Data Redundancy

The session and policy binding databases are partitioned such that each server group in a Session or Binding resource domain hosts a portion of the data. Because each server group consists of redundant servers (Active/Standby, Active/Spare, or Active/Standby/Spare), the data owned by each Server Group is redundant within the Server Group.

Active, Standby, and Spare servers within a SBR server group all maintain exact replicas of the data for the partition for which the server group is responsible. This data is kept in sync by using a form of signaling called replication. The synchronized tables on the Standby and Spare servers are continually audited and updated to match the master copy on the Active server.

data-redundancy.html#GUID-3170434A-D401-4838-AA06-63D624492F2E__FIG_42506DF8A09D4D73AD91476D4F64453D illustrates how a given Policy Binding table might be partitioned across four SBR Server Groups in a Policy Binding resource domain.

Figure 2-12 Binding Table Partitioning Across Server Groups


img/binding_partitioning_across_server_groups.png

data-redundancy.html#GUID-3170434A-D401-4838-AA06-63D624492F2E__FIG_1102E51569B04CAABC127292CFAFFDD3 illustrates how each SBR Server Group hosts a partition of several tables. Only the Active server within each server group can write to the database. The Standby and Spare servers replicate only actions (adds, changes, and deletes) performed by the Active server.

Figure 2-13 Multi-Table Resources

img/multi-table_resources.png
