Scenario Elements

The Scenario Elements area contains the information that you need to define a sequence scenario.

Figure 6-2 Sequence Scenario Editor—Scenario Elements Area


Sequence Scenario Editor—Scenario Elements Area

The Scenario Elements area contains the following fields:

  • Focus: Indicates the focal entity for a scenario; the focal entity key ID (for example, an account ID) must be captured in the pattern.
  • Scenario Class: Specify the scenario class for this scenario. A scenario class groups scenarios together based on similar behaviors of interest.
  • Name: Defines the long version of the scenario name, which is not displayed on the Web Application.
  • Short Name: Specifies the abbreviated name for the scenario, which is shown on the Web Application.
  • Scenario Class: Specify the scenario class for this scenario. A scenario class groups scenarios together based on similar behaviors of interest.
  • Description: Specify information that is pertinent to the scenario, this serves as the description in a generated pattern report.
  • Comments: Specifies additional information that you want to include in a scenario.
  • Scenario Catalog ID: Identifies the unique ID of a scenario.
  • Activated: Displays the current status of the open scenario. Activated status is the default; to deactivate, click the check box next to the Activated field.
