8.5.3.2 Create Draft Models

Once an objective has been created, a model draft or notebook can be created where model development can start.

To create a Draft Model:

1. Click Launch Workspace next to the corresponding Workspace to Launch the Dashboard window with application configuration and model creation menu.
2. Click Model Pipelines to display the Model Pipelines window.
   The window displays folders that contain models and model records in a table.
3. Click Add and select Draft from the list to display the Add Draft dialog box.

   Figure 8-58 Create Model








4. Create New Model is the default setting in the Model Details dialog box. Drag the toggle button to select Import Dump. Use Create New Model to start from a blank Notebook in Compliance Studio. You can also create a draft under Objective (Folder) also. Click an Objective to open it.
   OR

   Drag the toggle button to select Import Dump. Import Dump lets you drag and drop an existing file with model data and modify it. To import a model data dump from another model, see the Import a Workspace Model Data into a New Model section.

   To create a new model:

   1. Enter details for Draft Name and Description.

      Figure 8-59 Model Details- Create New Model








   2. Enter a tag in the Tags field.
   3. Click Create.
