Управление подключениями к источникам данных

Понимание и выполнение нескольких задач, связанных с предварительными условиями.

Для управления подключениями к данным с помощью REST API необходимы права на создание рабочих книг и подключение к данным в Oracle Analytics Cloud (DV Content Author).

Oracle Database

(Не SSL)

Базовый тип подключения

{
 "version": "2.0.0",
 "type": "connection",
 "name": "oracle_db_non_ssl_basic",
 "description": "Sample non-SSL Oracle Database connection created using Connections API",
 "content": {
   "connectionParams": {
     "connectionType": "oracle-database",
     "host": "example.com",
     "port": "1521",
     "serviceName": "orcl",
     "username": "admin",
     "password": "<password>",
     "remoteData": false,
     "systemConnection": false
   }
  }
 }

Расширенный тип подключения

{
  "version": "2.0.0",
  "type": "connection",
  "name": "oracle_db_non_ssl_advanced ",
  "description": " Sample non-SSL Oracle Database connection created with the advanced connection string format using Connections API",
  "content": {
    "connectionParams": {
     "connectionString": "(DESCRIPTION= (ADDRESS_LIST= (LOAD_BALANCE=on)(FAILOVER=ON) (ADDRESS=(PROTOCOL=tcp)(HOST=example.com)(PORT=1521))) (CONNECT_DATA=(SERVICE_NAME=ORCLPDB1)))",
     "username": "admin",
     "password": "<password>",
     "connectionType": "oracle-database",
     "remoteData": false,
     "systemConnection": false
    }
  }
}

Oracle Database с SSL

cwallet.sso (client credentials file)

Базовый тип подключения

cert: <cwallet.sso file location>
connectionParams: {
 "version": "2.0.0",
 "type": "connection",
 "name": "oracle_db_ssl",
 "description": "Sample Oracle Database connection with SSL created using Connections API",
 "content": {
   "connectionParams": {
     "connectionType": "oracle-database",
     "host": "example.com",
     "port": "2484",
     "serviceName": "ORCLPDB1",
     "username": "admin",
     "password": "<password>",
     "systemConnection": false,
     "remoteData": false
   }
  }
}

Oracle Autonomous Data Warehouse — без накопителя (TLS)

Базовый тип подключения

{
 "version": "2.0.0",
 "type": "connection",
 "name": "oracle_adw_walletless_basic",
 "description": "Sample Oracle ADW connection without a wallet created using Connections API",
 "content": {
   "connectionParams": { "connectionType": "oracle-autonomous-data-warehouse",
     "connectionString": "(description= (retry_count=20)(retry_delay=3)(address=(protocol=tcps)(port=1521) (host=example.com)) (connect_data=(service_name=example.com)) (security=(ssl_server_dn_match=yes)))",
     "username": "admin",
     "password": "<password>",
     "systemConnection": false,
     "remoteData": false,
     "sslType": "ServerSideSSL"
     }
   }
 }

Oracle Autonomous Data Warehouse — с накопителем (взаимная аутентификация TLS)

cwallet.sso (client credentials file)

Базовый тип подключения

cert: <cwallet.sso file location>

connectionParams: {
 "version": "2.0.0",
 "type": "connection",
 "name": "oracle_adw_with_wallet",
 "description": "Sample Oracle ADW connection with wallet created using Connections API",
 "content": {
   "connectionParams": {
     "connectionType": "oracle-autonomous-data-warehouse",
     "connectionString": "(description= (retry_count=20)(retry_delay=3)(address=(protocol=tcps)
                        (port=1522)(host=example.com))
                        (connect_data=(service_name=example.com))
                        (security=(ssl_server_dn_match=yes)))",
     "username": "admin",
     "password": "<password>",
     "remoteData": "false",
     "systemConnection": false,
     "sslType": "ClientSideSSL"
    }
  }
 }

PostgreSQL

(Не SSL)

Базовый тип подключения

{
 "version":"2.0.0",
 "type": "connection",
 "name": "postgres_non_SSL",
 "description": "Sample PostgreSQL connection created using Connections API",
 "content": {
   "connectionParams": {
     "connectionType": "postgresql-database",
     "host": "example.com",
     "port": "5432",
     "serviceName": "postgres",
     "username": "admin",
     "password": "<password>",
     "remoteData": false,
     "systemConnection": false
    }
  }
}

PostgreSQL с SSL

Базовый тип подключения

{
 "version":"2.0.0",
 "type": "connection",
 "name": "postgres_SSL_Conn",
 "description": "Sample PostgreSQL connection with SSL created using Connections API",
 "content": {
   "connectionParams": {
     "connectionType": "postgresql-database",
     "host": "example.com",
     "port": "5432",
     "serviceName": "postgres",
     "username": "admin",
     "password": "<password>",
     "sslType":"ServerSideSSL",
     "remoteData": false,
     "systemConnection": false
    }
  }
}

SQL Server

(Не SSL)

Базовый тип подключения

{
 "version":"2.0.0",
 "type": "connection",
 "name": "SqlServer_non_ssl",
 "description": "Sample non-SSL SQL Server connection created using Connections API",
 "content": {
   "connectionParams": {
     "connectionType": "sqlserver-database",
     "host": "example.com",
     "port": "1400",
     "serviceName": "sqlserver1",
     "username": "admin",
     "password": "<password>",
     "remoteData": false,
     "systemConnection": false
    }
  }
}

Базовый тип подключения

{
 "version":"2.0.0",
 "type": "connection",
 "name": "SqlServer_ssl",
 "description": "Sample SQL Server connection with SSL created using the Connections API",
 "content": {
   "connectionParams": {
     "connectionType": "sqlserver-database",
     "host": "example.com",
     "port": "60190",
     "serviceName": "sqlserver1",
     "username": "admin",
     "password": "<password>",
     "sslType":"ServerSideSSL",
     "remoteData": false,
     "systemConnection": false
    }
  }
}

MySQL

(Не SSL)

Базовый тип подключения

{
 "version":"2.0.0",
 "type": "connection",
 "name": "MySql_no_SSL",
 "description": "Sample MySQL connection created using the Connections API",
 "content": {
   "connectionParams": {
     "connectionType": "mysql-database",
     "host": "example.com",
     "port": "3307",
     "serviceName": "mysql1",
     "username": "admin",
     "password": "<password>",
     "remoteData": false,
     "systemConnection": false
    }
 }
}

Базовый тип подключения

{
 "version":"2.0.0",
 "type": "connection",
 "name": "MySql_ssl",
 "description": "Sample MySQL connection with SSL created using Connections API",
 "content": {
   "connectionParams": {
     "connectionType": "mysql-database",
     "host": "example.com",
     "port": "3306",
     "serviceName": "mysql1",
     "username": "admin",
     "password": "<password>",
     "sslType":"ServerSideSSL",
     "remoteData": false,
     "systemConnection": false
    }
  }
}

Oracle Essbase

Базовый тип подключения

{
 "version":"2.0.0",
 "type": "connection",
 "name": "Oracle_Essbase",
 "description": "Sample Oracle Essbase connection created using Connections API",
 "content": {
   "connectionParams": {
     "connectionType": "oracle-essbase",
     "dsn":"example.com",
     "username":"admin",
     "password":"<password>",
     "remoteData": false,
     "systemConnection": false,
     "authentication":"current"/"private"/"sso"
    }
  }
}
