NsConfig Metrics

This section provides details about the NSSF Managed Object (MO) metrics.

Table 5-1 ocnssf_nsconfig_config_added_total

Field	Details
Description	Count of number of managed object which were added by NSConfig. Trigger Condition: Operator configuration of the Managed Object. Operator configuration of the Managed Object. This is pegged when HTTP POST request is received by NSSF's NsConfig.
Type	Counter
Service Operation	POST operation on plmnConfig, supportedSlicesMapping, barredSlicesMapping, nsiProfileConfig, grSites
Dimension	managed_object

Table 5-2 ocnssf_nsconfig_config_updated_total

Field	Details
Description	Count of number of managed object which were updated by NSConfig.Trigger Condition: Operator configuration of the Managed Object. Operator configuration of the Managed Object. This is pegged when HTTP PUT request is received by NSSF's NsConfig.
Type	Counter
Service Operation	PUT operation on plmnConfig, supportedSlicesMapping, barredSlicesMapping, nsiProfileConfig, grSites, systemOptions, allConfig
Dimension	managed_object

Table 5-3 ocnssf_nsconfig_config_deleted_total

Field	Details
Description	Count of number of managed object which were deleted by NSConfig.Trigger Condition: Operator configuration of the Managed Object. Operator configuration of the Managed Object. This is pegged when HTTP DELETE, or PUT request is received by NSSF's NsConfig.
Type	Counter
Service Operation	DELETE operation on plmnConfig, supportedSlicesMapping, barredSlicesMapping, nsiProfileConfig, grSites, deleteConfig and PUT operation on allConfig
Dimension	managed_object

Table 5-4 ocnssf_nsconfig_requests_rx_total

Field	Details
Description	Count of number of requests which were received by NSConfig.Trigger Condition: Operator configuration of the Managed Object. Operator configuration of the Managed Object. This is pegged when HTTP DELETE, or PUT request is received by NSSF's NsConfig.
Type	Counter
Service Operation	This is pegged when any HTTP request is received by NSSF's NsConfig.
Dimension	managed_object method

Table 5-5 ocnssf_nsconfig_response_tx_total

Field	Details
Description	Count of number of requests which were returned successful by NSConfig.Trigger Condition: Operator configuration of the Managed Object. Operator configuration of the Managed Object.
Type	Counter
Service Operation	This is pegged when any HTTP request is received by NSSF's NsConfig.
Dimension	managed_object method status_code

Table 5-6 ocnssf_nsconfig_error_response_tx_total

Field	Details
Description	Count of number of requests which returned Error by NSConfig.Trigger Condition: Operator configuration of the Managed Object. Operator configuration of the Managed Object.
Type	Counter
Service Operation	This is pegged when any HTTP request is received by NSSF's NsConfig.
Dimension	managed_object method status_code
