Activating the Prepaid SMS Intercept Phase 1 Feature

This procedure is used to enable and turn on the Prepaid SMS Intercept Phase 1 feature.

The feature access key is based on the feature’s part number and the serial number of the EAGLE, making the feature access key site-specific.

The enable-ctrl-feat command enables the Prepaid SMS Intercept Phase 1 feature by inputting the feature’s access key and the feature’s part number with these parameters:

:fak – The feature access key provided by Oracle. The feature access key contains 13 alphanumeric characters and is not case sensitive

:partnum – The Oracle-issued part number of the Prepaid SMS Intercept Phase 1 feature, 893006701.

If the feature is being enabled with a temporary feature access key, the feature must not be in the in-use, expired, or unavailable state.

The enable-ctrl-feat command requires that the database contain a valid serial number for the EAGLE, and that this serial number is locked. This can be verified with the rtrv-serial-num command. The EAGLE is shipped with a serial number in the database, but the serial number is not locked. The serial number can be changed, if necessary, and locked once the EAGLE is on-site, with the ent-serial-num command. The ent-serial-num command uses these parameters.

:serial – The serial number assigned to the EAGLE. The serial number is not case sensitive.

:lock – Specifies whether or not the serial number is locked. This parameter has only one value, yes, which locks the serial number. Once the serial number is locked, it cannot be changed.

Note:

To enter and lock the EAGLE’s serial number, the ent-serial-num command must be entered twice, once to add the correct serial number to the database with the serial parameter, then again with the serial and the lock=yes parameters to lock the serial number. You should verify that the serial number in the database is correct before locking the serial number. The serial number can be found on a label affixed to the control shelf (shelf 1100).

Once the feature has been enabled, the feature must be activated with the chg-ctrl-feat command. The chg-ctrl-feat command uses these parameters:

:partnum – The Oracle-issued part number of the Prepaid SMS Intercept Phase 1 feature, 893006701.

:status=on – used to turn the Prepaid SMS Intercept Phase 1 feature on.

The status of the features in the EAGLE is shown with the rtrv-ctrl-feat command.

The Prepaid SMS Intercept Phase 1 requires that DSM or SLIC cards are installed and provisioned in the EAGLE. The rtrv-stp command can be used to verify if DSMs or SLIC cards are provisioned in the database. Specifying the type=dsm (the SLIC must be in odd numbered card slots) or type=slic (the SLIC in the even numbered card slots) parameter with the rtrv-stp command displays the DSM or SLIC cards.

  1. Display the status of the Prepaid SMS Intercept Phase 1 feature by entering the rtrv-ctrl-feat command.

    The following is an example of the possible output.

    rlghncxa03w 08-09-28 21:15:37 GMT EAGLE5 39.1.0
    The following features have been permanently enabled:

    Feature Name              Partnum    Status  Quantity
    Command Class Management  893005801  on      ----
    Intermed GTT Load Sharing 893006701  off     ----
    XGTT Table Expansion      893006101  off     ----
    XMAP Table Expansion      893007710  on      3000
    Large System # Links      893005910  on      2000
    Routesets                 893006401  on      6000
    HC-MIM SLK Capacity       893012707  on      64

    The following features have been temporarily enabled:

    Feature Name              Partnum    Status  Quantity     Trial Period Left
    Zero entries found.

    The following features have expired temporary keys:

    Feature Name              Partnum
    Zero entries found.

    If the rtrv-ctrl-feat output shows that the Prepaid SMS Intercept Phase 1 feature is permanently enabled, and its status is on, no further action is necessary.

    If the Prepaid SMS Intercept Phase 1 feature is permanently enabled, and its status is off, continue the procedure with 10.

    If the Prepaid SMS Intercept Phase 1 feature is temporarily enabled, and you wish to permanently enable this feature, or the temporary feature access key for that feature has expired, continue the procedure with 9.

    If the Prepaid SMS Intercept Phase 1 feature is to remain temporarily enabled, and its status is off, continue the procedure with 10. If the feature’s status is on, no further action is necessary.

    If the Prepaid SMS Intercept Phase 1 feature is to remain temporarily enabled, and its status is on, no further action is necessary.

    If the Prepaid SMS Intercept Phase 1 feature is not enabled, continue the procedure with 2.

  2. If the rtrv-ctrl-feat output in 1 shows any controlled features, continue the procedure with 9. If the rtrv-ctrl-feat output shows only the HC-MIM SLK Capacity feature with a quantity of 64, 3 through 6 must be performed.
  3. Display the serial number in the database with the rtrv-serial-num command. This is an example of the possible output.
    rlghncxa03w 08-09-28 21:15:37 GMT EAGLE5 39.1.0
    System serial number = nt00001231

    System serial number is not locked.

    rlghncxa03w 08-09-28 21:15:37 GMT EAGLE5 39.1.0
    Command Completed.

    Note:

    If the serial number is correct and locked, continue the procedure with 7. If the serial number is correct but not locked, continue the procedure with 6. If the serial number is not correct, but is locked, this feature cannot be enabled and the remainder of this procedure cannot be performed. Contact My Oracle Support to get an incorrect and locked serial number changed. Refer to My Oracle Support (MOS) for the contact information. The serial number can be found on a label affixed to the control shelf (shelf 1100).
  4. Enter the correct serial number into the database using the ent-serial-num command with the serial parameter.

    For this example, enter this command.

    ent-serial-num:serial=<EAGLE’s correct serial number>

    When this command has successfully completed, the following message should appear.

    rlghncxa03w 08-09-28 21:15:37 GMT EAGLE5 39.1.0
    ENT-SERIAL-NUM:  MASP A - COMPLTD
  5. Verify the serial number entered into 4 was entered correctly using the rtrv-serial-num command. This is an example of the possible output.
    rlghncxa03w 08-09-28 21:15:37 GMT EAGLE5 39.1.0
    System serial number = nt00001231

    System serial number is not locked.

    rlghncxa03w 08-09-28 21:15:37 GMT EAGLE5 39.1.0
    Command Completed.

    If the serial number was not entered correctly, repeat 4 and 5 and re-enter the correct serial number.

  6. Lock the serial number in the database by entering the ent-serial-num command with the serial number shown in 3, if the serial number shown in 3 is correct, or with the serial number shown in5, if the serial number was changed in 4, and with the lock=yes parameter.

    For this example, enter this command.

    ent-serial-num:serial=<EAGLE’s serial number>:lock=yes

    When this command has successfully completed, the following message should appear.

    rlghncxa03w 08-09-28 21:15:37 GMT EAGLE5 39.1.0
    ENT-SERIAL-NUM:  MASP A - COMPLTD
  7. Verify that the GTT feature is on, by entering the rtrv-feat command. If the GTT feature is on, the GTT field should be set to on.

    Note:

    The rtrv-feat command output contains other fields that are not used by this procedure. If you wish to see all the fields displayed by the rtrv-feat command, see the rtrv-feat command description in Commands User's Guide.

    If the GTT feature is not on, perform Adding a Service Module to turn the GTT feature on and add DSMs or SLIC cards to the EAGLE. After the GTT feature is turned on and the DSMs or SLIC cards have been added, continue the procedure with 9.

    If the GTT feature is on, continue the procedure with 8.

  8. Display any DSMs or SLIC cards by entering one of the following commands, respectively:

    rtrv-stp:type=dsm

    rtrv-stp:type=slic

    This is an example of the possible output if DSMs or SLIC cards are provisioned in the database.

    rlghncxa03w 08-09-28 21:15:37 GMT EAGLE5 39.1.0

    Card  Part Number  Rev Serial Number  Type     DB     APPL     GPL Version
    ----  -----------  --- -------------  ----     --     ----     -----------
    1105  870-1275-03  W    10245689323   DSM      40696M VSCCP     027-010-000
    1214  870-1275-03  W    10245689333   DSM      40696M VSCCP     027-010-000
    2107  870-1275-03  W    10245689343   DSM      40696M VSCCP     027-010-000
    Command Completed.

    This is an example of the possible output if there are no DSMs or SLIC cards provisioned in the database.

    rlghncxa03w 08-09-28 21:15:37 GMT EAGLE5 39.1.0

    Card  Part Number  Rev Serial Number  Type     DB     APPL     GPL Version
    ----  -----------  --- -------------  ----     --     ----     -----------

    Command Completed.

    If no DSMs or SLIC cards are shown in this step, perform Adding a Service Module to add an E5-SM8G-B cards. After the cards have been added, continue the procedure with 9.

    If cards are shown in this step, continue the procedure with 9.

  9. Enable the Prepaid SMS Intercept Phase 1 feature with either a permanent key or temporary key by entering the enable-ctrl-feat command. For this example, enter this command.

    enable-ctrl-feat:partnum=893006701

    When the enable-crtl-feat command has successfully completed, this message should appear.

    rlghncxa03w 08-09-28 21:15:37 GMT EAGLE5 39.1.0
    ENABLE-CTRL-FEAT: MASP B - COMPLTD
  10. The Prepaid SMS Intercept Phase 1 feature must be turned on using the chg-ctrl-feat command, specifying the Prepaid SMS Intercept Phase 1 feature part number and the status=on parameter. For this example, enter this command.

    chg-ctrl-feat:partnum=893006701:status=on

    When this command has successfully completed, the following message should appear.

    rlghncxa03w 08-09-28 21:15:37 GMT EAGLE5 39.1.0
    CHG-CTRL-FEAT: MASP B - COMPLTD
  11. Verify the changes by entering the rtrv-ctrl-feat command with the Prepaid SMS Intercept Phase 1 part number. Enter this command.

    rtrv-ctrl-feat:partnum=893006701

    The following is an example of the possible output.

    rlghncxa03w 08-09-28 21:15:37 GMT EAGLE5 39.1.0
    The following features have been permanently enabled:

    Feature Name              Partnum    Status  Quantity
    Prepaid SMS Intercept Ph1 893006701  on      ----

    The following features have been temporarily enabled:

    Feature Name              Partnum    Status  Quantity     Trial Period Left
    Zero entries found.

    The following features have expired temporary keys:

    Feature Name              Partnum
    Zero entries found.
  12. Back up the new changes using the chg-db:action=backup:dest=fixed command.

    These messages should appear, the active Maintenance and Administration Subsystem Processor (MASP) appears first.

    BACKUP (FIXED) : MASP A - Backup starts on active MASP.
    BACKUP (FIXED) : MASP A - Backup on active MASP to fixed disk complete.
    BACKUP (FIXED) : MASP A - Backup starts on standby MASP.
    BACKUP (FIXED) : MASP A - Backup on standby MASP to fixed disk complete.

Figure B-1 Activate the Prepaid SMS Intercept Phase 1 Feature - Sheet 1 of 3

Figure B-2 Activate the Prepaid SMS Intercept Phase 1 Feature - Sheet 2 of 3

Figure B-3 Activate the Prepaid SMS Intercept Phase 1 Feature - Sheet 3 of 3
