1.8.3 Fetch Values from List of Values (LOV)

This topic describes the systematic instruction to fetch values from list of values.

1. You can fetch data from an option list or list of values (LOV – ), if the LOV value is keyed in and tabbed out in its input field.
   System opens the LOV window in the following scenarios:

   • If more than one value exists for the value keyed in the input field of LOV.
   • If no value exists for the value keyed in the input field of LOV.

   The number of values and the total pages displayed in the LOV screen is based on the number of records matching the search criteria. Hence,

   • If the value that you have keyed in the input field has only one matching value in the LOV, then system will not open the LOV on tabbing out and all the return fields for that LOV will be automatically updated.
   • If more than one record is available, then the system displays the first 10 pages of the records. Click Next, Previous, Last and First Page to view the next set of records, previous set of records, last set of records, and first set of records, respectively.
   • If the total number of pages is less than 10, then the page count is displayed as Current Page of Exact Total Page Count. Else, the page count is displayed as Current Page of 10.
   • For both extensible and non-extensible screens, you can also maintain a query; in addition to existing LOV, for a particular column.

   Note:

   You can use wild card character (%) to search records in List of Values. If Minimum Search Character Length is enabled for a List of Values field, then you need to enter the minimum number of search characters along with wild card character to get valid results.

   If Exact Fetch is enabled for the field, then you must enter the exact text to get the value in the field.

   The system displays the following messages at the bottom of the screens, at different scenarios:

   • OK – if less than or equal to 10 records are fetched.
   • Please reframe your Search criteria – if more than 10 records are fetched.
   • No Records found – if no records are found matching the search criteria.
   • Error message – if the query fails

   Note:

   The LOV reduction field is case sensitive.
   The sample LOV screen is displayed below

   Figure 1-17 List of Values Currency


   Description of "Figure 1-17 List of Values Currency"
