2.2.9.1 ACH Settlement Account Derivation Rule Summary

1. On Homepage, specify PMSSETRL in the text box, and click next arrow.
   ACH Settlement Account Derivation Rule Summary screen is displayed.

   Figure 2-15 ACH Settlement Account Derivation Rule Summary


   Description of "Figure 2-15 ACH Settlement Account Derivation Rule Summary"
2. Search using one or more of the following parameters:
   • Authorization Status
   • Record Status
   • Network Code
3. Once you specified the parameters, click the Search button.
   System displays the records that match the search criteria.
4. Double click a record or click the Details button after selecting a record to view the detailed screen.
