Sun Netra Alarm Card Test (nalmtest)
|
nalmtest Description
nalmtest tests the alarm card on Sun Netra 210, Sun Netra 240, and Sun Netra 440 servers.
Note - The Sun Netra Alarm Card Test (nalmtest) was called the Sun Netra 240 Alarm Card Test (n240atest) in SunVTS 5.1 PS5.
|
|
Caution - Solaris 8 2/02 OS or subsequent compatible release is required to perform the nalmtest.
|
nalmtest Options
To reach the following dialog box, right-click on the test name in the System Map and select Test Parameter Options. If you do not see this test in the System Map, you might need to expand the collapsed groups. Refer to the SunVTS User's Guide for more details.
FIGURE 37-1 nalmtest Test Parameter Options Dialog Box
The following table describes the nalmtest options:
TABLE 37-1 nalmtest Options
nalmtest Options
|
Description
|
Alarm Critical
|
Toggles the Alarm critical LED.
|
Alarm Major
|
Toggle the Alarm critical Major.
|
Alarm Minor
|
Toggles the Alarm critical Minor.
|
Alarm User
|
Toggles the Alarm critical User.
|
Alarm FRUID
|
Performs the FruID checksum test on the alarm card.
|
Loop Count
|
Sets up the loop count for toggling all four alarm LEDS. The count number is 1 to 3.
|
nalmtest Test Modes
TABLE 37-2 nalmtest Supported Test Modes
Test Mode
|
Description
|
Connection
|
Determines if the devices are connected to the system you are testing and verifies that they are accessible. Device functionality is not verified. However, you can safely run connection mode tests while the system is offline.
|
Functional
|
Tests fully exercise all aspects of the device through the associated device drivers. These tests use a significant portion of the system resources and assume that the device is available for testing. For this reason, the system must be offline with no other users or application running. This mode is sometimes referred to as Offline mode.
|
nalmtest Command-Line Syntax
/opt/SUNWvts/bin/sparcv9/nalmtest standard_arguments [ -o
[ dev=device-name ]
[ cri=E(nable)|D(isable) ]
[ maj=E|D ]
[ min=E|D ]
[ usr=E|D ]
[ fru=E|D]
[ count=count-number] ]
TABLE 37-3 nalmtest Command-Line Syntax
Argument
|
Description
|
dev=
|
Specifies the name of the raw device to test.
|
cri=
|
Toggles the Alarm critical LED.
|
maj=
|
Toggles the Alarm critical Major.
|
min=
|
Toggles the Alarm critical Minor.
|
usr=
|
Toggles the Alarm critical User.
|
fru=
|
Performs FruID checksum test on the alarm card. This option does not apply to the Sun Netra 210 platform.
|
count=
|
Sets up the loop count for toggling all four alarm LEDS count-number is 1 to 3.
|
