are mapped to the cXML Fields at the header.There's a predefined DVM in use for this field.
PdfDraftPurchaseOrderLineVORow/PdfDraftPurchaseOrderLineLocationVORow/PdfDraftPurchaseOrderDistributionVORow/RequesterEmailAddress /cXML/Request/OrderRequest/OrderRequestHeader/ ShipTo/Address/Email
Note: The ship-to fields from the first line location (schedule) are mapped to the cXML Fields at the header.
PdfDraftPurchaseOrderLineVORow/PdfDraftPurchaseOrderLineLocationVORow/ShipToLocCountry /cXML/Request/OrderRequest/OrderRequestHeader/ ShipTo/Address/Phone/TelephoneNumber/CountryCode/@isoCountryCode
Note: The ship-to fields from the first line location (schedule) are mapped to the cXML Fields at the header.There's a predefined DVM in use for this field.
PdfDraftPurchaseOrderLineVORow/PdfDraftPurchaseOrderLineLocationVORow/ShipToLocCountry /cXML/Request/OrderRequest/OrderRequestHeader/ ShipTo/Address/Phone/TelephoneNumber/CountryCode
Note: The ship-to fields from the first line location (schedule) are mapped to the cXML Fields at the header.There's a predefined DVM in use for this field.
n/a /cXML/Request/OrderRequest/OrderRequestHeader/ ShipTo/Address/Phone/TelephoneNumber/AreaOrCityCode
Note: The ship-to fields from the first line location (schedule) are mapped to the cXML Fields at the header.
PdfDraftPurchaseOrderLineVORow/PdfDraftPurchaseOrderLineLocationVORow/PdfDraftPurchaseOrderDistributionVORow/RequesterPhoneNumber /cXML/Request/OrderRequest/OrderRequestHeader/ ShipTo/Address/Phone/TelephoneNumber/Number
Note: The ship-to fields from the first line location (schedule) are mapped to the cXML Fields at the header.
BillToLocCountry

There's a predefined DVM in use for this field.

 /cXML/Request/OrderRequest/OrderRequestHeader/BillTo/Address/@isoCountryCode
BillToLocationCode

There's a predefined DVM in use for this field.

 /cXML/Request/OrderRequest/OrderRequestHeader/BillTo/Address/@addressID
BillToBuName /cXML/Request/OrderRequest/OrderRequestHeader/BillTo/Address/Name
BillToLocAddressLine1 /cXML/Request/OrderRequest/OrderRequestHeader/ BillTo/Address/PostalAddress/Street
BillToLocAddressLine2 /cXML/Request/OrderRequest/OrderRequestHeader/ BillTo/Address/PostalAddress/Street
BillToLocAddressLine3 /cXML/Request/OrderRequest/OrderRequestHeader/ BillTo/Address/PostalAddress/Street
BillToLocTownOrCity /cXML/Request/OrderRequest/OrderRequestHeader/ BillTo/Address/PostalAddress/City
BillToLocStateProvn

There's a predefined DVM in use for this field.

 /cXML/Request/OrderRequest/OrderRequestHeader/ BillTo/Address/PostalAddress/State
BillToLocPostalCode /cXML/Request/OrderRequest/OrderRequestHeader/ BillTo/Address/PostalAddress/PostalCode
BillToLocCountry

There's a predefined DVM in use for this field.

 /cXML/Request/OrderRequest/OrderRequestHeader/BillTo/ Address/PostalAddress/Country/@isoCountryCode
BillToLocCountry

There's a predefined DVM in use for this field.

 /cXML/Request/OrderRequest/OrderRequestHeader/ BillTo/Address/PostalAddress/Country
BillToLocCountry

There's a predefined DVM in use for this field.

 /cXML/Request/OrderRequest/OrderRequestHeader/BillTo/ Address/Phone/TelephoneNumber/CountryCode/@isoCountryCode
BillToLocCountry

There's a predefined DVM in use for this field.

 /cXML/Request/OrderRequest/OrderRequestHeader/ BillTo/Address/Phone/TelephoneNumber/CountryCode
BillToLocTelephoneNumber1 /cXML/Request/OrderRequest/OrderRequestHeader/ BillTo/Address/Phone/TelephoneNumber/Number
CarrierPartyName /cXML/Request/OrderRequest/OrderRequestHeader/ Shipping/@trackingDomain
CurrencyCode

There's a predefined DVM in use for this field.

 /cXML/Request/OrderRequest/OrderRequestHeader/ Shipping/Money/@currency
CarrierPartyName /cXML/Request/OrderRequest/ OrderRequestHeader/Shipping/Description
/cXML/Request/OrderRequest/ OrderRequestHeader/Contact/@role

Set to buyer.
PersonName /cXML/Request/OrderRequest/ OrderRequestHeader/Contact/Name
SoldToLeAddressLine1 /cXML/Request/OrderRequest/OrderRequestHeader/ Contact/PostalAddress/Street
SoldToLeAddressLine2 /cXML/Request/OrderRequest/OrderRequestHeader/ Contact/PostalAddress/Street
SoldToLeAddressLine3 /cXML/Request/OrderRequest/OrderRequestHeader/Contact/PostalAddress/Street
SoldToLeAddressLine4 /cXML/Request/OrderRequest/OrderRequestHeader/Contact/PostalAddress/Street
SoldToLeTownOrCity /cXML/Request/OrderRequest/OrderRequestHeader/ Contact/PostalAddress/City
SoldToLeStateProvn

There's a predefined DVM in use for this field.

 /cXML/Request/OrderRequest/OrderRequestHeader/ Contact/PostalAddress/State
SoldToLePostalCode /cXML/Request/OrderRequest/OrderRequestHeader/ Contact/PostalAddress/PostalCode
SoldToLeCountry

There's a predefined DVM in use for this field.

 /cXML/Request/OrderRequest/OrderRequestHeader/Contact/PostalAddress/Country/@isoCountryCode
SoldToLeCountry

There's a predefined DVM in use for this field.

 /cXML/Request/OrderRequest/OrderRequestHeader/ Contact/PostalAddress/Country
PersonEmailAddress /cXML/Request/OrderRequest/ OrderRequestHeader/Contact/Email
SoldToLeCountry

There's a predefined DVM in use for this field.

 /cXML/Request/OrderRequest/OrderRequestHeader/Contact/Phone/ TelephoneNumber/CountryCode/@isoCountryCode
SoldToLeCountry

There's a predefined DVM in use for this field.

 /cXML/Request/OrderRequest/OrderRequestHeader/ Contact/Phone/TelephoneNumber/CountryCode
PersonWorkPhone /cXML/Request/OrderRequest/OrderRequestHeader/ Contact/Phone/TelephoneNumber/Number
PdfDraftPurchaseOrderHeaderVORow/ PdfDraftPurchaseOrderHeaderVOToAttachmentsVOAccessor/ AttachmentsVORow/FileName /cXML/Request/OrderRequest/OrderRequestHeader/ Comments/Attachment/URL/@name
PdfDraftPurchaseOrderHeaderVORow/ PdfDraftPurchaseOrderHeaderVOToAttachmentsVOAccessor/ AttachmentsVORow/DmDocumentId /cXML/Request/OrderRequest/OrderRequestHeader/ Comments/Attachment/URL
AcceptanceRequiredFlag /cXML/Request/OrderRequest/ OrderRequestHeader/Extrinsic[@name="ACKREQD"]
AcceptanceDueDate /cXML/Request/OrderRequest/OrderRequestHeader/ Extrinsic[@name="ACKBYDATE"]
TermsAndConditions /cXML/Request/OrderRequest/ OrderRequestHeader/Extrinsic[@name="TANDC"]
HeaderNoteToVendor /cXML/Request/OrderRequest/OrderRequestHeader/ Extrinsic[@name="NOTES_1"]

Sample Payload

Here's a sample of the payload:

<sendCollaborationDocument xmlns="http://xmlns.oracle.com/apps/scm/cmk" xmlns:wsa="http://www.w3.org/2005/08/addressing">
   <CollaborationEvent testFlag="true" testResult="Success">
      <CollaborationEventName>PurchaseOrderIssued</CollaborationEventName>
      <RecipientKey1>999992000323897</RecipientKey1>
      <RecipientKey2>999992000365366</RecipientKey2>
      <RecipientKeyType>Supplier Site</RecipientKeyType>
      <ObjectKey1>300100035338808</ObjectKey1>
      <ObjectKey2>1002676</ObjectKey2>
      <ObjectKey3>Vision Operations</ObjectKey3>
   </CollaborationEvent>
   <Document>
      <tns:getCmkInputPayloadResponse xmlns:tns="http://xmlns.oracle.com/apps/prc/po/manageDocument/publicModel/viewPdf/types/">
         <tns:result xmlns:ns2="http://xmlns.oracle.com/apps/prc/po/manageDocument/publicModel/viewPdf/v2/">
            <ns2:PdfDraftPurchaseOrderHeaderVORow>
               <ns2:Segment1>1004846</ns2:Segment1>
               <ns2:CurrencyCode>USD</ns2:CurrencyCode>
               <ns2:HeaderNoteToVendor>Note to Supplier</ns2:HeaderNoteToVendor>
               <ns2:Comments>PO description</ns2:Comments>
               <ns2:AcceptanceRequiredFlag>Y</ns2:AcceptanceRequiredFlag>
               <ns2:AcceptanceDueDate>2020-10-09T00:00:00.000+00:00</ns2:AcceptanceDueDate>
               <ns2:Attribute1>Attribute1</ns2:Attribute1>
               <ns2:Attribute2>Attribute2</ns2:Attribute2>
               <ns2:Attribute3>Attribute3</ns2:Attribute3>
               <ns2:Attribute4>Attribute4</ns2:Attribute4>
               <ns2:Attribute5>Attribute5</ns2:Attribute5>
               <ns2:Attribute6>Attribute6</ns2:Attribute6>
               <ns2:Attribute7>Attribute7</ns2:Attribute7>
               <ns2:Attribute8>Attribute8</ns2:Attribute8>
               <ns2:Attribute9>Attribute9</ns2:Attribute9>
               <ns2:Attribute10>Attribute10</ns2:Attribute10>
               <ns2:Attribute11>Attribute11</ns2:Attribute11>
               <ns2:Attribute12>Attribute12</ns2:Attribute12>
               <ns2:Attribute13>Attribute13</ns2:Attribute13>
               <ns2:Attribute14>Attribute14</ns2:Attribute14>
               <ns2:Attribute15>Attribute15</ns2:Attribute15>
               <ns2:Attribute16>Attribute16</ns2:Attribute16>
               <ns2:EmailAddress>my@mail</ns2:EmailAddress>
               <ns2:RevisionNum>0</ns2:RevisionNum>
               <ns2:TermsAndConditions>TermsAndConditions</ns2:TermsAndConditions>
               <ns2:BillToLocationName>BillToLocationName</ns2:BillToLocationName>
               <ns2:SoldToLeName>Vision Operations</ns2:SoldToLeName>
               <ns2:SupplierPartyName>CMK_PO_18</ns2:SupplierPartyName>
               <ns2:SupplierContactPartyName>CMK_PO18_ST CMK_PO18_ST</ns2:SupplierContactPartyName>
               <ns2:CarrierPartyName>Airborne</ns2:CarrierPartyName>
               <ns2:PersonName>Clare Furey</ns2:PersonName>
               <ns2:PersonWorkPhone>123-456-7890</ns2:PersonWorkPhone>
               <!--<ns2:PersonFax>123-456-7890</ns2:PersonFax> -->
               <ns2:PersonEmailAddress>my@mailm</ns2:PersonEmailAddress>
               <ns2:PaymentTermsName>30 Net</ns2:PaymentTermsName>
               <ns2:isShipToLocationMultiple>N</ns2:isShipToLocationMultiple>
               <ns2:Ordered>1000.00</ns2:Ordered>
               <ns2:VendorID>123456</ns2:VendorID>
               <ns2:OrderedDisplay>1000.00</ns2:OrderedDisplay>
               <!-- <ns2:SupplierNumber>1488256471</ns2:SupplierNumber>
                  <ns2:ChangeOrderDate>2020-08-12T20:26:40.0Z</ns2:ChangeOrderDate> -->
               <ns2:OrderDate>2020-10-01T15:49:35.000000</ns2:OrderDate>
               <ns2:OrderDateDisplay>01-OCT-2020</ns2:OrderDateDisplay>
               <!-- <ns2:TotalTaxDisplay>0.00</ns2:TotalTaxDisplay> -->
               <ns2:VendorSiteCode>CMK_PO18_ST</ns2:VendorSiteCode>
               <ns2:SupplierSiteCity>Any City</ns2:SupplierSiteCity>
               <!-- <ns2:SupplierSiteCounty>Any County</ns2:SupplierSiteCounty> -->
               <ns2:SupplierSiteState>Any State</ns2:SupplierSiteState>
               <ns2:SupplierSiteCountry>Any Country</ns2:SupplierSiteCountry>
               <ns2:SupplierSitePostalCode>123456</ns2:SupplierSitePostalCode>
               <ns2:SupplierSiteAddress1>Address1</ns2:SupplierSiteAddress1>
               <ns2:SupplierSiteAddress2>Address2</ns2:SupplierSiteAddress2>
               <ns2:SupplierSiteAddress3>Address3</ns2:SupplierSiteAddress3>
               <ns2:SupplierSiteFaxCountryCode>1</ns2:SupplierSiteFaxCountryCode>
               <ns2:SupplierSiteFaxAreaCode>123</ns2:SupplierSiteFaxAreaCode>
               <ns2:SupplierSiteFaxPhoneNumber>456-7890</ns2:SupplierSiteFaxPhoneNumber>
               <ns2:SupplierSitePhoneAreaCode>123</ns2:SupplierSitePhoneAreaCode>
               <ns2:SupplierSitePhoneCountryCode>1</ns2:SupplierSitePhoneCountryCode>
               <ns2:SupplierSitePhoneNumber>456-7890</ns2:SupplierSitePhoneNumber>
               <ns2:BillToLocTownOrCity>Any City</ns2:BillToLocTownOrCity>
               <ns2:BillToLocCountry>US</ns2:BillToLocCountry>
               <ns2:BillToLocPostalCode>10022-3422</ns2:BillToLocPostalCode>
               <ns2:BillToLocAddressLine1>90 Fifth Avenue</ns2:BillToLocAddressLine1>
               <ns2:BillToLocAddressLine2>AddressLine2</ns2:BillToLocAddressLine2>
               <ns2:BillToLocAddressLine3>AddressLine3</ns2:BillToLocAddressLine3>
               <ns2:BillToLocStateProvn>NY</ns2:BillToLocStateProvn>
               <!--<ns2:BillToLocCounty>New York</ns2:BillToLocCounty> -->
               <ns2:BillToLocTelephoneNumber1>BillToLocTelephoneNumber1</ns2:BillToLocTelephoneNumber1>
               <!--<ns2:PaymentTermsDescription>PaymentTermsDescription</ns2:PaymentTermsDescription> -->
               <ns2:BillToBuName>Vision Operations</ns2:BillToBuName>
               <!--<ns2:SoldToLeName>Vision Operations</ns2:SoldToLeName>
                  <ns2:TaxRegistrationNumber>SYS12125</ns2:TaxRegistrationNumber>
                  <ns2:ProcurementBuName>Vision Operations</ns2:ProcurementBuName> -->
               <ns2:BillToLocationCode>V1- New York City</ns2:BillToLocationCode>
               <!-- <ns2:ModeOfTransportName>Parcel</ns2:ModeOfTransportName>
                  <ns2:ServiceLevelName>2nd day air</ns2:ServiceLevelName>
                  <ns2:ShippingMethod>Airborne-Parcel-2nd day air</ns2:ShippingMethod> -->
               <ns2:SoldToLeTownOrCity>New York</ns2:SoldToLeTownOrCity>
               <ns2:SoldToLeCountry>US</ns2:SoldToLeCountry>
               <ns2:SoldToLePostalCode>10022</ns2:SoldToLePostalCode>
               <ns2:SoldToLeAddressLine1>475 Park Avenue</ns2:SoldToLeAddressLine1>
               <ns2:SoldToLeAddressLine2>AddressLine2</ns2:SoldToLeAddressLine2>
               <ns2:SoldToLeAddressLine3>AddressLine3</ns2:SoldToLeAddressLine3>
               <ns2:SoldToLeAddressLine4>AddressLine4</ns2:SoldToLeAddressLine4>
               <ns2:SoldToLeStateProvn>NY</ns2:SoldToLeStateProvn>
               <!-- <ns2:SoldToLeCounty>New York</ns2:SoldToLeCounty>
                  <ns2:BuyerManagedTransportFlag>N</ns2:BuyerManagedTransportFlag> -->
               <ns2:PdfDraftPurchaseOrderLineVORow>
                  <ns2:LineNum>1</ns2:LineNum>
                  <!-- <ns2:ItemRevision>Rev</ns2:ItemRevision>  -->
                  <ns2:ItemDescription>Envoy Laptop - Rugged</ns2:ItemDescription>
                  <ns2:UnitPrice>500</ns2:UnitPrice>
                  <!-- <ns2:Quantity>2</ns2:Quantity>-->
                  <ns2:NoteToVendor>NoteToVendor</ns2:NoteToVendor>
                  <ns2:VendorProductNum>AS92888</ns2:VendorProductNum>
                  <ns2:Attribute1>Attribute1</ns2:Attribute1>
                  <ns2:Attribute2>Attribute2</ns2:Attribute2>
                  <ns2:Attribute3>Attribute3</ns2:Attribute3>
                  <ns2:Attribute4>Attribute4</ns2:Attribute4>
                  <ns2:Attribute5>Attribute5</ns2:Attribute5>
                  <ns2:Attribute6>Attribute6</ns2:Attribute6>
                  <ns2:Attribute7>Attribute7</ns2:Attribute7>
                  <ns2:Attribute8>Attribute8</ns2:Attribute8>
                  <ns2:Attribute9>Attribute9</ns2:Attribute9>
                  <ns2:Attribute10>Attribute10</ns2:Attribute10>
                  <ns2:Attribute11>Attribute11</ns2:Attribute11>
                  <ns2:Attribute12>Attribute12</ns2:Attribute12>
                  <ns2:Attribute13>Attribute13</ns2:Attribute13>
                  <ns2:Attribute14>Attribute14</ns2:Attribute14>
                  <ns2:Attribute15>Attribute15</ns2:Attribute15>
                  <ns2:Attribute16>Attribute16</ns2:Attribute16>
                  <ns2:SupplierRefNumber>SupplierRefNumber</ns2:SupplierRefNumber>
                  <!-- <ns2:BlanketHeaderDocNumber>BlanketHeaderDocNumber</ns2:BlanketHeaderDocNumber>
                     <ns2:ContractHeaderDocNumber>ContractHeaderDocNumber</ns2:ContractHeaderDocNumber> -->
                  <ns2:UnitOfMeasure>Each</ns2:UnitOfMeasure>
                  <ns2:ItemNumber>AS92888_CUSTOMER</ns2:ItemNumber>
                  <!--  <ns2:AmountDisplay>1,000.00</ns2:AmountDisplay>
                     <ns2:TotalTaxDisplay>0.00</ns2:TotalTaxDisplay> -->
                  <ns2:UomBaseLanguage>Each</ns2:UomBaseLanguage>
                  <ns2:PdfDraftPurchaseOrderLineLocationVORow>
                     <ns2:Quantity>10</ns2:Quantity>
                     <ns2:QuantityDisplay>10</ns2:QuantityDisplay>
                     <ns2:NeedByDate>2020-11-01T00:00:00.000+00:00</ns2:NeedByDate>
                     <!--  <ns2:PromisedDate>2020-09-01</ns2:PromisedDate> -->
                     <ns2:PriceOverride>PriceOverride</ns2:PriceOverride>
                     <ns2:TaxableFlag>N</ns2:TaxableFlag>
                     <ns2:ShipmentNum>1</ns2:ShipmentNum>
                     <!-- <ns2:Amount>5.00</ns2:Amount>  -->
                     <ns2:LineLocShipToLocationName>LineLocShipToLocationName</ns2:LineLocShipToLocationName>
                     <ns2:ShipToLocTownOrCity>New York</ns2:ShipToLocTownOrCity>
                     <ns2:ShipToLocCountry>US</ns2:ShipToLocCountry>
                     <ns2:ShipToLocPostalCode>10022-3422</ns2:ShipToLocPostalCode>
                     <ns2:ShipToLocAddressLine1>90 Fifth Avenue</ns2:ShipToLocAddressLine1>
                     <ns2:ShipToLocAddressLine2>AddressLine2</ns2:ShipToLocAddressLine2>
                     <ns2:ShipToLocAddressLine3>AddressLine3</ns2:ShipToLocAddressLine3>
                     <!--<ns2:ShipToLocAddressLine4>AddressLine4</ns2:ShipToLocAddressLine4> -->
                     <ns2:ShipToLocStateProvn>NY</ns2:ShipToLocStateProvn>
                     <!--  <ns2:ShipToLocCounty>New York</ns2:ShipToLocCounty> -->
                     <ns2:ShiptoCustomerName>ShipTo</ns2:ShiptoCustomerName>
                     <!-- <ns2:ShiptoCustContactName>Claire</ns2:ShiptoCustContactName>
                        <ns2:ShiptoCustContactEmailAddress>my@mail</ns2:ShiptoCustContactEmailAddress>
                        <ns2:ShiptoCustContactPhoneNumber>123-456-7890</ns2:ShiptoCustContactPhoneNumber>
                        <ns2:RequestedShipDate>1957-08-13</ns2:RequestedShipDate>-->
                     <ns2:ShipToInternalLocationCode>V1-_NEW_YORK_CITY_0_2450399170046</ns2:ShipToInternalLocationCode>
                     <ns2:PdfDraftPurchaseOrderDistributionVORow>
                        <ns2:Requester>Requester_LineLocDist</ns2:Requester>
                        <ns2:Attribute1>Attribute1</ns2:Attribute1>
                        <ns2:Attribute2>Attribute2</ns2:Attribute2>
                        <ns2:Attribute3>Attribute3</ns2:Attribute3>
                        <ns2:Attribute4>Attribute4</ns2:Attribute4>
                        <ns2:Attribute5>Attribute5</ns2:Attribute5>
                        <ns2:Attribute6>Attribute6</ns2:Attribute6>
                        <ns2:Attribute7>Attribute7</ns2:Attribute7>
                        <ns2:Attribute8>Attribute8</ns2:Attribute8>
                        <ns2:Attribute9>Attribute9</ns2:Attribute9>
                        <ns2:Attribute10>Attribute10</ns2:Attribute10>
                        <ns2:Attribute11>Attribute11</ns2:Attribute11>
                        <ns2:Attribute12>Attribute12</ns2:Attribute12>
                        <ns2:Attribute13>Attribute13</ns2:Attribute13>
                        <ns2:Attribute14>Attribute14</ns2:Attribute14>
                        <ns2:Attribute15>Attribute15</ns2:Attribute15>
                        <ns2:Attribute16>Attribute16</ns2:Attribute16>
                        <ns2:RequesterEmailAddress>RequesterEmailAddress</ns2:RequesterEmailAddress>
                        <ns2:RequesterPhoneNumber>RequesterPhoneNumber</ns2:RequesterPhoneNumber>
                     </ns2:PdfDraftPurchaseOrderDistributionVORow>
                     <ns2:PdfDraftPurchaseOrderLineLocationVOToAttachmentsVOAccessor>
                        <ns2:AttachmentsVORow>
                           <ns2:FileName>BUG 24415509.docx</ns2:FileName>
                           <ns2:DmDocumentId>UCMFA00074730</ns2:DmDocumentId>
                        </ns2:AttachmentsVORow>
                     </ns2:PdfDraftPurchaseOrderLineLocationVOToAttachmentsVOAccessor>
                  </ns2:PdfDraftPurchaseOrderLineLocationVORow>
                  <ns2:PdfDraftPurchaseOrderLineVOToAttachmentsVOAccessor>
                     <ns2:AttachmentsVORow>
                        <ns2:FileName>Attachments.txt</ns2:FileName>
                        <ns2:DmDocumentId>UCMFA00074727</ns2:DmDocumentId>
                     </ns2:AttachmentsVORow>
                  </ns2:PdfDraftPurchaseOrderLineVOToAttachmentsVOAccessor>
                  <!--<ns2:PdfDraftPurchaseOrderConfigComponentVORow>
                     <ns2:ItemDescription>ItemDescription</ns2:ItemDescription>
                     <ns2:UnitPrice>21</ns2:UnitPrice>
                     <ns2:ItemRevision>ItemRevision</ns2:ItemRevision>
                     <ns2:ComponentQuantity>5.00</ns2:ComponentQuantity>
                     <ns2:OptionItemNumber>123</ns2:OptionItemNumber>
                     <ns2:UnitPriceDisplay>20</ns2:UnitPriceDisplay>
                     <ns2:ComponentLineNumber>101</ns2:ComponentLineNumber>
                     <ns2:BaseModelItemNumber>12345</ns2:BaseModelItemNumber>
                     <ns2:ParentLineNumber>101</ns2:ParentLineNumber>
                     <ns2:UnitOfMeasure>Each</ns2:UnitOfMeasure>
                     <ns2:SupplierItemNumber>AS92888</ns2:SupplierItemNumber>
                     </ns2:PdfDraftPurchaseOrderConfigComponentVORow> -->
               </ns2:PdfDraftPurchaseOrderLineVORow>
               <ns2:PdfDraftPurchaseOrderHeaderVOToAttachmentsVOAccessor>
                  <ns2:AttachmentsVORow>
                     <ns2:FileName>notes.txt</ns2:FileName>
                     <ns2:DmDocumentId>UCMFA00074696</ns2:DmDocumentId>
                  </ns2:AttachmentsVORow>
               </ns2:PdfDraftPurchaseOrderHeaderVOToAttachmentsVOAccessor>
            </ns2:PdfDraftPurchaseOrderHeaderVORow>
         </tns:result>
      </tns:getCmkInputPayloadResponse>
   </Document>
</sendCollaborationDocument>
