L.9.2 Test using Web API Testing tool (example Postman)

To test this service using the Web API Testing tool, follow these steps:

1. Create a new request from the tool's New Menu.
2. Select the request type as GET.
3. Enter the FTP Rest services URL.
4. In the headers section set the 'Content-Type= text/html'.
5. In param tabs of the request add key as 'requestId' and value as the request data for which I want to retrieve data. Example requestId=8.
6. Press the send button.
7. The request is submitted to the requested web service.
8. The service is invoked on the server and the requested/calculated values are shown in the response section of the tool.
9. This is a secured web service and uses basic authorization. So, the authorization section of the tool should be populated with a valid user Id and password of the FTP application.
10. The header section of the tool needs additional parameters 'userID' with the value of a valid FTP application User ID.

    This screenshot illustrates how the web service call is made using the tool.

    Figure L-5 Web API Testing Tool (example Postman)









Related Topics:

• See the OFS Funds Transfer Pricing Applications Pack Installation and Configuration Guide for more information on installing and configuring FTP Web Services.
