4.1 System Topology Check

System Topology Check

This procedure is part of feature activation preparation and is used to verify the system topology of the DSR network and servers.

1. Log in to the NOAM VIP GUI, establish a GUI session on the NOAM server by using the VIP address of the NOAM server.
2. Open the web browser and enter the URL, http://<Primary_NOAM_VIP_IP_Address>
3. Log in as the guiadmin user.

   Figure 4-1 Oracle System Login








4. Verify the network configuration data.
5. Expand the Configuration folder, click Networking and select Network.

   Figure 4-2 Navigation to Networks








6. Select the site network element tab.

   Figure 4-3 Network Element Tag








7. Click Report

   Figure 4-4 Report








8. Verify if the configuration data is correct for your network. Save or Print this report to keep copies for future reference.

   Figure 4-5 Save or Print








9. Verify the server configuration. Expand the Configuration and click Server Groups.

   Figure 4-6 Server Groups








10. Click Report.

    Figure 4-7 Report








11. Verify if the configuration data is correct for your network. Save or Print this report to keep copies for future reference.

    Figure 4-8 Save or Print








12. Analyze and plan the DA-MP re-start sequence. Analyze the system topology and plan for any DA-MPs, which will be out-of-service during the feature activation sequence. Analyze system topology gathered in Step 5 and Step 9. Determine exact sequence which DA-MP servers will be restarted (with the expected out-of-service periods).

    Note:

    It is recommended that no more than 50% of the MPs be restarted at once.

    If this procedure fails, contact My Oracle Support for assistance.
