5.3.3 Server Restart

  1. Select Domain and view the configuration.

    Figure 5-20 Settings for JMS Module


    Description of Figure 5-20 follows
    Description of "Figure 5-20 Settings for JMS Module"

  2. Go to Monitor Tree and select Servers Option.
  3. Select the Manage Server to Shutdown and Start.

    Figure 5-21 Settings for JMS Module


    Description of Figure 5-21 follows
    Description of "Figure 5-21 Settings for JMS Module"

  4. Click on the Manage Server to view the status.

    Figure 5-22 Settings for JMS Module


    Description of Figure 5-22 follows
    Description of "Figure 5-22 Settings for JMS Module"

  5. Click Edit Tree option to update the Manage Server Configuration.

    Figure 5-23 Settings for JMS Module


    Description of Figure 5-23 follows
    Description of "Figure 5-23 Settings for JMS Module"

  6. Go to Advanced > Node Manager to update the Arguments section.

    Figure 5-24 Create a New JMS System Module Resource


    Description of Figure 5-24 follows
    Description of "Figure 5-24 Create a New JMS System Module Resource"

Parent topic: Resource Creation
