C H A P T E R  3

Hardware Installation

This chapter provides instructions for installing the Sun StorageTek Enterprise PCI-X 4 Gb FC Single and Dual Port Emulex HBAs (henceforth referred to as single and dual port HBAs) in your system. It contains the following topics:



caution icon Caution - Damage to the HBA can occur as the result of careless handling or electrostatic discharge (ESD). Always handle the HBA with care to avoid damage to electrostatic sensitive components.


To minimize the possibility of ESD-related damage, Sun strongly recommends using both a workstation anti-static mat and an ESD wrist strap. You can get an ESD wrist strap from any reputable electronics store or from Sun as part number #250-1007. Observe the following precautions to avoid ESD-related problems:


procedure icon  To Verify the Packaging Contents

single-step bullet  Confirm that the single or dual port HBAs are shipped with the following items:


procedure icon  To Install the HBA Hardware

To install the single and dual port HBAs, you must open the system and identify an empty PCI or PCI-X slot. The single and dual port HBAs are keyed to prevent installation in +5.0-V signaling PCI slot types. If necessary, consult your system manual for instructions on removing the system cover.

1. Record IEEE and serial numbers.

Each HBA is shipped with at least one unique 64-bit identifier called the IEEE address. The Fibre Channel industry uses a World Wide Name (WWN) derived from the IEEE address. This number is needed for FC connectivity. Because the dual-port HBA has two ports, it has two IEEE addresses. The IEEE address is used for configuring your system. The serial number is used for communicating with Sun. All numbers are clearly marked on the board. Record these numbers before installation.

2. Shut down, power off, and unplug the system.

3. Remove the system case.

4. Remove the blank panel from an empty PCI or PCI-X slot.

5. If needed, replace the low-profile PCI bracket with the standard mounting bracket by performing the following steps:



Note - The single and dual port HBAs are shipped with a low-profile PCI bracket installed. This bracket is approximately 3.11 in. (7.9 cm) long. A standard mounting bracket, which is approximately 4.75 in. (12.6 cm), is provided with each X-option order.


a. Remove the mounting bracket screws from the single and dual port HBAs (see FIGURE 3-1).



FIGURE 3-1 Removing the Bracket Screws


b. Remove the bracket and store it for future use.

c. Align the new mounting bracket tabs with the holes in the HBA.



Note - Be careful not to push the bracket past the transceiver housing's grounding tabs. Ensure that the LEDs are properly aligned with the holes in the bracket.


d. Replace the screws that attach the HBA to the bracket.

6. Insert the HBA into the empty PCI or PCI-X slot. Press firmly until the adapter is seated. See FIGURE 3-2.

7. Secure the HBA mounting bracket to the case with the panel screw or clip.

8. Replace the system case and tighten the case screws.

The HBA is now installed in the system and is ready for the optical cable attachment.

FIGURE 3-2 Installing the Single and Dual Port HBAs




Note - FIGURE 3-2 is a typical installation, which may differ from your installation.



procedure icon  To Attach the Optical Cable



Note - The single and dual port HBAs do not allow normal data transmission on an optical link unless it is connected to another similar or compatible Fibre Channel product (that is, multimode to multimode).


Use multimode fiber-optic cable, intended for short-wave lasers, that adheres to the specifications in TABLE 3-1.


TABLE 3-1 Optical Cable Specifications

Fiber-Optic Cable

Maximum Length

Minimum Length

Connector

62.5/125 mu symbolm (multimode)

300 meters at 1.0625 Gbit/sec

150 meters at 2.125 Gbit/sec

70 meters at 4.25 Gbit/sec

2 meters

LC

50/125 mu symbolm (multimode)

500 meters at 1.0625 Gbit/sec

300 meters at 2.125 Gbit/sec

150 meters at 4.25 Gbit/sec

2 meters

LC


Follow these steps when attaching the optical cable:

1. Connect the fiber-optic cable to an LC connector on the dual port HBA (see FIGURE 3-3).

FIGURE 3-3 Attaching the Optical Cable


2. Connect the other end of the cable to the Fibre Channel device.

After the optical cable is connected to the HBA, you are ready to apply power to the system.


procedure icon  To Apply Power

1. Verify that the HBA is securely installed in the system.

2. Verify that the correct optical cable is attached.

3. Plug in and power on the system.

4. Observe the status of light-emitting diodes (LEDs) for the power-on self-test (POST) results as shown in TABLE 3-2.

TABLE 3-2 summarizes LED indicator combinations. The LEDs can be seen through the openings in the HBA's mounting bracket. Each port has a corresponding set of LEDs that provide a visual indication of the operating state.

The slow blink rate is 1 Hz; the fast blink rate is 4 Hz; the flashing state is an irregular on/off appearance reflecting program activity. For the Link Rate, between each group of fast blinks (1, 2, or 3), there is a 1-Hz pause when the LED is off. You should observe the LED sequence for several seconds to ensure that the pause is correctly identified.


TABLE 3-2 LED Indicator Status Definitions

Green LED

Yellow LED

State

Off

Off

Wake Up Failure (Dead Board)

Off

On

POST Failure (Dead Board)

Off

Slow Blink

Wake-Up Failure Monitor

Off

Fast Blink

Failure in POST

Off

Flashing

POST Processing in Progress

On

Off

Failure While Functioning

On

On

Failure While Functioning

On

1 Fast Blink

1-Gb Link Rate -
Normal, link up

On

2 Fast Blink

2-Gb Link Rate -
Normal, link up

On

3 Fast Blink

4-Gb Link Rate -
Normal, link up

Slow Blink

Off

Normal - Link Down

Slow Blink

On

Not defined

Slow Blink

Slow Blink

Offline for Download

Slow Blink

Fast Blink

Restricted Offline Mode (Waiting for Restart)

Slow Blink

Flashing

Restricted Offline Mode,
test active

Fast Blink

Off

Debug Monitor in Restricted Mode

Fast Blink

On

Not defined

Fast Blink

Slow Blink

Debug Monitor in Test Fixture Mode

Fast Blink

Fast Blink

Debug Monitor in Remote Debug Mode

Fast Blink

Flashing

Not defined



procedure icon  To Verify Proper Installation in SPARC Platforms

1. Enter the show-devs command at the ok prompt to list the installed devices.

The single and dual port HBAs can be identified in the output containing the SUNW,emlxs@n and SUNW,emlxs@n,1 node names, where n is usually a single-digit number from 0 to 9.

2. To positively identify the port as a Sun StorageTek 4 Gb FC port, access the SUNW,emlxs@N entries and enter .properties as shown in the example that follows.

In this example, there is one Dual Channel SG-XPCI2FC-EM4-Z adapter installed:


TABLE 3-3
{1} ok .properties
assigned-addresses       83000910 00000000 00104000 00000000 00002000
                         83000918 00000000 00106000 00000000 00002000
                         81000920 00000000 00000400 00000000 00000100
                         82000930 00000000 00180000 00000000 00040000
port_wwn                 10 00 00 00 c9 50 96 3f
node_wwn                 20 00 00 00 c9 50 96 3f
alternate-reg            01000920 00000000 00000000 00000000 00000100
reg                      00000900 00000000 00000000 00000000 00000000
                         03000910 00000000 00000000 00000000 00001000
                         03000918 00000000 00000000 00000000 00000100
                         02000930 00000000 00000000 00000000 00020000
compatible               pci10df,fc10
clock-frequency          02625a00
#size-cells              00000000
#address-cells           00000002
copyright                Copyright (c) 2005 Emulex
model                    LP11002-S
name                     SUNW,emlxs
device_type              scsi-fcp
manufacturer             Emulex
fcode-version            1.50a8
fcode-rom-offset         0000c000
66mhz-capable
fast-back-to-back
devsel-speed             00000001
class-code               000c0400
interrupts               00000002
latency-timer            00000040
cache-line-size          00000010
max-latency              00000000
min-grant                000000ff
subsystem-id             0000fc12
subsystem-vendor-id      000010df
revision-id              00000001
device-id                0000fc10
vendor-id                000010df


procedure icon  To Verify the Attached Storage

single-step bullet  If online storage is connected to the HBA installed in a SPARC system, use the apply show-children command to list the attached storage.

In the example that follows, a storage JBOD has twelve targets attached to one port of the dual-ported HBA.


TABLE 3-4
{0} ok apply show-children  /pci@7c0/pci@0/pci@9/SUNW,emlxs@0
Device  ALPA b6  WWPN 215000c0ff00223d
   LUN  0     ESI Device    SUN     StorEdge 3510F D1046
Link attention
Device  ALPA b9  WWPN 2100000c50c30555
   LUN  0     Disk     SEAGATE ST3146807FC     0006
Device  ALPA ba  WWPN 2100000c50c30525
   LUN  0     Disk     SEAGATE ST3146807FC     0006
Device  ALPA bc  WWPN 500000e010172831
   LUN  0     Disk     FUJITSU MAP3147F SUN146G0301
Device  ALPA c3  WWPN 2100000c50c3051b
   LUN  0     Disk     SEAGATE ST3146807FC     0006
Device  ALPA c5  WWPN 2100000c50c30567
   LUN  0     Disk     SEAGATE ST3146807FC     0006
Device  ALPA c6  WWPN 500000e0101727d1
   LUN  0     Disk     FUJITSU MAP3147F SUN146G0301
Device  ALPA c7  WWPN 21000004cf64f1db
   LUN  0     Disk     SEAGATE ST336752FSUN36G 0508
Device  ALPA c9  WWPN 2100000c50c30513
   LUN  0     Disk     SEAGATE ST3146807FC     0006
Device  ALPA ca  WWPN 500000e0101727b1
   LUN  0     Disk     FUJITSU MAP3147F SUN146G0301
Device  ALPA cb  WWPN 2100000c50c3050e
   LUN  0     Disk     SEAGATE ST3146807FC     0006
Device  ALPA cc  WWPN 21000004cf64dc04
   LUN  0     Disk     SEAGATE ST336752FSUN36G 0508
Device  ALPA cd  WWPN 21000004cf5728c0
   LUN  0     Disk     SEAGATE ST373307FSUN72G 0407
{0} ok



Note - You may need to use the reset-all command before entering apply show-children.



procedure icon  To Verify Proper Installation in x64 Based Systems

single-step bullet  Follow the instructions in the BIOS documentation provided with your system.
