3 GL File Format
Below table describes the various file format supported by GL Accounting Interface.
Delimann GL Format
Table 3-1 Delimann Format Header Structure
Field Name | Data Type | Description |
---|---|---|
Record Type |
CHAR |
“1” |
Transaction code |
CHAR |
/ |
Record Date (YYYYMMDD) |
CHAR |
Date of Summary |
Others |
CHAR |
/ |
Ship ID |
CHAR |
Ship-ID |
Date of Summary Accounting Date (YYYYMMDD) |
CHAR |
Date of Summary (same as Record Date) |
Month of Summary Date |
CHAR |
Month of Summary Date |
Currency Code |
CHAR |
Currency Code |
Record Number |
CHAR |
/ |
Reference Record Number |
CHAR |
Empty at the moment |
End of Record Indicator |
CHAR |
/ |
Table 3-2 Delimann Segment Structure
Field Name | Data Type | Description |
---|---|---|
Record Type |
CHAR |
“2” |
Department Flag |
CHAR |
Credit Amount = “40”, Debit Amount = “50” |
Amount in Currency Code |
CHAR |
Amount (Total/Day) |
Tax Amount |
CHAR |
Empty |
VAT Descriptor |
CHAR |
/ (Not Used) |
Position Text |
CHAR |
/ (Not Used) |
Cruise ID |
CHAR |
Cruise ID |
GL Company Code (GL Original) |
CHAR |
Company code |
GL Department Code (GL_DEPARTMENT) |
CHAR |
Department Code |
GL Main Account (GL_CONTROLACC) |
CHAR |
Gl Main Account code |
GL Sub Account ID (GL SUBACC) |
CHAR |
GL Sub-Accoiunt ID |
GL_MPM_ISSUE |
CHAR |
/ |
GL Material Code (GL_MATERIAL) |
CHAR |
/ |
Department ID |
CHAR |
Department ID |
Department Description |
CHAR |
Department ID Description |
End of Record Indicator |
CHAR |
/ |
Delimann Sample Output File
Below is the sample output file and the fields are separated by a semicolon (;) and it’s records fed by line feed. The file name is saved in “XXXX_Application_Date” format.
Figure 3-1 Sample Delimann Output File
AIDA GL Format
Table 3-3 Segment Structure for AIDA GL Format
Field Name | Data Type | Description |
---|---|---|
Company |
CHAR |
Acc GL Origin |
Location |
CHAR |
Acc GL Dept |
Center |
CHAR |
Acc GL Control Acc |
Account |
CHAR |
Acc GL SubAccount |
Analysis |
CHAR |
Acc GL Material |
Intercompany |
CHAR |
Acc GL Mpm Issue |
Debit |
CHAR |
Total debit amount |
Credit |
CHAR |
Total credit amount |
Department Code |
CHAR |
Department code |
Description |
CHAR |
Cruise comment |
AIDA Sample Output File
The filename for this output format is in a CSV format and its columns separated by a comma (,).
Figure 3-2 Sample AIDA Output File
