CME Alert

This ERD (see the following figure) illustrates how credit and fraud alerts are managed for communications and utilities customers. A fraud alert is associated with an account. Profile attributes provide more information about the fraud threshold for an account. A credit alert is related to an account and a statement. Activities can be performed on both types of alerts.

The following table lists the entities in this ERD and their corresponding tables.

Entity	Table
Account	S_ORG_EXT, S_PARTY
Activity	S_EVT_ACT
Alert Attachment	S_ALERT_ATT_CUT
Alerts	S_ALERT_CUT
Asset	S_ASSET
Bill Transactions	S_BILL_MAINT
Billing Profile	S_INV_PROF
Energy Consumption	S_USAGE
Fraud Profile	S_FRD_PROF_CUT
