Oracle® Secure Enterprise Search

Quick Installation Guide

10g Release 1 (10.1.6) for Linux x86-64

B28690-02

April 2006

This document describes how to install Oracle Secure Enterprise Search (SES). It includes the following sections:

System Requirements
Configuring Kernel Parameters
Installing on a Port Number Less Than 1024
Installing Oracle Secure Enterprise Search
Removing Oracle Secure Enterprise Search
Restarting Oracle Secure Enterprise Search
What to Do Next?
Additional Resources
Documentation Accessibility

1 System Requirements

Following are the software requirements:

Oracle SES can be installed on one of the following operating system versions:
- Red Hat Linux 3
- Red Hat Linux 4
- SuSE Linux Enterprise Server 9
The system must be running the following kernel version (or a later version):
- Red Hat Enterprise Linux 3 (Update 2): 2.4.21-15.EL
- Red Hat Enterprise Linux 4 (Update 1): 2.6.9-11.EL smp
- SuSE Linux Enterprise Server 9: 2.6.5-7.97

The following packages (or later versions) must be installed:

Red Hat Enterprise Linux 3 (Update 2):

make-3.79.1
gcc-3.2.3-34
glibc-2.3.2-95.20
glibc-devel-2.3.2-95.20
glibc-devel-2.3.2-95.20 (32 bit)
compat-db-4.0.14-5
compat-gcc-7.3-2.96.128
compat-gcc-c++-7.3-2.96.128
compat-libstdc++-7.3-2.96.128
compat-libstdc++-devel-7.3-2.96.128
gnome-libs-1.4.1.2.90-34.1 (32 bit)
openmotif21-2.1.30-8
setarch-1.3-1
libaio-0.3.96-3
libaio-devel-0.3.96-3

Red Hat Enterprise Linux 4 (Update 1):

make-3.80-5
gcc-3.4.3-22.1
gcc-c++-3.4.3-22.1
libstdc++-3.4.3-22.1
libstdc++-devel-3.4.3-22.1
glibc-2.3.4-2.9
glibc-common-2.3.4-2.9
compat-db-4.1.25-9
compat-gcc-3.2.3
gnome-libs-1.4.1.2.90-44.1
openmotif21-2.1.30-11.RHEL4.2
binutils-2.15.92.0.2-13
pdksh-5.2.14-30
sysstat-5.0.5-1

SuSE Linux Enterprise Server 9:

gcc-3.3.3-43
gcc-c++-3.3.3-43
glibc-2.3.3-98
libaio-0.3.98-18
libaio-devel-0.3.98-18
make-3.80
openmotif-libs-2.2.2-519.1

To ensure that the system meets these requirements, perform the following steps:

To determine which distribution and version of Linux is installed, enter the following command:
```
# cat /etc/issue
```
- On Red Hat Linux 3 systems only, enter the following command to determine whether the required kernel errata is installed:
```
# uname -r
2.4.21-15.EL
```
  In this example, the output shows the kernel version (2.4.21) and errata level (15.EL). If the errata level is less than 15, install the latest kernel update. Kernel updates are available from the Red Hat Network.
- On Red Hat Linux 4 systems only, enter the following command to determine whether the required kernel errata is installed:
```
# uname -r
2.6.9-11.EL
```
  In this example, the output shows the kernel version (2.6.9) and errata level (11.EL). If the errata level is less than 11, install the latest kernel update. Kernel updates are available from the Red Hat Network.
- On SUSE Linux 9 systems only, enter the following command to determine whether the required kernel is installed:
```
# uname -r
2.6.5-7.97
```
  In this example, the output shows the kernel version (2.6.5-7.97). If the kernel version is less than 2.6.5-7.97, contact SUSE for information about obtaining and installing the kernel updates.
To determine whether the required kernel version is installed, enter the following command:
```
# uname -r
```
To determine whether the required packages are installed, enter commands similar to the following:
```
# rpm -q package_name
```

Oracle SES requires a minimum of 2 GB of disk space. This includes 1 GB to install and approximately 500 MB to create the initial Oracle SES index.

Additional Oracle SES requirements are based on the amount of data that you need to search. Here are some configuration examples:

To index 100,000 documents:

4 GB disk space
1 GB RAM

The system must meet the following minimum hardware requirements:

512 MB of physical RAM
1 GB of swap space (or twice the size of RAM)

On systems with 2 GB or more of RAM, the swap space can be between one and two times the size of RAM.
400 MB of disk space in the /tmp directory
Between 1.5 GB and 3 GB of disk space for the Oracle software, depending on the installation type and platform.

To ensure that the system meets these requirements, perform the following steps:

To determine the physical RAM size, enter the following command:
```
# grep MemTotal /proc/meminfo
```
To determine the size of the configured swap space, enter the following command:
```
# grep SwapTotal /proc/meminfo
```
To determine the amount of free disk space available in the /tmp directory, enter the following command:
```
# df -k /tmp
```
To determine the amount of free disk on the system, enter the following command:
```
# df -k
```

To index 1,000,000 documents:

20 GB disk space
6 GB RAM

For installation help, including pre-installation tips, see the Oracle SES tutorial:

http://st-curriculum.oracle.com/tutorial/SESAdminTutorial/index.htm

Note:

The Oracle SES administration tool and default query application are certified on the following browsers:

Firefox 1.0, 1.0.1, 1.0.6, 1.0.7, 1.5
Internet Explorer 6.0
Netscape 7.1, 7.2
Mozilla 1.7.3

2 Configuring Kernel Parameters

Before starting the Oracle installation, verify that the parameters shown in the following table are set to values greater than or equal to the recommended value shown. The procedure following the table describes how to verify and set the values.

Table 1 Kernel Parameters

Parameter	Value	File
`semmsl` `semmns` `semopm` `semmni`	250 32000 100 128	`/proc/sys/kernel/sem`
`shmall`	2097152	`/proc/sys/kernel/shmall`
`shmmax`	Half the size of physical memory	`/proc/sys/kernel/shmmax`
`shmmni`	4096	`/proc/sys/kernel/shmmni`
`file-max`	65536	`/proc/sys/fs/file-max`
`ip_local_port_range`	1024 65000	`/proc/sys/net/ipv4/ip_local_port_range`

Note:

If the current value for any parameter is higher than the value listed in this table, do not change the value of that parameter.

To view the current value specified for these kernel parameters, and to change them if necessary, follow these steps:

Enter commands similar to the following to view the current values of the kernel parameters:

Note:

Make a note of the current values and identify any values that you must change.

Table 2 Commands for Kernel Parameters

Parameter	Command
`semmsl`, `semmns`, `semopm`, `semmni`	`# /sbin/sysctl -a \| grep sem` This command displays the value of the semaphore parameters in the order listed.
`shmall`, `shmmax`, `shmmni`	`# /sbin/sysctl -a \| grep shm`
`file-max`	`# /sbin/sysctl -a \| grep file-max`
`ip_local_port_range`	`# /sbin/sysctl -a \| grep ip_local_port_range` This command displays a range of port numbers.

If the value of any kernel parameter is different than the recommended value, then complete the following steps:
1. Using a text editor, create or edit the /etc/sysctl.conf file and add or edit lines similar to the following:

  Note:
  Include lines only for the kernel parameter values that you want to change. For the semaphore parameters (kernel.sem), you must specify all four values. However, if any of the current values are larger than the recommended value, then specify the larger value.
```
kernel.shmall = 2097152
kernel.shmmax = 2147483648
kernel.shmmni = 4096
kernel.sem = 250 32000 100 128
fs.file-max = 65536
net.ipv4.ip_local_port_range = 1024 65000
```
  By specifying the values in the /etc/sysctl.conf file, they persist when you reboot the system.
2. Enter the following command to change the current values of the kernel parameters:
```
# /sbin/sysctl -p
```
  Review the output from this command to verify that the values are correct. If the values are incorrect, then edit the /etc/sysctl.conf file and enter this command again.

2.1 Setting Shell Limits for the oracle User

To improve the performance of the software, you must increase the following shell limits for the oracle user:

Table 3 Shell Limits for oracle User

Shell Limit	Item in limits.conf	Hard Limit
Maximum number of open file descriptors	`nofile`	65536
Maximum number of processes available to a single user	`nproc`	16384

To increase the shell limits:

Add the following lines to the /etc/security/limits.conf file:

*    soft    nproc   2047
*    hard    nproc   16384
*    soft    nofile  1024
*    hard    nofile  65536

Add the following line to the /etc/pam.d/login file, if it does not already exist:
```
session    required     /lib64/security/pam_limits.so
```

Depending on the oracle user's default shell, make the following changes to the default shell start-up file:

For the Bourne, Bash, or Korn shell, add the following lines to the /etc/profile file:

if [ $USER = "oracle" ]; then
        if [ $SHELL = "/bin/ksh" ]; then
              ulimit -p 16384
              ulimit -n 65536
        else
              ulimit -u 16384 -n 65536
        fi
fi

For the C or tcsh shell, add the following lines to the /etc/csh.login file:

if ( $USER == "oracle" ) then
        limit maxproc 16384
        limit descriptors 65536
endif

Reboot the system after setting shell limits.

3 Installing on a Port Number Less Than 1024

Oracle SES must be installed by a non-root user. On UNIX platforms, only root users can bind to ports less than 1024. To install Oracle SES on a port number less than 1024, follow these steps:

During installation, specify the port (for example, 80).
After the installation is complete, log in as the root user.

Run the following commands:

chgrp -R root $ORACLE_HOME/jdk
$ORACLE_HOME/bin/searchctl start

Note:

The searchctl start command must be run by a root user. However, the searchctl stop command can be run by either a root user or the user who installed Oracle SES.
$ORACLE_HOME represents the directory where Oracle SES was installed.

If your installation completes on a port greater than 1024 and you want to change to a port less than 1024, then take the following steps:

Shutdown the middle tier with the following command:
```
$ORACLE_HOME/bin/searchctl stop
```
Edit the value for the port attribute in $ORACLE_HOME/oc4j/j2ee/OC4J_SEARCH/config/http-web-site.xml. (Ensure that the new port is not already in use.)
Log in as the root user.

Run the following commands:

chgrp -R root $ORACLE_HOME/jdk
$ORACLE_HOME/bin/searchctl start

4 Installing Oracle Secure Enterprise Search

For easy instructions on installing Oracle SES, see the Installation Tips tutorial:

http://st-curriculum.oracle.com/tutorial/SESAdminTutorial/index.htm

In the following instructions, the disc mount point is referred to as /SD_CDROM. If your mount point is different, then substitute the correct mount point name for all references to /SD_CDROM.

To start the installer:

Ensure that you have checked all the minimum requirements, as described in "System Requirements".
Log in to the computer as the user who will install Oracle SES.
Insert the Oracle Secure Enterprise Search CD-ROM.
If your computer does not have automount, then see "Mounting the CD-ROM" for steps on mounting the CD-ROM manually.
Start up the installer:
```
prompt> cd
prompt> /SD_CDROM/runInstaller
```
This launches Oracle Universal Installer.

Note:
Do not run the installer from the mount point directory. The cd command changes your current directory to your home directory, so you do not start the installer from the mount point.

In the Oracle Universal Installer, the only value that you must specify is the administrative password. The remaining values are set to a default, but they can be overridden. Following is the list of the installation parameters:
- Search Server Name: Name for your search server.
- Administrative Password: The password that you will later use to log on to the administration tool.
- HTTP Port: The port on which the Oracle SES middle tier will listen. For example, if you installed Oracle SES on host myhost.oracle.com and you specify port 7890, then your search page URL will be http://myhost.oracle.com:7890/search/query/search.

  See Also:
  "Installing on a Port Number Less Than 1024"
- Destination Path: The location where Oracle SES software is installed
- Data Storage Location: The location where Oracle SES will store its data.
The following screenshot shows the Oracle Universal Installer screen.

Description of the illustration install9.gif

4.1 Mounting the CD-ROM

Follow these steps if your computer does not automount the CD-ROM:

Insert the CD-ROM.
Log in as the root user:
```
prompt> su
Password:
```
Create the CD-ROM mount point directory:
```
prompt> /usr/bin/mkdir /SD_CDROM
```
Mount the CD-ROM drive on the mount point directory:
```
prompt> /bin/mount -t iso9660 /dev/cdrom /SD_CDROM
```
In the preceding example, /SD_CDROM is the disc mount point directory and /dev/cdrom is the device name for the disc device.
Log out from the root user.
```
# exit
```

5 Removing Oracle Secure Enterprise Search

To remove Oracle SES, run $ORACLE_HOME/install/deinstall_ses as the user who installed Oracle SES.

Note:

If the Oracle SES instance was bound to a port less than 1024 and the middle tier ran as root user, then after removal there could be files left under $ORACLE_HOME. After the removal completes, log in as the root user and delete those files.

6 Restarting Oracle Secure Enterprise Search

The tool for starting and stopping the search engine is searchctl. To restart Oracle SES after rebooting, navigate to the $ORACLE_HOME/bin directory where Oracle SES is installed and run searchctl startall.

Users are prompted for a password when running searchctl commands.

For detailed steps, see the Startup / Shutdown lesson in the Oracle SES tutorial:

http://st-curriculum.oracle.com/tutorial/SESAdminTutorial/index.htm

7 What to Do Next?

To become familiar with Oracle Secure Enterprise Search, Oracle suggests that you complete the following tasks:

Follow the Oracle Secure Enterprise Search tutorial:

http://st-curriculum.oracle.com/tutorial/SESAdminTutorial/index.htm
Log in to the Oracle SES administration tool, using the user name and password set in the installation. With the administration tool, you can:
- Define sources to search.
- Configure and schedule the crawling of the sources.
- Monitor the status and performance of crawling and search.
Click the Help link in the top right corner of any page in the administration tool for context-sensitive help.
Read the Oracle Secure Enterprise Search Administrator's Guide.
In a production environment, where a load balancer or other monitoring tools are used to ensure system availability, Oracle SES can also be easily monitored through the following URL
```
 http://host:port/monitor/check.jsp
```
The URL should return the following message: Oracle Secure Enterprise Search instance is up.

Note:
This message is not translated to other languages, because system monitoring tools may need to byte-compare this string.

If Oracle Secure Enterprise Search is not available, then the URL returns either a connection error or the HTTP error code 503.

8 Additional Resources

To download free release notes, installation documentation, white papers, or other collateral, visit Oracle Technology Network (OTN). You must register online before using OTN; registration is free and can be done at

http://www.oracle.com/technology/membership/

If you already have a user name and password for OTN, then you can go directly to the documentation section of OTN at

http://www.oracle.com/technology/documentation

8.1 Oracle Support Services

If you purchased Oracle Product Support, you can call Oracle Support Services for assistance. Oracle Support Services include phone assistance, version updates, and access to our service offerings. You have access to phone support 24 hours a day, 7 days a week. In the U.S.A., you can call Product Support at 1-800-223-1711.

Ensure you have your CSI (CPU Support Identifier) number ready when you call. Keep the CSI number for your records, because it is your key to Oracle Support Services. The Oracle Store sends the CSI number to you in an e-mail alert when it processes your order. If you do not have your CSI number and you are in the U.S.A., you can look up your CSI number by accessing our online Order Tracker, which provides detailed order information. Go to the Oracle Store and click on Order Tracker located above the top navigation bar.

For Oracle Support Services locations outside the U.S.A., call your local support center for information about how to access support. To find the local support center in your country, visit the Support Web Center at

http://www.oracle.com/support

At the Support Web Center you will find information on Oracle Support Services, such as:

Contact information
Instructions on how to access electronic services
Helpful Web sites
Support resources
Oracle Support Portfolio
Oracle Support Services news

With Oracle Product Support, you have round-the-clock access to OracleMetaLink, the Oracle Support Services premier Web support offering. OracleMetaLink offers you access to installation assistance, product documentation, and a technical solution knowledge base.

It has technical forums, where you can post questions about your Oracle products and receive answers from Oracle Technical Support Analysts and other Oracle users. The questions and answers remain posted for the benefit of all users.

OracleMetaLink options include:

Service Request (SR) access
Patch downloads
Bug database query access
Product life-cycle information

You can access OracleMetaLink at

https://metalink.oracle.com

8.2 Quick Reference

Resource	Contact Information or Web Site
OracleMetaLink	`https://metalink.oracle.com`
Purchase additional products, full-use licenses, version updates, and documentation in the U.S.A.	`http://oraclestore.oracle.com`
Access technical resources for developers	`http://www.oracle.com/technology/index.html`
Access information about technical support	`http://www.oracle.com/support`
Locate local Oracle Support Centers outside the U.S.A.	`http://www.oracle.com/support`
Locate local Oracle offices outside the U.S.A	`http://www.oracle.com/global/index.html`
Call Client Relations in the U.S.A.	1-800-223-1711
Speak with your sales representative in the U.S.A.	1-800-ORACLE-1
Obtain TTY access to technical support in the U.S.A.	1-800-446-2398

9 Documentation Accessibility

Our goal is to make Oracle products, services, and supporting documentation accessible, with good usability, to the disabled community. To that end, our documentation includes features that make information available to users of assistive technology. This documentation is available in HTML format, and contains markup to facilitate access by the disabled community. Accessibility standards will continue to evolve over time, and Oracle is actively engaged with other market-leading technology vendors to address technical obstacles so that our documentation can be accessible to all of our customers. For more information, visit the Oracle Accessibility Program Web site at

http://www.oracle.com/accessibility/

Accessibility of Code Examples in Documentation

Screen readers may not always correctly read the code examples in this document. The conventions for writing code require that closing braces should appear on an otherwise empty line; however, some screen readers may not always read a line of text that consists solely of a bracket or brace.

Accessibility of Links to External Web Sites in Documentation

This documentation may contain links to Web sites of other companies or organizations that Oracle does not own or control. Oracle neither evaluates nor makes any representations regarding the accessibility of these Web sites.

TTY Access to Oracle Support Services

Oracle provides dedicated Text Telephone (TTY) access to Oracle Support Services within the United States of America 24 hours a day, seven days a week. For TTY support, call 800.446.2398.

Oracle Secure Enterprise Search Quick Installation Guide, 10g Release 1 (10.1.6) for Linux x86-64

B28690-02

The Programs (which include both the software and documentation) contain proprietary information; they are provided under a license agreement containing restrictions on use and disclosure and are also protected by copyright, patent, and other intellectual and industrial property laws. Reverse engineering, disassembly, or decompilation of the Programs, except to the extent required to obtain interoperability with other independently created software or as specified by law, is prohibited.

The information contained in this document is subject to change without notice. If you find any problems in the documentation, please report them to us in writing. This document is not warranted to be error-free. Except as may be expressly permitted in your license agreement for these Programs, no part of these Programs may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose.

If the Programs are delivered to the United States Government or anyone licensing or using the Programs on behalf of the United States Government, the following notice is applicable:

U.S. GOVERNMENT RIGHTS Programs, software, databases, and related documentation and technical data delivered to U.S. Government customers are "commercial computer software" or "commercial technical data" pursuant to the applicable Federal Acquisition Regulation and agency-specific supplemental regulations. As such, use, duplication, disclosure, modification, and adaptation of the Programs, including documentation and technical data, shall be subject to the licensing restrictions set forth in the applicable Oracle license agreement, and, to the extent applicable, the additional rights set forth in FAR 52.227-19, Commercial Computer Software—Restricted Rights (June 1987). Oracle Corporation, 500 Oracle Parkway, Redwood City, CA 94065

The Programs are not intended for use in any nuclear, aviation, mass transit, medical, or other inherently dangerous applications. It shall be the licensee's responsibility to take all appropriate fail-safe, backup, redundancy and other measures to ensure the safe use of such applications if the Programs are used for such purposes, and we disclaim liability for any damages caused by such use of the Programs.

Oracle, JD Edwards, PeopleSoft, and Siebel are registered trademarks of Oracle Corporation and/or its affiliates. Other names may be trademarks of their respective owners.

The Programs may provide links to Web sites and access to content, products, and services from third parties. Oracle is not responsible for the availability of, or any content provided on, third-party Web sites. You bear all risks associated with the use of such content. If you choose to purchase any products or services from a third party, the relationship is directly between you and the third party. Oracle is not responsible for: (a) the quality of third-party products or services; or (b) fulfilling any of the terms of the agreement with the third party, including delivery of products or services and warranty obligations related to purchased products or services. Oracle is not responsible for any loss or damage of any sort that you may incur from dealing with any third party.
