CREATE VECTOR INDEX
Purpose
Vector indexes speed up vector searches and are either exact search indexes or approximate search indexes. An exact search gives 100% accuracy at the cost of heavy compute resources. Approximate search indexes, also called vector indexes, trade accuracy for performance.
Vectors are grouped or connected together based on similarity, where similarity is determined by their relative distance to each other. Greedy searches are done across these groups and connections to find the best, closest match to the query vector being searched for. A search using a vector index is called an approximate search.
There are two vector indexes supported in vector search: IVF (Inverted File) Flat index and HNSW (Hierarchical Navigable Small Worlds) index. IVF Flat (also simply called IVF) is a partitionedbased index, while HNSW is a graphbased index. All partition based indexes are classifed as Neighbor Partition Vector Index, and all graphbased indexes are classifed as InMemory Neighbor Graph Vector Index.
See Also:
Create Vector Indexes of the AI Vector Search User's Guide
Syntax
(vector_index_organization_clause::=,vector_index_parameters_clause::=,vector_index_parameters_hnsw_clause::=,vector_index_parameters_ivf_clause::=)
vector_index_organization_clause::=
vector_index_parameters_clause::=
vector_index_parameters_hnsw_clause::=
vector_index_parameters_ivf_clause::=
Semantics
vector_index_parameters_hnsw_clause
HNSW Specific Parameters
NEIGHBORS
and M
are equivalent and represent the maximum number of neighbors a vector can have on any layer. The last vertex has one additional flexibility that it can have up to 2M neighbors.
EFCONSTRUCTION
represents the maximum number of closest vector candidates considered at each step of the search during insertion.
The valid range for HNSW vector index parameters are:

ACCURACY
: > 0 and <= 100
DISTANCE
:EUCLIDEAN
,L2_SQUARED
(akaEUCLIDEAN_SQUARED
),COSINE
,DOT
,MANHATTAN
,HAMMING

TYPE
:HNSW

NEIGHBORS
: >0 and <= 2048
EFCONSTRUCTION
: >0 and <= 65535
vector_index_parameters_ivf_clause
IVF Parameters
NEIGHBOR
PARTITIONS
determines the number of centroid partitions that are created by the index.
SAMPLE_PER_PARTITION
decides the total number of vectors that are passed to the clustering algorithm (number of samples per partition times the number of neighbor partitions). Note, that passing all the vectors would significantly increase the total time to create the index. Instead, aim to pass a subset of vectors that can capture the data distribution.
MIN_VECTORS_PER_PARTITION
represents the target minimum number of vectors per partition. Aim to trim out any partition that can end up with fewer than 100 vectors. This may result in lesser number of centroids. Its values can range from 0 (no trimming of centroids) to num_vectors (would result in 1 neighbor partition).
The valid range for IVF vector index parameters are:

ACCURACY
: > 0 and <= 100
DISTANCE
:EUCLIDEAN
,L2_SQUARED
(akaEUCLIDEAN_SQUARED
),COSINE
,DOT
,MANHATTAN
,HAMMING

TYPE
:IVF

NEIGHBOR PARTITIONS
: >0 and <= 10000000
SAMPLE_PER_PARTITION
: from 1 to (num_vectors/neighbor_partitions)
MIN_VECTORS_PER_PARTITION
: from 0 (no trimming of centroid partitions) to total number of vectors (would result in 1 centroid partition)
Examples
CREATE VECTOR INDEX galaxies_hnsw_idx ON galaxies (embedding) ORGANIZATION INMEMORY NEIGHBOR GRAPH DISTANCE COSINE WITH TARGET ACCURACY 95;
CREATE VECTOR INDEX galaxies_hnsw_idx ON galaxies (embedding) ORGANIZATION INMEMORY NEIGHBOR GRAPH DISTANCE COSINE WITH TARGET ACCURACY 90 PARAMETERS (type HNSW, neighbors 40, efconstruction 500);
CREATE VECTOR INDEX galaxies_ivf_idx ON galaxies (embedding) ORGANIZATION NEIGHBOR PARTITIONS DISTANCE COSINE WITH TARGET ACCURACY 95;
CREATE VECTOR INDEX galaxies_ivf_idx ON galaxies (embedding) ORGANIZATION NEIGHBOR PARTITIONS DISTANCE COSINE WITH TARGET ACCURACY 90 PARAMETERS (type IVF, neighbor partitions 10);
