2 Deployment

OCNADD supports CNE deployment. There are a few variations in the deployment process for both the platforms. For more information about OCNADD installation, see Oracle Communications Network Analytics Data Director Installation, Upgrade, and Fault Recovery Guide.

The following diagram depicts the OCNADD deployment in the 5G architecture:

Figure 2-1 OCNADD Deployment


OCNADD Deployment

Note:

From release 23.1.0 onwards OCNADD supports Synthetic Feeds along with HTTP2 Feeds.
OCNADD uses the following common services of CNE:
  • Kubernetes
  • Prometheus
  • Metallb (Load balancer)
  • cnDBTier
