Configuring Siebel Business Applications > Configuring Multi-Value Group, Association, and Shuttle Applets > Creating Multi-Value Groups and Multi-Value Group Applets > About the Multi-Value Group AppletA multi-value group applet lists records from the detail business component that the multi-value group references. These records are child records in the parent-child relationship with the record of the master business component. The multi-value group applet does the following:
For more information, see Multi-Value Group, Multi-Value Link, and Multi-Value Group Applet. Viewing an Example of a Multi-Value Group AppletYou can view an example of a multi-value group applet. To view an example of a multi-value group applet
Siebel CRM displays the Account Addresses multi-value group applet. This applet lists the detail Address records that Siebel CRM associates with the master account record. This dialog box lists the address information that is associated with each account, including the street address, city, state, and ZIP Code. A check mark in the Primary column indicates that Siebel CRM displays data from this record in the Address field of the Account Entry Applet. You can view the list of addresses that Siebel CRM associates with the account while the Account Addresses multi-value group applet is open. You can add, query, or delete an address. Relationships and Objects of a Multi-Value Group AppletThe list column is a child of the list. It includes a Field property that identifies the field in the detail business component that the multi-value group references. Siebel CRM displays this data in the list column. For more information, see How a Business Component Field Identifies the Type of Data. Figure 47 describes the relationships and objects that Siebel CRM uses in a multi-value group applet. Properties of a Multi-Value Group AppletTable 52 describes some of the properties of the multi-value group applet. |
