About Classic or Non-Integrated Replicat

In classic mode, Replicat is a single-threaded process that uses standard SQL to apply data to the target tables. In this mode, Replicat operates as follows:

  • Reads the Oracle GoldenGate trail.

  • Performs data filtering, mapping, and conversion.

  • Constructs SQL statements that represent source database DML or DDL transactions (in committed order).

  • Applies the SQL to the target through the SQL interface that is supported for the given target database, such as ODBC or the native database interface.

As shown in this figure, you can apply transactions in parallel with a Classic Replicat, but only by partitioning the workload across multiple Replicat processes. A parameter file must be created for each Replicat.

To determine whether to use classic mode for any objects, you must determine whether the objects in one Replicat group will ever have dependencies on objects in any other Replicat group, transactional or otherwise. Not all workloads can be partitioned across multiple Replicat groups and still preserve the original transaction atomicity. For example, tables for which the workload routinely updates the primary key cannot easily be partitioned in this manner. DDL replication (if supported for the database) is not viable in this mode, nor is the use of some SQLEXEC or EVENTACTIONS features that base their actions on a specific record.

If your tables do not have any foreign key dependencies or updates to primary keys, classic mode may be suitable. Classic mode requires less overhead than coordinated mode.
