Mini Time of Use Reminder

Positioned in the top right of the progress version of the Peak Focused Report, the Mini Time of Use Reminder module is a customer's first point of reference for understanding peak electricity cost periods based on their Time of Use plan. The module clearly displays the multiplier for high-cost periods and their specific timings, provides a color-coded timeline that highlights peak times in for easy identification, and adapts to different utility peak times and billing structures, such as demand charges.

Appears in: Peak Focused Report

On this page:

• Mini Time of Use Reminder
  • Requirements
    • Utility Requirements
    • Customer Requirements
  • Limitations
  • User Experience
  • User Experience Variations
    • Three Peak Periods
    • Demand Charge
    • Footnote

Requirements

Utility Requirements

Category	Description
Required Cloud Service	Energy Efficiency Cloud Service
Scale	Note applicable.

Customer Requirements

Category	Description
Billing Frequency	Monthly or bi-monthly.
Data Delivery Frequency	Monthly, bi-monthly, or quarterly.
Data Requirements	AMI data and rate metadata.
Data History	A minimum of one historical bill.
Data Coverage	Not applicable.
Supported Fuels	Electric-only.

Back to Top

Limitations

• Peak Focused Report only: This module is only available as part of the Peak Focused Report.
• Time of Use Rate Plan: This module is only available to customers on Time of Use rate plans.
• Demand Charge: This module supports customers on Time of Use plans with demand charges.

Back to Top

User Experience

This section describes the user experience for a customer with two peak periods.

Header: The header informs the customers what the multiplier in cost will be during the peak period and what times the period will occur.

• Weekday Price Ratio: The multiplier of cost during the peak period.
• High Cost Period Label: Rate plan-specific name for the high cost period. For example, "peak period" or "on-peak."
• Weekday High Cost Period Start Time: The time the peak period will start. For example, 4pm.
• Weekday High Cost Period End Time: The time the peak period will end. For example, 7pm.

Cost Period Bar: The cost period bar provides a visual representation of the high cost period.

• High Cost Period Color: The high cost period is indicated by a warning-color to provide a visual cue to the customer to take heed of this time period. In the example image, the "on-peak" period is indicated by a dark orange warning color.
• Low Cost Period Color: The low cost period is indicated by a cool color. In the example image, "off-peak" is indicated by a cool blue color.
• High Cost Start and End Times: The high cost period start time and end time are noted on the bar.

Cost Period Legend: The cost period legend defines which colors represent cost periods in the cost period bar.

Back to Top

User Experience Variations

Three Peak Periods

This image is an example of the Mini Time of Use Reminder module for a customer with three peak periods.

If the customer has three peak periods, the user experience varies as follows.

Cost Period Bar: The cost period bar provides a visual representation of the low, medium, and highest cost periods. For three peak period times, it includes the following:

• High Cost Period Color: The high cost period is indicated by a warning color to provide a visual cue to the customer to take heed of this time period. In the example image, the "on-peak" period is indicated by a dark orange warning color.
• Medium Cost Period Color: The medium cost period is indicated by a medium color. In the example image, the "partial-peak" period is indicated by a light orange color that is lighter than the high cost period warning color.
• Low Cost Period Color: The low cost period is indicated by a light cool color. In the example image, "off-peak" is indicated by the blue color.
• Cost Start and End Times: The cost period start time and end time are noted on the bar.

Cost Period Legend: The cost period legend defines which colors represent cost periods in the cost period bar. Only one legend item is displayed for more than one block of the same color.

Back to Top

Demand Charge

This image is an example of the Mini Time of Use Reminder module for a customer with demand charge rate in addition to the Time of Use plan.

If the customer has demand charging, then the user experience varies as follows.

Header: The header informs the customers when the demand charge occurs.

Weekday High Cost Period Start Time: The time the peak period will start. For example, 4pm.

• Weekday High Cost Period End Time: The time the peak period will end. For example, 9pm.
• Cost Period Bar: The cost period bar provides a visual representation of the high cost period.

Cost Period Colors: The cost period provide the customer with a visual cue to draw their attention to the most crucial times to save every during peak events.

• High Cost Period Color: The high cost period is indicated by a warning-color to provide a visual cue to the customer to take heed of this time period. This is the period when demand charging occurs. In the example image, the "on-peak" period is indicated by a dark orange warning color.
• Medium Cost Period Color: The low cost period is indicated by a medium color. In the example image, the "partial-peak" period is indicated by a light orange color.
• Low Cost Period Color: The lowest cost period is indicated by a cool color. In the example image, the "off-peak" period is indicated by a cool blue color.

Cost Period Legend: The cost period legend defines which colors represent cost periods in the cost period bar.

Back to Top

Footnote

If the footnote is configured, it appears below the cost period legend. An asterisk appears in the heading next to the peak day.

Back to Top
