2 Deployment Environment
This section provides information about the cloud native platform infrastructure details for deploying Oracle Communications Cloud Native Core, Converged Policy.
Note:
The performance and capacity of the Policy system may vary based on the Call model, Feature/Interface configurations, underlying CNE and hardware environment, including but not limited to the complexity of deployed policies, policy table size, object expression, and custom json usage in policy design.2.1 Deployed Components
This section provides details about the deployed components.
Deployment Platform
Oracle Communications Cloud Native Environment (CNE) 23.3.3 and BareMetal can be used for performing benchmark tests.
Table 2-1 Observability Services
| Service Name | Version |
|---|---|
| OpenSearch | 2.3.0 |
| Fluentd | 1.16.2 |
| Prometheus | 2.44.0 |
| Grafana | 9.5.3 |
| Jaeger | 1.45.0 |
Cloud Native Orchestrator
Kubernetes 1.27.x is used to manage application pods across the cluster.
cnDBTier
cnDBTier 23.2.2 is used for performing benchmark tests.
Policy Infrastructure Details
Infrastructure used for benchmarking Policy performance run is described in this section.
Table 2-2 Hardware Details
| Hardware | Details |
|---|---|
| Environment | BareMetal |
| Server | Oracle Server X8-2 |
| Model | Intel(R) Xeon(R) Platinum 8260 |
| Clock Speed | 2.400 GHz |
| Total Cores | 24 |
| Memory Size | 32 GB |
| Type | DDR4 SDRAM |
| Installed DIMMs | 18 |
| Maximum DIMMs | 24 |
| Installed Memory | 576 GB |
Table 2-3 Software Details
| Aplications | Version |
|---|---|
| PCF | 23.4.0 |
| cnDBTier | 23.2.2 |
| OSO | 23.3.2 |
| CNE | 23.3.3 |
For more information about Policy Installation details, see Oracle Communications Cloud Native Core, Converged Policy Installation, Upgrade, and Fault Recovery Guide.
