2 Deployment Environment

This section provides information about the cloud native platform infrastructure details for deploying Oracle Communications Cloud Native Core, Converged Policy.

Note:

The performance and capacity of the Policy system may vary based on the Call model, Feature/Interface configurations, underlying CNE and hardware environment, including but not limited to the complexity of deployed policies, policy table size, object expression, and custom json usage in policy design.

2.1 Deployed Components

This section provides details about the deployed components.

Deployment Platform

Oracle Communications Cloud Native Core, Cloud Native Environment (CNE) 23.3.3 and BareMetal can be used for performing benchmark tests.

Table 2-1 Observability Services

Service Name	Version
OpenSearch	2.3.0
Fluentd	1.16.2
Prometheus	2.51.1
Grafana	9.5.3
Jaeger	1.52.0

Cloud Native Orchestrator

Kubernetes 1.28.x is used to manage application pods across the cluster.

cnDBTier

cnDBTier 24.1.0 is used for performing benchmark tests.

Policy Infrastructure Details

Infrastructure used for benchmarking Policy performance run is described in this section.

Table 2-2 Hardware Details

Hardware	Details
Environment	BareMetal
Server	Oracle Server X8-2
Model	Intel(R) Xeon(R) Platinum 8260
Clock Speed	2.400 GHz
Total Cores	96
Memory Size	576 GB
Type	DDR4 SDRAM
Installed DIMMs	18
Maximum DIMMs	24
Installed Memory	576 GB

Table 2-3 Software Details

Aplications	Version
Policy	24.1.0
cnDBTier	24.1.0
OSO	No
CNE	23.3.3

For more information about Policy Installation, see Oracle Communications Cloud Native Core, Converged Policy Installation, Upgrade, and Fault Recovery Guide.

2.2 Deployment Diagram

The following diagram describes the Policy application deployed in converged mode on a Two-Site Georedundant replication setup.

Figure 2-1 Policy Deployment in Single Site with ASM Disabled

Figure 2-2 Policy Deployment in Two-Site GR Setup

Figure 2-3 Policy Deployment in Four-Site GR Setup
