6 NRF Metrics, KPIs, and Alerts
6.1 NRF Metrics
This section includes information about metrics for Oracle Communications Cloud Native Core, Network Repository Function.
Note:
- Sample NRF dashboard for Grafana is delivered to the customer through NRF CSAR package. Metrics and functions used to achieve KPI are covered in NRF CSAR package. For more information on how to download the NRF CSAR package from MOS, see Oracle Communications Cloud Native Core, Network Repository Function Installation, Upgrade, and Fault Recovery Guide.
- The metric scraping time varies as per the environment in which it is deployed.
The name of the metrics may contain suffix such as total, seconds, max and
so on. It gets added by the micrometer registry if it is not present in the metrics
name. The metric name has the following format for suffix: <Basename of the
metric>_<Suffix>
Table 6-1 Metrics type and Suffix
Metric Type | Suffix | Description |
---|---|---|
Counter | _total | Represents the total number of occurrences of an event or traffic, such as measuring the total amount of traffic received and transmitted by NRF, and so on. |
Gauge | NA | Represents a single numerical value that changes randomly. This metric type is used to measure various parameters, such as NRF load values, memory usage, and so on. |
Histogram | _max, _bucket, _count, or _sum | Represents the sample observations like request durations or response sizes and counts them in configurable buckets. To measure the latency values, _seconds is used. |
Dimensions Legend for the Metrics
The following table includes the details about the metrics dimensions:
Table 6-2 Dimensions Legend
Dimension | Description |
---|---|
Action | Used in Gateway metrics.
Indicates the type of action taken for the requests. (rejects or processes a denied request based on the value of congestion level attribute in the denied request actions object. Sample Values: REJECT, CONTINUE |
ActionId | Used in Gateway metrics.
Indicates the unique Id of the request. Sample Values: 1, 2 |
Allowed | Used in Gateway metrics.
Indicates if the requests are accepted or rejected. If the request is below fillRate, the value is set as true. If the request is above the fillRate, the value is set as false. Sample Values: true, false |
application | Indicates the application name.
Sample Values: ocnrf |
authority |
Used in Gateway metrics. Indicates the destination address. |
BackendSvc |
Used in Gateway metrics. Indicates the address of destination. |
BackendSvcAddressType |
Used in Gateway metrics. Indicates the IP type (IPv4/IPv6) of the destination from the Egress Gateway. |
Bucket | Indicates how many profiles are returned in the response of Discovery request. Range is not configurable. Possible values are 0-10, +Inf. According to NF profiles returned, corresponding bucket will be incremented by one. For example, if 2 profiles are returned, then bucket 2 will be incremented by one. Profiles getting returned more than 10 will fall in +Inf bucket. |
CertificateName | Indicates the ccaHeaderValidation file name configured in Helm. |
ClientCertIdentity |
Used in Gateway metrics. Indicates the certificate identity of the client, SAN=127.0.0.1,localhost CN=localhost, N/A if data is not available. |
ClientNfInstanceId | Indicates the client NF Instance Id for NF Access Token. |
client_type |
Used in Gateway metrics. Indicates the type of jetty client being used at Ingress Gateway.Sample Values: h2, h2c |
CongestionLevel |
Used in Gateway metrics. Indicates the congestion level of the pods. Sample Values: 0, 1, 2, 3 |
connectionId | Indicates the connectionId of the http2 connection. |
ConsumerInstanceId | Indicates the consumer NF's NfInstanceId configured in Sub in JWT token. |
ConsumerNFInstanceId | Indicates the consumer NF Instance Id for NF Access Token |
ConsumerNFType | Indicates request is for which consumer NF type. |
content_available | Used in Gateway metrics.
Indicates if the incoming request to Ingress Gateway has a request body present in it. Sample Values: true, false |
DataType | Indicates the type of data.
Sample Values: NfProfiles, NfSubscriptions |
dbOperation | Indicates the database operation type such as Create, update, delete, and find. |
DestinationHost |
Used in Gateway metrics. Indicates the destination IP address or FQDN of the host. |
destinationHostAddressType |
Used in Gateway metrics. Indicates the destination IP type (IPv4 or IPv6) from Egress Gateway. |
Direction |
Used in Gateway metrics. Indicates the direction of the request or response. In case of Ingress Gateway, the value is ingress. In case of Egress Gateway, the values are egress, egressOut. |
DiscardAction |
Used in Gateway metrics. Indicates the type of pod discard in overload filter. Sample Values: PercentageBased, PriorityBased |
dnsResolvedType |
Used in Gateway metrics. Indicates the actual DNS resolved IP type (IPv4 or IPv6) of the destination. |
egressRoutingMode |
Used in Gateway metrics. Indicates the value of the egressRoutingMode configured in Egress Gateway. Sample Values: IPv4, IPv6, IPv4_IPv6, IPv6_IPv4, None |
ErrorProfile |
Used in Gateway metrics. Indicates a valid error code for rejected requests based on the action. Sample Values: "ERR_POD_PROTECTION_RATE_LIMIT" |
error_reason |
Indicates the reason for failure response received. If message is sent in the response, then it is filled with the message otherwise exception class is filled. In case of successful response it is filled with "no-error". Sample Values:
|
ErrorOriginator |
Used in Gateway metrics. Indicates the source of error like ServiceProducer, Nrf, IngressGW, None. |
ErrorReason | Indicates the CCA header validation failed message like: aud claim validation failed, sub claim validation failed, JWT Signature does not match, X5C certificate has expired. |
event |
Used in Gateway metrics. Indicates the lifecycle event processed during the jetty request processing with the back-end services.Sample Values: onQueued, onBegin, onHeaders, onCommit, onContent, onSuccess, onFailure |
ExceptionAttribute | Indicates the NFDiscover search query attribute due to which NFDiscover service operation is not rejected even SLF specific mandatory attributes are missing from search query. |
FailureReason | Indicates the failure reason for Roaming Support.
Sample Values:
|
ForwardingBarringReason | Indicates the forwarding barring reason for NF Access
Token and NFDiscover service operations.
Sample
Values:
|
GroupId | Indicates the GroupId returned by SLF/UDR corresponding to SubscriptionId. |
HeartbeatTimer | Indicates the heartbeatTimer of the NfProfile. The value is considered in seconds. |
Host |
Used in Gateway metrics. Indicates the gateway port (IP or FQDN). Indicates the remote address of client connected to the Ingress Gateway. |
HttpStatusCode | Indicates the HTTP Status Code.
Sample Values 429, 500 Note: If this error code is generated by Egress Gateway microservice, then the status code is updated as Egw-<response code>. Sample Value: Egw-429 |
HttpVersion | Indicates the Http protocol version.
Sample Values:
|
Id |
Used in Gateway metrics. Corresponds to the id defined in the routes of the Pod Protection configuration. Sample Values: 1, 2, 3, default_route |
InstanceIdentifier |
Used in Gateway metrics. Indicates the pod prefixes configured in helm when there are multiple instances in same deployment- Prefix configured in helm otherwise UNKNOWN. |
isCurrentKeyId | Indicates if a specific metric is for current key id
in Access Token Configuration.
Sample Values: true, false |
isLeaderPod |
Used in Perf-Info. Indicates if the pod calculating the threshold level is a leader pod or not. Sample Values: true, false |
jetty_request_timeout | Used in Gateway metrics.
Indicates if a request at Egress Gateway failed due to request timeout at jetty level. Sample Values: true, false |
KeyId | Indicates if the Key Id from Access Token Configuration is used to sign the Access Token. |
KeyType | Indicates the Key type of Access Token Configuration (private key or certificate). |
LoadLevel | Used in Gateway metrics.
Indicates the load level of backend microservices which are configured in the "routes" of the Ingress Gateway microservice. Sample Values: L1, L2 |
Method/method | Indicates the HTTP Method Name.
Sample Values:
|
NegotiatedTLSVersion | This denotes the TLS version used for communication between the server and the client. Sample Values: TLSv1.2, TLSv1.3. |
NewStatus | Indicates the new NfStatus of the NfProfile or
NfService.
Sample Values:
|
NfFqdn |
Indicates the FQDN of consumer NF. The nfFqdn dimension will contain the FQDN as present in the nfProfile.When service mesh is enabled, this dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
NfInstanceId | Indicates the Unique identity of the NF Instance sending request to NRF. |
NfServiceFqdn | Indicates the FQDN of the NfService. |
NFServiceType |
Used in Gateway metrics. Indicates the NFType extracted from URI. Path is /nxxx-yyy/vz/....... Where nxxx-yyy is NFServiceType UNKNOWN if unable to extract NFServiceType from the path Example: nnrf-nfm/v1/nf-instances |
NfSetFqdn | Indicates the domain name or FQDN for NAPTR record. It is populated using amfSetFqdn. |
NfType | Indicates the types of Network Functions (NF). |
NFType |
Used in Gateway metrics. Indicates the NFType extracted from URI. Path is /nxxx-yyy/vz/....... Where xxx will be changed to (Upper Case) is NFType UNKNOWN if unable to extract NFType from the path Example: nnrf-nfm/v1/nf-instances |
Node | Indicates the name of the Kubernetes worker node on which microservice is running. |
NotificationEventType | Indicates the subscription request is
for which event types.
Sample Values:
|
NotificationHostPort | Indicates the port of notification callback server. |
NRFRole | Indicates the NRF role whether it is hNRF or
vNRF.
Sample Values: hNRF, vNRF |
NrfFqdn | Indicates the FQDN of NRF. |
nrfInstanceId | Indicates the Nrf Instance Id of NRF. |
NrfLevel | Indicates the NRF Deployment Name by which NRF can be identified, it will be NRF Instance Id passed through Helm. |
Nsi | Indicates the Network slices are identified by Network Slice Instances (NSIs). It is in the string format. |
NumberOfRetriesAttempted | Indicates the number of retries attempted to notification callback server. |
oAuthHeaderPresent |
Used in Gateway metrics. Indicates if the oAuth header is present or not. Sample Values: true, false |
oAuthTokenPresent |
Used in Gateway metrics. Indicates if the oAuth token is present or not. Sample Values: true, false |
OperationType | Indicates the Operation type of the request sent
towards DNS server.
Sample Values:
|
OperationType | Indicates if the NFSubscribe Service
operation to specify if the request is to create or update the
subscription.
Sample Values:
|
peer | Indicates the SCP peer. |
peerset | Indicates the SCP peerset. |
PreviousSLFFqdn | Indicates the target SLF FQDN where the previous request was sent to and failed. |
PreviousStatus | Indicates the previous NfStatus of the NfProfile or
NfService.
Sample Values:
|
Priority |
Used in Gateway metrics. Indicates the priority of the request. Sample Values: 24 |
ProducerInstanceId | Indicates the NrfInstanceId. |
quantile | Indicates the latency values with ranges as 10ms, 20ms, 40ms, 80ms, 100ms, 200ms, 500ms, 1000ms, and 5000ms. |
QueryType |
Indicates the type of the query sent by the NF. Sample Values:
|
receivedAddressType |
Used in Gateway metrics. Indicates the IP type (IPv4/IPv6) of the remote client connected to the Ingress Gateway. |
RejectionReason | Indicates the rejection reason for NF
Access Token, Roaming Support, Subscription limit breached.
Sample Values:
|
RemoteNrfInstanceId | Indicates the Nrf Instance Id of the remote NRF. |
RemoteSiteName | Indicates the site name of remote NRF. |
Replacement | Indicates the value as populated using 3GPP AMF
name.
Sample Values:
|
RequesterNfType | Indicates the NF type which
originating the request. This value comes from UserAgent header. For
NFDiscover Service operation it is taken from Search Query.
In case, there is no header or value, this value will be UNKNOWN in the metrics. |
RequesterPLMNId | Indicates the PLMN ID which originating the request. |
RequestType |
Indicates the type of the service request sent by the NF. Sample Values:
|
ResponseReason | Indicates the response reason in response sent back
to NF.
Sample Values:
|
route_id | Used in Gateway metrics. Indicates a unique Id to identify a specific route. All the requests always get mapped to a unique route. Sample Values: egress_scp_proxy1, default_route |
RouteLevelColor |
Used in Gateway metrics. Indicates Green color for the requests accepted at route level policer and Red for requests rejected at route level policer. Sample Values: RED, GREEN |
Route_path |
Used in Gateway metrics. Indicates the Path predicate or Header predicate that matched the current request. |
Scheme | Inidicates the HTTP protocol scheme.
Sample Values:
|
Scope | Indicates the scope as received in the AccessToken
Request
Sample Values: NfDiscover, NFProfileRetrieval |
SecretName | Indicates the k8SecretName configured in Helm. |
serialNumber | Indicates the type of the certificate.
Sample Values: serialNumber=4661 is used for RSA and serialNumber =4662 is used for ECDSA |
service |
Used in Perf-Info. Indicates the NRF microservice type. Sample Values: ocnrf-nfaccesstoken, ocnrf-nfdiscovery |
ServiceInstanceId | Indicates the unique ID of the service instance within a given NF Instance. |
ServiceName | Indicates the service instance
name.
Sample Values: nudm-sdm |
ServiceOperation | Indicates the service operations as defined in 3GPP
specification for NRF.
Sample Values
|
siteName | Indicates the site name of NRF. |
SkipSLFLookupParameter | Indicates the NFDiscover search query attribute due
to which SLF lookup is skipped.
Sample Values: group-id-list |
SkipSLFLookupValue | Indicates the configured value for which SLF lookup is skipped, if
enableValueBasedSkipSLFLookup is set to
true.
If the value of
|
slfFqdn | Indicates the FQDN of the SLF. |
sni_status | Indicates if the SNI feature is enabled or disabled
when an invalid SNI (direct and indirect routing) is sent.
Sample Values:
|
sNssai | Indicates the Network slices are identified by Single Network Slice Selection Assistance Information (SNSSAI). It is in string format as outlined in 3GPP TS 29.571 section 5.4.4.2. |
SourceNrfSetId | Indicates the set ID of the source NRF. |
Status | Indicates the HTTP Status Code in response.
When used in Gateway metrics it indicates the status of the pod. Sample Values: DISCARDED |
StatusCode | Indicates the HTTP Status code. |
SubscriberPLMNId | Indicates request is for which subscriber PLMN ID. |
SubscriptionIdType | Indicates the Subscription Id type for which SLF query is received. |
subscriptionLimitFeatureStatus | Indicates whether the Subscription Limit feature is
enabled or disabled.
Sample Values:
|
SubscriptionStatus | Indicates the Status of subscription.
Sample Values:
|
tableName | Indicates the NRF Table Name |
TargetNfInstanceId | Indicates the target NF Instance Id for NF Access Token. |
TargetNfType | Indicates request is for which target NF type. |
TargetNrfFqdn | Indicates the FQDN of the NRF to which the request is forwarded to. |
TargetNrfSetId | Indicating the set ID of the target NRF. |
TargetPLMNId | Indicates request is for which target PLMN ID. |
TargetSLFFqdn | Indicates the target SLF FQDN where the current SLF request is sent. |
TLSFqdn | Indicates the Fully Qualified Domain Name (FQDN) received in TLS Certificate. |
TriggerMode | Indicates the trigger mode.
Sample Values
|
type |
This dimension is used in Gateway services and in Perf-Info.
|
Updatetype (Partial/Complete) | Indicates if the NF Update is with
PUT (Complete) or PATCH (Partial) methods.
Sample
Values:
|
Uri | Indicates the URI defined to identify the service operation at Ingress Gateway. |
vendor | Indicates the Vendor name of
NRF.
Sample Values:Oracle |
vfqdn | Indicates the FQDN of the peer. |
XfccHeaderPresent |
Used in Gateway metrics. Indicates if the XFCC header is present or not. Sample Values: true, false |
6.1.1 NRF Gateways Metrics
This section provides details about the Gateway metrics of NRF.
6.1.1.1 Ingress Gateway Metrics
Table 6-3 oc_ingressgateway_msgcopy_requests_total
Field | Details |
---|---|
Description | This is incremented whenever request message is sent or acknowledged from Kafka. |
Type | Counter |
Dimensions | type |
Table 6-4 oc_ingressgateway_msgcopy_responses_total
Field | Details |
---|---|
Description | This is incremented whenever response message is sent or acknowledged from Kafka. |
Type | Counter |
Dimensions | type |
Table 6-5 oc_ingressgateway_dd_unreachable
Field | Details |
---|---|
Description |
This indicates whether DD (kafka) is reachable or not 0 - reachable, 1 - unreachable |
Type | Gauge |
Table 6-6 oc_ingressgateway_jetty_request_stat_metrics_total
Field | Details |
---|---|
Description | This metric is pegged for every event occurred when a request is sent to Ingress Gateway. |
Type | Counter |
Dimensions | event, client_type, InstanceIdentifier, DestinationHost |
Table 6-7 oc_ingressgateway_jetty_response_stat_metrics_total
Field | Details |
---|---|
Description | This metric is pegged for every event occurred when a response is received by Ingress Gateway. |
Type | Counter |
Dimensions | event, client_type, InstanceIdentifier, DestinationHost |
Table 6-8 oc_ingressgateway_traffic_rejection_mode
Field | Details |
---|---|
Description | Gauge metric that pegs if the traffic is being rejected or not. The possible values are 0 and 1 (where "1" stands for rejected). |
Type | Gauge |
Table 6-9 oc_ingressgateway_http_requests_total
Field | Details |
---|---|
Description | Total number of ingress requests received at NRF. |
Type | Counter |
Dimensions | ClientCertIdentity, NFType, NFServiceType, Host, DestinationHost, oAuthTokenPresent, HttpVersion, Scheme, Route_path, InstanceIdentifier, consumerNfType, consumerInstanceId, ConsumerFqdn |
Table 6-10 oc_ingressgateway_http_responses_total
Field | Details |
---|---|
Description | Total number of responses for the following service
operations at NRF:
|
Type | Counter |
Dimensions | Status, Method, Route_path, NFType, NFServiceType, Host, DestinationHost, HttpVersion, Scheme, InstanceIdentifier, ClientCertIdentity, ErrorOriginator, jetty_request_timeout, error-reason |
Table 6-11 oc_ingressgateway_http_responses_total (4xx responses)
Field | Details |
---|---|
Description | Total number of 4xx responses for the following service
operations at NRF.
|
Type | Counter |
Dimensions | Status, Method, Route_path, NFType, NFServiceType, Host, DestinationHost, HttpVersion, Scheme, InstanceIdentifier, ClientCertIdentity, ErrorOriginator, jetty_request_timeout, error-reason |
Table 6-12 oc_ingressgateway_http_responses_total (5xx responses)
Field | Details |
---|---|
Description | Total number of 5xx responses for the following service
operations at NRF.
|
Type | Counter |
Dimensions | Status, Method, Route_path, NFType, NFServiceType, Host, DestinationHost, HttpVersion, Scheme, InstanceIdentifier, ClientCertIdentity, ErrorOriginator, jetty_request_timeout, error-reason |
Table 6-13 oc_ingressgateway_request_latency_seconds
Field | Details |
---|---|
Description | Time (in microseconds) to process an Ingress Gateway request. It is measured from when the request is received to when the response is sent |
Type | Histogram |
Dimensions | quantile, InstanceIdentifier, Route_path, Method |
Table 6-14 oc_ingressgateway_connection_failure_total
Field | Details |
---|---|
Description | Total number of failures at Ingress Gateway while establishing a connection with NRF. |
Type | Counter |
Dimensions | Host, Port, Direction, InstanceIdentifier, error_reason, ErrorOriginator |
Table 6-15 oc_ingressgateway_request_processing_latency_seconds
Field | Details |
---|---|
Description | Metric to capture the amount of time taken for processing of the request only within Ingress Gateway |
Type | Histogram |
Dimensions | quantile, InstanceIdentifier, Route_path, Method |
Table 6-16 oc_ingressgateway_request_content_metrics_total
Field | Details |
---|---|
Description | This metric is pegged by default filter RequestContentMetrics. It pegs whether a request has the request body or not. |
Type | Counter |
Dimensions | method, content_available, InstanceIdentifier |
Table 6-17 oc_ingressgateway_xfcc_header_validate_total
Field | Details |
---|---|
Description | This metric is pegged when xfccHeaderValidation is enabled in XfccHeaderValidationFilter. This metric along with the specified dimension captures the successful/ un-successful validation of XFCC header in the incoming request. |
Type | Counter |
Dimensions | Route_path, Status, Cause, CertsCompared, InstanceIdentifier, ErrorOriginator, ServiceType, ErrorDetail |
Table 6-18 oc_ingressgateway_incoming_connections
Field | Details |
---|---|
Description | Gauge metric that will peg active incoming connections from client to Ingress Gateway. |
Type | Gauge |
Dimensions | Direction, Host, InstanceIdentifier |
Table 6-19 oc_ingressgateway_outgoing_connections
Field | Details |
---|---|
Description | Gauge metric that will peg active outgoing connections from Ingress Gateway to destination. |
Type | Gauge |
Dimensions | Direction, Host, InstanceIdentifier |
Table 6-20 oc_ingressgateway_count_invalid_route
Field | Details |
---|---|
Description | Counter metric that is pegged for every invalid route. |
Type | Counter |
Dimensions | oAuthHeaderPresent, XfccHeaderPresent |
Table 6-21 oc_ingressgateway_request_latency_seconds_bucket
Field | Details |
---|---|
Description | This metric is pegged when a request comes to Ingress gateway. It shows latency consumed by ingress to process the request. |
Type | Histogram |
Dimensions | Method, Route_path, InstanceIdentifier |
Table 6-22 oc_ingressgateway_server_latency_seconds_bucket
Field | Details |
---|---|
Description | This metric is pegged when a request comes to Ingress gateway. It shows latency consumed by the backend to process the request. |
Type | Histogram |
Dimensions | Method, Route_path, InstanceIdentifier |
Table 6-23 oc_ingressgateway_jetty_request_stat_metrics_total
Field | Details |
---|---|
Description | This metric is pegged for every outgoing request from Ingress gateway to the backend at jetty level |
Type | Counter |
Dimensions | DestinationHost, InstanceIdentifier, event, client_type |
Table 6-24 oc_ingressgateway_cca_header_request_total
Field | Details |
---|---|
Description | This metric is pegged when CCA validation is enabled and CCA header is present in the request. |
Type | Counter |
Dimensions | ConsumerInstanceId, ProducerInstanceId |
Table 6-25 oc_ingressgateway_cca_header_response_total
Field | Details |
---|---|
Description | This metric is pegged when an error response is sent due to a validation error of the CCA header. |
Type | Counter |
Dimensions | ConsumerInstanceId, ProducerInstanceId, StatusCode, ErrorReason |
Table 6-26 oc_ingressgateway_cca_certificate_info
Field | Details |
---|---|
Description | Gauge metric used to peg the expiry date of the certificate. This metric is used further for raising alarms. |
Type | Counter |
Dimensions | CertificateName, SecretName, SerialNumber |
Table 6-27 oc_ingressgateway_pod_congestion_state
Field | Details |
---|---|
Description | The metric is used to track the overall congestion state
per Ingress Gateway pod. The values of the metric is as follow:
Note: Prometheus automatically injects pod name with label name "kubernetes_pod_name" to metric. This information is used for alert. |
Type | Gauge |
Dimensions | InstanceIdentifier |
Table 6-28 oc_ingressgateway_pod_resource_stress
Field | Details |
---|---|
Description | This metric pegs the CPU usage and the pending message count, based on which Ingress Gateway pod is calculating its congestion state. |
Type | Gauge |
Dimensions | InstanceIdentifier, type
Possible values for type are CPU, MEMORY, PENDING_REQUEST. Note: The type "MEMORY" is not used to determine the pod congestion state in NRF Ingress Gateway. |
Table 6-29 oc_ingressgateway_pod_resource_state
Field | Details |
---|---|
Description |
This metric pegs the congestion state per resource type which is calculated based on the resource usage and configured threshold. The values of the metric is as follow:
Note: Prometheus automatically injects pod name with label name "kubernetes_pod_name" to metric. This information is used for alert. |
Type | Gauge |
Dimensions | InstanceIdentifier, type
Possible values for type are CPU, MEMORY, PENDING_REQUEST. Note: The type "MEMORY" is not used to determine the pod congestion state in NRF Ingress Gateway. |
Table 6-30 oc_ingressgateway_incoming_pod_connections_rejected_total
Field | Details |
---|---|
Description |
This metric pegs the number of connections dropped at Congested or DoC state. Note: Prometheus automatically injects pod name with label name "kubernetes_pod_name" to metric. This information is used for alert. |
Type | Counter |
Dimensions | InstanceIdentifier, Direction |
Table 6-31 oc_ingressgateway_incoming_tls_connections
Field | Details |
---|---|
Description | Number of TLS connections received on the Ingress Gateway and their negotiated TLS versions. The versions can be TLSv1.3 or TLSv1.2. |
Type | Gauge |
Dimensions | NegotiatedTLSVersion, Host, Direction, InstanceIdentifier |
Table 6-32 oc_ingressgateway_incoming_ip_type
Field | Details |
---|---|
Description | This is incremented when the IP type of the active incoming connections from the client to Ingress Gateway. |
Type | Gauge |
Dimensions | host, receivedAddressType |
Table 6-33 oc_ingressgateway_outgoing_ip_type
Field | Details |
---|---|
Description | This is incremented when the IP type of the active outgoing connections from Ingress Gateway to the backend services. |
Type | Gauge |
Dimensions | BackendSvc, BackendSvcAddressType |
Table 6-34 oc_ingressgateway_http_request_ratelimit_values_total
Field | Details |
---|---|
Description |
This metric tracks the total count of requests handled by the rate limiting filter, categorized by whether each request was allowed or denied. If there was no route configuration for the dropped message, the id attribute is set to "NA". |
Type | Counter |
Dimension | Id, Allowed, RouteLevelColor |
Table 6-35 oc_ingressgateway_http_request_ratelimit_reject_chain_duration_histogram_seconds
Field | Details |
---|---|
Description | Records the reject chain duration. |
Type | Histogram |
Dimension | NA |
Table 6-36 oc_ingressgateway_http_request_ratelimit_reject_chain_length_histogram
Field | Details |
---|---|
Description | This metric records the number of consecutive requests rejected before a successful acceptance and adds it to the corresponding bucket. This metric provides the number of failed requests due to bursty traffic. |
Type | Histogram |
Dimension | NA |
Table 6-37 oc_ingressgateway_http_request_ratelimit_denied_count_total
Field | Details |
---|---|
Description | Records the details of the denied request.
If there is no denied request action configuration, the ActionId attribute is set to "default". |
Type | Counter |
Dimension | Action, ActionId, CongestionLevel, Priority, ErrorProfile |
Table 6-38 oc_ingressgateway_congestion_cpu_state
Field | Details |
---|---|
Description | Records the CPU levels of the congestion state. |
Type | Gauge |
Dimension | NA |
Table 6-39 oc_ingressgateway_congestion_system_state
Field | Details |
---|---|
Description | Records the system level based on CPU. |
Type | Gauge |
Dimension | NA |
Table 6-40 oc_ingressgateway_system_state_duration_percentage
Field | Details |
---|---|
Description | Records the percentage of time the system was in a particular congestion level. |
Type | Gauge |
Dimension | level |
Table 6-41 oc_ingressgateway_congestion_level_total
Field | Details |
---|---|
Description | Counts the number of times a congestion level was identified. This congestion level value varies between 0-10. |
Type | Counter |
Dimension | NA |
Table 6-42 oc_ingressgateway_congestion_level_bucket_total
Field | Details |
---|---|
Description | Identifies the number of times the congestion level was
observed.
Note: This metric also records any increase
in CPU, which sometimes is not recorded in the
|
Type | Histogram |
Dimension | NA |
Table 6-43 oc_ingressgateway_congestion_cpu_percentage_bucket
Field | Details |
---|---|
Description | Records the CPU percentage. |
Type | Histogram |
Dimension | NA |
Table 6-44 oc_ingressgateway_route_overloadcontrol_discard_total
Field | Details |
---|---|
Description | This metric is pegged when the incoming request is discarded by the Overload load filter on percentage basis. Note: The LoadLevel label identifies the exact overload threshold at which each request is dropped. |
Type | Counter |
Dimension | DiscardAction, ErrorOriginator, InstanceIdentifier, LoadLevel, Method, Scheme, ServiceName, Status |
6.1.1.2 Egress Gateway Metrics
Table 6-45 oc_egressgateway_msgcopy_requests_total
Field | Details |
---|---|
Description | This is incremented whenever request message is sent or acknowledged from Kafka. |
Type | Counter |
Dimensions | type |
Table 6-46 oc_egressgateway_msgcopy_responses_total
Field | Details |
---|---|
Description | This is incremented whenever response message is sent or acknowledged from Kafka. |
Type | Counter |
Dimensions | type |
Table 6-47 oc_egressgateway_dd_unreachable
Field | Details |
---|---|
Description |
This indicates whether DD (kafka) is reachable or not 0 - reachable, 1 - unreachable |
Type | Gauge |
Dimensions | NA |
Table 6-48 oc_egressgateway_http_requests_total
Field | Details |
---|---|
Description | Metric to capture the request count reaches the Egress Gateway from the application microservice and pegs with Direction as egress. Also, when the request goes out of Egress Gateway and pegs with Direction as egressOut. |
Type | Counter |
Dimensions | Method, NFType, NFServiceType, Host, HttpVersion, Scheme, Proxy, InstanceIdentifier, Direction,DestinationHost |
Table 6-49 oc_egressgateway_http_responses_total
Field | Details |
---|---|
Description | Metric to capture when Egress Gateway sends response back to backend NF microservice and pegs with Direction as egress. Also, when the response is received Egress gateway and pegs with Direction as egressOut |
Type | Counter |
Dimensions | Status, Method, NFType, NFServiceType, Host, HttpVersion, Scheme, InstanceIdentifier, Direction, BlacklistedFqdn, DestinationHost, ErrorOriginator, jetty_request_timeout, error-reason |
Table 6-50 oc_egressgateway_connection_failure_total
Field | Details |
---|---|
Description | This metric will be pegged by jetty client when the destination is not reachable by Egress Gateway. Here, the destination is producer NF. |
Type | Counter |
Dimensions | Host, Port, InstanceIdentifier, Direction, error_reason, ErrorOriginator |
Table 6-51 oc_egressgateway_request_processing_latency_seconds
Field | Details |
---|---|
Description | Metric captures the amount of time taken for processing the request only within Egress Gateway |
Type | Histogram |
Dimensions | quantile, InstanceIdentifier, Route_path, Method |
Table 6-52 oc_egressgateway_request_latency_seconds
Field | Details |
---|---|
Description | This metric is pegged in the last custom filter of the Egress Gateway while the response is being sent back to the consumer NF. This metric tracks the amount of time taken for processing the request. It starts as soon the request reaches the first custom filter of the application and lasts till the response is sent back to the consumer NF from the last custom filter of the application. |
Type | Histogram |
Dimensions | quantile, InstanceIdentifier, Route_path, Method |
Table 6-53 oc_egressgateway_request_content_metrics_total
Field | Details |
---|---|
Description | This metric is pegged by default filter RequestContentMetrics. It pegs whether request has request body or not. |
Type | Counter |
Dimensions | method, content_available, InstanceIdentifier |
Table 6-54 oc_egressgateway_incoming_connections
Field | Details |
---|---|
Description | Gauge metric that will peg active incoming connections from client to Egress Gateway. |
Type | Gauge |
Dimensions | Direction, Host, InstanceIdentifier |
Table 6-55 oc_egressgateway_outgoing_connections
Field | Details |
---|---|
Description | Gauge metric that will peg active outgoing connections from Egress Gateway to destination. |
Type | Gauge |
Dimensions | Direction, Host, InstanceIdentifier |
Table 6-56 oc_egressgateway_server_latency_seconds
Field | Details |
---|---|
Description | This metric is pegged in Jetty response listener that captures the amount of time taken for processing of the request by jetty client |
Type | Histogram |
Dimensions | quantile, InstanceIdentifier, Host, Method |
Table 6-57 oc_egressgateway_jetty_request_stat_metrics_total
Field | Details |
---|---|
Description | This metric is pegged for every outgoing request from Egress gateway to the backend at jetty level |
Type | Counter |
Dimensions | DestinationHost, InstanceIdentifier, event |
Table 6-58 oc_egressgateway_jetty_response_stat_metrics_total
Field | Details |
---|---|
Description | This metric is pegged for every event occurred when a response is received by Egress Gateway. |
Type | Counter |
Dimensions | event, client_type, InstanceIdentifier, DestinationHost |
Table 6-59 oc_egressgateway_sni_error_total
Field | Details |
---|---|
Description | Indicates the count of TLS connection failure due to SNI validation failure. |
Type | Counter |
Dimensions | error_reason, sni_status |
Table 6-60 oc_egressgateway_peer_health_status
Field | Details |
---|---|
Description | It defines Egress Gateway peer health status.
|
Type | Gauge |
Dimensions | peer, vfqdn |
Table 6-61 oc_egressgateway_peer_health_ping_request_total
Field | Details |
---|---|
Description | This metric is incremented every time a health ping is sent toward a peer. |
Type | Counter |
Dimensions | peer, vfqdn
Note: If virtual host is configured then vfqdn is pegged along with peer otherwise only peer will be pegged. |
Table 6-62 oc_egressgateway_peer_health_ping_response_total
Field | Details |
---|---|
Description | This metric is incremented every time a health ping response is received from a peer irrespective of success or failure. |
Type | Counter |
Dimensions | peer, vfqdn, status, cause
Note: If virtual host is configured then vfqdn is pegged along with peer otherwise only peer will be pegged. |
Table 6-63 oc_egressgateway_peer_health_status_transitions_total
Field | Details |
---|---|
Description | This metric is incremented every time a peer is transitioned from Available to Unavailable or from Unavailable to Available. |
Type | Counter |
Dimensions | peer, vfqdn, from, to |
Table 6-64 oc_egressgateway_peer_count
Field | Details |
---|---|
Description | This metric is incremented every time for the peer count. |
Type | Gauge |
Dimensions | peerset |
Table 6-65 oc_egressgateway_peer_available_count
Field | Details |
---|---|
Description | This metric is incremented every time for the available peer count. |
Type | Gauge |
Dimensions | peerset |
Table 6-66 oc_egressgateway_outgoing_tls_connections
Field | Details |
---|---|
Description | Number of TLS connections received on the Egress Gateway and their negotiated TLS versions. The versions can be TLSv1.3 or TLSv1.2. |
Type | Gauge |
Dimensions | NegotiatedTLSVersion, Host, Direction, InstanceIdentifier |
Table 6-67 oc_egressgateway_incoming_ip_type
Field | Details |
---|---|
Description | This is incremented when the IP type of the active incoming connections from the NRF microservices to the Egress Gateway. |
Type | Gauge |
Dimensions | host, receivedAddressType |
Table 6-68 oc_egressgateway_outgoing_ip_type
Field | Details |
---|---|
Description | This is incremented when the IP type of the active outgoing connections from Egress Gateway to the destination. |
Type | Gauge |
Dimensions | destinationHost, destinationHostAddressType |
Table 6-69 oc_egressgateway_dualstack_ip_rejected_total
Field | Details |
---|---|
Description | This is incremented by counting the total IP rejections which are caused by a IP mismatch between the IP type configured in the egressRoutingMode and the IP type returned by DNS resolution. |
Type | Gauge |
Dimensions | authority, egressRoutingMode, dnsResolvedType |
Table 6-70 oc_egressgateway_podlevel_throttling_allowed_total
Field | Details |
---|---|
Description |
Indicates the total number of requests processed by Egress Gateway microservice when the Egress Gateway pod throttling feature is enabled. Note: The metric will not be pegged if the Egress Gateway pod throttling feature is disabled. |
Type | Counter |
Dimensions | route_id |
6.1.1.3 Common Gateway Metrics
Table 6-71 oc_configserver_reachability
Field | Details |
---|---|
Description | Gauge metric to peg the reachability of the configuration server |
Type | Gauge |
Dimensions | NA |
Table 6-72 oc_configclient_request_total
Field | Details |
---|---|
Description | This metric is pegged whenever the configuration client is polling for configuration update from common configuration server. |
Type | Counter |
Dimensions | releaseVersion, configVersion |
Table 6-73 oc_configclient_response_total
Field | Details |
---|---|
Description | This metrics is pegged whenever config client receives response from common configuration server. |
Type | Counter |
Dimensions | releaseVersion, configVersion, updated |
Table 6-74 oc_oauth_nrf_request_total
Field | Details |
---|---|
Description | This metric is pegged in the OAuth client implementation if the request is sent to NRF for requesting the OAuth token. OAuth client implementation is used in Egress Gateway. |
Type | Counter |
Dimensions | ConsumerNFInstanceId, ConsumerNFType, TargetNFType, TargetNFInstanceId, scope, NrfFqdn |
Table 6-75 oc_oauth_nrf_response_success_total
Field | Details |
---|---|
Description | This metric is pegged in the OAuth client implementation if an OAuth token is successfully received from the NRF. OAuth client implementation is used in Egress Gateway. |
Type | Counter |
Dimensions | ConsumerNFInstanceId, ConsumerNFType, TargetNFType, TargetNFInstanceId, scope, NrfFqdn,StatusCode |
Table 6-76 oc_oauth_nrf_response_failure_total
Field | Details |
---|---|
Description | This metric is pegged in the OAuthClientFilter in Egress Gateway whenever GetAccessTokenFailedException is caught. |
Type | Counter |
Dimensions | ConsumerNFInstanceId, ConsumerNFType, TargetNFType, TargetNFInstanceId, scope, NrfFqdn, ErrorOriginator, StatusCode |
Table 6-77 oc_oauth_request_failed_internal_total
Field | Details |
---|---|
Description | This metric is pegged in the OAuthClientFilter in Egress Gateway whenever InternalServerErrorException is caught. |
Type | Counter |
Dimensions | ConsumerNFInstanceId, ConsumerNFType, ErrorOriginator, NrfFqdn, StatusCode, TargetNFType, TargetNFInstanceId, scope |
Table 6-78 oc_oauth_token_cache_total
Field | Details |
---|---|
Description | This metric is pegged in the OAuth Client Implementation if the OAuth token is found in the cache. |
Type | Counter |
Dimensions | ConsumerNFInstanceId, ConsumerNFType, TargetNFType, TargetNFInstanceId, scope, NrfFqdn |
Table 6-79 oc_oauth_request_invalid_total
Field | Details |
---|---|
Description | This metric is pegged in the OAuthClientFilter in Egress Gateway whenever a BadAccessTokenRequestException/JsonProcessingException is caught. |
Type | Counter |
Dimensions | ConsumerNFInstanceId, ConsumerNFType, TargetNFType, TargetNFInstanceId, scope, StatusCode, ErrorOriginator, NrfFqdn |
Table 6-80 security_cert_x509_expiration_seconds
Field | Details |
---|---|
Description | Indicates the time to certificate expiry in epoch seconds. |
Type | Histogram |
Dimensions | serialNumber |
6.1.2 Configuring NRF Metrics Dashboard in OCI
This section describes the steps to upload the
ocnrf_oci_metric_dashboard_25.1.200.json
file on OCI Logging Analytics Dashboard.
As OCI doesn't support Grafana, OCI uses the Logging Analytics Dashboard Service for
visualizing the metrics and logs.
- Log in to OCI Console.
Note:
For more details about logging in to the OCI, refer to Signing In to the OCI Console. - Open the navigation menu and click Observability & Management.
- Under Logging Analytics, click Dashboards. The Dashboards page appears.
- Choose the Compartment on the left pane.
- Click Import dashboards.
- User can select and upload the
ocnrf_oci_metric_dashboard_25.1.200.json
file. ##METRIC_NAMESPACE in json file must be customized to metrics namespace that the user provided while deploying OCI adaptor. - Import dashboard page appears. Click Import button on the page.
- Click filter
option in the ocnrf_oci_metric_dashboard page and select the Compartment, Namespace, Log Group Compartment, and Region from the drop-down list.
User can view the imported dashboard and can view the metrics in the dashboard.
Figure 6-1 ocnrf_oci_metric_dashboard
6.1.3 NRF NF Metrics
This section provides details about the NRF metrics.
Table 6-81 ocnrf_nfRegister_rx_requests_total
Field | Details |
---|---|
Description | Number of Registration Requests received. |
Type | Counter |
Dimensions | NrfLevel, NfInstanceId, RequesterNfType, NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-82 ocnrf_nfRegister_tx_responses_total
Field | Details |
---|---|
Description | Number of Registration Responses sent. |
Type | Counter |
Dimensions | NrfLevel, NfInstanceId, RequesterNfType, HttpStatusCode,
NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-83 ocnrf_nfRegister_rx_requests_success_perService_total
Field | Details |
---|---|
Description | Number of Registrations received and processed successfully per Service. |
Type | Counter |
Dimensions | NrfLevel, NfInstanceId, serviceName, serviceInstanceId,
NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Recommended legend to see dimension level data (as applicable) | NfRegistrations Per Service [ serviceName :- {{ serviceName }}, nfInstanceId :- {{NfInstanceId}} ] |
Table 6-84 ocnrf_nfUpdate_rx_requests_total
Field | Details |
---|---|
Description | Number of Update Requests received. |
Type | Counter |
Dimensions | NrfLevel, NfInstanceId, RequesterNfType, Updatetype
(Partial/Complete), NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-85 ocnrf_nfUpdate_tx_responses_total
Field | Details |
---|---|
Description | Number of Update Responses sent. |
Type | Counter |
Dimensions | NrfLevel, NfInstanceId, RequesterNfType, Updatetype
(Partial/Complete), HttpStatusCode, NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-86 ocnrf_nfUpdate_rx_requests_success_perService_total
Field | Details |
---|---|
Description | Number of NfUpdates received and processed successfully per Service. |
Type | Counter |
Dimensions | NrfLevel, Updatetype (Partial/Complete), NfInstanceId,
ServiceName, ServiceInstanceId, NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Recommended legend to see dimension level data (as applicable) | NFUpdates Per Service [serviceName :- {{ serviceName }}, serviceInstanceId:- {{ServiceInstanceId}}] |
Table 6-87 ocnrf_nfHeartbeat_rx_requests_total
Field | Details |
---|---|
Description | Number of Heartbeat Requests received. |
Type | Counter |
Dimensions | NrfLevel, NfInstanceId, RequesterNfType, NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-88 ocnrf_nfHeartBeat_tx_responses_total
Field | Details |
---|---|
Description | Number of Heartbeat Responses sent |
Type | Counter |
Dimensions | Nrflevel, NfInstanceId, RequesterNfType, HttpStatusCode,
NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-89 ocnrf_nfDeregister_rx_requests_total
Field | Details |
---|---|
Description | Number of deregistration requests received. |
Type | Counter |
Dimensions | NrfLevel, NfInstanceId, RequesterNfType, NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-90 ocnrf_nfDeregister_tx_responses_total
Field | Details |
---|---|
Description | Number of deregistration responses sent. |
Type | Counter |
Dimensions | NrfLevel, NfInstanceId, RequesterNfType, HttpStatusCode,
NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-91 ocnrf_nfDeregister_rx_requests_success_perService_total
Field | Details |
---|---|
Description | Number of deregistration requests received and process successfully per service. |
Type | Counter |
Dimensions | NrfLevel, serviceName, serviceInstanceId, NfInstanceId,
NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Recommended legend to see dimension level data (as applicable) | NFDeregistration Per Service [ serviceName :- {{ serviceName }}, serviceInstanceId:- {{ServiceInstanceId}} ] |
Table 6-92 ocnrf_nfListRetrieval_rx_requests_total
Field | Details |
---|---|
Description | Number of NFListRetrieval requests received. |
Type | Counter |
Dimensions | NrfLevel, RequesterNfType, NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-93 ocnrf_nfListRetrieval_tx_responses_total
Field | Details |
---|---|
Description | Number of NFListRetrieval responses sent. |
Type | Counter |
Dimensions | NrfLevel, RequesterNfType, HttpStatusCode, NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-94 ocnrf_nfProfileRetrieval_rx_requests_total
Field | Details |
---|---|
Description | Number of NFProfileRetrieval requests received. |
Type | Counter |
Dimensions | NrfLevel, NfInstanceId, NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-95 ocnrf_nfProfileRetrieval_tx_responses_total
Field | Details |
---|---|
Description | Number of NFProfileRetrieval responses sent. |
Type | Counter |
Dimensions | NrfLevel, NfInstanceId, HttpStatusCode, NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-96 ocnrf_heartbeat_missed_total
Field | Details |
---|---|
Description | Number of heartbeats missed. |
Type | Counter |
Dimensions | NrfLevel, NfType, NfInstanceId, NfFqdn
Note: The NfFqdn dimension contain the FQDN as present in the NfProfile. |
Table 6-97 ocnrf_nfStatusSubscribe_rx_requests_total
Field | Details |
---|---|
Description | Number of NStatusSubscribe requests received. |
Type | Counter |
Dimensions | NrfLevel, RequesterNfType, OperationType, NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-98 ocnrf_nfStatusSubscribe_tx_responses_total
Field | Details |
---|---|
Description | Number of NfStatusSubscribe responses sent.
In case of subscription limit feature, NRF includes and populates new measurements for number of new subscription requests or subscription renewal rejected (due to limit being exceeded) per second. |
Type | Counter |
Dimensions | NrfLevel, RequesterNfType, HttpStatusCode,
OperationType, NfFqdn, RejectionReason
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-99 ocnrf_nfset_active_subscriptions
Field | Details |
---|---|
Description |
Number of global subscription count status. For georedundancy, it reflects the total subscriptions in quad or triplet set. |
Type | Gauge |
Dimensions | NrfLevel |
Table 6-100 ocnrf_nfset_limit_level
Field | Details |
---|---|
Description | Indicates the global subscription limit threshold level. |
Type | Gauge |
Dimensions | NrfLevel |
Table 6-101 ocnrf_subscription_migration_status
Field | Details |
---|---|
Description | Indicates the status of the migration of records in the
NfSubscriptions table.
Value 1 indicates that the migration is in Progress. Value 0 indicates the migration is Complete. |
Type | Gauge |
Dimensions | subscriptionLimitFeatureStatus |
Table 6-102 ocnrf_nfStatusUnsubscribe_rx_requests_total
Field | Details |
---|---|
Description | Number of NfStatusUnsubscribe requests received. |
Type | Counter |
Dimensions | NrfLevel, RequesterNfType, NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-103 ocnrf_nfStatusUnsubscribe_tx_responses_total
Field | Details |
---|---|
Description | Number of NfStatusUnsubscribe responses sent. |
Type | Counter |
Dimensions | NrfLevel, RequesterNfType, HttpStatusCode, NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-104 ocnrf_nfStatusNotify_tx_requests_total
Field | Details |
---|---|
Description | Number of NfStatusNotify requests sent. |
Type | Counter |
Dimensions | NrfLevel, NotificationEventType, TargetNfType, NfFqdn
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-105 ocnrf_nfStatusNotify_rx_responses_total
Field | Details |
---|---|
Description | Number of NfStatusNotify responses received. |
Type | Counter |
Dimensions | NrfLevel, NotificationEventType, NotificationHostPort,
NumberOfRetriesAttempted, TargetNfType, HttpStatusCode, NfFqdn
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-106 ocnrf_nfStatusNotify_requests_failed_total
Field | Details |
---|---|
Description | Number of NfStatusNotify requests failed to sent out. |
Type | Counter |
Dimensions | NrfLevel, NotificationEventType, TargetNfType, NfFqdn
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-107 ocnrf_nfDiscover_rx_requests_total
Field | Details |
---|---|
Description | Number of NfDiscover Requests received. |
Type | Counter |
Dimensions | NrfLevel, TargetNfType, RequesterNfType, NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Recommended legend to see dimension level data (as applicable) | NfDiscover Req [ TargetNf :- {{ TargetNfType }}, RequesterNfType :- {{RequesterNfType}} ] |
Table 6-108 ocnrf_nfDiscover_tx_responses_total
Field | Details |
---|---|
Description | Number of NfDiscover responses sent. |
Type | Counter |
Dimensions | NrfLevel, TargetNfType, RequesterNfType, HttpStatusCode,
NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-109 ocnrf_nfDiscover_rx_requests_success_perService_total
Field | Details |
---|---|
Description | Number of NfDiscover requests received and processed successfully per Service. |
Type | Counter |
Dimensions | NrfLevel, RequesterNfType, serviceName, NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Recommended legend to see dimension level data (as applicable) | NFDiscover Per Service [ serviceName :- {{ serviceName }} ] |
Table 6-110 ocnrf_nfDiscover_profiles_discovered_total
Field | Details |
---|---|
Description | Number of Profiles returned in discovery response. Depending on bucket size and corresponding value will tell how many profiles are returned in discovery response. |
Type | Counter |
Dimensions | NrfLevel, TargetNfType, Bucket, NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Recommended legend to see dimension level data (as applicable) | Discovered profiles [ TargetNfType :- {{TargetNfType}}, Bucket :- {{ Bucket }} ] |
Table 6-111 ocnrf_active_registrations_count
Field | Details |
---|---|
Description | Number of active NFs that are registered at the local site at any point of time. |
Type | Counter |
Dimensions | RequesterNfType, NrfLevel |
Recommended legend to see dimension level data (as applicable) | Active Registrations [ NfType-{{ NfType }}, NrfLevel-{{ NrfLevel }} ] |
Table 6-112 ocnrf_message_processing_time_seconds
Field | Details |
---|---|
Description | Time taken by NRF specific microservice to process the service operation (NfRegister/NfUpdate-Partial/NfUpdate-Complete/NfDeregister/NfProfileRetrieval/NfListRetrieval/NfHeartBeat/NfDiscover/NFStatusSubscribe/NFStatusUnSubscribe/NfAccessToken) Note: Latency calculated by this metric does not include time taken by NRF API gateway. |
Type | Histogram |
Dimensions | NrfLevel, NfFqdn, RequesterNfType, ServiceOperation
Note: The NfFqdnss dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Recommended legend to see dimension level data (as applicable) | Avg NRF Latency {{ ServiceOperation }} {{ RequesterNfType }} |
Table 6-113 ocnrf_dbmetrics_total
Field | Details |
---|---|
Description | Database operation count corresponding to every service operation. |
Type | Counter |
Dimensions | method, dbOperation, NrfLevel, HttpStatusCode |
Table 6-114 ocnrf_dbmetrics_round_trip_time_seconds
Field | Details |
---|---|
Description |
Time (in microseconds) taken by database operation corresponding to every service operation (NfRegister/NfUpdate/NfDeregister/NfProfileRetrieval/NfListRetrieval/NfHeartBeat/NfDiscover/NfSubscribe/NfUnsubscribe/NfStatusNotify/NfAccessToken/NrfConfiguration/InternalConfigurationCache) |
Type | Histogram |
Dimensions | method, dbOperation, serviceOperation, tableName: (NRF Table Names), NrfLevel, HttpStatusCode |
Table 6-115 ocnrf_nf_suspended_total
Field | Details |
---|---|
Description | The number of profiles that have been marked as SUSPENDED when a profile has missed nfHeartBeatMissAllowed. |
Type | Counter |
Dimensions | NrfLevel, NfInstanceId,NfStatus, HeartbeatTimer,
NfFqdn
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-116 ocnrf_nfSubscriptions_expired_total
Field | Details |
---|---|
Description | The number of NfSubscriptions whose validityTime has expired. |
Type | Counter |
Dimensions | NrfLevel |
Table 6-117 ocnrf_nfDiscover_emptyList_total
Field | Details |
---|---|
Description |
This metric is pegged:
|
Type | Counter |
Dimensions | NfType, FeatureStatus |
Table 6-118 ocnrf_operational_state
Field | Details |
---|---|
Description | This metric is pegged when the operational state of
NRF
switches between NORMAL and COMPLETE_SHUTDOWN.
|
Type | Gauge |
Dimensions | NrfLevel |
Table 6-119 ocnrf_audit_status
Field | Details |
---|---|
Description | This metric indicates whether the NRF Audit is
in-progress or in paused state. The status of the audit procedures at
.
Note:
NrfAuditor will continue to remain in the paused state for some
time, even after
|
Type | Gauge |
Dimensions | NrfLevel |
Table 6-120 ocnrf_nfDiscover_limiting_profile_count_for_nfSet_total
Field | Details |
---|---|
Description | This metric will be pegged when the "Limiting the Number
of Producers Based on NF Set Ids and Extended Preferred Locality"
features are enabled and the number of NF profiles sent in the discovery
response is less than the
profileCountInDiscoveryResponse
configuration.
|
Type | Counter |
Dimensions | TargetNfType, RequesterNfType, NrfLevel |
Table 6-121 ocnrf_nfDiscover_limiting_profiles_not_applied_for_nfSet_total
Field | Details |
---|---|
Description | This metric will be pegged when "Limiting the Number of
Producers Based on NF Set Ids" feature could not be applied due to the
unavailability of nfSetIdList in any one of the NF
profiles selected with the first matching location(s) from
targetPreferredLocations configuration in
extendedPreferredLocality .
|
Type | Counter |
Dimensions | TargetNfType, RequesterNfType, NrfLevel |
Table 6-122 ocnrf_nfDiscover_tx_response_size_bytes
Field | Details |
---|---|
Description |
The size of the NfDiscover response. The size is pegged in bytes and is published in buckets of 1KB, 3KB, 7KB, 10KB, 15KB, 20KB, 30KB, 40KB, 50KB, 60KB, 70KB, and 80KB. |
Type | Histogram |
Dimensions | TargetNfType |
Table 6-123 ocnrf_nf_profile_size
Field | Details |
---|---|
Description |
The size of the registered NfProfiles. Note:The size of the metric is calculated as per the payload received during registration or update of the profile. To calculate the size of the payload, save the payload in a text file without spaces, and verify the size of the file using Linux tools like wc. |
Type | Gauge |
Dimensions | NfInstanceId, NfType |
Table 6-124 ocnrf_nfProfile_size_limit_breached
Field | Details |
---|---|
Description |
Indicates the number of NF profiles that get rejected due to profile size limit during registration or update service operations. |
Type | Counter |
Dimensions | NfInstanceId, NfType, ServiceOperation |
6.1.4 NF Screening Metrics
This section provides details about the NF screening metrics.
Table 6-125 ocnrf_nfScreening_nfFqdn_requestFailed_total
Field | Details |
---|---|
Description | The total number of requests for which screening failed against NF FQDN screening list. |
Type | Counter |
Service Operation | NFRegister, NFUpdate |
Dimensions | NrfLevel, RequesterNfType, NfFqdn
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-126 ocnrf_nfScreening_nfFqdn_requestRejected_total
Field | Details |
---|---|
Description | The total number of requests rejected for which screening failed against NF FQDN screening list. |
Type | Counter |
Service Operation | NFRegister, NFUpdate |
Dimensions | NrfLevel, RequesterNfType, NfFqdn
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-127 ocnrf_nfScreening_nfIpEndPoint_requestFailed_total
Field | Details |
---|---|
Description | The total number of requests for which screening failed against NF IP endpoint screening list. |
Type | Counter |
Service Operation | NFRegister, NFUpdate |
Dimensions | NrfLevel, RequesterNfType, NfFqdn |
Table 6-128 ocnrf_nfScreening_nfIpEndPoint_requestRejected_total
Field | Details |
---|---|
Description | The total number of requests rejected because screening failed against NF IP endpoint screening list. |
Type | Counter |
Service Operation | NFRegister, NFUpdate |
Dimensions | NrfLevel, RequesterNfType, NfFqdn
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-129 ocnrf_nfScreening_callbackUri_requestFailed_total
Field | Details |
---|---|
Description | The total number of requests for which screening failed against Callback URI screening list. |
Type | Counter |
Service Operation | NFRegister, NFUpdate, NFStatusSubscribe |
Dimensions | NrfLevel, RequesterNfType, NfFqdn
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-130 ocnrf_nfScreening_callbackUri_requestRejected_total
Field | Details |
---|---|
Description | The total number of requests rejected because screening failed against Callback URI screening list. |
Type | Counter |
Service Operation | NFRegister, NFUpdate, NFStatusSubscribe |
Dimensions | NrfLevel, RequesterNfType, NfFqdn
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-131 ocnrf_nfScreening_plmnId_requestFailed_total
Field | Details |
---|---|
Description | The total number of requests for which screening failed against PLMN id screening list. |
Type | Counter |
Service Operation | NFRegister, NFUpdate |
Dimensions | NrfLevel, RequesterNfType, NfFqdn
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-132 ocnrf_nfScreening_nfFqdn_requestRejected_total
Field | Details |
---|---|
Description | The total number of requests rejected because screening failed against PLMN id screening list. |
Type | Counter |
Service Operation | NFRegister, NFUpdate |
Dimensions | NrfLevel, RequesterNfType, NfFqdn
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-133 ocnrf_nfScreening_nfTypeRegister_requestFailed_total
Field | Details |
---|---|
Description | The total number of NFRegister requests rejected as NF type was not allowed to register with NRF. |
Type | Counter |
Service Operation | NFRegister |
Dimensions | NrfLevel, RequesterNfType, NfFqdn
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-134 ocnrf_nfScreening_nfTypeRegister_requestRejected_total
Field | Details |
---|---|
Description | The total number of NFRegister requests for which screening failed against NF type screening list. |
Type | Counter |
Service Operation | NFRegister |
Dimensions | NrfLevel, RequesterNfType, NfFqdn
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-135 ocnrf_nfScreening_notApplied_InternalError_total
Field | Details |
---|---|
Description | The total number of times screening not applied due to internal error. |
Type | Counter |
Service Operation | NFRegister, NFUpdate, NFStatusSubscribe |
Dimensions | NrfLevel, RequesterNfType, NfFqdn
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
6.1.5 NF Access token Metrics
This section provides details about the NF access token metrics.
Table 6-136 ocnrf_accessToken_rx_requests_total
Field | Details |
---|---|
Description | The total number of access token requests received. |
Type | Counter |
Service Operation | AccessToken |
Dimensions | TargetNfType, ClientNfType, TargetNfInstanceId,
ClientNfInstanceId, ServiceName, NrfLevel, NfFqdn
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-137 ocnrf_accessToken_tx_responses_total
Field | Details |
---|---|
Description | The total number of access token responses sent. |
Type | Counter |
Service Operation | AccessToken |
Dimensions |
TargetNfType, RequesterNfType, TargetNfInstanceId, ClientNfInstanceId, Scope, NrfLevel, HttpStatusCode, NfFqdn, KeyId, RejectionReason Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
6.1.6 NRF Configuration Metrics
This section provides details about the NRF configuration metrics.
Table 6-138 ocnrf_oauth_keyData_healthStatus
Field | Details |
---|---|
Description | Oauth Token Signing keys health status
Value 0 - Healthy Value 1 - Unhealthy |
Type | Gauge |
Service Operation | Configuration |
Dimensions | KeyId, KeyType, isCurrentKeyId, NrfLevel |
Table 6-139 ocnrf_oauth_currentKeyId_configuredStatus
Field | Details |
---|---|
Description | Oauth Current Key Id Configuration Status
Value 0 - Healthy Value 1 - Unhealthy |
Type | Gauge |
Service Operation | Configuration |
Dimensions | NrfLevel |
Table 6-140 ocnrf_oauth_keyData_expiryStatus
Field | Details |
---|---|
Description |
Oauth Token Signing keys Expiry Status (Value is expiry time in epoch time) |
Type | Gauge |
Service Operation | Configuration |
Dimensions | KeyId, isCurrentKeyId, NrfLevel |
6.1.7 NRF SLF Metrics
This section provides details about the NRF SLF metrics.
Table 6-141 ocnrf_nfDiscover_forSLF_rx_requests_total
Field | Details |
---|---|
Description | The total number of NF Discover request received for SLF. |
Type | Counter |
Service Operation | NFDiscover |
Dimensions | TargetNfType, NrfLevel, NfFqdn
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-142 ocnrf_nfDiscover_forSLF_tx_responses_total
Field | Details |
---|---|
Metric Name | ocnrf_nfDiscover_forSLF_tx_responses_total |
Description | The total number of NF Discover responses sent for SLF. |
Type | Counter |
Service Operation | NFDiscover |
Dimensions | TargetNfType, NrfLevel, HttpStatusCode, ResponseReason,
NfFqdn
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-143 ocnrf_SLF_tx_requests_total
Field | Details |
---|---|
Description | The total number of SLF query request sent. |
Type | Counter |
Service Operation | NFDiscover |
Dimensions | TargetNfType, NrfLevel, SubscriptionIdType, NfFqdn,
slfFqdn
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-144 ocnrf_SLF_rx_responses_total
Field | Details |
---|---|
Description | The total number of SLF query response received. |
Type | Counter |
Service Operation | NFDiscover |
Dimensions | TargetNfType, NrfLevel, SubscriptionIdType,
HttpStatusCode, GroupId, NfFqdn, slfFqdn
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-145 ocnrf_nfDiscover_SLFlookup_skipped_total
Field | Details |
---|---|
Description | The total number of NF Discover requests received for SLF but SLF lookup is skipped. |
Type | Counter |
Service Operation | NFDiscover |
Dimensions | TargetNfType, NrfLevel, NfFqdn, SkipSLFLookupParameter,
SkipSLFLookupValue
Note:
|
Table 6-146 ocnrf_nfDiscover_continue_mandatoryAttributes_missing_total
Field | Details |
---|---|
Description | The total number of NF Discover requests processed while SLF is enabled but SLF mandatory attributes are missing in Search query. |
Type | Counter |
Service Operation | NFDiscover |
Dimensions | TargetNfType, NrfLevel, NfFqdn, ExceptionAttribute
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-147 ocnrf_max_slf_attempts_exhausted_total
Field | Details |
---|---|
Description | The maximum number of SLF attempts to the hosts present
in the SLF configuration.
This metric is pegged when
either of the following reasons:
|
Type | Counter |
Service Operation | NFDiscover |
Dimensions | TargetNfType, NfFqdn
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-148 ocnrf_slf_jetty_latency_seconds
Field | Details |
---|---|
Description | Time (in microseconds) after sending query to SLF and getting response from SLF. |
Type | Histogram |
Service Operation | NFDiscover |
Dimensions | Host, InstanceIdentifier, Method, NrfLevel, ServiceOperation |
Table 6-149 ocnrf_SLF_reroutes_total
Field | Details |
---|---|
Description | The total number of SLF query which is rerouted to alternate SLFs. |
Type | Counter |
Service Operation | NFDiscover |
Dimensions | RequesterNfType, TargetNfType, TargetSLFFqdn, and PreviousSLFFqdn |
6.1.8 NRF Forwarding Metrics
This section provides details about the NRF forwarding metrics.
Table 6-150 ocnrf_forward_accessToken_tx_requests_total
Field | Details |
---|---|
Description | The total number of Access Token Request forwarded to Primary or Secondary NRF. |
Type | Counter |
Service Operation | AccessToken |
Dimensions | TargetNfType, RequesterNfType, TargetNfInstanceId,
ClientNfInstanceId, Scope, NrfLevel, NfFqdn
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-151 ocnrf_forward_accessToken_rx_responses_total
Field | Details |
---|---|
Description | The total number of Access Token Responses for request forwarded to Primary/Secondary NRF |
Type | Counter |
Service Operation | AccessToken |
Dimensions | TargetNfType,RequesterNfType, TargetNfInstanceId,
ClientNfInstanceId, Scope, NrfLevel, HttpStatusCode, RejectionReason,
NfFqdn
Note: The NfFqdn dimension indicates the FQDN of the consumer NF. This dimension will contain the FQDN if the service mesh sends the FQDN of the consumer NF in the XFCC header, else the dimension contains the value as UNKNOWN.Rejection reason with meaning
|
Table 6-152 ocnrf_forward_nfProfileRetrieval_tx_requests_total
Field | Details |
---|---|
Description | The total number of Profile Retrieval Request forwarded to Primary/Secondary NRF. |
Type | Counter |
Service Operation | NFProfileRetrieval |
Dimensions | NrfLevel, NfInstanceId, NfFqdn
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-153 ocnrf_forward_nfProfileRetrieval_rx_responses_total
Field | Details |
---|---|
Description | The total number of Profile Retrieval Responses for Request forwarded to Primary/Secondary NRF. |
Type | Counter |
Service Operation | NFProfileRetrieval |
Dimensions | NrfLevel, NfInstanceId, HttpStatusCode, RejectionReason,
NfFqdn
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-154 ocnrf_forward_nfStatusSubscribe_tx_requests_total
Field | Details |
---|---|
Description | The total number of Status Subscribe Request forwarded to Primary/Secondary NRF. |
Type | Counter |
Service Operation | NFStatusSubscribe, NFStatusUnsubscribe |
Dimensions | NrfLevel, RequesterNfType, OperationType, NfFqdn
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-155 ocnrf_forward_nfStatusSubscribe_rx_responses_total
Field | Details |
---|---|
Description | The total number of Responses for Status Subscribe Request forwarded to Primary/Secondary NRF. |
Type | Counter |
Service Operation | NFStatusSubscribe, NFStatusUnsubscribe |
Dimensions | NrfLevel, RequesterNfType, HttpStatusCode,
OperationType, RejectionReason, NfFqdn
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-156 ocnrf_forward_nfDiscover_tx_requests_total
Field | Details |
---|---|
Description | The total number of NF Discovery Request forwarded to Primary/Secondary NRF. |
Type | Counter |
Service Operation | NFDiscover |
Dimensions | NrfLevel, TargetNfType, RequesterNfType, NfFqdn
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-157 ocnrf_forward_nfDiscover_rx_responses_total
Field | Details |
---|---|
Description | The total number of Responses for NF Discovery Request forwarded to Primary/Secondary NRF. |
Type | Counter |
Service Operation | NFDiscover |
Dimensions | NrfLevel, TargetNfType, RequesterNfType, HttpStatusCode,
RejectionReason, NfFqdn
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-158 ocnrf_forward_round_trip_time_seconds
Field | Details |
---|---|
Description | Time taken by NRF specific microservice to forward the message to other Primary or Secondary NRF with the service operation: NFProfileRetrieval/NFStatusSubscribe/NfStatusUnsubscribe/AccessToken |
Type | Histogram |
Service Operation | NFStatusSubscribe, NFStatusUnsubscribe, NFProfileRetrieval, AccessToken |
Dimensions | NrfLevel, RequesterNfType, serviceOperation, NfFqdn
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-159 ocnrf_forward_nfDiscover_barred_total
Field | Details |
---|---|
Description | The total number of discovery requests barred from getting forwarded to another NRF. |
Type | Counter |
Service Operation | NFDiscover |
Dimensions | NrfLevel, TargetNfType, RequesterNfType, NfFqdn,
ForwardingBarringReason
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-160 ocnrf_forward_accessToken_barred_total
Field | Details |
---|---|
Description | The total number of access token requests barred from getting forwarded to another NRF. |
Type | Counter |
Service Operation | AccessToken |
Dimensions | TargetNfType, RequesterNfType, TargetNfInstanceId,
ClientNfInstanceId, Scope, NrfLevel, NfFqdn, ForwardingBarringReason
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-161 ocnrf_forward_nfStatusSubscribe_barred_total
Field | Details |
---|---|
Description | The total number of status subscribe requests barred from getting forwarded to another NRF. |
Type | Counter |
Service Operation | NFStatusSubscribe, NFStatusUnsubscribe |
Dimensions | NrfLevel, RequesterNfType, OperationType, NfFqdn
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-162 ocnrf_forward_profileRetrieval_barred_total
Field | Details |
---|---|
Description | The total number of profile retrieval requests barred from getting forwarded to another NRF. |
Type | Counter |
Service Operation | NFProfileRetrieval |
Dimensions | NrfLevel, NfInstanceId, NfFqdn
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-163 ocnrf_forward_jetty_latency_seconds
Field | Details |
---|---|
Description | Time (in microseconds) after sending query to SLF and getting response from SLF. |
Type | Histogram |
Service Operation | NFDiscover |
Dimensions | Host, InstanceIdentifier, Method, NrfLevel, ServiceOperation |
6.1.9 Roaming Support Metrics
This section provides details about the NRF roaming metrics.
Table 6-164 ocnrf_roaming_nfStatusSubscribe_rx_requests_total
Field | Details |
---|---|
Description | Number of inter-PLMN subscription creation requests received by NRF from NF Consumers (in case of vNRF) and hSEPP (in case of hNRF). |
Type | Counter |
Service Operation | NFStatusSubscribe |
Dimensions | NrfLevel, RequesterPLMNId, TargetPLMNId, NfFqdn,
NRFRole, OperationType
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-165 ocnrf_roaming_nfStatusSubscribe_tx_responses_total
Field | Details |
---|---|
Description | Number of inter-PLMN subscription creation responses sent by NRF. |
Type | Counter |
Service Operation | NFStatusSubscribe |
Dimensions | NrfLevel, RequesterPLMNId, TargetPLMNId, NfFqdn,
NRFRole, OperationType, HttpStatusCode, RejectionReason
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-166 ocnrf_roaming_nfStatusSubscribe_tx_requests_total
Field | Details |
---|---|
Description | Number of inter-PLMN subscription creation requests sent by vNRF towards hNRF. |
Type | Counter |
Service Operation | NFStatusSubscribe |
Dimensions | NrfLevel, RequesterPLMNId, TargetPLMNId, NfFqdn,
OperationType
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-167 ocnrf_roaming_nfStatusSubscribe_rx_responses_total
Field | Details |
---|---|
Description | Number of inter-PLMN subscription creation response received by vNRF from hNRF for routed or forwarded requests. |
Type | Counter |
Service Operation | NFStatusSubscribe |
Dimensions | NrfLevel, RequesterPLMNId, TargetPLMNId, NfFqdn,
OperationType, HttpStatusCode, FailureReason
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-168 ocnrf_roaming_nfStatusSubscribe_rx_requests_total
Field | Details |
---|---|
Description | Number of inter-PLMN subscription update requests received by NRF from NF Consumers (in case of vNRF) and hSEPP (in case of hNRF). |
Type | Counter |
Service Operation | NFStatusSubscribe - Update |
Dimensions | NrfLevel, NfFqdn, NRFRole, OperationType
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-169 ocnrf_roaming_nfStatusSubscribe_tx_responses_total
Field | Details |
---|---|
Description | Number of inter-PLMN subscription update responses sent by NRF. |
Type | Counter |
Service Operation | NFStatusSubscribe - Update |
Dimensions | NrfLevel, NfFqdn, NRFRole, OperationType,
HttpStatusCode, RejectionReason
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-170 ocnrf_roaming_nfStatusSubscribe_tx_requests_total
Field | Details |
---|---|
Description | Number of inter-PLMN subscription update requests routed or forwarded by vNRF towards hNRF. |
Type | Counter |
Service Operation | NFStatusSubscribe - Update |
Dimensions | NrfLevel, NfFqdn, OperationType
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-171 ocnrf_roaming_nfStatusSubscribe_rx_responses_total
Field | Details |
---|---|
Description | Number of inter-PLMN subscription update response received by vNRF from hNRF for routed/forwarded requests. |
Type | Counter |
Service Operation | NFStatusSubscribe - Update |
Dimensions | NrfLevel, NfFqdn, OperationType, HttpStatusCode,
FailureReason
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-172 ocnrf_roaming_nfStatusUnSubscribe_rx_requests_total
Field | Details |
---|---|
Description | Number of inter-PLMN subscription unsubscribe requests received by NRF from NF Consumers (in case of vNRF) and hSEPP (in case of hNRF). |
Type | Counter |
Service Operation | NFStatusUnSubscribe |
Dimensions | NrfLevel, NfFqdn, NRFRole
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-173 ocnrf_roaming_nfStatusUnSubscribe_tx_responses_total
Field | Details |
---|---|
Description | Number of inter-PLMN subscription unsubscribe responses sent by NRF. |
Type | Counter |
Service Operation | NF Status UnSubscribe |
Dimensions | NrfLevel, NfFqdn, NRFRole, HttpStatusCode,
RejectionReason
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-174 ocnrf_roaming_nfStatusUnSubscribe_tx_requests_total
Field | Details |
---|---|
Description | Number of inter-PLMN subscription unsubscribe requests routed or forwarded by vNRF towards hNRF. |
Type | Counter |
Service Operation | NFStatusUnSubscribe |
Dimensions | NrfLevel, NfFqdn
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-175 ocnrf_roaming_nfStatusUnSubscribe_rx_responses_total
Field | Details |
---|---|
Description | Number of inter-PLMN subscription unsubscribe response received by vNRF from hNRF for routed or forwarded requests. |
Type | Counter |
Service Operation | NFStatusUnSubscribe |
Dimensions | NrfLevel, NfFqdn, HttpStatusCode, FailureReason
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-176 ocnrf_roaming_nfDiscover_rx_requests_total
Field | Details |
---|---|
Description | Number of inter-PLMN NFDiscover requests received by NRF from NF Consumers (in case of vNRF) and hSEPP (in case of hNRF). |
Type | Counter |
Service Operation | NFDiscover |
Dimensions | NrfLevel, RequesterPLMNId, TargetPLMNId, NfFqdn,
NRFRole
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-177 ocnrf_roaming_nfDiscover_tx_responses_total
Field | Details |
---|---|
Description | Number of inter-PLMN NFDiscover response sent by NRF. |
Type | Counter |
Service Operation | NFDiscover |
Dimensions | NrfLevel, RequesterPLMNId, TargetPLMNId, NfFqdn,
NRFRole, HttpStatusCode, RejectionReason
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-178 ocnrf_roaming_nfDiscover_tx_requests_total
Field | Details |
---|---|
Description | Number of inter-PLMN NF Discover request routed or forwarded by vNRF towards hNRF |
Type | Counter |
Service Operation | NFDiscover |
Dimensions | NrfLevel, RequesterPLMNId, TargetPLMNId, NfFqdn
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-179 ocnrf_roaming_nfDiscover_rx_responses_total
Field | Details |
---|---|
Description | Number of inter-PLMN NFDiscover response received by vNRF from hNRF for routed or forwarded requests. |
Type | Counter |
Service Operation | NFDiscover |
Dimensions | NrfLevel, RequesterPLMNId, TargetPLMNId, NfFqdn,
HttpStatusCode, FailureReason
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-180 ocnrf_roaming_accessToken_rx_requests_total
Field | Details |
---|---|
Description | Number of inter-PLMN Access Token requests received by NRF from NF Consumers (in case of vNRF) and hSEPP (in case of hNRF). |
Type | Counter |
Service Operation | AccessToken |
Dimensions | NrfLevel, RequesterPLMNId, TargetPLMNId, NfFqdn,
NRFRole
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-181 ocnrf_roaming_accessToken_tx_responses_total
Field | Details |
---|---|
Description | Number of inter-PLMN Access Token response sent by NRF |
Type | Counter |
Service Operation | AccessToken |
Dimensions | NrfLevel, RequesterPLMNId, TargetPLMNId, NfFqdn,
NRFRole, HttpStatusCode, RejectionReason
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-182 ocnrf_roaming_accessToken_tx_requests_total
Field | Details |
---|---|
Description | Number of inter-PLMN Access Token request routed or forwarded by vNRF towards hNRF. |
Type | Counter |
Service Operation | AccessToken |
Dimensions | NrfLevel, RequesterPLMNId, TargetPLMNId, NfFqdn
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-183 ocnrf_roaming_accessToken_rx_responses_total
Field | Details |
---|---|
Description | Number of inter-PLMN Access Token response received by vNRF from hNRF for routed or forwarded requests. |
Type | Counter |
Service Operation | AccessToken |
Dimensions | NrfLevel, RequesterPLMNId, TargetPLMNId, NfFqdn,
HttpStatusCode, FailureReason
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-184 ocnrf_roaming_nfStatusNotify_tx_requests_total
Field | Details |
---|---|
Description | Number of NFStatusNotify requests sent for inter_PLMN cases |
Type | Counter |
Service Operation | NFNotify |
Dimensions | NrfLevel, NotificationEventType, TargetNfType, NfFqdn,
SubscriptionId, SubscriberPLMNId
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-185 ocnrf_roaming_nfStatusNotify_rx_responses_total
Field | Details |
---|---|
Description | Number of NFStatusNotify responses received for inter_PLMN cases. |
Type | Counter |
Service Operation | NFNotify |
Dimensions | NrfLevel, NotificationEventType, TargetNfType, NfFqdn,
HttpStatusCode, SubscriptionId, SubscriberPLMNId
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-186 ocnrf_roaming_round_trip_time_seconds
Field | Details |
---|---|
Description | Average Latency between messages sent by visited NRF towards home NRF and after receiving response from home NRF for NRF Roaming messages. |
Type | Counter |
Service Operation | NFStatusSubscribe, NFStatusUnSubscribe, NfAccessToken |
Dimensions | NrfLevel, RequesterPLMNId, TargetPLMNId,
ServiceOperation, NfFqdn
Note: The NfFQDN dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-187 ocnrf_roaming_jetty_latency_seconds
Field | Details |
---|---|
Description | Time (in microseconds) after sending query to SLF and getting response from SLF. |
Type | Histogram |
Service Operation | NFDiscover |
Dimensions | Host, InstanceIdentifier, Method, NrfLevel, ServiceOperation |
6.1.10 Georedundancy Metrics
This section provides details about the georedundancy metrics.
Table 6-188 ocnrf_dbreplication_status
Field | Details |
---|---|
Description | The current status of the replication channel between
the given site and the remote site(s). This metric is pegged only if the
georedundancy feature is enabled.
Value 0 - UP Value 1 - DOWN |
Type | Gauge |
Service Operation | NA |
Dimensions | NrfLevel, RemoteSiteName, RemoteNrfInstanceId |
Table 6-189 ocnrf_dbreplication_down_time_seconds
Field | Details |
---|---|
Description | Time taken for the replication status to change from "INACTIVE" to "ACTIVE". This metric is pegged only if the georedundancy feature is enabled. |
Type | Histogram |
Service Operation | NA |
Dimensions | NrfLevel, DbReplicationDownStartTime, DbReplicationDownEndTime, RemoteSiteName, RemoteNrfInstanceId |
Table 6-190 ocnrf_nf_switch_over_total
Field | Details |
---|---|
Description | The number of NFInstances that got switched over from the mated site. |
Type | Counter |
Service Operation | NfRegister, NfUpdate,NfDeregister, NfHeartbeat |
Dimensions | NrfLevel, NfInstanceId, RemoteNrfInstanceId,
Service_Operation,OperationType, NfFqdn
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-191 ocnrf_nfSubscriptions_switch_over_total
Field | Details |
---|---|
Description | The number of NfSubscriptions that got switched over from the mated site. |
Type | Counter |
Service Operation | NfStatusSubscribe, NfStatusUnsubscribe, NrfAuditor |
Dimensions | NrfLevel, RemoteNrfInstanceId, serviceOperation, OperationType |
Table 6-192 ocnrf_stale_nf_deleted_total
Field | Details |
---|---|
Description | The number of NfInstances that get deleted by the NrfAuditor when it detects a record to be stale. |
Type | Counter |
Service Operation | NA |
Dimensions | NrfLevel, NfInstanceId, NfStatus, NfFqdn
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-193 ocnrf_stale_nfSubscriptions_deleted_total
Field | Details |
---|---|
Description | The number of NfSubscriptions that get deleted by the NrfAuditor when it detects a record to be stale. |
Type | Counter |
Service Operation | NA |
Dimensions | NrfLevel, SubscriptionStatus |
Table 6-194 ocnrf_reported_dbreplication_status
Field | Details |
---|---|
Description | The current status of the replication channel between
the given site and a remote site(s) as reported by the DB Monitor
Service. This metric shall be pegged only if the georedundancy feature
is enabled.
Value 0 - UP Value 1 - DOWN |
Type | Gauge |
Service Operation | NA |
Dimensions | NrfLevel, nrfInstanceId,SiteName |
Table 6-195 ocnrf_replication_status_check_total
Field | Details |
---|---|
Description | If the metric value remains constant over a period of time, an alert is raised. |
Type | Counter |
Service Operation | NA |
Dimensions | NrfLevel |
Table 6-196 ocnrf_replication_status_check_total
Field | Details |
---|---|
Description |
This metric measures whether replication status monitoring thread is running in the following NRF microservices:
This metric is pegged before the replication status monitoring
performs the replication check as per the interval configured in
|
Type | Counter |
Service Operation | NA |
Dimensions | NrfLevel |
6.1.11 NF Authentication Metrics
This section provides details about the network function authentication metrics.
Table 6-197 ocnrf_nf_authentication_failure_total
Field | Details |
---|---|
Description | The total number of request for which FQDN based authentication failed at OCNRF. |
Type | Counter |
Service Operation |
NFAccessToken/NFRegistration/NFSubscription/NFDiscovery/NfListRetrieval/NfProfileRetrieval
For NfListRetrieval and NfProfileRetrieval serviceOperations NfFqdn is filled as NotApplicable. If OC-XFCC-DNS header is not received at NRF microservice then TLSFqdn is filled as "UNKNOWN". |
Dimensions | NrfLevel, Method, ServiceOperation, NfFqdn,
TLSFqdn
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
6.1.12 NF Instance and NF Services Status Change Metrics
This section provides details about the NF Instance and NF Services Status Change metrics.
Table 6-198 ocnrf_nfInstance_status_change_total
Field | Details |
---|---|
Description |
This metric indicates the total number of times the NfStatus changed for a given NfInstance. For each NfStatus change this metric will be pegged with a combination of NfInstanceId, PreviousStatus, and NewStatus (with other dimensions). For example, NfInstanceId-1 changed its NfStatus from SUSPENDED to REGISTERED, then the metric will be pegged with a combination of NfInstanceId-1, PreviousStatus as SUSPENDED, and NewStatus as REGISTERED.
Similarly, NfInstanceId-1 changed its NfStatus from REGISTERED to UNDISCOVERABLE, then the metric will be pegged with a combination of NfInstanceId-1, PreviousStatus as REGISTERED, and NewStatus as UNDISCOVERABLE. |
Type | Counter |
Service Operation | NfRegister, NfUpdate, NfDeregister |
Dimensions | NrfLevel, NfInstanceId, NfProfileFqdn, NfType, PreviousStatus, NewStatus |
Table 6-199 ocnrf_nfService_status_change_total
Field | Details |
---|---|
Description |
This metric indicates the total number of times the NfServiceStatus changed for a given NfServiceInstance of a NfProfile. For each NfServiceStatus change this metric will be pegged with a combination of NfInstanceId, NfServiceInstanceId, PreviousStatus, and NewStatus (with other dimensions). For example, NfInstanceId-1's NfServiceInstanceId-1 changed its NfServiceStatus from SUSPENDED to REGISTERED, then the metric will be pegged with a combination of NfInstanceId-1, NfServiceInstanceId-1, PreviousStatus as SUSPENDED, and NewStatus as REGISTERED.
Similarly, NfInstanceId-1's NfServiceInstanceId-1 changed its NfServiceStatus from REGISTERED to UNDISCOVERABLE, then the metric will be pegged with a combination of NfInstanceId-1, NfServiceInstanceId-1, PreviousStatus as REGISTERED, and NewStatus as UNDISCOVERABLE. |
Type | Counter |
Service Operation | NfRegister, NfUpdate, NfDeregister |
Dimensions | NrfLevel, NfInstanceId, NfServiceName, NfServiceInstanceId, NfProfileFqdn, NfServiceFqdn, PreviousStatus, NewStatus |
6.1.13 DNS NAPTR Update Metrics
This section provides details about the DNS NAPTR update metrics.
NRF Microservices Metrics
Table 6-200 ocnrf_dns_naptr_tx_requests_total
Field | Details |
---|---|
Description | Number of DNS record update requests sent.
Note: The value of OperationType dimension is Update. |
Type | Counter |
Service Operation | NFRegister, NFUpdate, NFDeregister, NRF Audit |
Dimensions | NrfLevel, NfInstanceId, NfFqdn, NfSetFqdn,
Replacement, OperationType, TriggerMode
Possible
Values:
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-201 ocnrf_dns_naptr_rx_responses_total
Field | Details |
---|---|
Description | Number of DNS record update responses received. |
Type | Counter |
Service Operation | NFRegister, NFUpdate, NFDeregister, NRF Audit |
Dimensions | NrfLevel, NfInstanceId, NfFqdn, NfSetFqdn,
Replacement, OperationType, HttpStatusCode, FailureReason,
TriggerMode
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-202 ocnrf_dns_naptr_tx_requests_total
Field | Details |
---|---|
Description | Number of DNS record delete requests sent.
Note: The value of OperationType dimension is Delete. |
Type | Counter |
Service Operation | NFRegister, NFUpdate, NFDeregister, NRF Audit |
Dimensions | NrfLevel, NfInstanceId, NfFqdn, NfSetFqdn,
Replacement, OperationType, HttpStatusCode, FailureReason,
TriggerMode
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-203 ocnrf_dns_naptr_rx_responses_total
Field | Details |
---|---|
Description | Number of DNS record delete responses received.
Note: The value of OperationType dimension is Delete. |
Type | Counter |
Service Operation | None |
Dimensions | NrfLevel, NfInstanceId, NfFqdn, NfSetFqdn,
Replacement, OperationType, HttpStatusCode, FailureReason,
TriggerMode
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-204 ocnrf_dns_naptr_audit_tx_requests_total
Field | Details |
---|---|
Description | Number of DNS record audit requests sent.
Note: The value of OperationType dimension is Get. |
Type | Counter |
Service Operation | None |
Dimensions | NrfLevel, NFInstanceId, NfFqdn, NfSetFqdn,
Replacement, OperationType
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-205 ocnrf_dns_naptr_audit_rx_responses_total
Field | Details |
---|---|
Description | Number of DNS record audit responses received.
Note: The value of OperationType dimension is Get. |
Type | Counter |
Service Operation | None |
Dimensions | NrfLevel, NFInstanceId, NfFqdn, NfSetFqdn,
Replacement, OperationType, HttpStatusCode,
FailureReason
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-206 ocnrf_dns_naptr_failure_rx_responses
Field | Details |
---|---|
Metric Name | ocnrf_dns_naptr_failure_rx_responses |
Description | Number of DNS record failed responses received. |
Type | Gauge |
Service Operation | None |
Dimensions | NrfLevel, NFInstanceId, NfFqdn, NfSetFqdn,
Replacement
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-207 ocnrf_dns_naptr_round_trip_time_seconds
Field | Details |
---|---|
Description | Average Latency between messages sent by NRF towards DNS and after receiving response from DNS. |
Type | Histogram |
Service Operation | NFRegister, NFUpdate, NFDeregister, NRFAudit, DNS NAPTR Audit, Manual |
Dimensions | NrfLevel, NFInstanceId, NfFqdn, NfSetFqdn, Replacement,
OperationType, TriggerMode
Note: The NfFqdn dimension contains the FQDN as present in the NfProfile. |
Table 6-208 ocnrf_dns_naptr_nfRegistration_tx_requests_total
Field | Details |
---|---|
Description | Number of DNS record trigger sent by NFRegistration microservice to Artisan microservice. |
Type | Counter |
Service Operation | NFRegister, NFUpdate, NFDeregister |
Dimensions | NfInstanceId, TriggerType, NrfLevel |
Table 6-209 ocnrf_dns_naptr_nfRegistration_rx_responses_total
Field | Details |
---|---|
Description | Number of DNS record trigger response received by NFRegistration microservice from Artisan microservice. |
Type | Counter |
Service Operation | NFRegister, NFUpdate, NFDeregister |
Dimensions | NfInstanceId, TriggerType, NrfLevel |
Table 6-210 ocnrf_dns_naptr_nrfAuditor_tx_requests_total
Field | Details |
---|---|
Description | Number of DNS record trigger sent by NRFAuditor microservice to Artisan microservice. |
Type | Counter |
Service Operation | NRFAuditor |
Dimensions | NfInstanceId, TriggerType, NrfLevel |
Table 6-211 ocnrf_dns_naptr_nrfAuditor_rx_responses_total
Field | Details |
---|---|
Description | Number of DNS record trigger response received by NRFAuditor microservice from Artisan microservice. |
Type | Counter |
Service Operation | NRFAuditor |
Dimensions | NfInstanceId, NrfLevel |
Table 6-212 ocnrf_dns_naptr_trigger_rx_requests_total
Field | Details |
---|---|
Description | Number of DNS record trigger request received by Artisan microservice. |
Type | Counter |
Service Operation | None |
Dimensions | NfInstanceId, NrfLevel |
Table 6-213 ocnrf_dns_naptr_trigger_tx_responses_total
Field | Details |
---|---|
Description | Number of DNS record trigger responses sent by Artisan microservice. |
Type | Counter |
Service Operation | None |
Dimensions | NfInstanceId, NrfLevel |
NRF Alternate Route Service Metrics
Table 6-214 oc_alternate_route_upstream_dns_request_timeout_total
Field | Details |
---|---|
Description | Number of DNS record requests timeout total. |
Type | Counter |
Service Operation | Service towards DNS server |
Dimensions | amfFqdn, host, port, replacement |
6.1.14 Pod Protection Metrics
This section provides details about the Pod Protection metrics.
Table 6-215 ocnrf_pod_congestion_state
Field | Details |
---|---|
Description | The metric is used to track the overall congestion state
per nfSubscription pod. The values of the metric is as follow:
Note: If the pod protection feature is disabled, this metric will not be available or will contain value as -1. |
Type | Gauge |
Dimensions | NrfLevel |
Table 6-216 ocnrf_pod_cpu_congestion_state
Field | Details |
---|---|
Description | The metric is used to track the congestion state based
on the CPU usage of the subscription pod. This metric is valid only when
the nfSubscription pod protection feature is enabled. The values of the
metric is as follow:
Note: If the pod protection feature is disabled, this metric will not be available or will contain value as -1. |
Type | Gauge |
Dimensions | NrfLevel |
Table 6-217 ocnrf_pod_pending_message_count_congestion_state
Field | Details |
---|---|
Description | The metric is used to track the congestion state based
on the message pending count of the subscription pod. This metric is
valid only when the nfSubscription pod protection feature is enabled.
The values of the metric is as follow:
Note: If the pod protection feature is disabled, this metric will not be available or will contain value as -1. |
Type | Gauge |
Dimensions | NrfLevel |
Table 6-218 ocnrf_incoming_connections
Field | Details |
---|---|
Metric Name | ocnrf_incoming_connections |
Description | The metric is used to track the number of incoming connections. This metric is applicable only for nfsubscription service. |
Type | Gauge |
Dimensions | NrfLevel |
Table 6-219 ocnrf_max_concurrent_streams
Field | Details |
---|---|
Description | The metric is used to track the maximum concurrent streams per connection. This metric is applicable only for nfsubscription service. |
Type | Gauge |
Dimensions | NrfLevel , connectionId |
Table 6-220 ocnrf_pod_cpu_usage
Field | Details |
---|---|
Description | The CPU usage of the pod.
Note: If the pod protection feature is disabled, this metric will not be available or will contain value as 0. |
Type | Gauge |
Dimensions | NrfLevel |
Table 6-221 ocnrf_pod_pending_message_count
Field | Details |
---|---|
Description | The Pending Message Count value of the
pod.
Note: If the pod protection feature is disabled, this metric will not be available or will contain value as 0. |
Type | Gauge |
Dimensions | NrfLevel |
Table 6-222 ocnrf_pod_incoming_connection_rejected_total
Field | Details |
---|---|
Description | The number of connections that have been rejected in the DoC or Congested state. This metric is applicable only for nfsubscription service. |
Type | Counter |
Dimensions | NrfLevel |
Table 6-223 ocnrf_nfNotification_trigger_total
Field | Details |
---|---|
Description | The number of times a notification trigger is sent to nfSubscription service from the nfregistration and nrfauditor services. |
Type | Counter |
Dimensions | NotificationEventType, errorReason: The reason if nfNotification trigger failed from nfregistration or nrfauditor service pods to nfsubscription service pods. |
6.1.15 Network Slice Specific Metrics
This section describes the Network Slice Specific metrics that are pegged based on Network Slice Instances (NSIs) and Single Network Slice Selection Assistance Information (SNSSAI).
Table 6-224 ocnrf_nfDiscover_rx_requests_perSnssai_total
Field | Details |
---|---|
Description | The total number of NFDiscover requests received at a
slice that is identified by specific SNSSAI. This metric is pegged for
each snssai present in the search query parameters. The
search query attributes are snssais and
plmn-specific-snssai-list .
Note:
|
Type | Counter |
Service Operation | NFDiscover |
Dimensions | sNssai |
Table 6-225 ocnrf_nfDiscover_tx_success_response_perSnssai_total
Field | Details |
---|---|
Description | The total number of success discovery responses with one
or more matching NfProfiles sent per slice that is identified by SNSSAI.
The metric is pegged for each unique snssai present in
the profiles of discovery response. The search query attributes are
snssais and
plmn-specific-snssai-list . The NfProfile attributes
are snssais , perPlmnSnssaiList ,
sNssaiSmfInfoList , and
sNssaiUpfInfoList .
Note:
|
Type | Counter |
Service Operation | NFDiscover |
Dimensions | sNssai |
Table 6-226 ocnrf_nfDiscover_tx_empty_response_perSnssai_total
Field | Details |
---|---|
Description | The total number of discovery responses sent with no
matching NfProfiles for a slice identified by SNSSAI. This metric is
pegged for each snssai present in the search query
parameters. The search query attributes are snssais and
plmn-specific-snssai-list .
Note:
|
Type | Counter |
Service Operation | NFDiscover |
Dimensions | sNssai |
Table 6-227 ocnrf_nfDiscover_tx_failure_response_perSnssai_total
Field | Details |
---|---|
Description | The total number of failure discovery responses sent per
slice that is identified by specific SNSSAI. This metric is pegged for
each snssai present in the search query parameters. The
search query attributes are snssais and
plmn-specific-snssai-list .
Note:
|
Type | Counter |
Service Operation | NFDiscover |
Dimensions | sNssai, HttpStatusCode |
Table 6-228 ocnrf_nfDiscover_rx_requests_perNsi_total
Field | Details |
---|---|
Description | The total number of NFDiscover requests received at a
slice that is identified by NSI. This metric is pegged for each
nsi present in the search query parameter. The
search query attribute is nsi-list .
Note:
|
Type | Counter |
Service Operation | NFDiscover |
Dimensions | Nsi |
Table 6-229 ocnrf_nfDiscover_tx_success_response_perNsi_total
Field | Details |
---|---|
Description | The total number of success discovery responses with one
or more matching NfProfiles sent per slice that is identified by
specific NSI. The metric is pegged for each nsi in the
intersection of nsi-list search query parameter and
nsiList attribute in the NfProfile present in the
discovery response.
Note:
|
Type | Counter |
Service Operation | NFDiscover |
Dimensions | Nsi |
Table 6-230 ocnrf_nfDiscover_tx_empty_response_perNsi_total
Field | Details |
---|---|
Description | The total number of discovery response with no matching
NfProfiles for a slice identified by NSI. The metric is pegged for each
nsi present in the search query parameter. The
search query attribute is nsi-list .
Note:
|
Type | Counter |
Service Operation | NFDiscover |
Dimensions | Nsi |
Table 6-231 ocnrf_nfDiscover_tx_failure_response_perNsi_total
Field | Details |
---|---|
Description | The total number of failure discovery response for a
slice identified by NSI. The metric is pegged for each
nsi present in the search query parameter. The
search query attribute is nsi-list .
Note:
|
Type | Counter |
Service Operation | NFDiscover |
Dimensions | Nsi, HttpStatusCode |
Table 6-232 ocnrf_nfDiscover_tx_forwarded_requests_perSnssai_total
Field | Details |
---|---|
Description | The total number of discovery requests forwarded to
another NRF for a slice identified by SNSSAI. The metric is pegged for
each snssai present in the search query parameters. The
search query attributes are snssais and
plmn-specific-snssai-list .
Note:
|
Type | Counter |
Service Operation | NFDiscover |
Dimensions | sNssai, TargetNrfFqdn, NfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-233 ocnrf_nfDiscover_rx_success_forwarded_responses_perSnssai_total
Field | Details |
---|---|
Description | The total number of success responses with one or more
matching NfProfiles that is received for forwarded discovery request for
a slice identified by SNSSAI. The metric is pegged for each
snssai present in the intersection of the
snssai present in the search query and in the
profile. The search query attributes are snssais and
plmn-specific-snssai-list . The NfProfile attributes
are snssais , perPlmnSnssaiList ,
sNssaiSmfInfoList , and
sNssaiUpfInfoList .
Note:
|
Type | Counter |
Service Operation | NFDiscover |
Dimensions | sNssai, NfFqdn, TargetNrfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-234 ocnrf_nfDiscover_rx_empty_forwarded_responses_perSnssai_total
Field | Details |
---|---|
Description | The total number of responses that is received for
forwarded discovery request with no matching NfProfiles for a slice
identified by SNSSAI. The metric is pegged for each
snssai present in the search query parameters. The
search query attributes are snssais and
plmn-specific-snssai-list .
Note:
|
Type | Counter |
Service Operation | NFDiscover |
Dimensions | sNssai, NfFqdn, TargetNrfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-235 ocnrf_nfDiscover_rx_failure_forwarded_responses_perSnssai_total
Field | Details |
---|---|
Description | The total number of failure responses for forwarded
discovery requests for a slice identified by SNSSAI. The metric is
pegged for each snssai present in the search query
parameters. The search query attributes are snssais and
plmn-specific-snssai-list .
Note:
|
Type | Counter |
Service Operation | NFDiscover |
Dimensions | sNssai, NfFqdn, HttpStatusCode, TargetNrfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-236 ocnrf_nfDiscover_tx_forwarded_requests_perNsi_total
Field | Details |
---|---|
Description | The total number of discovery requests forwarded to
another NRF for a slice identified by NSI. The metric is pegged for each
nsi present in the search query parameter. The
search query attribute is nsi-list .
Note: The NSI belongs to the Producer NF that is discovered. |
Type | Counter |
Service Operation | NFDiscover |
Dimensions | Nsi, NfFqdn, TargetNrfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-237 ocnrf_nfDiscover_rx_success_forwarded_responses_perNsi
Field | Details |
---|---|
Description | The total number of success response for forwarded
discovery requests for a slice identified by NSI. The NSI associated
with producer NF being discovered. The metric is pegged for each
nsi in the intersection of
nsi-list search query parameter and
nsiList attribute in the NfProfiles present in the
discovery response.
Note:
|
Type | Counter |
Service Operation | NFDiscover |
Dimensions | Nsi, NfFqdn, TargetNrfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-238 ocnrf_nfDiscover_rx_empty_forwarded_responses_perNsi
Field | Details |
---|---|
Description | The total number of responses with no matching
NfProfiles for forwarded discovery request for a slice identified by
NSI. The NSI is associated with the producer NF being discovered. The
metric is pegged for each nsi present in the search
query parameter. The search query attribute is
nsi-list .
Note:
|
Type | Counter |
Service Operation | NFDiscover |
Dimensions | Nsi, NfFqdn, TargetNrfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-239 ocnrf_nfDiscover_rx_failure_forwarded_responses_perNsi_total
Field | Details |
---|---|
Description | The total number of failure response for forwarded
discovery requests for a slice identified by NSI. The metric is pegged
for each nsi present in the search query parameter. The
search query attribute is nsi-list .
Note:
|
Type | Counter |
Service Operation | NFDiscover |
Dimensions | Nsi, NfFqdn, HttpStatusCode, TargetNrfFqdn
Note: The NfFqdn dimension indicates the consumer NF FQDN. This dimension contains the NfFqdn if the service mesh sends the consumer NF FQDN in XFCC header, else the dimension will contain the value as UNKNOWN. |
Table 6-240 ocnrf_nfRegister_requests_perSnssai_total
Field | Details |
---|---|
Description | The total number of NFRegister requests received at a
slice that is identified by specific SNSSAI. The metric is pegged for
each snssai present in the NfProfile being registered.
The attributes considered are snssais ,
perPlmnSnssaiList ,
sNssaiSmfInfoList , and
sNssaiUpfInfoList .
Note:
|
Type | Counter |
Service Operation | NFRegister |
Dimensions | sNssai |
Table 6-241 ocnrf_nfRegister_success_responses_perSnssai_total
Field | Details |
---|---|
Description | The total number of successful NFRegister responses with
one or more matching NfProfiles sent per slice identified by SNSSAI. The
metric is pegged for each snssai present in the
NfProfile being registered. The attributes considered are
snssais , perPlmnSnssaiList ,
sNssaiSmfInfoList , and
sNssaiUpfInfoList .
Note: Only
|
Type | Counter |
Service Operation | NFRegister |
Dimensions | sNssai |
Table 6-242 ocnrf_nfRegister_failure_responses_perSnssai_total
Field | Details |
---|---|
Description | The total number of failure NFRegister responses sent
per slice identified by SNSSAIs. The metric is pegged for each
snssai present in the NfProfile being registered.
The attributes considered are snssais ,
perPlmnSnssaiList ,
sNssaiSmfInfoList , and
sNssaiUpfInfoList .
Note:
|
Type | Counter |
Service Operation | NFRegister |
Dimensions | sNssai, HttpStatusCode |
Table 6-243 ocnrf_nfRegister_requests_perNsi_total
Field | Details |
---|---|
Description | The total number of NFRegister requests received at a
slice that is identified by NSI. The metric is pegged for each
nsi present in the NfProfile being registered. The
attribute considered is nsiList .
Note: The metric may not get pegged if the NFRegister request has an invalid body. |
Type | Counter |
Service Operation | NFRegister |
Dimensions | Nsi |
Table 6-244 ocnrf_nfRegister_success_responses_perNsi_total
Field | Details |
---|---|
Description | The total number of successful NFRegister responses with
one or more matching NfProfiles sent per slice that is identified by
NSI. The metric is pegged for each nsi present in the
NfProfile being registered. The attribute considered is
nsiList .
|
Type | Counter |
Service Operation | NFRegister |
Dimensions | Nsi |
Table 6-245 ocnrf_nfRegister_failure_responses_perNsi_total
Field | Details |
---|---|
Description | The total number of failure NFRegister responses sent
per slice that is identified by NSI. The metric is pegged for each
nsi present in the NfProfile being registered. The
attribute considered is nsiList .
Note: The metric may not get pegged if the NFRegister request has an invalid body. |
Type | Counter |
Service Operation | NFRegister |
Dimensions | Nsi, HttpStatusCode |
Table 6-246 ocnrf_nfUpdate_requests_perSnssai_total
Field | Details |
---|---|
Description | The total number of NFUpdate requests for slices
identified by SNSSAIs. The metric is pegged for Complete Update and
Partial Update(PATCH) of a registered NfProfile and for each
snssais present in the NfProfile registered. The
attributes considered are snssais ,
perPlmnSnssaiList ,
sNssaiSmfInfoList , and
sNssaiUpfInfoList .
Note:
|
Type | Counter |
Service Operation | NFUpdate |
Dimensions | sNssai |
Table 6-247 ocnrf_nfUpdate_success_responses_perSnssai_total
Field | Details |
---|---|
Description | The total number of successful NFUpdate responses with
one or more matching NfProfiles sent per slice identified by SNSSAI. The
metric is pegged for Complete Update and Partial Update(PATCH) of a
registered NfProfile and for each snssais present in
the NfProfile registered. The attributes considered are
snssais , perPlmnSnssaiList ,
sNssaiSmfInfoList , and
sNssaiUpfInfoList .
Note:
|
Type | Counter |
Service Operation | NFUpdate |
Dimensions | sNssai |
Table 6-248 ocnrf_nfUpdate_failure_responses_perSnssai_total
Field | Details |
---|---|
Description | The total number of failure NFUpdate responses sent per
slice identified by SNSSAIs. The metric is pegged for Complete Update
and Partial Update(PATCH) of a registered NfProfile and for each
snssais present in the NfProfile registered. The
attributes considered are snssais ,
perPlmnSnssaiList ,
sNssaiSmfInfoList , and
sNssaiUpfInfoList .
Note:
|
Type | Counter |
Service Operation | NFUpdate |
Dimensions | sNssai, HttpStatusCode |
Table 6-249 ocnrf_nfUpdate_requests_perNsi_total
Field | Details |
---|---|
Description | The total number of NFUpdate requests for slices
identified by NSI. The metric is pegged for Complete Update and Partial
Update (PATCH) of a registered NfProfile and for each
nsi present in the NfProfile registered. The
attribute considered is nsiList .
Note:
|
Type | Counter |
Service Operation | NFUpdate |
Dimensions | Nsi |
Table 6-250 ocnrf_nfUpdate_success_responses_perNsi_total
Field | Details |
---|---|
Description | The total number of successful NFUpdate responses for
slices identified by NSI. The metric is pegged for Complete Update and
Partial Update (PATCH) of a registered NfProfile and for each
nsi present in the NfProfile registered. The
attribute considered is nsiList .
Note:
|
Type | Counter |
Service Operation | NFUpdate |
Dimensions | Nsi |
Table 6-251 ocnrf_nfUpdate_failure_responses_perNsi_total
Field | Details |
---|---|
Description | The total number of failure NFUpdate responses for
slices identified by NSI. The metric is pegged for Complete Update and
Partial Update (PATCH) of a registered NfProfile and for each
nsi present in the NfProfile registered. The
attribute considered is nsiList .
Note:
|
Type | Counter |
Service Operation | NFUpdate |
Dimensions | Nsi, HttpStatusCode |
Table 6-252 ocnrf_nfDeregister_requests_perSnssai_total
Field | Details |
---|---|
Description | The total number of NFDeregister requests received at a
slice that is identified by SNSSAIs. The metric is pegged for each
snssais present in the registered NfProfile. The
attributes considered are snssais ,
perPlmnSnssaiList ,
sNssaiSmfInfoList , and
sNssaiUpfInfoList .
Note:
|
Type | Counter |
Service Operation | NFDeregister |
Dimensions | sNssai |
Table 6-253 ocnrf_nfDeregister_success_responses_perSnssai_total
Field | Details |
---|---|
Description | The total number of successful NFDeregister responses
with one or more matching NfProfiles sent per slice that is identified
by SNSSAI. The metric is pegged for each snssais
present in the registered NfProfile. The attributes considered are
snssais , perPlmnSnssaiList ,
sNssaiSmfInfoList , and
sNssaiUpfInfoList .
Note:
|
Type | Counter |
Service Operation | NFDeregister |
Dimensions | sNssai |
Table 6-254 ocnrf_nfDeregister_failure_responses_perSnssai_total
Field | Details |
---|---|
Description | The total number of failure NFDeregister responses sent
per slice that is identified by SNSSAIs. The metric is pegged for each
snssais present in the registered NfProfile. The
attributes considered are snssais ,
perPlmnSnssaiList ,
sNssaiSmfInfoList , and
sNssaiUpfInfoList .
Note:
|
Type | Counter |
Service Operation | NFDeregister |
Dimensions | sNssai, HttpStatusCode |
Table 6-255 ocnrf_nfDeregister_requests_perNsi_total
Field | Details |
---|---|
Description | The total number of NFDeregister requests received at a
slice that is identified by NSI. The metric is pegged for each
nsi present in the registered NfProfile. The
attribute considered is nsiList .
Note:
|
Type | Counter |
Service Operation | NFDeregister |
Dimensions | Nsi |
Table 6-256 ocnrf_nfDeregister_success_responses_perNsi_total
Field | Details |
---|---|
Description | The total number of successful NFDeregister responses
with one or more matching NfProfiles sent per slice that is identified
by NSI. The metric is pegged for each nsi present in
the registered NfProfile. The attribute considered is
nsiList .
Note:
|
Type | Counter |
Service Operation | NFDeregister |
Dimensions | Nsi |
Table 6-257 ocnrf_nfDeregister_failure_responses_perNsi_total
Field | Details |
---|---|
Description | The total number of failure NFDeregister responses sent
per slice that is identified by NSI. The metric is pegged for each
nsi present in the registered NfProfile. The
attribute considered is nsiList .
Note:
|
Type | Counter |
Service Operation | NFDeregister |
Dimensions | Nsi, HttpStatusCode |
Table 6-258 ocnrf_nfHeartBeat_requests_perSnssai_total
Field | Details |
---|---|
Description | The total number of NF HeartBeat requests received at a
slice that is identified by SNSSAIs. The attributes considered are
snssais , perPlmnSnssaiList ,
sNssaiSmfInfoList , and
sNssaiUpfInfoList .
Note:
|
Type | Counter |
Service Operation | NfHeartBeat |
Dimensions | sNssai |
Table 6-259 ocnrf_nfHeartBeat_success_responses_perSnssai_total
Field | Details |
---|---|
Description | The total number of success NF HeartBeat responses with
one or more matching NfProfiles sent per slice that is identified by
SNSSAIs. The attributes considered are snssais ,
perPlmnSnssaiList ,
sNssaiSmfInfoList , and
sNssaiUpfInfoList .
Note:
Only |
Type | Counter |
Service Operation | NfHeartBeat |
Dimensions | sNssai |
Table 6-260 ocnrf_nfHeartBeat_failure_responses_perSnssai_total
Field | Details |
---|---|
Description | The total number of failure NF HeartBeat Update
responses for slices identified by SNSSAIs. The attributes considered
are snssais , perPlmnSnssaiList ,
sNssaiSmfInfoList , and
sNssaiUpfInfoList .
Note:
|
Type | Counter |
Service Operation | NfHeartBeat |
Dimensions | sNssai, HttpStatusCode |
Table 6-261 ocnrf_nfHeartBeat_requests_perNsi_total
Field | Details |
---|---|
Description | The total number of NF HeartBeat requests received at a
slice that is identified by Nsi. The attribute considered is
nsiList .
Note:
|
Type | Counter |
Service Operation | NfHeartBeat |
Dimensions | Nsi |
Table 6-262 ocnrf_nfHeartBeat_success_responses_perNsi_total
Field | Details |
---|---|
Description | The total number of successful NF HeartBeat responses
with one or more matching NfProfiles sent per slice that is identified
by Nsi. The attribute considered is nsiList .
Note: Only |
Type | Counter |
Service Operation | NfHeartBeat |
Dimensions | Nsi |
Table 6-263 ocnrf_nfHeartBeat_failure_responses_perNsi_total
Field | Details |
---|---|
Description | The total number of failure NF HeartBeat responses sent
per slice that is identified by Nsi. The attribute considered is
nsiList .
|
Type | Counter |
Service Operation | NfHeartBeat |
Dimensions | Nsi, HttpStatusCode |
6.1.16 NRF Cache Data Metrics
Table 6-264 ocnrf_cds_rx_requests_total
Field | Details |
---|---|
Description | The number of requests received at Cache Data Service. |
Type | Counter |
Dimensions | NrfLevel, RequestType
Possible values for RequestType are RemoteAndLocalSetProfiles, ProfilesByQueryParam, and RemoteAndLocalSetSubscriptions |
Table 6-265 ocnrf_cds_tx_responses_total
Field | Details |
---|---|
Description | The number of responses sent by the Cache Data Service. |
Type | Counter |
Dimensions | NrfLevel, RequestType, HttpStatusCode.
Possible values for RequestType are RemoteAndLocalSetProfiles, ProfilesByQueryParam, and RemoteAndLocalSetSubscriptions |
Table 6-266 ocnrf_cds_round_trip_time_seconds
Field | Details |
---|---|
Description | The time taken to process the request at Cache Data Service in 50, 90, 95, and 99 percentiles. |
Type | Histogram |
Dimensions | NrfLevel, RequestType
Possible values for RequestType are RemoteAndLocalSetProfiles, ProfilesByQueryParam, and RemoteAndLocalSetSubscriptions |
Table 6-267 ocnrf_query_remote_cds_requests_total
Field | Details |
---|---|
Description | The number of requests sent to the NRF of a remote NRF set by Cache Data Service. |
Type | Counter |
Dimensions | NrfLevel, QueryType, RemoteNrfFqdn, TargetNrfSetId.
Possible values of QueryType are NfProfiles and NfSubscriptions. |
Table 6-268 ocnrf_query_remote_cds_responses_total
Field | Details |
---|---|
Description | The number of responses received from the NRF of a remote NRF set by Cache Data Service. |
Type | Counter |
Dimensions | NrfLevel, QueryType, HttpStatusCode, RemoteNrfFqdn,
TargetNrfSetId.
Possible values of QueryType are NfProfiles and NfSubscriptions. |
Table 6-269 ocnrf_query_remote_cds_round_trip_time_seconds
Field | Details |
---|---|
Description | The time taken between the request sent by Cache Data
Service towards remote NRF set and response received.
It is measured in 50, 90, 95, and 99 percentiles. |
Type | Histogram |
Dimensions | NrfLevel, QueryType, HttpStatusCode, RemoteNrfFqdn,
TargetNrfSetId.
Possible values of QueryType are NfProfiles and NfSubscriptions. |
Table 6-270 ocnrf_query_remote_cds_message_size_bytes
Field | Details |
---|---|
Description | The size of the response received by the Cache Data Service from the remote NRF set. The size is pegged in bytes and is published in buckets of 1kB, 5KB, 10KB, 50KB, 100KB, 500KB, and 1MB. |
Type | Histogram |
Dimensions | NrfLevel, QueryType, RemoteNrfFqdn, HttpStatusCode, SourceNrfSetId,
TargetNrfSetId.
Possible values of QueryType are NfProfiles and NfSubscriptions. |
Table 6-271 ocnrf_cache_fallback_total
Field | Details |
---|---|
Description | The number of times the request was fulfilled from the in-memory cache of Cache Data Service due to cnDBTier query errors. |
Type | Counter |
Dimensions | NrfLevel, ErrorReason |
Table 6-272 ocnrf_db_fallback_total
Field | Details |
---|---|
Description | The number of times a service request was fulfilled from the cnDBTier using local NRF set data as the query towards the Cache Data Service failed. |
Type | Counter |
Dimensions | NrfLevel, ServiceOperation
Possible values of ServiceOperation are NfProfileRetrieval, NfListRetrieval, NfAccessToken, NfDiscover, NfStatusSubscribe, NfStatusUnsubscribe, and NfStatusNotify |
Table 6-273 ocnrf_query_cds_requests_total
Field | Details |
---|---|
Description | The number of requests to the Cache Data Service sent by the local NRF microservices for state data. For the list of local NRF microservices, see the Enhanced NRF Set Based Deployment (NRF Growth) section. |
Type | Counter |
Dimensions | NrfLevel, ServiceOperation
Possible values of ServiceOperation are NfProfileRetrieval, NfListRetrieval, NfAccessToken, NfDiscover, NfSubscribe, NfUnsubscribe, notifyProfileChange, notifyProfileDeregistration, notifyProfileRegistration, FindAllNfSubscription, NFInstanceFetch, CUSTOM_NRF_AUDIT_NF_COUNT, and CUSTOM_NRF_AUDIT_NF_SIZE. |
Table 6-274 ocnrf_query_cds_responses_total
Field | Details |
---|---|
Description | The number of responses from the Cache Data Service to the local NRF microservices for state data. For the list of local NRF microservices, see the Enhanced NRF Set Based Deployment (NRF Growth) section. |
Type | Counter |
Dimensions | NrfLevel, HttpStatusCode, ServiceOperation
Possible values of ServiceOperation are NfProfileRetrieval, NfListRetrieval, NfAccessToken, NfDiscover, NfSubscribe, NfUnsubscribe, notifyProfileChange, notifyProfileDeregistration, notifyProfileRegistration, FindAllNfSubscription, NFInstanceFetch, CUSTOM_NRF_AUDIT_NF_COUNT, and CUSTOM_NRF_AUDIT_NF_SIZE. |
Table 6-275 ocnrf_query_cds_round_trip_time_seconds
Field | Details |
---|---|
Description | The time taken between the request sent by local NRF set microservices to Cache Data Service and response received. It is measured in 50, 95, and 99 percentiles. |
Type | Histogram |
Dimensions | NrfLevel, ServiceOperation
Possible values of ServiceOperation are NfProfileRetrieval, NfListRetrieval, NfAccessToken, NfDiscover, NfSubscribe, NfUnsubscribe, notifyProfileChange, notifyProfileDeregistration, notifyProfileRegistration, FindAllNfSubscription, NFInstanceFetch, CUSTOM_NRF_AUDIT_NF_COUNT, and CUSTOM_NRF_AUDIT_NF_SIZE. |
Table 6-276 ocnrf_dbmetrics_total
Field | Details |
---|---|
Description | The number of database operation counts corresponding to every service operation. |
Type | Counter |
Dimensions | method, dbOperation, ServiceOperation, NrfLevel,
HttpStatusCode
Possible values for:
|
Table 6-277 ocnrf_nf_registered_count
Field | Details |
---|---|
Description | The total number of NFs registered in the segment. |
Type | Gauge |
Dimensions | NrfLevel, RequesterNfType |
Table 6-278 ocnrf_cache_sync_count_total
Field | Details |
---|---|
Description | The number of in-memory cache entries synchronized. The metric is pegged at the at the Cache Data Service and Discovery Service. |
Type | Counter |
Dimensions | NrfLevel, NrfFqdn, SourceNrfSetId, TargetNrfSetId,
DataType, CompleteSync
Possible values of DataType are NfProfiles and NfSubscriptions Possible values of CompleteSync are true and false |
Table 6-279 ocnrf_remote_set_unavailable_total
Field | Details |
---|---|
Description | All the NRFs of a remote NRF set are unavailable for synchronizing state data. |
Type | Counter |
Dimensions | NrfLevel,SourceNrfSetId, TargetNrfSetId |
Table 6-280 ocnrf_all_remote_sets_unavailable_total
Field | Details |
---|---|
Description | All the NRFs of all remote NRF sets are unavailable for synchronizing state data. |
Type | Counter |
Dimensions | NrfLevel,SourceNrfSetId, TargetNrfSetId |
Table 6-281 ocnrf_cds_rx_remote_requests_total
Field | Details |
---|---|
Description | The number of requests received at Cache Data Service from remote NRFs. |
Type | Counter |
Dimensions | QueryType |
Table 6-282 ocnrf_cds_rx_remote_responses_total
Field | Details |
---|---|
Description | The number of responses sent by the Cache Data Service to the remote NRF. |
Type | Counter |
Dimensions | QueryType |
Table 6-283 ocnrf_cds_remote_rx_request_round_trip_time
Field | Details |
---|---|
Description | The time taken to process the request received from the Remote NRF at Cache Data Service. |
Type | Histogram |
Dimensions | QueryType |
6.1.17 Overload Control
Table 6-284 load_level
Field | Details |
---|---|
Description | The metric is used to track the load level as per the services. |
Type | Gauge |
Dimensions | service, isLeaderPod |
Table 6-285 service_resource_stress
Field | Details |
---|---|
Description | This metric tracks CPU, memory, failure count, and pending requests on the basis of which the overload level of a service is calculated. |
Type | Gauge |
Dimension | type, service, isLeaderPod |
Table 6-286 service_resource_overload_level
Field | Details |
---|---|
Description | This metric tracks an individual resource's overload level that is calculated based on the resource usage and configured threshold. |
Type | Gauge |
Dimension | type, service, isLeaderPod |
6.2 NRF KPIs
This section includes information about KPIs for Oracle Communications Cloud Native Core, Network Repository Function (NRF).
Note:
Sample NRF dashboard for Grafana is delivered to the customer through NRF CSAR package. Metrics and functions used to achieve KPI are already covered in NRF CSAR package.6.2.1 NRF Service KPIs
This section lists the service status, Gateway, Service latency, Database latency KPIs.
Table 6-287 Registration Service Success Ratio (2xx) %
Field | Details |
---|---|
Description | Measures the total number of successful registration service
operations at NRF.
For more information about metric used, see NRF Gateways Metrics. |
Expression | Expression: sum(increase(oc_ingressgateway_http_responses_total{Status=~\"2.*\",Route_path=~\".*nnrf-nfm/v1/nf-instances.*\",kubernetes_namespace=\"$namespace\"}[5m]))/sum(increase(oc_ingressgateway_http_responses_total{Route_path=~\".*nnrf-nfm/v1/nf-instances.*\",kubernetes_namespace=\"$namespace\"}[5m]))*100 |
Table 6-288 Subscription Service Success Ratio (2xx) %
Field | Details |
---|---|
Description | Measures the total number of successful subscription service
operations at NRF.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(increase(oc_ingressgateway_http_responses_total{Status=~\"2.*\",Route_path=~\".*nnrf-nfm/v1/nf-instances.*\",kubernetes_namespace=\"$namespace\"}[5m]))/sum(increase(oc_ingressgateway_http_responses_total{Route_path=~\".*nnrf-nfm/v1/nf-instances.*\",kubernetes_namespace=\"$namespace\"}[5m]))*100 |
Table 6-289 Discover Service Success Ratio (2xx) %
Field | Details |
---|---|
Description | Measures the total number of successful discover service operations
at NRF.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(increase(oc_ingressgateway_http_responses_total{Status=~\"2.*\",Route_path=~\".*nnrf-disc/v1/nf-instances.*\",kubernetes_namespace=\"$namespace\"}[5m]))/sum(increase(oc_ingressgateway_http_responses_total{Route_path=~\".*nnrf-disc/v1/nf-instances.*\",kubernetes_namespace=\"$namespace\"}[5m]))*100 |
Table 6-290 AccessToken Service Success Ratio (2xx) %
Field | Details |
---|---|
Description | Measures the total number of successful Access Token service
operations at NRF.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(increase(oc_ingressgateway_http_responses_total{Status=~\"2.*\",Route_path=~".*oauth2/token.*",kubernetes_namespace=\"$namespace\"}[5m]))/sum(increase(oc_ingressgateway_http_responses_total{Route_path=~".*oauth2/token.*",kubernetes_namespace=\"$namespace\"}[5m]))*100 |
Table 6-291 SLF Query Success Ratio (2xx) %
Field | Details |
---|---|
Description | Measures the total number of SLF query response received.
For more information about metric used, see NRF SLF Metrics. |
Expression | sum(increase(ocnrf_SLF_rx_responses_total{HttpStatusCode=~\"2.*\",kubernetes_namespace=\"$namespace\"}[5m]))/sum(increase(ocnrf_SLF_rx_responses_total{kubernetes_namespace=\"$namespace\"}[5m]))*100 |
Table 6-292 Active Registrations
Field | Details |
---|---|
Description | Measures the total number of active registered NFs at any point of time to indicate that the data comes per NF type. This is based on [ NfType :- {{ RequesterNfType }} ] |
Expression | sum(ocnrf_active_registrations_count{namespace="$namespace"}) by(RequesterNfType) |
Table 6-293 Suspended NFs
Field | Details |
---|---|
Description | Measures the difference in number of profiles that have been marked as suspended when a profile has missed nfHeartBeatMissAllowed. This is based on [NfInstance :- {{ NfInstanceId }}] |
Expression | increase(ocnrf_nf_suspended_total{namespace="$namespace"}[5m]) |
Table 6-294 Total NfSubscriptions expired
Field | Details |
---|---|
Description | Measures the total number of NfSubscriptions whose validityTime has expired. |
Expression | increase(ocnrf_nfSubscriptions_expired_total{namespace="$namespace"}[5m]) |
Table 6-295 NfDiscoveredProfiles
Field | Details |
---|---|
Description | Measures the rate of number of profiles returned in discovery
response.
For more information about metric used, see NRF NF Metrics. |
Expression | sum(irate(ocnrf_nfDiscover_profiles_discovered_total{namespace="$namespace"}[2m])) by (Bucket,TargetNfType) |
Table 6-296 NfRegister Responses
Field | Details |
---|---|
Description | Measures the rate of successful registration responses sent. This is
based on [ HttpStatusCode:- {{HttpStatusCode}}, NfFqdn-{{ NfFqdn }}]
For more information about metric used, see NRF NF Metrics. |
Expression | sum(irate(ocnrf_nfRegister_tx_responses_total{namespace="$namespace"}[2m])) by (HttpStatusCode, NfFqdn) |
Table 6-297 NfUpdate Response (Complete)
Field | Details |
---|---|
Description | Measures the rate of successful updates response sent. This is based
on [ HttpStatusCode :- {{HttpStatusCode }}, NfFqdn :- {{ NfFqdn }} ]
For more information about metric used, see NRF NF Metrics. |
Expression | sum(irate(ocnrf_nfUpdate_tx_responses_total{namespace="$namespace",Updatetype="Complete"}[2m])) by (HttpStatusCode, NfFqdn) |
Table 6-298 NfUpdate Response (Partial)
Field | Details |
---|---|
Description | Measures the rate of successful updates of an NF Profile which is
previously registered at NRF. This is based on [ HttpStatusCode :-
{{HttpStatusCode }}, NfFqdn :- {{ NfFqdn }} ]
For more information about metric used, see NRF NF Metrics. |
Expression | sum(irate(ocnrf_nfUpdate_tx_responses_total{namespace="$namespace",Updatetype="Partial"}[2m])) by (HttpStatusCode, NfFqdn) |
Table 6-299 NfDeregister Responses
Field | Details |
---|---|
Description | Measures the rate of successful Deregistration of NFs at NRF. This is
based on [ HttpStatusCode :- {{HttpStatusCode}},NfFqdn :- {{ NfFqdn }}
]
For more information about metric used, see NRF NF Metrics. |
Expression | sum(irate(ocnrf_nfDeregister_tx_responses_total{namespace="$namespace"}[2m])) by (HttpStatusCode, NfFqdn) |
Table 6-300 NfProfileRetrieval Response
Field | Details |
---|---|
Description | Measures the rate at which NfProfileRetrieval service requests that
NRF rejects due to various error reasons. This KPI considers all non
success error codes. This is based on [HttpStatusCode :-
{{HttpStatusCode}}]
For more information about metric used, see NRF NF Metrics. |
Expression | sum(irate(ocnrf_nfProfileRetrieval_tx_responses_total{namespace="$namespace"}[2m])) by(HttpStatusCode) |
Table 6-301 NfHeartbeat Responses
Field | Details |
---|---|
Description | Measures the number of Heartbeat Responses sent. This is based on
[HttpStatusCode :- {{HttpStatusCode}}]
For more information about metric used, see NRF NF Metrics. |
Expression | sum(irate(ocnrf_nfHeartBeat_tx_responses_total{namespace="$namespace"}[2m])) by(HttpStatusCode) |
Table 6-302 NFStatusSubscribe
Field | Details |
---|---|
Description | Measures the total number of NfStatusSubscribe responses sent. This
is based on [HttpStatusCode :- {{HttpStatusCode}} ]
For more information about metric used, see NRF NF Metrics. |
Expression | sum(irate(ocnrf_nfStatusSubscribe_tx_responses_total{namespace="$namespace",OperationType="Create"}[2m])) by (HttpStatusCode) |
Table 6-303 NFStatusSubscribe (PATCH)
Field | Details |
---|---|
Description | Measures the total number of NfStatusSubscribe update responses sent.
This is based on [HttpStatusCode :- {{HttpStatusCode}} ]
For more information about metric used, see NRF NF Metrics. |
Expression | sum(irate(ocnrf_nfStatusSubscribe_tx_responses_total{namespace="$namespace",OperationType="Update"}[2m])) by (HttpStatusCode) |
Table 6-304 NFStatusUnsubscribe [HttpStatusCode :- {{HttpStatusCode}}]
Field | Details |
---|---|
Description | Measures the total number of NfStatusUnsubscribe responses sent.
For more information about metric used, see NRF NF Metrics. |
Expression | sum(irate(ocnrf_nfStatusUnsubscribe_tx_responses_total{namespace="$namespace"}[2m])) by (HttpStatusCode) |
Table 6-305 NfStatusNotify Response
Field | Details |
---|---|
Description | Measures the total number of NfStatusNotify responses received. This
is based on [HttpStatusCode :- {{HttpStatusCode}}]
For more information about metric used, see NRF NF Metrics. |
Expression | sum(irate(ocnrf_nfStatusNotify_rx_responses_total{namespace="$namespace"}[2m])) by(HttpStatusCode) |
Table 6-306 NfDiscovery Responses
Field | Details |
---|---|
Description | Measures the total number of NfDiscover responses sent. This is based
on [HttpStatusCode :- {{HttpStatusCode}}]
For more information about metric used, see NRF NF Metrics. |
Expression | sum(irate(ocnrf_nfDiscover_tx_responses_total{namespace="$namespace"}[2m])) by (HttpStatusCode) |
Table 6-307 SLF Response
Field | Details |
---|---|
Description | Measures the total number of SLF query response received. This is based on [ HttpStatusCode :- {{HttpStatusCode}},TargetNfType :- {{TargetNfType}} ] |
Expression | sum(irate(ocnrf_SLF_rx_responses_total{namespace="$namespace"}[2m])) by(HttpStatusCode,TargetNfType) |
Table 6-308 Forwarded Response
Field | Details |
---|---|
Description | Measures the total number of forwarded query response received. This is based on [ HttpStatusCode :- {{HttpStatusCode}}] |
Expression | sum(irate(ocnrf_forward_nfDiscover_rx_responses_total{namespace="$namespace"}[2m])) by(HttpStatusCode) |
Table 6-309 Access Token Success
Field | Details |
---|---|
Description | Measures the total number of successful Access Token service
operations at NRF.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(irate(oc_ingressgateway_http_responses_total{Status="200 OK",Route_path=~".*/oauth2/token.*",Method="POST",namespace="$namespace"}[5m])) |
Table 6-310 4xx Responses (AccessToken)
Field | Details |
---|---|
Description | Measures the rate of successful AccessToken requests with 4xx
response at NRF.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(irate(oc_ingressgateway_http_responses_total{Status=~"4.*",Route_path=~".*/oauth2/token*.",namespace="$namespace"}[5m])) |
Table 6-311 5xx Responses (AccessToken)
Field | Details |
---|---|
Description | Measures the rate of successful AccessToken requests with 5xx
response at NRF.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(irate(oc_ingressgateway_http_responses_total{Status=~"5.*",Route_path=~".*/oauth2/token.*",namespace="$namespace"}[5m])) |
Table 6-312 Current KeyId Health
Field | Details |
---|---|
Description | Measures the health status of Oauth Token Signing keys. This is based
on [ KeyId : {{ KeyId }}, KeyType : {{ KeyType }}]
For more information about metric used, see NRF NF Metrics. |
Expression | ocnrf_oauth_keyData_healthStatus{app_kubernetes_io_name=\"nrfconfiguration\",isCurrentKeyId=\"true\",kubernetes_namespace=\"$namespace\"} |
Table 6-313 NF AccessToken Failures
Field | Details |
---|---|
Description | Measures the rate at which NFAccesstoken service requests that NRF
rejects due to various error reasons. This KPI considers all non success
error codes.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(irate(oc_ingressgateway_http_responses_total{Status!~"2.*",Route_path=~".*oauth2/token.*",kubernetes_namespace="$namespace"}[5m])) |
Table 6-314 NF Discover Profile Discovered
Field | Details |
---|---|
Description | Measures the number of Profiles returned in discovery response.
Depending on bucket size and corresponding value will tell how many
profiles are returned in discovery response.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(irate(ocnrf_nfDiscover_profiles_discovered_total{namespace="$namespace"}[2m])) by (Bucket,TargetNfType) |
Table 6-315 Egress Gateway Response for Nrf Forward Response {{ Status }}
Field | Details |
---|---|
Description | Measures the rate of Nrf forward response received. This
is based on {{ Status }} of Nrf Forward Response.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(irate(oc_egressgateway_http_responses_total{namespace="$namespace",Method="GET",NFServiceType="nnrf-disc"}[2m])) by(Status) |
Table 6-316 Egress Gateway Response for SLF Response {{ Status }}
Field | Details |
---|---|
Description | Measures the rate of SLF forward response received. This
is based on {{ Status }} of SLF response.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(irate(oc_egressgateway_http_responses_total{namespace="$namespace",Method="GET",NFServiceType="nudr-group-id-map"}[2m])) by(Status) |
Table 6-317 Ingress Request Rate
Field | Details |
---|---|
Description | Measures the rate of incoming requests at NRF.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(irate(oc_ingressgateway_http_requests_total{container="ingressgateway",namespace="$namespace"}[2m])) |
Table 6-318 Response with 2xx status code
Field | Details |
---|---|
Description | Measures the rate of outgoing response with 2xx status
code.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(irate(oc_ingressgateway_http_responses_total{Status=~"2.*",container="ingressgateway",namespace="$namespace"}[5m])) |
Table 6-319 Response with 4xx status code
Field | Details |
---|---|
Description | Measures the rate of outgoing response with 4xx status
code.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(irate(oc_ingressgateway_http_responses_total{Status=~"4.*",container="ingressgateway",namespace="$namespace"}[5m])) |
Table 6-320 Response with 5xx status code
Field | Details |
---|---|
Description | Measures the rate of outgoing response with 5xx status
code.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(irate(oc_ingressgateway_http_responses_total{Status=~"5.*",container="ingressgateway",namespace="$namespace"}[5m])) |
Table 6-321 NRF Outgoing Response
Field | Details |
---|---|
Description | Measures the rate of outgoing requests at NRF.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(irate(oc_ingressgateway_http_responses_total{app_kubernetes_io_name=\"ingressgateway\",kubernetes_namespace=\"$namespace\"}[5m])) |
Table 6-322 Egress Request Rate
Field | Details |
---|---|
Description | Measures the rate of outgoing requests at NRF.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(irate(oc_egressgateway_http_requests_total{namespace="$namespace"}[5m])) |
Table 6-323 Response with 2xx status code
Field | Details |
---|---|
Description | Measures the rate of outgoing response with 2xx status
code.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(irate(oc_egressgateway_http_responses_total{Status=~"2.*",namespace="$namespace",Direction="egress"}[5m])) |
Table 6-324 Response with 4xx status code
Field | Details |
---|---|
Description | Measures the rate of outgoing response with 4xx status
code.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(irate(oc_egressgateway_http_responses_total{Status=~"4.*",namespace="$namespace",Direction="egress"}[5m])) |
Table 6-325 Response with 5xx status code
Field | Details |
---|---|
Description | Measures the rate of outgoing response with 5xx status
code.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(irate(oc_egressgateway_http_responses_total{Status=~"5.*",namespace="$namespace",Direction="egress"}[5m])) |
Table 6-326 Egress Response Rate
Field | Details |
---|---|
Description | Measures the rate of outgoing requests at NRF.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(irate(oc_egressgateway_http_responses_total{namespace="$namespace",Direction="egressOut"}[5m])) |
Table 6-327 Ingress Request Rate
Field | Details |
---|---|
Description | This metric is pegged for every event occurred when a
request is sent to Ingress Gateway.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(irate(oc_ingressgateway_jetty_request_stat_metrics_total{event="onCommit",app_kubernetes_io_name="ingressgateway",namespace="$namespace"}[2m])) by (pod) |
Table 6-328 Ingress Response Rate
Field | Details |
---|---|
Description | This metric is pegged for every event occurred when a
response is received from Ingress Gateway.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(irate(oc_ingressgateway_jetty_response_stat_metrics_total{event="onComplete",app_kubernetes_io_name="ingressgateway",namespace="$namespace"}[2m])) by (pod) |
Table 6-329 Total Incoming Connections at Pod
Field | Details |
---|---|
Description | Measures the total number of active incoming connections
per Egress Gateway pod.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum by (pod) (oc_egressgateway_incoming_connections{namespace="$namespace"}) |
Table 6-330 Total Incoming Connections
Field | Details |
---|---|
Description | Measures the total number of active incoming connections
from client to Egress Gateway.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum (oc_egressgateway_incoming_connections{namespace="$namespace"}) |
Table 6-331 Total Outgoing Connections at pod
Field | Details |
---|---|
Description | Measures the total number of active outgoing connections per Egress Gateway pod. For more information about metric used, see NRF Gateways Metrics. |
Expression | sum by (pod) (oc_egressgateway_outgoing_connections{namespace="$namespace"}) |
Table 6-332 Total Outgoing Connections
Field | Details |
---|---|
Description | Measures the total number of active outgoing connections from Egress Gateway. For more information about metric used, see NRF Gateways Metrics. |
Expression | sum (oc_egressgateway_outgoing_connections{namespace="$namespace"}) |
Table 6-333 Total Incoming Connections at Pod
Field | Details |
---|---|
Description | Measures the total number of active incoming connections
per Ingress Gateway pod.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum by (pod) (oc_ingressgateway_incoming_connections{namespace="$namespace"}) |
Table 6-334 Total Incoming Connections
Field | Details |
---|---|
Description | Measures the total number of active incoming connections
from client to Ingress Gateway.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum (oc_ingressgateway_incoming_connections{namespace="$namespace"}) |
Table 6-335 Total Outgoing Connections at pod
Field | Details |
---|---|
Description | Measures the total number of active outgoing connections per Ingress Gateway pod. For more information about metric used, see NRF Gateways Metrics. |
Expression | sum by (pod) (oc_ingressgateway_outgoing_connections{namespace="$namespace"}) |
Table 6-336 Total Outgoing Connections
Field | Details |
---|---|
Description | Measures the total number of active outgoing connections from Ingress Gateway. For more information about metric used, see NRF Gateways Metrics. |
Expression | sum (oc_ingressgateway_outgoing_connections{namespace="$namespace"}) |
Table 6-337 SLF Egress Gateway Latency 99%
Field | Details |
---|---|
Description | Measures the number of SLF request falling in 99 percentile of the latency value at Egress Gateway. |
Expression | avg(oc_egressgateway_request_latency_seconds{namespace="$namespace",Method="GET",quantile="0.99"}) |
Table 6-338 SLF Egress Gateway Latency 95%
Field | Details |
---|---|
Description | Measures the number of SLF request falling in 95 percentile of the latency value at Egress Gateway. |
Expression | avg(oc_egressgateway_request_latency_seconds{namespace="$namespace",Method="GET",quantile="0.95"}) |
Table 6-339 SLF Egress Gateway Latency 90%
Field | Details |
---|---|
Description | Measures the number of SLF request falling in 90 percentile of the latency value at Egress Gateway. |
Expression | avg(oc_egressgateway_request_latency_seconds{namespace="$namespace",Method="GET",quantile="0.90"}) |
Table 6-340 SLF Egress Gateway Latency 50%
Field | Details |
---|---|
Description | Measures the number of SLF request falling in 50 percentile of the latency value at Egress Gateway. |
Expression | avg(oc_egressgateway_request_latency_seconds{namespace="$namespace",Method="GET",quantile="0.50"}) |
Table 6-341 NfAccess Token Latency 99%
Field | Details |
---|---|
Description | Measures the average amount of time taken for processing NfAccess token latency falling in 99 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/oauth2/token",Method="POST",quantile="0.99"}) |
Table 6-342 NfAccess Token Latency 95%
Field | Details |
---|---|
Description | Measures the average amount of time taken for processing NfAccess token latency falling in 95 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/oauth2/token",Method="POST",quantile="0.95"}) |
Table 6-343 NfAccess Token Latency 90%
Field | Details |
---|---|
Description | Measures the average amount of time taken for processing NfAccess token latency falling in 90 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/oauth2/token",Method="POST",quantile="0.90"}) |
Table 6-344 NfAccess Token Latency 50%
Field | Details |
---|---|
Description | Measures the average amount of time taken for processing NfAccess token latency falling in 50 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/oauth2/token",Method="POST",quantile="0.50"}) |
Table 6-345 Discovery SLF Latency 99%
Field | Details |
---|---|
Description | Measures the number of SLF discovery request falling in 99 percentile of the latency value. |
Expression | avg(ocnrf_slf_jetty_latency_seconds{namespace="$namespace",ServiceOperation="NfDiscover",quantile="0.99"}) |
Table 6-346 Discovery SLF Latency 90%
Field | Details |
---|---|
Description | Measures the number of SLF discovery request falling in 90 percentile of the latency value. |
Expression | avg(ocnrf_slf_jetty_latency_seconds{namespace="$namespace",ServiceOperation="NfDiscover",quantile="0.9"}) |
Table 6-347 Discovery SLF Latency 50%
Field | Details |
---|---|
Description | Measures the number of SLF discovery request falling in 50 percentile of the latency value. |
Expression | avg(ocnrf_slf_jetty_latency_seconds{namespace="$namespace",ServiceOperation="NfDiscover",quantile="0.5"}) |
Table 6-348 Discovery SLF Latency 95%
Field | Details |
---|---|
Description | Measures the number of SLF discovery request falling in 95 percentile of the latency value. |
Expression | avg(ocnrf_slf_jetty_latency_seconds{namespace="$namespace",ServiceOperation="NfDiscover",quantile="0.95"}) |
Table 6-349 Discovery Latency 99%
Field | Details |
---|---|
Description | Measures the number of discovery request falling in 99 percentile of the latency value. |
Expression | avg(ocnrf_message_processing_time_seconds{namespace="$namespace",ServiceOperation="NfDiscover",quantile="0.99"}) |
Table 6-350 Discovery Latency 90%
Field | Details |
---|---|
Description | Measures the number of discovery request falling in 90 percentile of the latency value. |
Expression | avg(ocnrf_message_processing_time_seconds{namespace="$namespace",ServiceOperation="NfDiscover",quantile="0.9"}) |
Table 6-351 Discovery Latency 50%
Field | Details |
---|---|
Description | Measures the number of discovery request falling in 50 percentile of the latency value. |
Expression | avg(ocnrf_message_processing_time_seconds{namespace="$namespace",ServiceOperation="NfDiscover",quantile="0.5"}) |
Table 6-352 Discovery Latency 95%
Field | Details |
---|---|
Description | Measures the number of discovery request falling in 95 percentile of the latency value. |
Expression | avg(ocnrf_message_processing_time_seconds{namespace="$namespace",ServiceOperation="NfDiscover",quantile="0.95"}) |
Table 6-353 Ingress Gateway Discovery Latency 99%
Field | Details |
---|---|
Description | Measures the number of discovery request falling in 99 percentile of the latency value at Ingress Gateway. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-disc/v1/nf-instances/**",quantile="0.99"}) |
Table 6-354 Ingress Gateway Discovery Latency 90%
Field | Details |
---|---|
Description | Measures the number of discovery request falling in 90 percentile of the latency value at Ingress Gateway. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-disc/v1/nf-instances/**",quantile="0.9"}) |
Table 6-355 Ingress Gateway Discovery Latency 50%
Field | Details |
---|---|
Description | Measures the number of discovery request falling in 50 percentile of the latency value at Ingress Gateway. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-disc/v1/nf-instances/**",quantile="0.5"}) |
Table 6-356 Ingress Gateway Discovery Latency 95%
Field | Details |
---|---|
Description | Measures the number of discovery request falling in 95 percentile of the latency value at Ingress Gateway. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-disc/v1/nf-instances/**",quantile="0.95"}) |
Table 6-357 Ingress Gateway Backend Latency 99%
Field | Details |
---|---|
Description | Measures the number of request falling in 99 percentile of the latency value at Ingress Gateway backend. |
Expression | avg(oc_ingressgateway_server_latency_seconds{namespace="$namespace",quantile="0.99",Method="GET"}) |
Table 6-358 Ingress Gateway Backend Latency 95%
Field | Details |
---|---|
Description | Measures the number of request falling in 95 percentile of the latency value at Ingress Gateway backend. |
Expression | avg(oc_ingressgateway_server_latency_seconds{namespace="$namespace",quantile="0.95",Method="GET"}) |
Table 6-359 Ingress Gateway Backend Latency 90%
Field | Details |
---|---|
Description | Measures the number of request falling in 90 percentile of the latency value at Ingress Gateway backend. |
Expression | avg(oc_ingressgateway_server_latency_seconds{namespace="$namespace",quantile="0.9",Method="GET"}) |
Table 6-360 Discovery Cache Sync
Field | Details |
---|---|
Description | Measures the rate at which in-memory cache entries in the nfdiscovery are synched with Cache Data Service. |
Expression | sum(rate(ocnrf_cache_sync_count_total{namespace="$namespace",container="nfdiscovery"}[2m])) |
Table 6-361 Ingress Gateway Backend Latency 50%
Field | Details |
---|---|
Description | Measures the number of request falling in 50 percentile of the latency value at Ingress Gateway backend. |
Expression | avg(oc_ingressgateway_server_latency_seconds{namespace="$namespace",quantile="0.5",Method="GET"}) |
Table 6-362 Ingress Gateway Latency 99%
Field | Details |
---|---|
Description | Measures the number of request falling in 99 percentile of the latency value at Ingress Gateway. |
Expression | avg(oc_ingressgateway_request_latency_seconds{namespace="$namespace",quantile="0.99",Method="GET"}) |
Table 6-363 Ingress Gateway Latency 95%
Field | Details |
---|---|
Description | Measures the number of request falling in 95 percentile of the latency value at Ingress Gateway. |
Expression | avg(oc_ingressgateway_request_latency_seconds{namespace="$namespace",quantile="0.95",Method="GET"}) |
Table 6-364 Ingress Gateway Latency 90%
Field | Details |
---|---|
Description | Measures the number of request falling in 90 percentile of the latency value at Ingress Gateway. |
Expression | avg(oc_ingressgateway_request_latency_seconds{namespace="$namespace",quantile="0.9",Method="GET"}) |
Table 6-365 Ingress Gateway Latency 50%
Field | Details |
---|---|
Description | Measures the number of request falling in 50 percentile of the latency value at Ingress Gateway. |
Expression | avg(oc_ingressgateway_request_latency_seconds{namespace="$namespace",quantile="0.5",Method="GET"}) |
Table 6-366 Forward Latency 99%
Field | Details |
---|---|
Description | Measures the number of forward request falling in 99 percentile of the latency value. |
Expression | avg(ocnrf_forward_jetty_latency_seconds{namespace="$namespace",ServiceOperation="NfDiscover",quantile="0.99"}) |
Table 6-367 Forward Latency 95%
Field | Details |
---|---|
Description | Measures the number of forward request falling in 95 percentile of the latency value. |
Expression | avg(ocnrf_forward_jetty_latency_seconds{namespace="$namespace",ServiceOperation="NfDiscover",quantile="0.95"}) |
Table 6-368 Forward Latency 90%
Field | Details |
---|---|
Description | Measures the number of forward request falling in 90 percentile of the latency value. |
Expression | avg(ocnrf_forward_jetty_latency_seconds{namespace="$namespace",ServiceOperation="NfDiscover",quantile="0.9"}) |
Table 6-369 Forward Latency 50%
Field | Details |
---|---|
Description | Measures the number of forward request falling in 50 percentile of the latency value. |
Expression | avg(ocnrf_forward_jetty_latency_seconds{namespace="$namespace",ServiceOperation="NfDiscover",quantile="0.5"}) |
Table 6-370 NfStatusSubscribe Latency 99%
Field | Details |
---|---|
Description | Measures the number of NF status subscription request falling in 99 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/subscriptions/**",Method="POST",quantile="0.99"}) |
Table 6-371 NfStatusSubscribe Latency 95%
Field | Details |
---|---|
Description | Measures the number of NF status subscription request falling in 95 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/subscriptions/**",Method="POST",quantile="0.95"}) |
Table 6-372 NfStatusSubscribe Latency 90%
Field | Details |
---|---|
Description | Measures the number of NF status subscription request falling in 90 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/subscriptions/**",Method="POST",quantile="0.9"}) |
Table 6-373 NfStatusSubscribe Latency 50%
Field | Details |
---|---|
Description | Measures the number of NF status subscription request falling in 50 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/subscriptions/**",Method="POST",quantile="0.5"}) |
Table 6-374 NfStatusSubscribe Latency (PATCH) 99%
Field | Details |
---|---|
Description | Measures the number of NF status subscription (PATCH) request falling in 99 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/subscriptions/**",Method="PATCH",quantile="0.99"}) |
Table 6-375 NfStatusSubscribe Latency (PATCH) 95%
Field | Details |
---|---|
Description | Measures the number of NF status subscription (PATCH) request falling in 95 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/subscriptions/**",Method="PATCH",quantile="0.95"}) |
Table 6-376 NfStatusSubscribe Latency (PATCH) 90%
Field | Details |
---|---|
Description | Measures the number of NF status subscription (PATCH) request falling in 90 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/subscriptions/**",Method="PATCH",quantile="0.90"}) |
Table 6-377 NfStatusSubscribe Latency (PATCH) 50%
Field | Details |
---|---|
Description | Measures the number of NF status subscription (PATCH) request falling in 50 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/subscriptions/**",Method="PATCH",quantile="0.50"}) |
Table 6-378 NfStatusUnsubscribe Latency 99%
Field | Details |
---|---|
Description | Measures the number of status unsubscription request falling in 99 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/subscriptions/**",Method="DELETE",quantile="0.99"}) |
Table 6-379 NfStatusUnsubscribe Latency 95%
Field | Details |
---|---|
Description | Measures the number of status unsubscription request falling in 95 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/subscriptions/**",Method="DELETE",quantile="0.95"}) |
Table 6-380 NfStatusUnsubscribe Latency 90%
Field | Details |
---|---|
Description | Measures the number of status unsubscription request falling in 90 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/subscriptions/**",Method="DELETE",quantile="0.90"}) |
Table 6-381 NfStatusUnsubscribe Latency 50%
Field | Details |
---|---|
Description | Measures the number of status unsubscription request falling in 50 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/subscriptions/**",Method="DELETE",quantile="0.50"}) |
Table 6-382 NfNotification trigger Success
Field | Details |
---|---|
Description | Measures the rate of success notification trigger sent to nfSubscription service from the nfregistration and nrfauditor services. |
Expression | sum(rate(ocnrf_nfNotification_trigger_total{errorReason="noError",namespace="$namespace"}[2m])) |
Table 6-383 NfNotification trigger Failure
Field | Details |
---|---|
Description | Measures the rate of error notification trigger sent to nfSubscription service from the nfregistration and nrfauditor services. |
Expression | sum(rate(ocnrf_nfNotification_trigger_total{errorReason!="noError",namespace="$namespace"}[2m])) |
Table 6-384 NfUpdate Latency 99%
Field | Details |
---|---|
Description | Measures the number of update request falling in 99 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/nf-instances/**",Method="PATCH",quantile="0.99"}) |
Table 6-385 NfUpdate Latency 95%
Field | Details |
---|---|
Description | Measures the number of update request falling in 95 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/nf-instances/**",Method="PATCH",quantile="0.95"}) |
Table 6-386 NfUpdate Latency 90%
Field | Details |
---|---|
Description | Measures the number of update request falling in 90 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/nf-instances/**",Method="PATCH",quantile="0.9"}) |
Table 6-387 NfUpdate Latency 50%
Field | Details |
---|---|
Description | Measures the number of update request falling in 50 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/nf-instances/**",Method="PATCH",quantile="0.5"}) |
Table 6-388 NfRegister Latency 99%
Field | Details |
---|---|
Description | Measures the number of register request falling in 99 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/nf-instances/**",Method="PUT",quantile="0.99"}) |
Table 6-389 NfRegister Latency 95%
Field | Details |
---|---|
Description | Measures the number of register request falling in 95 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/nf-instances/**",Method="PUT",quantile="0.95"}) |
Table 6-390 NfRegister Latency 90%
Field | Details |
---|---|
Description | Measures the number of register request falling in 90 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/nf-instances/**",Method="PUT",quantile="0.9"}) |
Table 6-391 NfRegister Latency 50%
Field | Details |
---|---|
Description | Measures the number of register request falling in 50 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/nf-instances/**",Method="PUT",quantile="0.5"}) |
Table 6-392 NfDeregister Latency 99%
Field | Details |
---|---|
Description | Measures the number of deregister request falling in 99 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/nf-instances/**",Method="DELETE",quantile="0.99"}) |
Table 6-393 NfDeregister Latency 95%
Field | Details |
---|---|
Description | Measures the number of deregister request falling in 95 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/nf-instances/**",Method="DELETE",quantile="0.95"}) |
Table 6-394 NfDeregister Latency 90%
Field | Details |
---|---|
Description | Measures the number of deregister request falling in 90 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/nf-instances/**",Method="DELETE",quantile="0.90"}) |
Table 6-395 NfDeregister Latency 50%
Field | Details |
---|---|
Description | Measures the number of deregister request falling in 50 percentile of the latency value. |
Expression | avg(oc_ingressgateway_request_processing_latency_seconds{namespace="$namespace",Route_path="/nnrf-nfm/v1/nf-instances/**",Method="DELETE",quantile="0.50"}) |
Table 6-396 NfDiscovery Database Latency 99%
Field | Details |
---|---|
Description | Measures the number of discovery request falling in 99 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfDiscover",quantile="0.99"}) |
Table 6-397 NfDiscovery Database Latency 95%
Field | Details |
---|---|
Description | Measures the number of discovery request falling in 95 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfDiscover",quantile="0.95"}) |
Table 6-398 NfDiscovery Database Latency 90%
Field | Details |
---|---|
Description | Measures the number of discovery request falling in 90 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfDiscover",quantile="0.90"}) |
Table 6-399 NfDiscovery Database Latency 50%
Field | Details |
---|---|
Description | Measures the number of discovery request falling in 50 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfDiscover",quantile="0.50"}) |
Table 6-400 NfRegistration Database Latency 99%
Field | Details |
---|---|
Description | Measures the number of NfRegistration request falling in 99 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfRegister",quantile="0.99"}) |
Table 6-401 NfRegistration Database Latency 95%
Field | Details |
---|---|
Description | Measures the number of NfRegistration request falling in 95 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfRegister",quantile="0.95"}) |
Table 6-402 NfRegistration Database Latency 90%
Field | Details |
---|---|
Description | Measures the number of NfRegistration request falling in 90 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfRegister",quantile="0.90"}) |
Table 6-403 NfRegistration Database Latency 50%
Field | Details |
---|---|
Description | Measures the number of NfRegistration request falling in 50 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfRegister",quantile="0.50"}) |
Table 6-404 NfUpdate Database Latency 99%
Field | Details |
---|---|
Description | Measures the number of NfUpdate request falling in 99 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfUpdate",quantile="0.99"}) |
Table 6-405 NfUpdate Database Latency 95%
Field | Details |
---|---|
Description | Measures the number of NfUpdate request falling in 95 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfUpdate",quantile="0.95"}) |
Table 6-406 NfUpdate Database Latency 90%
Field | Details |
---|---|
Description | Measures the number of NfUpdate request falling in 90 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfUpdate",quantile="0.90"}) |
Table 6-407 NfUpdate Database Latency 50%
Field | Details |
---|---|
Description | Measures the number of NfUpdate request falling in 50 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfUpdate",quantile="0.50"}) |
Table 6-408 NfHeartBeat Database Latency 99%
Field | Details |
---|---|
Description | Measures the number of NfHeartBeat request falling in 99 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfHeartBeat",quantile="0.99"}) |
Table 6-409 NfHeartBeat Database Latency 95%
Field | Details |
---|---|
Description | Measures the number of NfHeartBeat request falling in 95 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfHeartBeat",quantile="0.95"}) |
Table 6-410 NfHeartBeat Database Latency 90%
Field | Details |
---|---|
Description | Measures the number of NfHeartBeat request falling in 90 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfHeartBeat",quantile="0.9"}) |
Table 6-411 NfHeartBeat Database Latency 50%
Field | Details |
---|---|
Description | Measures the number of NfHeartBeat request falling in 50 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfHeartBeat",quantile="0.5"}) |
Table 6-412 NfDeregister Database Latency 99%
Field | Details |
---|---|
Description | Measures the number of NfDeregister request falling in 99 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfDeregister",quantile="0.99"}) |
Table 6-413 NfDeregister Database Latency 95%
Field | Details |
---|---|
Description | Measures the number of NfDeregister request falling in 95 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfDeregister",quantile="0.95"}) |
Table 6-414 NfDeregister Database Latency 90%
Field | Details |
---|---|
Description | Measures the number of NfDeregister request falling in 90 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfDeregister",quantile="0.90"}) |
Table 6-415 NfDeregister Database Latency 50%
Field | Details |
---|---|
Description | Measures the number of NfDeregister request falling in 50 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfDeregister",quantile="0.50"}) |
Table 6-416 NfSubscribe Database Latency 99%
Field | Details |
---|---|
Description | Measures the number of NfSubscribe request falling in 99 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfSubscribe",quantile="0.99"}) |
Table 6-417 NfSubscribe Database Latency 95%
Field | Details |
---|---|
Description | Measures the number of NfSubscribe request falling in 95 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfSubscribe",quantile="0.95"}) |
Table 6-418 NfSubscribe Database Latency 90%
Field | Details |
---|---|
Description | Measures the number of NfSubscribe request falling in 90 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfSubscribe",quantile="0.90"}) |
Table 6-419 NfSubscribe Database Latency 50%
Field | Details |
---|---|
Description | Measures the number of NfSubscribe request falling in 50 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfSubscribe",quantile="0.50"}) |
Table 6-420 NfUnsubscribe Database Latency 99%
Field | Details |
---|---|
Description | Measures the number of NfUnsubscribe request falling in 99 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfSubscriptions",serviceOperation="NfUnsubscribe",quantile="0.99"}) |
Table 6-421 NfStatusNotify Database Latency 99%
Field | Details |
---|---|
Description | Measures the number of NfStatusNotify request falling in 99 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfSubscriptions",serviceOperation="NfStatusNotify",quantile="0.99"}) |
Table 6-422 NfStatusNotify Database Latency 95%
Field | Details |
---|---|
Description | Measures the number of NfStatusNotify request falling in 95 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfSubscriptions",serviceOperation="NfStatusNotify",quantile="0.95"}) |
Table 6-423 NfStatusNotify Database Latency 90%
Field | Details |
---|---|
Description | Measures the number of NfStatusNotify request falling in 90 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfSubscriptions",serviceOperation="NfStatusNotify",quantile="0.90"}) |
Table 6-424 NfStatusNotify Database Latency 50%
Field | Details |
---|---|
Description | Measures the number of NfStatusNotify request falling in 50 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfSubscriptions",serviceOperation="NfStatusNotify",quantile="0.50"}) |
Table 6-425 NfAccessToken Database Latency 99%
Field | Details |
---|---|
Description | Measures the number of NfAccessToken request falling in 99 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfAccessToken",quantile="0.99"}) |
Table 6-426 NfAccessToken Database Latency 95%
Field | Details |
---|---|
Description | Measures the number of NfAccessToken request falling in 95 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfAccessToken",quantile="0.95"}) |
Table 6-427 NfAccessToken Database Latency 90%
Field | Details |
---|---|
Description | Measures the number of NfAccessToken request falling in 90 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfAccessToken",quantile="0.90"}) |
Table 6-428 NfAccessToken Database Latency 50%
Field | Details |
---|---|
Description | Measures the number of NfAccessToken request falling in 50 percentile of the latency value. |
Expression | avg(ocnrf_dbmetrics_round_trip_time_seconds{namespace="$namespace",tableName="NfInstances",serviceOperation="NfAccessToken",quantile="0.50"}) |
Note:
For example, if min is 0 and max is 100, the number of request falling in 95 percentile, which is quantile="0.95", is measured in the Latency 95% KPI.Table 6-429 NF Profile Size Average
Field | Details |
---|---|
Description | Measures the average size of the NF profiles registered at NRF. For more information about metric used, see NRF NF Metrics. |
Expression | avg by (NfType) (ocnrf_nf_profile_size{namespace="$namespace"})) |
Table 6-430 NF Profile Size Max
Field | Details |
---|---|
Description | Measures the maximum size of the NF profiles registered at NRF. For more information about metric used, see NRF NF Metrics. |
Expression | max by (NfType) (ocnrf_nf_profile_size{namespace="$namespace"}) |
Table 6-431 Discovery Response Size
Field | Details |
---|---|
Description | Measures the NfDiscovery response size.
For more information about metric used, see NRF NF Metrics. |
Expression | histogram_quantile(0.99,sum(rate(ocnrf_nfDiscover_tx_response_size_bytes_bucket{namespace="$namespace",TargetNfType="<NF>"}[2m]))
by (TargetNfType,le))
Where, |
Table 6-432 NF Profile Size Limit Breached
Field | Details |
---|---|
Description | Measures the rate of requests rejected due to breach in nfProfile size limit. |
Expression | sum(rate(ocnrf_nfProfile_size_limit_breached_total{namespace="$namespace"}[2m])) by (NfInstanceId, ServiceOperation) |
6.2.2 Resource Usage KPIs
This section lists the KPIs to measure the CPU, Memory usage, and Kubernetes Horizontal Pod Autoscaling (HPA) counts at NRF. These KPIs are calculated based on Kubernetes metrics.
Table 6-433 nfregistration
Field | Details |
---|---|
Description | Measures the amount of CPU resources consumed by the containers for nfregistration service. |
Expression | sum(rate(container_cpu_usage_seconds_total{container="nfregistration",namespace="$namespace"}[2m])) |
Table 6-434 nfsubscription
Field | Details |
---|---|
Description | Measures the amount of CPU resources consumed by the containers for nfsubscription service. |
Expression | sum(rate(container_cpu_usage_seconds_total{container="nfsubscription",namespace="$namespace"}[2m])) |
Table 6-435 nfdiscovery
Field | Details |
---|---|
Description | Measures the amount of CPU resources consumed by the containers for nfdiscovery service. |
Expression | sum(rate(container_cpu_usage_seconds_total{container="nfdiscovery",namespace="$namespace"}[2m])) |
Table 6-436 nrfauditor
Field | Details |
---|---|
Description | Measures the amount of CPU resources consumed by the containers for nrfauditor service. |
Expression | sum(rate(container_cpu_usage_seconds_total{container="nrfauditor",namespace="$namespace"}[2m])) |
Table 6-437 nfaccesstoken
Field | Details |
---|---|
Description | Measures the amount of CPU resources consumed by the containers for nfaccesstoken service. |
Expression | sum(rate(container_cpu_usage_seconds_total{container="nfaccesstoken",namespace="$namespace"}[2m])) |
Table 6-438 nrfconfiguration
Field | Details |
---|---|
Description | Measures the amount of CPU resources consumed by the containers for nrfconfiguration service. |
Expression | sum(rate(container_cpu_usage_seconds_total{container="nrfconfiguration",namespace="$namespace"}[2m])) |
Table 6-439 ingress-gateway
Field | Details |
---|---|
Description | Measures the amount of CPU resources consumed by the containers for Ingress Gateway service. |
Expression | sum(rate(container_cpu_usage_seconds_total{container="ingressgateway",namespace="$namespace"}[2m])) |
Table 6-440 egress-gateway
Field | Details |
---|---|
Description | Measures the amount of CPU resources consumed by the containers for Egress Gateway service. |
Expression | sum(rate(container_cpu_usage_seconds_total{container="egressgateway",namespace="$namespace"}[2m])) |
Table 6-441 nfregistration
Field | Details |
---|---|
Description | Measures the amount of memory consumed by the containers for nfregistration service. |
Expression | sum (container_memory_usage_bytes{container="nfregistration",namespace="$namespace"}) |
Table 6-442 nfsubscription
Field | Details |
---|---|
Description | Measures the amount of memory consumed by the containers for nfsubscription service. |
Expression | sum (container_memory_usage_bytes{container="nfsubscription",namespace="$namespace"}) |
Table 6-443 nfdiscovery
Field | Details |
---|---|
Description | Measures the amount of memory consumed by the containers for nfdiscovery service. |
Expression | sum (container_memory_usage_bytes{container="nfdiscovery",namespace="$namespace"}) |
Table 6-444 nrfauditor
Field | Details |
---|---|
Description | Measures the amount of memory consumed by the containers for nrfauditor service. |
Expression | sum (container_memory_usage_bytes{container="nrfauditor",namespace="$namespace"}) |
Table 6-445 nfaccesstoken
Field | Details |
---|---|
Description | Measures the amount of memory consumed by the containers for nfaccesstoken service. |
Expression | sum (container_memory_usage_bytes{container="nfaccesstoken",namespace=$namespace"}) |
Table 6-446 nrfconfiguration
Field | Details |
---|---|
Description | Measures the amount of memory consumed by the containers for nrfconfiguration service. |
Expression | sum (container_memory_usage_bytes{container="nrfconfiguration",namespace="$namespace"}) |
Table 6-447 ingress-gateway
Field | Details |
---|---|
Description | Measures the amount of memory consumed by the containers for Ingress Gateway service. |
Expression | sum (container_memory_usage_bytes{container="ingressgateway",namespace="$namespace"}) |
Table 6-448 egress-gateway
Field | Details |
---|---|
Description | Measures the amount of memory consumed by the containers for Egress Gateway service. |
Expression | sum (container_memory_usage_bytes{container="egressgateway",namespace="$namespace"}) |
Table 6-449 ocnrf-ingressgateway
Field | Details |
---|---|
Description | Measures the number of Ingress Gateway replicas currently available and managed by the autoscaler. |
Expression | kube_horizontalpodautoscaler_status_current_replicas{namespace="$namespace",horizontalpodautoscaler=~".*-ingressgateway.*"} |
Table 6-450 ocnrf-nfregistration
Field | Details |
---|---|
Description | Measures the number of nfregistration replicas currently available and managed by the autoscaler. |
Expression | kube_horizontalpodautoscaler_status_current_replicas{namespace="$namespace",horizontalpodautoscaler=~".*-nfregistration.*"} |
Table 6-451 ocnrf-nfsubscription
Field | Details |
---|---|
Description | Measures the number of nfsubscription replicas currently available and managed by the autoscaler. |
Expression | kube_horizontalpodautoscaler_status_current_replicas{namespace="$namespace",horizontalpodautoscaler=~".*-nfsubscription.*"} |
Table 6-452 ocnrf-nfdiscovery
Field | Details |
---|---|
Description | Measures the number of nfdiscovery replicas currently available and managed by the autoscaler. |
Expression | kube_horizontalpodautoscaler_status_current_replicas{namespace="$namespace",horizontalpodautoscaler=~".*-nfdiscovery.*"} |
Table 6-453 ocnrf-nfaccesstoken
Field | Details |
---|---|
Description | Measures the number of nfaccesstoken replicas currently available and managed by the autoscaler. |
Expression | kube_horizontalpodautoscaler_status_current_replicas{namespace="$namespace",horizontalpodautoscaler=~".*-nfaccesstoken.*"} |
Table 6-454 ocnrf-egressgateway
Field | Details |
---|---|
Description | Measures the number of egressgateway replicas currently available and managed by the autoscaler. |
Expression | kube_horizontalpodautoscaler_status_current_replicas{namespace="$namespace",horizontalpodautoscaler=~".*-egressgateway.*"} |
6.2.3 Feature Specific KPIs
This section lists the KPIs related to Global Subscription Limit, Pod Protection, NF FQDN validation, Geo redundancy features at NRF. These KPIs are calculated based on Kubernetes metrics.
6.2.3.1 Global Subscription Limit Feature
6.2.3.1.1 Global Subscription Limit Level
Table 6-455 Active Subscriptions
Field | Details |
---|---|
Description | Measures the total number of active subscriptions. |
Expression | ocnrf_nfset_active_subscriptions{kubernetes_namespace=\"$namespace\"} |
Table 6-456 Subscription Limit level
Field | Details |
---|---|
Description | Measures the subscription limit. |
Expression | ocnrf_nfset_limit_level{kubernetes_namespace=\"$namespace\"} |
6.2.3.1.2 Subscription Limit Breached
Table 6-457 Total NfStatusSubscribe(Create) Rejected
Field | Details |
---|---|
Description | Measures the total number of create subscription requests that are rejected. |
Expression | sum(rate(ocnrf_nfStatusSubscribe_tx_responses_total{namespace="$namespace",RejectionReason="SubscriptionLimitExceeded",OperationType="Create"}[2m])) |
Table 6-458 Total NfStatusSubscribe(Update) Rejected
Field | Details |
---|---|
Description | Measures the total number of update subscription requests that are rejected. |
Expression | sum(rate(ocnrf_nfStatusSubscribe_tx_responses_total{namespace="$namespace",RejectionReason="SubscriptionLimitExceeded",OperationType="Update"}[2m])) |
6.2.3.2 NF FQDN Validation KPIs
This section lists the network function fully qualified domain name (FQDN) validation KPIs at NRF.
Table 6-459 NfRegister - FQDN Validation Failed
Field | Details |
---|---|
Description | Measures the total number of registration request for
which FQDN based authentication failed at NRF. This is based on [ NfFqdn
:- {{ NfFqdn}}].
For more information about metric used, see NF Authentication Metrics. |
Expression | increase(ocnrf_nf_authentication_failure_total{namespace=\"$namespace\",ServiceOperation=\"NfRegister\"}[5m]) |
Table 6-460 NfSubscribe - FQDN Validation Failed
Field | Details |
---|---|
Description | Measures the total number of subscription request for
which FQDN based authentication failed at NRF. This is based on [ NfFqdn
:- {{ NfFqdn}}].
For more information about metric used, see NF Authentication Metrics. |
Expression | increase(ocnrf_nf_authentication_failure_total{namespace=\"$namespace\",ServiceOperation=\"NfStatusSubscribe\"}[5m]) |
Table 6-461 NFDiscover - FQDN Validation Failed
Field | Details |
---|---|
Description | Measures the total number of discovery request for which
FQDN based authentication failed at NRF. This is based on [ NfFqdn :- {{
NfFqdn}}].
For more information about metric used, see NF Authentication Metrics. |
Expression | increase(ocnrf_nf_authentication_failure_total{namespace=\"$namespace\",ServiceOperation=\"NFDiscover\"}[5m]) |
Table 6-462 NFAccessToken - FQDN Validation Failed
Field | Details |
---|---|
Description | Measures the total number of access token request for
which FQDN based authentication failed at NRF. This is based on [ NfFqdn
:- {{ NfFqdn}}].
For more information about metric used, see NF Authentication Metrics. |
Expression | increase(ocnrf_nf_authentication_failure_total{namespace=\"$namespace\",ServiceOperation=\"NFAccessToken\"}[5m]) |
Table 6-463 NFProfileRetrieval - FQDN Validation Failed
Field | Details |
---|---|
Description | Measures the total number of profile retrieval request
for which FQDN based authentication failed at NRF. This is based on [
NfFqdn :- {{ NfFqdn}}].
For more information about metric used, see NF Authentication Metrics. |
Expression | increase(ocnrf_nf_authentication_failure_total{namespace=\"$namespace\",ServiceOperation=\"NFProfileRetrieval\"}[5m]) |
Table 6-464 NFListRetrieval - FQDN Validation Failed
Field | Details |
---|---|
Description | Measures the total number of NF list retrieval request
for which FQDN based authentication failed at NRF. This is based on [
NfFqdn :- {{ NfFqdn}}].
For more information about metric used, see NF Authentication Metrics. |
Expression | increase(ocnrf_nf_authentication_failure_total{namespace=\"$namespace\",ServiceOperation=\"NFListRetrieval\"}[5m]) |
6.2.3.3 Georedundancy KPIs
This section lists the georedundancy KPIs at NRF.
Table 6-465 Total NFs switch over
Field | Details |
---|---|
Description | Measures the number of NFInstances that got switched over
from the mated site. This is based on [ ServiceOperation :- {{
Service_Operation }} ,RemoteNrfInstanceId :- {{ RemoteNrfInstanceId }}].
For more information about metric used, see Georedundancy Metrics. |
Expression | increase(ocnrf_nf_switch_over_total{kubernetes_namespace=\"$namespace\"}[5m]) |
Table 6-466 Total Subscriptions switch over
Field | Details |
---|---|
Description | Measures the number of NfSubscriptions that got switched
over from the mated site. This is based on [ ServiceOperation :- {{
ServiceOperation }} RemoteNrfInstanceId :- {{ RemoteNrfInstanceId }}].
For more information about metric used, see Georedundancy Metrics. |
Expression | increase(ocnrf_nfSubscriptions_switch_over_total{kubernetes_namespace=\"$namespace\"}[5m]) |
Table 6-467 Total Stale NFs deleted
Field | Details |
---|---|
Description | Measures the number of NfInstances that get deleted by
the NrfAuditor when it detects a record to be stale.
For more information about metric used, see Georedundancy Metrics. |
Expression | increase(ocnrf_stale_nf_deleted_total{namespace="$namespace"}[5m]) |
Table 6-468 Total Stale Subscriptions deleted
Field | Details |
---|---|
Description | Measures the number of NfSubscriptions that get deleted
by the NrfAuditor when it detects a record to be stale.
For more information about metric used, see Georedundancy Metrics. |
Expression | increase(ocnrf_stale_nfSubscriptions_deleted_total{namespace="$namespace"}[5m]) |
6.2.3.4 Subscription Pod Protection
Table 6-469 Subscription Pod Overall Congestion State
Field | Details |
---|---|
Description | Tracks the overall congestion state per nfSubscription pod. |
Expression | sum(ocnrf_pod_congestion_state{namespace='$namespace'}) by (pod) |
Table 6-470 Subscription Pod CPU Congestion state
Field | Details |
---|---|
Description | Tracks the congestion state based on the CPU usage of the subscription pod. |
Expression | sum(ocnrf_pod_cpu_congestion_state{namespace='$namespace'}) by (pod) |
Table 6-471 Subscription Pod CPU Usage
Field | Details |
---|---|
Description | Measures the CPU usage of the pod. |
Expression | sum(ocnrf_pod_cpu_usage{namespace="$namespace",container="nfsubscription"}) by (pod) |
Table 6-472 Subscription Pod Pending Message Count Congestion state
Field | Details |
---|---|
Description | Tracks the congestion state based on the pending message count of the subscription pod. |
Expression | sum(ocnrf_pod_pending_message_count_congestion_state{namespace='$namespace'}) by (pod) |
Table 6-473 Subscription Pod Pending Message Count
Field | Details |
---|---|
Description | Measures the Pending Message Count value of the pod. |
Expression | sum(ocnrf_pod_pending_message_count{namespace="$namespace",container="nfsubscription"}) by (pod) |
Table 6-474 Subscription Pod Incoming Connections Rejected
Field | Details |
---|---|
Description | Measures the number of connections that have been rejected in the DoC or Congested state. This is based on {{pod }}. |
Expression | sum(rate(ocnrf_pod_incoming_connection_rejected_total{namespace="$namespace"}[2m])) by (pod) |
Table 6-475 Incoming Connections
Field | Details |
---|---|
Description | Tracks the number of incoming connections. This is based on {{pod }}. |
Expression | sum(irate(ocnrf_incoming_connections{namespace="$namespace"}[2m])) by (pod) |
Table 6-476 Max Streams
Field | Details |
---|---|
Description | Tracks the maximum concurrent streams per connection. This is based on {{ pod }} : {{ connectionId }}. |
Expression | sum(ocnrf_max_concurrent_streams{namespace="$namespace"}) by(pod,connectionId) |
6.2.3.5 Controlled Shutdown of NRF
This section lists the controlled shutdown KPIs at NRF.
Table 6-477 Operational State {{ pod }}
Field | Details |
---|---|
Description | Measures the Operational State of NRF.
The metric is pegged in the NrfAuditor microservice. If any one of the NrfAuditor pod shows the operational state as COMPLETE_SHUTDOWN, then the state shall be considered as Complete Shutdown. For more information about metric used, see NRF NF Metrics. |
Expression | sum(ocnrf_operational_state{namespace="$namespace"}) by (pod) |
Table 6-478 NRF Audit status
Field | Details |
---|---|
Description | Measures the audit status of NRF.
The metric is pegged in the NrfAuditor microservice. If any one of the NrfAuditor pod shows the audit state as paused then the audit status is considered as paused. For more information about metric used, see NRF NF Metrics. |
Expression | sum(ocnrf_audit_status{namespace="$namespace"}) |
6.2.3.6 Network Slice Specific KPIs
This section lists the network slice specific KPIs at NRF.
Table 6-479 Request [sNssai: {{ sNssai }}]
Field | Details |
---|---|
Description | Measures the total number of NfRegister requests received
at a slice that is identified by specific SNSSAI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfRegister_requests_perSnssai_total{namespace="$namespace"}[2m])) by(sNssai) |
Table 6-480 Success [sNssai:{{ sNssai }}]
Field | Details |
---|---|
Description | Measures the total number of NfRegister successful
response sent per slice that is identified by specific SNSSAI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfRegister_success_responses_perSnssai_total{namespace="$namespace"}[5m])) by (sNssai) |
Table 6-481 Failures [sNssai: {{ sNssai }}]
Field | Details |
---|---|
Description | Measures the total number of NfRegister failure response
sent per slice that is identified by specific SNSSAI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfRegister_failure_responses_perSnssai_total{namespace="$namespace"}[2m])) by (sNssai) |
Table 6-482 Request [sNssai: {{ sNssai }}]
Field | Details |
---|---|
Description | Measures the total number of NfDeregister requests
received at a slice that is identified by specific SNSSAI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfDeregister_requests_perSnssai_total{namespace="$namespace"}[2m])) by(sNssai) |
Table 6-483 Success [sNssai:{{ sNssai }}]
Field | Details |
---|---|
Description | Measures the total number of NfDeregister successful
response sent per slice that is identified by specific SNSSAI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfDeregister_success_responses_perSnssai_total{namespace="$namespace"}[5m])) by (sNssai) |
Table 6-484 Failures [sNssai: {{ sNssai }}]
Field | Details |
---|---|
Description | Measures the total number of NfDeregister failure
response sent per slice that is identified by specific SNSSAI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfDeregister_failure_responses_perSnssai_total{namespace="$namespace"}[2m])) by (sNssai) |
Table 6-485 Success [Nsi :{{ Nsi }}]
Field | Details |
---|---|
Description | Measures the total number of NfDeregister successful
response sent per slice that is identified by specific NSI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfDeregister_success_responses_perNsi_total{namespace="$namespace"}[5m])) by (Nsi) |
Table 6-486 Failures [Nsi :{{ Nsi }}]
Field | Details |
---|---|
Description | Measures the total number of NfDeregister failure
response sent per slice that is identified by specific NSI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfDeregister_failure_responses_perNsi_total{namespace="$namespace"}[2m])) by (Nsi) |
Table 6-487 Requests [sNssai: {{ sNssai }}]
Field | Details |
---|---|
Description | Measures the total number of NfUpdate requests received
at a slice that is identified by specific SNSSAI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfUpdate_requests_perSnssai_total{namespace="$namespace"}[2m])) by(sNssai) |
Table 6-488 Success [sNssai:{{ sNssai }}]
Field | Details |
---|---|
Description | Measures the total number of NfUpdate successful response
sent per slice that is identified by specific SNSSAI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfUpdate_success_responses_perSnssai_total{namespace="$namespace"}[5m])) by (sNssai) |
Table 6-489 Failures [sNssai: {{ sNssai }}]
Field | Details |
---|---|
Description | Measures the total number of NfUpdate failure response
sent per slice that is identified by specific SNSSAI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfUpdate_failure_responses_perSnssai_total{namespace="$namespace"}[2m])) by (sNssai) |
Table 6-490 Requests [Nsi: {{ Nsi }}]
Field | Details |
---|---|
Description | Measures the total number of NfUpdate requests received
at a slice that is identified by specific NSI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfUpdate_requests_perNsi_total{namespace="$namespace"}[2m])) by(Nsi) |
Table 6-491 Success [Nsi :{{ Nsi }}]
Field | Details |
---|---|
Description | Measures the total number of NfUpdate successful response
sent per slice that is identified by specific NSI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfUpdate_success_responses_perNsi_total{namespace="$namespace"}[5m])) by (Nsi) |
Table 6-492 Failures [Nsi :{{ Nsi }}]
Field | Details |
---|---|
Description | Measures the total number of NfUpdate failure response
sent per slice that is identified by specific NSI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfUpdate_failure_responses_perNsi_total{namespace="$namespace"}[2m])) by (Nsi) |
Table 6-493 Requests [sNssai: {{ sNssai }}]
Field | Details |
---|---|
Description | Measures the total number of NF HeartBeat requests
received at a slice that is identified by specific SNSSAI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfHeartBeat_requests_perSnssai_total{namespace="$namespace"}[2m])) by(sNssai) |
Table 6-494 Success [sNssai:{{ sNssai }}]
Field | Details |
---|---|
Description | Measures the total number of NF HeartBeat successful
response sent per slice that is identified by specific SNSSAI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfHeartBeat_success_responses_perSnssai_total{namespace="$namespace"}[5m])) by (sNssai) |
Table 6-495 Failures [sNssai: {{ sNssai }}]
Field | Details |
---|---|
Description | Measures the total number of NF HeartBeat failure
response sent per slice that is identified by specific SNSSAI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfHeartBeat_failure_responses_perSnssai_total{namespace="$namespace"}[2m])) by (sNssai) |
Table 6-496 Requests [Nsi: {{ Nsi }}]
Field | Details |
---|---|
Description | Measures the total number of NF HeartBeat requests
received at a slice that is identified by specific NSI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfHeartBeat_requests_perNsi_total{namespace="$namespace"}[2m])) by(Nsi) |
Table 6-497 Success [Nsi :{{ Nsi }}]
Field | Details |
---|---|
Description | Measures the total number of NF HeartBeat successful
response sent per slice that is identified by specific NSI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfHeartBeat_success_responses_perNsi_total{namespace="$namespace"}[5m])) by (Nsi) |
Table 6-498 Failures [Nsi :{{ Nsi }}]
Field | Details |
---|---|
Description | Measures the total number of NF HeartBeat failure
response sent per slice that is identified by specific NSI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfHeartBeat_failure_responses_perNsi_total{namespace="$namespace"}[2m])) by (Nsi) |
Table 6-499 Requests [sNssai: {{ sNssai }}]
Field | Details |
---|---|
Description | Measures the total number of NfDiscovery requests
received at a slice that is identified by specific SNSSAI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfDiscover_rx_requests_perSnssai_total{namespace="$namespace"}[2m])) by(sNssai) |
Table 6-500 Success [sNssai:{{ sNssai }}]
Field | Details |
---|---|
Description | Measures the total number of NfDiscovery successful
response sent per slice that is identified by specific SNSSAI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfDiscover_tx_success_response_perSnssai_total{namespace="$namespace"}[5m])) by (sNssai) |
Table 6-501 Failures [sNssai: {{ sNssai }}]
Field | Details |
---|---|
Description | Measures the total number of NfDiscovery failure response
sent per slice that is identified by specific SNSSAI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfDiscover_tx_failure_response_perSnssai_total{namespace="$namespace"}[2m])) by (sNssai) |
Table 6-502 Empty [sNssai: {{ sNssai }}]
Field | Details |
---|---|
Description | Measures the total number of NfDiscovery empty response
sent per slice that is identified by specific SNSSAI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfDiscover_tx_empty_response_perSnssai_total{namespace="$namespace"}[2m])) by (sNssai) |
Table 6-503 Requests [Nsi: {{ Nsi }}]
Field | Details |
---|---|
Description | Measures the total number of NfDiscovery requests
received at a slice that is identified by specific NSI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfDiscover_rx_requests_perNsi_total{namespace="$namespace"}[2m])) by(Nsi) |
Table 6-504 Success [Nsi :{{ Nsi }}]
Field | Details |
---|---|
Description | Measures the total number of nfDiscovery successful
response sent per slice that is identified by specific NSI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfDiscover_tx_success_response_perNsi_total{namespace="$namespace"}[5m])) by (Nsi) |
Table 6-505 Failures [Nsi :{{ Nsi }}]
Field | Details |
---|---|
Description | Measures the total number of NfDiscovery failure response
sent per slice that is identified by specific NSI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfDiscover_tx_failure_response_perNsi_total{namespace="$namespace"}[2m])) by (Nsi) |
Table 6-506 Empty [Nsi: {{ Nsi }}]
Field | Details |
---|---|
Description | Measures the total number of NfDiscovery empty response
sent per slice that is identified by specific NSI.
For more information about metric used, see Network Slice Specific Metrics. |
Expression | sum(irate(ocnrf_nfDiscover_tx_empty_response_perNsi_total{namespace="$namespace"}[2m])) by (Nsi) |
6.2.3.7 SCP Health Status
This section lists the controlled shutdown KPIs at NRF.
Table 6-507 Available Peers {{peerset}}
Field | Details |
---|---|
Description | Measures the total number of available peers in a
peerset.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(oc_egressgateway_peer_available_count{namespace="$namespace"}) by (peerset) |
Table 6-508 Ping Request
Field | Details |
---|---|
Description | Measures the rate of Ping Requests to the peers.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(irate(oc_egressgateway_peer_health_ping_request_total{namespace="$namespace"}[2m])) |
Table 6-509 Ping Response {{ status }}
Field | Details |
---|---|
Description | Measures the rate of Ping Responses to the peers.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(irate(oc_egressgateway_peer_health_ping_response_total{namespace="$namespace"}[2m])) by (status) |
Table 6-510 SCP health status {{ peer }}
Field | Details |
---|---|
Description | Measures the health status of the peer.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(oc_egressgateway_peer_health_status{namespace="$namespace"}) by (peer) |
Table 6-511 Total Peers {{peerset}}
Field | Details |
---|---|
Description | Measures the total number of peers in a peerset.
For more information about metric used, see NRF Gateways Metrics. |
Expression | sum(oc_egressgateway_peer_count{namespace="$namespace"}) by (peerset) |
6.2.3.8 Ingress Gateway Pod Protection
Table 6-512 OCNRF Ingress-Gateway Pod Overall Congestion State
Field | Details |
---|---|
Description | Indicates the current state of the Ingress Gateway pod. |
Expression | sum(oc_ingressgateway_pod_congestion_state{namespace='$namespace'}) by (pod) |
Table 6-513 OCNRF Ingress-Gateway Pod CPU Congestion State
Field | Details |
---|---|
Description | Tracks the CPU utilization based on which Ingress Gateway pod is calculating its congestion state. |
Expression | sum(oc_ingressgateway_pod_resource_state{type="CPU",namespace='$namespace'}) by (pod) |
Table 6-514 OCNRF Ingress-Gateway Pod CPU Usage
Field | Details |
---|---|
Description | Tracks the CPU utilization based on which Ingress Gateway pod is calculating its congestion state. |
Expression | sum(oc_ingressgateway_pod_resource_stress{type="CPU",namespace='$namespace'}) by (pod) |
Table 6-515 OCNRF Ingress-Gateway Incoming Pod Connections Rejected
Field | Details |
---|---|
Description | Tracks the number of connections dropped at Congested or DOC state. |
Expression | sum(irate(oc_ingressgateway_incoming_pod_connections_rejected_total{namespace="$namespace"}[5m])) by (pod) |
Table 6-516 OCNRF Ingress-Gateway Pod Pending Message Congestion State
Field | Details |
---|---|
Description | Tracks the congestion state based on the pending message count of the Ingress Gateway pod. |
Expression | sum(oc_ingressgateway_pod_resource_state{type="PENDING_REQUEST",namespace='$namespace'}) by (pod) |
Table 6-517 OCNRF Ingress Gateway Pod Pending Messages
Field | Details |
---|---|
Description | Measures the pending message count usage of the Ingress Gateway pod. |
Expression | sum(oc_ingressgateway_pod_resource_stress{type="PENDING_REQUEST",namespace='$namespace'}) by (pod) |
6.2.3.9 NRF Growth Specific KPIs
Table 6-518 Total Number of CDS Requests
Field | Details |
---|---|
Description | Measures the rate of incoming requests at Cache Data Service. |
Expression | sum(rate(ocnrf_cds_rx_requests_total{namespace="$namespace"}[2m])) |
Table 6-519 Total Number of CDS Responses
Field | Details |
---|---|
Description | Measures the rate of responses from Cache Data Service. |
Expression | sum(rate(ocnrf_cds_tx_responses_total{namespace="$namespace"}[2m]))
by (HttpStatusCode) |
Table 6-520 Total Number of CDS Requests per Service Operation
Field | Details |
---|---|
Description | Measures the rate of outgoing requests by local NRF microservices to Cache Data Service for state data. |
Expression | sum(rate(ocnrf_query_cds_requests_total{namespace="$namespace"}[2m]))
by (ServiceOperation) |
Table 6-521 Total Number of CDS Responses per Service Operation
Field | Details |
---|---|
Description | Measures the rate of response received by local NRF microservices from Cache Data Service for state data. |
Expression | sum(rate(ocnrf_query_cds_responses_total{namespace="$namespace"}[2m]))
by (ServiceOperation,HttpStatusCode) |
Table 6-522 CDS Latency 50%
Field | Details |
---|---|
Description | Measures the average amount of time taken to process the requests by Cache Data Service at the 50 percentile of the latency value. |
Expression | avg(ocnrf_cds_round_trip_time_seconds{namespace="$namespace",quantile="0.5"}) |
Table 6-523 CDS Latency 90%
Field | Details |
---|---|
Description | Measures the average amount of time taken to process the requests by Cache Data Service at the 90 percentile of the latency value. |
Expression | avg(ocnrf_cds_round_trip_time_seconds{namespace="$namespace",quantile="0.9"}) |
Table 6-524 CDS Latency 95%
Field | Details |
---|---|
Description | Measures the average amount of time taken to process the requests by Cache Data Service at the 95 percentile of the latency value. |
Expression | avg(ocnrf_cds_round_trip_time_seconds{namespace="$namespace",quantile="0.95"}) |
Table 6-525 CDS Latency 99%
Field | Details |
---|---|
Description | Measures the average amount of time taken to process the requests by Cache Data Service at the 99 percentile of the latency value. |
Expression | avg(ocnrf_cds_round_trip_time_seconds{namespace="$namespace",quantile="0.99"}) |
Table 6-526 CDS Request Latency 99% for NfAccessToken Service Operation
Field | Details |
---|---|
Description | Measures the average amount of time taken for querying state data from Cache Data Service for NfAccessToken service operation at the 99 percentile of the latency value. |
Expression | avg(ocnrf_query_cds_round_trip_time_seconds{namespace="$namespace",quantile="0.99",ServiceOperation="NfAccessToken"}) |
Table 6-527 CDS Request Latency 99% for NfDiscover Service Operation
Field | Details |
---|---|
Description | Measures the average amount of time taken for querying state data from Cache Data Service for NfDiscover service operation at the 99 percentile of the latency value. |
Expression | avg(ocnrf_query_cds_round_trip_time_seconds{namespace="$namespace",quantile="0.99",ServiceOperation="NfDiscover"}) |
Table 6-528 CDS Request Latency 99% for NfListRetrieval Service Operation
Field | Details |
---|---|
Description | Measures the average amount of time taken for querying state data from Cache Data Service for NfListRetrieval service operation at the 99 percentile of the latency value. |
Expression | avg(ocnrf_query_cds_round_trip_time_seconds{namespace="$namespace",quantile="0.99",ServiceOperation="NfListRetrieval"}) |
Table 6-529 CDS Request Latency 99% for NfProfileRetrieval Service Operation
Field | Details |
---|---|
Description | Measures the average amount of time taken for querying state data from Cache Data Service for NfProfileRetrieval service operation at the 99 percentile of the latency value. |
Expression | avg(ocnrf_query_cds_round_trip_time_seconds{namespace="$namespace",quantile="0.99",ServiceOperation="NfProfileRetrieval"}) |
Table 6-530 CDS Request Latency 99% for NfSubscribe Service Operation
Field | Details |
---|---|
Description | Measures the average amount of time taken for querying state data from Cache Data Service for NfSubscribe service operation at the 99 percentile of the latency value. |
Expression | avg(ocnrf_query_cds_round_trip_time_seconds{namespace="$namespace",quantile="0.99",ServiceOperation="NfSubscribe"}) |
Table 6-531 CDS Request Latency 99% for NfUnsubscribe Service Operation
Field | Details |
---|---|
Description | Measures the average amount of time taken for querying state data from Cache Data Service for NfUnsubscribe service operation at the 99 percentile of the latency value. |
Expression | avg(ocnrf_query_cds_round_trip_time_seconds{namespace="$namespace",quantile="0.99",ServiceOperation="NfUnsubscribe"}) |
Table 6-532 CDS Request Latency 99% for notifyProfileDeregistration Service Operation
Field | Details |
---|---|
Description | Measures the average amount of time taken for querying state data from Cache Data Service for notifyProfileDeregistration service operation at the 99 percentile of the latency value. |
Expression | avg(ocnrf_query_cds_round_trip_time_seconds{namespace="$namespace",quantile="0.99",ServiceOperation="notifyProfileDeregistration"}) |
Table 6-533 CDS Request Latency 99% for notifyProfileRegistration Service Operation
Field | Details |
---|---|
Description | Measures the average amount of time taken for querying state data from Cache Data Service for notifyProfileRegistration service operation at the 99 percentile of the latency value. |
Expression | avg(ocnrf_query_cds_round_trip_time_seconds{namespace="$namespace",quantile="0.99",ServiceOperation="notifyProfileRegistration"}) |
Table 6-534 CDS Request Latency 99% for notifyProfileChange Service Operation
Field | Details |
---|---|
Description | Measures the average amount of time taken for querying state data from Cache Data Service for notifyProfileChange service operation at the 99 percentile of the latency value. |
Expression | avg(ocnrf_query_cds_round_trip_time_seconds{namespace="$namespace",quantile="0.99",ServiceOperation="notifyProfileChange"}) |
Table 6-535 CDS Request Latency 99% for nrfauditor Service Operation
Field | Details |
---|---|
Description | Measures the average amount of time taken for querying state data from Cache Data Service for nrfauditor service operation at the 99 percentile of the latency value. |
Expression | avg(ocnrf_query_cds_round_trip_time_seconds{namespace="$namespace",quantile="0.99",ServiceOperation="nrfauditor"}) |
Table 6-536 Total Number of CDS Requests per Request Type
Field | Details |
---|---|
Description | Measures the rate of incoming requests at Cache Data Service per request type. |
Expression | sum(rate(ocnrf_cds_rx_requests_total{namespace="$namespace"}[2m]))
by (RequestType) |
Table 6-537 Total Number of CDS Responses per Request Type
Field | Details |
---|---|
Description | Measures the rate of responses from Cache Data Service per request type. |
Expression | sum(rate(ocnrf_cds_tx_responses_total{namespace="$namespace"}[2m]))
by (RequestType, HttpStatusCode) |
Table 6-538 Total Number of Remote CDS Requests
Field | Details |
---|---|
Description | Measures the rate of requests sent to the NRF of a remote NRF set by Cache Data Service. |
Expression | sum(rate(ocnrf_query_remote_cds_requests_total{namespace="$namespace"}[2m]))
by (TargetNrfSetId) |
Table 6-539 Total Number of Remote CDS Responses
Field | Details |
---|---|
Description | Indicates the total number of responses received from the NRF in the remote set. |
Expression | sum(rate(ocnrf_query_remote_cds_responses_total{namespace="$namespace"}[2m]))
by (TargetNrfSetId, HttpStatusCode) |
Table 6-540 Remote CDS Query Latency 50%
Field | Details |
---|---|
Description | Measures the average amount of time taken to process the requests sent by Cache Data Service towards remote NRF set and response received at the 50 percentile of the latency value. |
Expression | avg(ocnrf_query_remote_cds_round_trip_time_seconds{namespace="$namespace",quantile="0.5"}) |
Table 6-541 Remote CDS Query Latency 90%
Field | Details |
---|---|
Description | Measures the average amount of time taken to process the requests sent by Cache Data Service towards remote NRF set and response received at the 90 percentile of the latency value. |
Expression | avg(ocnrf_query_remote_cds_round_trip_time_seconds{namespace="$namespace",quantile="0.9"}) |
Table 6-542 Remote CDS Query Latency 95%
Field | Details |
---|---|
Description | Measures the average amount of time taken to process the requests sent by Cache Data Service towards remote NRF set and response received at the 95 percentile of the latency value. |
Expression | avg(ocnrf_query_remote_cds_round_trip_time_seconds{namespace="$namespace",quantile="0.95"}) |
Table 6-543 Remote CDS Query Latency 99%
Field | Details |
---|---|
Description | Measures the average amount of time taken to process the requests sent by Cache Data Service towards remote NRF set and response received at the 99 percentile of the latency value. |
Expression | avg(ocnrf_query_remote_cds_round_trip_time_seconds{namespace="$namespace",quantile="0.99"}) |
Table 6-544 Database Fallback
Field | Details |
---|---|
Description | Measures the rate at which the service request was fulfilled from the database by the NRF microservices as the query towards the Cache Data Service failed. |
Expression | sum(rate(ocnrf_db_fallback_total{namespace="$namespace"}[2m]))
by (ServiceOperation) |
Table 6-545 CDS Cache Sync
Field | Details |
---|---|
Description | Measures the rate at which state data entries are synched from the local database at CDS. |
Expression | sum(rate(ocnrf_cache_sync_count_total{namespace="$namespace",container="nrfcachedata"}[2m])) |
6.2.3.10 Egress Gateway Pod Throttling
Table 6-546 Egress Gateway Discards Due To Rate Limit
Field | Details |
---|---|
Description | Measures the requests discarded by Egress Gateway due to Egress
Gateway Pod Throttling feature.
For more information about metric used, see Egress Gateway Metrics. |
Expression | sum(rate(oc_egressgateway_podlevel_throttling_discarded_total{namespace="$namespace"}[2m])) by (pod) |
6.2.3.11 Ingress Gateway Pod Protection Using Rate Limiting
Table 6-547 Allowed Request Rate Per Route Id
Field | Details |
---|---|
Description | Measures the request rate allowed per Route Id.
For more information about metric used, see Ingress Gateway Metrics. |
Expression | sum(irate(oc_ingressgateway_http_request_ratelimit_values_total{Allowed="true",namespace="$namespace"}[2m])) by (Id) |
Table 6-548 Total Rejections Chain Length
Field | Details |
---|---|
Description | Measures the number of consecutive rejects before a successful
accept. The metric indicates rejections due to traffic burst.
For more information about metric used, see Ingress Gateway Metrics. |
Expression | sum(rate(oc_ingressgateway_http_request_ratelimit_reject_chain_length_histogram_bucket{namespace="$namespace"}[2m])) by (le) |
Table 6-549 Discard Request Action Traffic Rate
Field | Details |
---|---|
Description | Measures the rate of requests rejected or processed based on the
discard request action.
For more information about metric used, see Ingress Gateway Metrics. |
Expression | sum(irate(oc_ingressgateway_http_request_ratelimit_denied_count_total{namespace="$namespace"}[2m])) by (Action) |
Table 6-550 Pod Congestion Level
Field | Details |
---|---|
Description | Measures the congestion level of the pod.
For more information about metric used, see Ingress Gateway Metrics. |
Expression | sum(rate(oc_ingressgateway_congestion_level_bucket_total{namespace="$namespace"}[2m])) by (le) |
6.3 NRF Alerts
This section includes information about the NRF alerts.
The following table describes the various alert levels generated by NRF:
Table 6-551 Alerts Levels or Severity Types
Alerts Levels/Severity Types | Definition |
---|---|
Critical | Indicates a severe issue that poses a significant risk to safety, security, or operational integrity. It requires immediate response to address the situation and prevent serious consequences. Raised for conditions may affect the service of NRF. |
Major | Indicates a more significant issue that has an impact on operations or poses a moderate risk. It requires prompt attention and action to mitigate potential escalation. Raised for conditions may affect the service of NRF. |
Minor | Indicates a situation that is low in severity and does not pose an immediate risk to safety, security, or operations. It requires attention but does not demand urgent action. Raised for conditions may affect the service of NRF. |
Info or Warn (Informational) | Provides general information or updates that are not related to immediate risks or actions. These alerts are for awareness and do not typically require any specific response. WARN and INFO alerts may not impact the service of NRF. |
Note:
- Summary or dimensions may vary based on deployment.
- The alert triggering time varies as per the environment in which it is deployed.
- The performance and capacity of the NRF system may vary based on the call model, Feature or Interface configuration, and underlying CNE and hardware environment.
6.3.1 System Level Alerts
This section lists the system level alerts.
6.3.1.1 OcnrfNfStatusUnavailable
Table 6-552 OcnrfNfStatusUnavailable
Field | Details |
---|---|
Description | 'OCNRF services unavailable' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : All OCNRF services are unavailable.' |
Severity | Critical |
Condition | When all the NRF services are unavailable, either because the NRF is getting deployed or purged. The NRF services considered are nfregistration, nfsubscription, nrfauditor, nrfconfiguration, nfaccesstoken, nfdiscovery, appinfo, ingressgateway, and egressgateway. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7016 |
Metric Used |
'up' Note: This is a Prometheus metric used for instance availability monitoring. If this metric is not available, use a similar metric as exposed by the monitoring system. |
Recommended Actions | The alert is cleared automatically when the NRF services
restart.
Steps:
|
Available in OCI | No |
6.3.1.2 OcnrfPodsRestart
Table 6-553 OcnrfPodsRestart
Field | Details |
---|---|
Description | 'Pod <Pod Name> has restarted. |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : A Pod has restarted' |
Severity | Major |
Condition | A pod belonging to any of the NRF services have restarted. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7017 |
Metric Used | 'kube_pod_container_status_restarts_total'
Note: This is a Kubernetes metric. If this metric is not available, use a similar metric as exposed by the monitoring system. |
Recommended Actions |
The alert is cleared automatically if the specific pod is up. Steps:
|
Available in OCI | No |
6.3.1.3 NnrfNFManagementServiceDown
Table 6-554 NnrfNFManagementServiceDown
Field | Details |
---|---|
Description | 'OCNRF Nnrf_Management service <nfregistration|nfsubscription|nrfauditor> is down' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : NFManagement service is down' |
Severity | Critical |
Condition | This alert is raised when either NFRegistration, NFSubscription, or NrfAuditor services are unavailable. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7018 |
Metric Used | ''up'
Note: This is a Prometheus metric used for instance availability monitoring. If this metric is not available, use a similar metric as exposed by the monitoring system. |
Recommended Actions | The alert is cleared when all the Nnrf_NFManagement
services nfregistration, nfsubscription, and nrfauditor are available.
Steps:
|
Available in OCI | No |
6.3.1.4 NnrfAccessTokenServiceDown
Table 6-555 NnrfAccessTokenServiceDown
Field | Details |
---|---|
Description | 'OCNRF Nnrf_NFAccessToken service nfaccesstoken is down' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : NFAccessToken service down' |
Severity | Critical |
Condition | This alert is raised when NFAccessToken service is unavailable. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7020 |
Metric Used | ''up''
Note: This is a Prometheus metric used for instance availability monitoring. If this metric is not available use a similar metric as exposed by the monitoring system. |
Recommended Actions | The alert is cleared when the Nnrf_AccessToken service
is available.
Steps:
|
Available in OCI | No |
6.3.1.5 NnrfNFDiscoveryServiceDown
Table 6-556 NnrfNFDiscoveryServiceDown
Field | Details |
---|---|
Description | 'OCNRF Nnrf_NFDiscovery service nfdiscovery is down' |
Applicable in OCI | No |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : NFDiscovery service down' |
Severity | Critical |
Condition | NFDiscovery is unavailable. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7019 |
Metric Used | 'up'
Note: This is a Prometheus metric used for instance availability monitoring. If this metric is not available, use a similar metric as exposed by the monitoring system. |
Recommended Actions |
The alert is cleared when the Nnrf_NFDiscovery service is available. Steps:
|
Available in OCI | No |
6.3.1.6 OcnrfRegistrationServiceDown
Table 6-557 OcnrfRegistrationServiceDown
Field | Details |
---|---|
Description | 'OCNRF NFRegistration service nfregistration is down' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : NFRegistration service is down' |
Severity | Critical |
Condition | None of the pods of the NFRegistration microservice is available. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7021 |
Metric Used | 'up'
Note: This is a Prometheus metric used for instance availability monitoring. If this metric is not available, use a similar metric as exposed by the monitoring system. |
Recommended Actions |
The alert is cleared when the nfregistration service is available. Steps:
|
Available in OCI | No |
6.3.1.7 OcnrfSubscriptionServiceDown
Table 6-558 OcnrfSubscriptionServiceDown
Field | Details |
---|---|
Description | 'OCNRF NFSubscription service nfsubscription is down. |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : NFSubscription service is down' |
Severity | Critical |
Condition | None of the pods of the NFSubscription microservice is available. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7022 |
Metric Used | 'up'
Note: This is a Prometheus metric used for instance availability monitoring. If this metric is not available, use a similar metric as exposed by the monitoring system. |
Recommended Actions | The alert is cleared when the nfsubscription service is
available.
Steps:
|
Available in OCI | No |
6.3.1.8 OcnrfDiscoveryServiceDown
Table 6-559 OcnrfDiscoveryServiceDown
Field | Details |
---|---|
Description | 'OCNRF NFDiscovery service nfdiscovery is down' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : NFDiscovery service down' |
Severity | Critical |
Condition | None of the pods of the NFDiscovery microservice is available. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7023 |
Metric Used | 'up'
Note: This is a Prometheus metric used for instance availability monitoring. If this metric is not available, use a similar metric as exposed by the monitoring system. |
Recommended Actions | The alert is cleared when the nfdiscovery service is
available.
Steps:
|
Available in OCI | No |
6.3.1.9 OcnrfAccessTokenServiceDown
Table 6-560 OcnrfAccessTokenServiceDown
Field | Details |
---|---|
Description | 'OCNRF NFAccessToken service nfaccesstoken is down |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : NFAccesstoken service down' |
Severity | Critical |
Condition | None of the pods of the NFAccessToken microservice is available. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7024 |
Metric Used | 'up'
Note: This is a Prometheus metric used for instance availability monitoring. If this metric is not available, use a similar metric as exposed by the monitoring system. |
Recommended Actions | The alert is cleared when the nfaccesstoken service is
available.
Steps:
|
Available in OCI | No |
6.3.1.10 OcnrfAuditorServiceDown
Table 6-561 OcnrfAuditorServiceDown
Field | Details |
---|---|
Description | 'OCNRF NrfAuditor service nrfauditor is down' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : NrfAuditor service down' |
Severity | Critical |
Condition | None of the pods of the NrfAuditor microservice is available. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7026 |
Metric Used | 'up' Note: This is a Prometheus metric used for instance availability monitoring. If this metric is not available, use a similar metric as exposed by the monitoring system. |
Recommended Actions |
The alert is cleared when the nrfauditor service is available. Steps:
|
Available in OCI | No |
6.3.1.11 OcnrfConfigurationServiceDown
Table 6-562 OcnrfConfigurationServiceDown
Field | Details |
---|---|
Description | 'OCNRF NrfConfiguration service nrfconfiguration is down' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : NrfConfiguration service down' |
Severity | Critical |
Condition | None of the pods of the NrfConfiguration microservice is available. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7025 |
Metric Used | 'up'
Note: This is a Prometheus metric used for instance availability monitoring. If this metric is not available, use a similar metric as exposed by the monitoring system. |
Recommended Actions |
The alert is cleared when the nrfconfiguration service is available. Steps:
|
Available in OCI | No |
6.3.1.12 OcnrfAppInfoServiceDown
Table 6-563 OcnrfAppInfoServiceDown
Field | Details |
---|---|
Description | 'OCNRF Appinfo service appinfo is down' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : Appinfo service down' |
Severity | Critical |
Condition | None of the pods of the appinfo microservice is available. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7027 |
Metric Used | 'up'
Note: This is a Prometheus metric used for instance availability monitoring. If this metric is not available, use a similar metric as exposed by the monitoring system. |
Recommended Actions |
The alert is cleared when the appinfo service is available. Steps:
|
Available in OCI | No |
6.3.1.13 OcnrfArtisanServiceDown
Table 6-564 OcnrfArtisanServiceDown
Field | Details |
---|---|
Description | 'OCNRF NrfArtisan service {{$labels.app_kubernetes_io_name}} is down' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : NrfArtisan service is down' |
Severity | Critical |
Condition | NrfArtisan is unavailable. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7056 |
Metric Used | 'up'
Note: This is a Prometheus metric used for instance availability monitoring. If this metric is not available, use the similar metric as exposed by the monitoring system. |
Recommended Actions |
The alert is cleared when the NrfArtisan service is available. Steps:
|
Available in OCI | No |
6.3.1.14 OcnrfAlternateRouteServiceDown
Table 6-565 OcnrfAlternateRouteServiceDown
Field | Details |
---|---|
Description | 'OCNRF AlternateRoute service {{$labels.app_kubernetes_io_name}} is down' |
Applicable in OCI | No |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : AlternateRoute service is down' |
Severity | Critical |
Condition | AlternateRoute is unavailable. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7057 |
Metric Used |
'up' Note: This is a Prometheus metric used for instance availability monitoring. If this metric is not available, use the similar metric as exposed by the monitoring system. |
Recommended Actions |
The alert is cleared when the alternate-route service is available. Steps:
|
6.3.1.15 OcnrfPerfInfoServiceDown
Table 6-566 OcnrfPerfInfoServiceDown
Field | Details |
---|---|
Description | 'OCNRF Perfinfo service {{$labels.app_kubernetes_io_name}} is down' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : Perfinfo service down' |
Severity | Critical |
Condition | Perfinfo is unavailable. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7058 |
Metric Used |
'up' Note: This is a Prometheus metric used for instance availability monitoring. If this metric is not available, use the similar metric as exposed by the monitoring system. |
Recommended Actions |
The alert is cleared when the Perfinfo service is available. Steps:
|
Available in OCI | No |
6.3.1.16 OcnrfIngressGatewayServiceDown
Table 6-567 OcnrfIngressGatewayServiceDown
Field | Details |
---|---|
Description | 'OCNRF Ingress-Gateway service ingressgateway is down' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : Ingress-gateway service down' |
Severity | Critical |
Condition | None of the pods of the Ingress Gateway microservice is available. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7028 |
Metric Used | 'up'
Note: This is a Prometheus metric used for instance availability monitoring. If this metric is not available, use a similar metric as exposed by the monitoring system. |
Recommended Actions |
The alert is cleared when the Ingress Gateway service is available. Steps:
|
Available in OCI | No |
6.3.1.17 OcnrfEgressGatewayServiceDown
Table 6-568 OcnrfEgressGatewayServiceDown
Field | Details |
---|---|
Description | 'OCNRF Egress-Gateway service egressgateway is down' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : Egress-Gateway service down' |
Severity | Critical |
Condition | None of the pods of the Egress Gateway microservice is available. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7029 |
Metric Used | 'up'
Note: This is a Prometheus metric used for instance availability monitoring. If this metric is not available, use a similar metric as exposed by the monitoring system. |
Recommended Actions |
The alert is cleared when the Egress Gateway service is available. Steps:
|
Available in OCI | No |
6.3.1.18 OcnrfTotalIngressTrafficRateAboveMinorThreshold
Table 6-569 OcnrfTotalIngressTrafficRateAboveMinorThreshold
Field | Details |
---|---|
Description | 'Total Ingress traffic Rate is above configured minor threshold. (current value is: {{ $value }})' |
Summary | 'timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Traffic Rate is above 80 Percent of Max requests per second' |
Severity | Minor |
Condition |
The total NRF Ingress Message rate has crossed the configured minor threshold of 800 TPS. Default value of this alert trigger point in alert file is when NRF Ingress Rate crosses 80 % of 1000 (Maximum ingress request rate). |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7001 |
Metric Used | 'oc_ingressgateway_http_requests_total' |
Recommended Actions |
The alert is cleared either when the total Ingress Traffic rate falls below the minor threshold or when the total traffic rate crosses the major threshold, in which case the OcnrfTotalIngressTrafficRateAboveMajorThreshold alert is raised. Note: The threshold is configurable in the alert file. Reassess why the NRF is receiving additional traffic (for example, Mated site NRF is unavailable in georedundancy scenario). If this alert is unexpected, contact My Oracle Support.Steps:
|
Available in OCI | No |
6.3.1.19 OcnrfTotalIngressTrafficRateAboveMajorThreshold
Table 6-570 OcnrfTotalIngressTrafficRateAboveMajorThreshold
Field | Details |
---|---|
Description | 'Total Ingress traffic Rate is above major threshold. (current value is: {{ $value }})' |
Summary | 'timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Traffic Rate is above 90 Percent of Max requests per second' |
Severity | Major |
Condition |
The total NRF Ingress Message rate has crossed the configured major threshold of 900 TPS. Default value of this alert trigger point in the alert file is when NRF Ingress Rate crosses 90 % of 1000 (Maximum ingress request rate). |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7002 |
Metric Used | 'oc_ingressgateway_http_requests_total' |
Recommended Actions |
The alert is cleared when the total Ingress Traffic rate falls below the major threshold or when the total traffic rate crosses the critical threshold, in which case the OcnrfTotalIngressTrafficRateAboveCriticalThreshold alert is raised. Note: The threshold is configurable in the alert file. Reassess why the NRF is receiving additional traffic (for example, Mated site NRF is unavailable in georedundancy scenario). If this alert is unexpected, contact My Oracle Support.Steps:
|
Available in OCI | No |
6.3.1.20 OcnrfTotalIngressTrafficRateAboveCriticalThreshold
Table 6-571 OcnrfTotalIngressTrafficRateAboveCriticalThreshold
Field | Details |
---|---|
Description | 'Total Ingress traffic Rate is above critical threshold.(current value is: {{ $value }})' |
Summary | 'timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Traffic Rate is more than 52000 requests per second' |
Severity | Critical |
Condition |
The total NRF Ingress Message rate has crossed the configured critical threshold of 52000 TPS. Default value of this alert trigger point in the alert file is when NRF Ingress Rate crosses 52000 TPS. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7003 |
Metric Used | 'oc_ingressgateway_http_requests_total' |
Recommended Actions |
The alert is cleared when the Ingress traffic rate falls below the critical threshold. Note: The threshold is configurable in the alert file. Reassess why the NRF is receiving additional traffic (for example, Mated site NRF is unavailable in georedundancy scenario). If this alert is unexpected, contact My Oracle Support.Steps:
|
Available in OCI | No |
6.3.1.21 OcnrfTransactionErrorRateAbove0Dot1Percent
Table 6-572 OcnrfTransactionErrorRateAbove0Dot1Percent
Field | Details |
---|---|
Description | 'Transaction Error rate is above 0.1 Percent of Total Transactions (current value is {{ $value }})' |
Summary | 'timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Transaction Error Rate detected above 0.1 Percent of Total Transactions' |
Severity | Warning |
Condition | The number of failed transactions is above 0.1 percent of the total transactions. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7004 |
Metric Used | 'oc_ingressgateway_http_responses_total' |
Recommended Actions |
The alert is cleared when the number of failure transactions is below 0.1 percent of the total transactions or when the number of failed transactions crosses the 1% threshold, in which case the OcnrfTransactionErrorRateAbove1Percent is raised. Steps:
|
Available in OCI | No |
6.3.1.22 OcnrfTransactionErrorRateAbove1Percent
Table 6-573 OcnrfTransactionErrorRateAbove1Percent
Field | Details |
---|---|
Description | 'Transaction Error rate is above 1 Percent of Total Transactions (current value is {{ $value }})' |
Summary | 'timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Transaction Error Rate detected above 1 Percent of Total Transactions' |
Severity | Warning |
Condition | When the number of failed transactions is above 1 percent of the total transactions. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7005 |
Metric Used | 'oc_ingressgateway_http_responses_total' |
Recommended Actions |
The alert is cleared when the number of failure transactions is below 1% of the total transactions or when the number of failed transactions crosses the 10% threshold, in which case the OcnrfTransactionErrorRateAbove10Percent is raised. Steps:
|
Available in OCI | No |
6.3.1.23 OcnrfTransactionErrorRateAbove10Percent
Table 6-574 OcnrfTransactionErrorRateAbove10Percent
Field | Details |
---|---|
Description | 'Transaction Error rate is above 10 Percent of Total Transactions (current value is {{ $value }})' |
Summary | 'timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Transaction Error Rate detected above 10 Percent of Total Transactions' |
Severity | Minor |
Condition | The number of failed transactions has crossed the minor threshold of 10 percent of the total transactions. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7006 |
Metric Used | 'oc_ingressgateway_http_responses_total' |
Recommended Actions |
The alert is cleared when the number of failure transactions is below 10 percent of the total transactions or when the number of failed transactions crosses the 25 percent threshold, in which case the OcnrfTransactionErrorRateAbove25Percent is raised. Steps:
|
Available in OCI | No |
6.3.1.24 OcnrfTransactionErrorRateAbove25Percent
Table 6-575 OcnrfTransactionErrorRateAbove25Percent
Field | Details |
---|---|
Description | 'Transaction Error rate is above 25 Percent of Total Transactions (current value is {{ $value }})' |
Summary | 'timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Transaction Error Rate detected above 25 Percent of Total Transactions' |
Severity | Major |
Condition | The number of failed transactions has crossed the minor threshold of 25 percent of the total transactions. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7007 |
Metric Used | 'oc_ingressgateway_http_responses_total' |
Recommended Actions |
The alert is cleared when the number of failure transactions is below 25 percent of the total transactions or when the number of failed transactions crosses the 50 percent threshold, in which case the OcnrfTransactionErrorRateAbove50Percent is raised. Steps:
|
Available in OCI | No |
6.3.1.25 OcnrfTransactionErrorRateAbove50Percent
Table 6-576 OcnrfTransactionErrorRateAbove50Percent
Field | Details |
---|---|
Description | 'Transaction Error rate is above 50 Percent of Total Transactions (current value is {{ $value }})' |
Summary | 'timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Transaction Error Rate detected above 50 Percent of Total Transactions' |
Severity | Critical |
Condition | The number of failed transactions has crossed the minor threshold of 50 percent of the total transactions. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7008 |
Metric Used | 'oc_ingressgateway_http_responses_total' |
Recommended Actions |
The alert is cleared when the number of failure transactions is below 50 percent of the total transactions. Steps:
|
Available in OCI | No |
6.3.1.26 OcnrfTotalEgressTrafficRateAboveCriticalThreshold
Table 6-577 OcnrfTotalEgressTrafficRateAboveCriticalThreshold
Field | Details |
---|---|
Description | 'Egress traffic rate is above the configured critical threshold. (current value is: {{ $value }})' |
Summary | ''kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Traffic Rate is above 51600 requests per second' |
Severity | Critical |
Condition | This alarm is raised when the Egress traffic rate is greater than the critical configured threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7109 |
Metric Used | oc_egressgateway_http_requests_total |
Recommended Actions | The alert is cleared either when the total discovery
rate falls below the critical threshold.
Note: The
threshold is configurable in the alert file. Reassess why the NRF is
receiving additional traffic (for example, Mated site NRF is unavailable
in georedundancy scenario). If this alert is unexpected, contact My Oracle
Support.
Steps:
|
Available in OCI | No |
6.3.1.27 OcnrfTotalForwardingTrafficRateAboveCriticalThreshold
Table 6-578 OcnrfTotalForwardingTrafficRateAboveCriticalThreshold
Field | Details |
---|---|
Description | 'NRF-NRF Forwarding Rate is above the configured critical threshold. (current value is: {{ $value }})' |
Summary | 'kubernetes_namespace: $labels.kubernetes_namespace, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Traffic Rate is above 5200 requests per second.' |
Severity | Critical |
Condition | This alarm is raised when the rate between NRF and NRF Forwarding is greater than the critical configured threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7110 |
Metric Used | ocnrf_forward_nfDiscover_tx_requests_total |
Recommended Actions | The alert is cleared either when the total NRF
Forwarding rate falls below the critical threshold.
Note: The threshold is configurable in the alert file.
Reassess why the NRF is receiving additional traffic (for example, Mated
site NRF is unavailable in georedundancy scenario). If this alert is
unexpected, contact My Oracle
Support.
Steps:
|
Available in OCI | No |
6.3.1.28 OcnrfHeapUsageCrossedMinorThreshold
Table 6-579 OcnrfHeapUsageCrossedMinorThreshold
Field | Details |
---|---|
Description | 'OCNRF Heap Usage for pod {{ $labels.pod }} has crossed the configured minor threshold (50%) (value={{ $value }}) of its limit.' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, podname: {{$labels.pod}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : Heap Usage of pod exceeded 50% of its limit.' |
Severity | Minor |
Condition | This alert is raised when the Java memory heap usage of pods exceeds the configured minor threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7126 |
Metric Used | jvm_memory_used_bytes |
Recommended Actions |
The alert is cleared when the heap usage of pods falls below the minor threshold. Note: The threshold is configurable in the alert file. If this alert is unexpected, contact My Oracle Support. Steps:
|
Available in OCI | No |
6.3.1.29 OcnrfHeapUsageCrossedMajorThreshold
Table 6-580 OcnrfHeapUsageCrossedMajorThreshold
Field | Details |
---|---|
Description | 'OCNRF Heap Usage for pod {{ $labels.pod }} has crossed the configured major threshold (60%) (value={{ $value }}) of its limit.' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, podname: {{$labels.pod}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : Heap Usage of pod is more than or equal to 60% and less than 70% of its limit.' |
Severity | Major |
Condition | This alert is raised when the Java memory heap usage of pods exceeds the configured major threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7127 |
Metric Used | jvm_memory_used_bytes |
Recommended Actions |
The alert is cleared when the heap usage of pods falls below the major threshold. Note: The threshold is configurable in the alert file. If this alert is unexpected, contact My Oracle Support. Steps:
|
Available in OCI | No |
6.3.1.30 OcnrfHeapUsageCrossedCriticalThreshold
Table 6-581 OcnrfHeapUsageCrossedCriticalThreshold
Field | Details |
---|---|
Description | 'OCNRF Heap Usage for pod {{ $labels.pod }} has crossed the configured critical threshold (70%) (value={{ $value }}) of its limit.' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, podname: {{$labels.pod}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : Heap Usage of pod is more than 70% of its limit.' |
Severity | Critical |
Condition | This alert is raised when the Java memory heap usage of pods exceeds the configured critical threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7128 |
Metric Used | jvm_memory_used_bytes |
Recommended Actions |
The alert is cleared when the heap usage of pods falls below the critical threshold. Note: The threshold is configurable in the alert file. If this alert is unexpected, contact My Oracle Support. Steps:
|
Available in OCI | No |
6.3.2 Service Level Alerts
This section lists the service level alerts.
6.3.2.1 OcnrfAccessTokenRequestsRejected
Table 6-582 OcnrfAccessTokenRequestsRejected
Field | Details |
---|---|
Description | 'AccessToken request(s) have been rejected by OCNRF (current value is: {{ $value }})' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} AccessToken Request has been rejected by OCNRF.' |
Severity | Warning |
Condition | NRF rejected an AccessToken Request |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7014 |
Metric Used | 'ocnrf_accessToken_tx_responses_total' |
Recommended Actions | The alert is cleared automatically.
Steps:
|
Available in OCI | No |
6.3.2.2 OcnrfAuditorMultiplePodUnavailable
Table 6-583 OcnrfAuditorMultiplePodUnavailable
Field | Details |
---|---|
Description | Ocnrf Auditor Multiple Pods are Unavailable in deployment |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : Ocnrf Auditor Multiple Pods are Unavailable' |
Severity | Critical |
Condition | Ocnrf Auditor Multiple Pods are Unavailable. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7075 |
Metric Used | NA |
Recommended Actions |
This alert is raised due to auditor multiple pods are unavailable. This alert is cleared automatically when the pods are available. |
Available in OCI | No |
6.3.2.3 OcnrfAppInfoMultiplePodUnavailable
Table 6-584 OcnrfAppInfoMultiplePodUnavailable
Field | Details |
---|---|
Description | Ocnrf AppInfo Multiple Pods are Unavailable in deployment |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : Ocnrf AppInfo Multiple Pods are Unavailable' |
Severity | Critical |
Condition | Ocnrf Auditor Multiple Pods are Unavailable. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7076 |
Metric Used | NA |
Recommended Actions |
This alert is raised due to App-Info multiple pods are unavailable. This alert is cleared automatically when the pods are available. |
Available in OCI | No |
6.3.2.4 OcnrfPerfInfoMultiplePodUnavailable
Table 6-585 OcnrfPerfInfoMultiplePodUnavailable
Field | Details |
---|---|
Description | Ocnrf PerfInfo Multiple Pods are Unavailable in deployment |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : Ocnrf PerfInfo Multiple Pods are Unavailable' |
Severity | Critical |
Condition | Ocnrf PerfInfo Multiple Pods are Unavailable. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7077 |
Metric Used | NA |
Recommended Actions |
This alert is raised due to perf-Info multiple pods are unavailable. This alert is cleared automatically when the pods are available. |
Available in OCI | No |
6.3.2.5 OcnrfTotalSLFRateAboveCriticalThreshold
Table 6-586 OcnrfTotalSLFRateAboveCriticalThreshold
Field | Details |
---|---|
Description | 'NRF-SLF Rate is above the configured critical threshold. (current value is: {{ $value }})' |
Summary | 'kubernetes_namespace: $labels.kubernetes_namespace, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Traffic Rate is above 45600 requests per second.' |
Severity | Critical |
Condition | This alarm is raised when the rate between NRF and SLF reaches is greater than the critical configured threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7111 |
Metric Used | ocnrf_SLF_tx_requests_total |
Recommended Actions | The alert is cleared either when the total SLF rate
falls below the critical threshold.
Note: The
threshold is configurable in the alert file. Reassess why the NRF is
receiving additional traffic (for example, Mated site NRF is unavailable
in georedundancy scenario). If this alert is unexpected, contact My Oracle
Support.
Steps:
|
Available in OCI | No |
6.3.2.6 OcnrfTotalDiscoveryRateAboveCriticalThreshold
Table 6-587 OcnrfTotalDiscoveryRateAboveCriticalThreshold
Field | Details |
---|---|
Description | 'Total Discovery Rate is above the configured critical threshold. (current value is: {{ $value }})' |
Summary | 'kubernetes_namespace: $labels.kubernetes_namespace, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Traffic Rate is above 51600 requests per second.' |
Severity | Critical |
Condition | This alarm is raised when the total discovery rate is greater than the critical configured threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7112 |
Metric Used | ocnrf_nfDiscover_rx_requests_total |
Recommended Actions | The alert is cleared when the total discovery rate falls
below the critical threshold.
Note: The threshold
is configurable in the alert file. Reassess why the NRF is receiving
additional traffic (for example, Mated site NRF is unavailable in
georedundancy scenario). If this alert is unexpected, contact My Oracle
Support.
Steps:
|
Available in OCI | No |
6.3.2.7 OcnrfAccessTokenRequestsAboveThreshold
Table 6-588 OcnrfAccessTokenRequestsAboveThreshold
Field | Details |
---|---|
Description | 'Total Access token request rate is above the configured critical threshold. (current value is: {{ $value }})' |
Summary | 'namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Total Access token request rate is above 5' |
Severity | Critical |
Condition | The alert is raised when the rate of Access Token requests is greater than the configured threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7115 |
Metric Used | ocnrf_accessToken_rx_requests_total |
Recommended Actions | The alert is cleared when the total number of access
token request rate falls below the critical threshold.
Note: The threshold is configurable in the alert file.
Reassess why the NRF is receiving additional traffic (for example, Mated
site NRF is unavailable in georedundancy scenario). If this alert is
unexpected, contact My Oracle
Support.
Steps:
|
Available in OCI | No |
6.3.2.8 OcnrfNfUpdateRequestsAboveThreshold
Table 6-589 OcnrfNfUpdateRequestsAboveThreshold
Field | Details |
---|---|
Description | 'Total NfUpdate request rate is above the configured critical threshold. (current value is: {{ $value }})' |
Summary | 'namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Total NfUpdate request rate is above 5' |
Severity | Critical |
Condition | This alert is raised when the total number of NfUpdate requests is greater than the configured threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7116 |
Metric Used | ocnrf_nfUpdate_rx_requests_total |
Recommended Actions | The alert is cleared when the total number of NfUpdate
request falls below the critical threshold.
Note:
The threshold is configurable in the alert file. Reassess why the NRF is
receiving additional traffic (for example, Mated site NRF is unavailable
in georedundancy scenario). If this alert is unexpected, contact My Oracle
Support.
Steps:
|
Available in OCI | No |
6.3.2.9 OcnrfRegisteredNfCountAboveThreshold
Table 6-590 OcnrfRegisteredNfCountAboveThreshold
Field | Details |
---|---|
Description | 'Total Number of active registrations in OCNRF is above critical threshold. (current value is: {{ $value }})' |
Summary | 'namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Total Number of active registrations in OCNRF is above 260' |
Severity | Critical |
Condition | The alert is raised when the total number of NFs registered in the set is greater than the configured threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7118 |
Metric Used | ocnrf_nf_registered_count |
Recommended Actions | The alert is cleared when the total number active
registrations in NRF falls below the critical threshold.
Note: The threshold is configurable in the alert file.
Reassess why the NRF is receiving additional registrations. If this
alert is unexpected, contact My Oracle
Support.
Step:
|
Available in OCI | No |
6.3.2.10 OcnrfNfHeartBeatRequestsAboveThreshold
Table 6-591 OcnrfNfHeartBeatRequestsAboveThreshold
Field | Details |
---|---|
Description | 'Total NfHeartBeat request rate is above the configured critical threshold. (current value is: {{ $value }})' |
Summary | 'namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Total NfHeartBeat request rate is above 52' |
Severity | Critical |
Condition | This alert is raised when the total number of NfHeartBeat requests is greater than the configured threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7117 |
Metric Used | ocnrf_nfHeartBeat_rx_requests_total |
Recommended Actions | The alert is cleared when the total number of
NfHeartBeat request falls below the critical threshold.
Note: The threshold is configurable in the alert file.
Reassess why the NRF is receiving additional traffic (for example, Mated
site NRF is unavailable in georedundancy scenario). If this alert is
unexpected, contact My Oracle
Support.
Steps:
|
Available in OCI | No |
6.3.2.11 OcnrfRegisteredNfCountAboveThreshold
Table 6-592 OcnrfRegisteredNfCountAboveThreshold
Field | Details |
---|---|
Description | 'Total Number of active registrations in OCNRF is above critical threshold. (current value is: {{ $value }})' |
Summary | 'namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Total Number of active registrations in OCNRF is above 260' |
Severity | Critical |
Condition | The alert is raised when the total number of NFs registered in the set is greater than the configured threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7118 |
Metric Used | ocnrf_nf_registered_count |
Recommended Actions | The alert is cleared when the total number active
registrations in NRF falls below the critical threshold.
Note: The threshold is configurable in the alert file.
Reassess why the NRF is receiving additional registrations. If this
alert is unexpected, contact My Oracle
Support.
Step:
|
Available in OCI | No |
6.3.2.12 OcnrfTotalSubscriptionsAboveThreshold
Table 6-593 OcnrfTotalSubscriptionsAboveThreshold
Field | Details |
---|---|
Description | 'Total Number of active subscriptions in OCNRF is above the critical threshold. (current value is: {{ $value }})' |
Summary | 'namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Total Number of active subscriptions in OCNRF is above 1000.' |
Severity | Critical |
Condition | This alert is raised when the total number of active subscriptions in NRF is greater than the configured threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7121 |
Metric Used | ocnrf_nfset_active_subscriptions |
Recommended Actions | The alert is cleared when the total number active
subscriptions in NRF is less than the critical threshold.
Note: The threshold is configurable in the alert file.
Reassess why the NRF has received additional subscriptions (for example,
Mated site NRF is unavailable in georedundancy scenario). If this alert
is unexpected, contact My Oracle
Support.
Steps:
|
Available in OCI | No |
6.3.2.13 OcnrfDiscoveryRequestsForUDRAboveThreshold
Table 6-594 OcnrfDiscoveryRequestsForUDRAboveThreshold
Field | Details |
---|---|
Description | 'Total NfDiscover request rate for nfType UDR is above the configured critical threshold. (current value is: {{ $value }})' |
Summary | 'namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Total NfDiscover request rate for nfType UDR is above above 700' |
Severity | Critical |
Condition | This alert is raised when the rate of nfDiscover requests for nfType UDR is greater than the configured threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7122 |
Metric Used | ocnrf_nfDiscover_rx_requests_total |
Recommended Actions | The alert is cleared when the rate of nfDiscover requests for nfType UDR is below than the critical threshold. Note: The threshold is configurable in the alert file. Reassess why the NRF is receiving additional traffic for UDR. If this alert is unexpected, contact My Oracle Support. |
Available in OCI | No |
6.3.2.14 OcnrfDiscoveryRequestsForUDMAboveThreshold
Table 6-595 OcnrfDiscoveryRequestsForUDMAboveThreshold
Field | Details |
---|---|
Description | 'Total NfDiscover request rate for nfType UDM is above the configured critical threshold. (current value is: {{ $value }})' |
Summary | 'namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Total NfDiscover request rate for nfType UDM is above above 46000' |
Severity | Critical |
Condition | This alert is raised when the rate of nfDiscover requests for nfType UDM is greater than the configured threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7123 |
Metric Used | ocnrf_nfDiscover_rx_requests_total |
Recommended Actions | The alert is cleared when the rate of nfDiscover requests for nfType UDM is below than the critical threshold. Note: The threshold is configurable in the alert file. Reassess why the NRF is receiving additional traffic for UDM. If this alert is unexpected, contact My Oracle Support. |
Available in OCI | No |
6.3.2.15 OcnrfDiscoveryRequestsForAMFAboveThreshold
Table 6-596 OcnrfDiscoveryRequestsForAMFAboveThreshold
Field | Details |
---|---|
Description | 'Total NfDiscover request rate for nfType AMF is above the configured critical threshold. (current value is: {{ $value }})' |
Summary | 'namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Total NfDiscover request rate for nfType AMF is above 2500' |
Severity | Critical |
Condition | This alert is raised when the rate of nfDiscover requests for nfType AMF is greater than the configured threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7124 |
Metric Used | ocnrf_nfDiscover_rx_requests_total |
Recommended Actions | The alert is cleared when the rate of nfDiscover requests for nfType AMF is below than the critical threshold. Note: The threshold is configurable in the alert file. Reassess why the NRF is receiving additional traffic for AMF. If this alert is unexpected, contact My Oracle Support. |
Available in OCI | No |
6.3.2.16 OcnrfDiscoveryRequestsForSMFAboveThreshold
Table 6-597 OcnrfDiscoveryRequestsForSMFAboveThreshold
Field | Details |
---|---|
Description | 'Total NfDiscover request rate for nfType SMF is above the configured critical threshold. (current value is: {{ $value }})' |
Summary | 'namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Total NfDiscover request rate for nfType SMF is above 4500' |
Severity | Critical |
Condition | This alert is raised when the rate of nfDiscover requests for nfType SMF is greater than the configured threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7125 |
Metric Used | ocnrf_nfDiscover_rx_requests_total |
Recommended Actions | The alert is cleared when the rate of nfDiscover requests for nfType SMF is below than the critical threshold. Note: The threshold is configurable in the alert file. Reassess why the NRF is receiving additional traffic for SMF. If this alert is unexpected, contact My Oracle Support. |
Available in OCI | No |
6.3.3 NfProfile Status Change Alerts
This section lists the alerts raised when there is status change in NfProfile.
6.3.3.1 OcnrfRegisteredPCFsBelowCriticalThreshold
Table 6-598 OcnrfRegisteredPCFsBelowCriticalThreshold
Field | Details |
---|---|
Description | 'The number of registered NFs detected below critical threshold (current value is: {{ $value }})' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, nftype:{{$labels.RequesterNfType}}, nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: The number of registered NFs detected below critical threshold.' |
Severity | Critical |
Condition |
The number of NFs of the given NFType PCF currently registered with NRF is below the critical threshold. Note: Operator can add similar alerts for each NfType and configure the corresponding thresholds as required. Default value of this alert trigger point in the alert file is when registered PCFs count with NRF is below 2. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7009 |
Metric Used | 'ocnrf_active_registrations_count' |
Recommended Actions |
The alert is cleared when the number of registered PCFs is above the critical threshold. Steps:
|
Notes |
|
Available in OCI | No |
6.3.3.2 OcnrfRegisteredPCFsBelowMajorThreshold
Table 6-599 OcnrfRegisteredPCFsBelowMajorThreshold
Field | Details |
---|---|
Description | 'The number of registered NFs detected below major threshold (current value is: {{ $value }})' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, nftype:{{$labels.NfType}}, nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: The number of registered NFs detected below major threshold.' |
Severity | Major |
Condition |
The number of NFs of the given NFType PCF currently registered with NRF is below the major threshold. Note: Operator can add similar alerts for each NfType and configure the corresponding thresholds as required. Default value of this alert trigger point in the alert file is when Registered PCFs count with NRF is greater than or equal to 2 and below 10. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7010 |
Metric Used | 'ocnrf_active_registrations_count' |
Recommended Actions |
The alert is cleared when the number of registered PCFs is above the major threshold. Steps:
|
Notes |
|
Available in OCI | No |
6.3.3.3 OcnrfRegisteredPCFsBelowMinorThreshold
Table 6-600 OcnrfRegisteredPCFsBelowMinorThreshold
Field | Details |
---|---|
Description | 'The number of registered NFs detected below minor threshold (current value is: {{ $value }})' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, nftype:{{$labels.NfType}}, nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: The number of registered NFs detected below minor threshold.' |
Severity | Minor |
Condition |
The number of NFs of the given NFType PCF currently registered with NRF is below the minor threshold. Note: Operator can add similar alerts for each NfType and configure the corresponding thresholds as required. Default value of this alert trigger point in the alert file is when registered PCFs count with NRF is greater than or equal to 10 and below 20. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7011 |
Metric Used | 'ocnrf_active_registrations_count' |
Recommended Actions |
The alert is cleared when the number of registered PCFs is above the minor threshold. Steps:
|
Notes |
|
Available in OCI | No |
6.3.3.4 OcnrfRegisteredPCFsBelowThreshold
Table 6-601 OcnrfRegisteredPCFsBelowThreshold
Field | Details |
---|---|
Description | 'The number of registered NFs is approaching minor threshold (current value is: {{ $value }})' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, nftype:{{$labels.NfType}}, nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: The number of registered NFs approaching minor threshold.' |
Severity | Warning |
Condition |
The number of NFs of the given NFType PCF currently registered with NRF is approaching minor threshold. Note: Operator can add similar alerts for each NfType and configure the corresponding thresholds as required. Default value of this alert trigger point in the alert file is when registered PCFs count with NRF is greater than or equal to 20 and below 30. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7012 |
Metric Used | 'ocnrf_active_registrations_count' |
Recommended Actions |
The alert is cleared when the number of registered PCFs is approaching minor threshold. Steps:
|
Notes |
|
Available in OCI | No |
6.3.3.5 OcnrfTotalNFsRegisteredBelowCriticalThreshold
Table 6-602 OcnrfTotalNFsRegisteredBelowCriticalThreshold
Field | Details |
---|---|
Description | 'Number of active registrations in OCNRF (current value is: {{ $value }}) is below critical threshold' |
Summary | kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : Active registrations count. |
Severity | Critical |
Condition | The total number of NFs currently in "REGISTERED" state
with the NRF is below the critical threshold.
Note: The threshold values are provided as an example. User can configure the threshold value as per the requirement. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7042 |
Metric Used | 'ocnrf_active_registrations_count' |
Recommended Actions | The alert is cleared when the number of registered NFs
is above the critical threshold.
Steps:
|
Notes |
|
Available in OCI | Yes |
6.3.3.6 OcnrfTotalNFsRegisteredBelowMajorThreshold
Table 6-603 OcnrfTotalNFsRegisteredBelowMajorThreshold
Field | Details |
---|---|
Description | 'Number of active registrations in OCNRF (current value is: {{ $value }}) is below major threshold' |
Summary | kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : Active registrations count. |
Severity | Major |
Condition | The total number of NFs currently in "REGISTERED" state
with the NRF is below the major threshold.
Note: The threshold values are provided as an example. The user can configure the threshold value as per the requirement. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7043 |
Metric Used | 'ocnrf_active_registrations_count' |
Recommended Actions | The alert is cleared when the number of registered NFs
is above the major threshold.
Steps:
|
Notes |
|
Available in OCI | Yes |
6.3.3.7 OcnrfTotalNFsRegisteredBelowMinorThreshold
Table 6-604 OcnrfTotalNFsRegisteredBelowMinorThreshold
Field | Details |
---|---|
Description | 'Number of active registrations in OCNRF (current value is: {{ $value }}) is below minor threshold' |
Summary | kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : Active registrations count. |
Severity | Minor |
Condition | The total number of NFs currently in "REGISTERED" state
with the NRF is below the minor threshold.
Note: The threshold values are provided as an example. The user can configure the threshold value as per the requirement. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7044 |
Metric Used | 'ocnrf_active_registrations_count' |
Recommended Actions | The alert is cleared when the number of registered NFs
is above the minor threshold.
Steps:
|
Notes |
|
Available in OCI | Yes |
6.3.3.8 OcnrfTotalNFsRegisteredApproachingMinorThreshold
Table 6-605 OcnrfTotalNFsRegisteredApproachingMinorThreshold
Field | Details |
---|---|
Description | 'Number of active registrations in OCNRF (current value is: {{ $value }}) is approaching minor threshold' |
Summary | kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : Active registrations count. |
Severity | Info |
Condition | The total number of NFs currently in "REGISTERED" state
with the NRF is approaching minor threshold.
Note: The threshold values provided as an example. The user can configure the threshold as per need. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7045 |
Metric Used | 'ocnrf_active_registrations_count' |
Recommended Actions | The alert is cleared when the number of registered NFs
are approaching minor threshold.
Steps: No action is required. This is an information alert. |
Notes |
|
Available in OCI | Yes |
6.3.3.9 OcnrfNFStatusTransitionToRegistered
Table 6-606 OcnrfNFStatusTransitionToRegistered
Field | Details |
---|---|
Description | 'NF with NF profile fqdn {{$labels.NfProfileFqdn}} NF instance id {{$labels.NfInstanceId}} NF type {{$labels.NfType}} is REGISTERED , previous status was {{$labels.PreviousStatus}}' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}},podname: {{$labels.kubernetes_pod_name}},NfInstanceId: {{$labels.NfInstanceId}},NfProfileFqdn: {{$labels.NfProfileFqdn}},NfType: {{$labels.NfType}},PreviousStatus: {{$labels.PreviousStatus}},NewStatus: {{$labels.NewStatus}},timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} NF is REGISTERED.' |
Severity | Info |
Condition | NF Instance's status transitions to REGISTERED.
Note: When multiple alerts are present for a given NF, the latest alert is always considered. The timestamp can also be seen in the "Active Since" field of the alert in Prometheus. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7046 |
Metric Used | ocnrf_nfInstance_status_change_total |
Recommended Actions | The alert is cleared automatically after a window of 5
minutes.
Steps: No action is required. This is an information alert. |
Available in OCI | Yes |
6.3.3.10 OcnrfNFServiceStatusTransitionToRegistered
Table 6-607 OcnrfNFServiceStatusTransitionToRegistered
Field | Details |
---|---|
Description | 'NF service {{$labels.NfServiceName}} and service instance id {{$labels.NfServiceInstanceId}} of NF profile fqdn {{$labels.NfProfileFqdn}} and instance id {{$labels.NfInstanceId}} is REGISTERED, previous status was {{$labels.PreviousStatus}}' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}},podname: {{$labels.kubernetes_pod_name}},NfInstanceId: {{$labels.NfInstanceId}},NfServiceName: {{$labels.NfServiceName}},NfServiceInstanceId:{{$labels.NfServiceInstanceId}},NfProfileFqdn: {{$labels.NfProfileFqdn}},NfServiceFqdn: {{$labels.NfServiceFqdn}},PreviousStatus: {{$labels.PreviousStatus}},NewStatus: {{$labels.NewStatus}},timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} NF service is REGISTERED.' |
Severity | Info |
Condition | Status of an NF Instance's service transitions to
REGISTERED.
Note: When multiple alerts are present for a given NF, the latest alert is always considered. The timestamp can also be seen in the "Active Since" field of the alert in Prometheus. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7047 |
Metric Used | ocnrf_nfService_status_change_total |
Recommended Actions | The alert is cleared automatically after a window of 5
minutes.
Steps: No action is required. This is an information alert. |
Available in OCI | Yes |
6.3.3.11 OcnrfNFStatusTransitionToSuspended
Table 6-608 OcnrfNFStatusTransitionToSuspended
Field | Details |
---|---|
Description | 'NF with NF profile fqdn {{$labels.NfProfileFqdn}} NF instance id {{$labels.NfInstanceId}} NF type {{$labels.NfType}} is SUSPENDED, previous status was {{$labels.PreviousStatus}}' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}},podname: {{$labels.kubernetes_pod_name}},NfInstanceId: {{$labels.NfInstanceId}},NfProfileFqdn: {{$labels.NfProfileFqdn}},NfType: {{$labels.NfType}},PreviousStatus: {{$labels.PreviousStatus}},NewStatus: {{$labels.NewStatus}},timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} NF is SUSPENDED.' |
Severity | Major |
Condition | NF Instance's status transitions to SUSPENDED.
Note: When multiple alerts are present for a given NF, the latest alert is always considered. The timestamp can also be seen in the "Active Since" field of the alert in Prometheus. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7048 |
Metric Used | ocnrf_nfInstance_status_change_total |
Recommended Actions | The alert is cleared automatically after a window of 5
minutes.
Steps:
|
Available in OCI | Yes |
6.3.3.12 OcnrfNFServiceStatusTransitionToSuspended
Table 6-609 OcnrfNFServiceStatusTransitionToSuspended
Field | Details |
---|---|
Description | 'NF service {{$labels.NfServiceName}} and service instance id {{$labels.NfServiceInstanceId}} of NF profile fqdn {{$labels.NfProfileFqdn}} and instance id {{$labels.NfInstanceId}} is SUSPENDED, previous status was {{$labels.PreviousStatus}}' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}},podname: {{$labels.kubernetes_pod_name}},NfInstanceId: {{$labels.NfInstanceId}},NfServiceName: {{$labels.NfServiceName}},NfServiceInstanceId:{{$labels.NfServiceInstanceId}},NfProfileFqdn: {{$labels.NfProfileFqdn}},NfServiceFqdn: {{$labels.NfServiceFqdn}},PreviousStatus: {{$labels.PreviousStatus}},NewStatus: {{$labels.NewStatus}},timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} NF service is SUSPENDED.' |
Severity | Minor |
Condition | Status of an NF Instance's service transitions to
SUSPENDED.
Note: When multiple alerts are present for a given NF, the latest alert is always considered. The timestamp can also be seen in the "Active Since" field of the alert in Prometheus. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7049 |
Metric Used | ocnrf_nfService_status_change_total |
Recommended Actions | The alert is cleared automatically after a window of 5
minutes.
Steps:
|
Available in OCI | Yes |
6.3.3.13 OcnrfNFStatusTransitionToUndiscoverable
Table 6-610 OcnrfNFStatusTransitionToUndiscoverable
Field | Details |
---|---|
Description | 'NF with NF profile fqdn {{$labels.NfProfileFqdn}} NF instance id {{$labels.NfInstanceId}} NF type {{$labels.NfType}} is UNDISCOVERABLE, previous status was {{$labels.PreviousStatus}}' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}},podname: {{$labels.kubernetes_pod_name}},NfInstanceId: {{$labels.NfInstanceId}},NfProfileFqdn: {{$labels.NfProfileFqdn}},NfType: {{$labels.NfType}},PreviousStatus: {{$labels.PreviousStatus}},NewStatus: {{$labels.NewStatus}},timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} NF is UNDISCOVERABLE.' |
Severity | Info |
Condition | NF Instance's status transitions to UNDISCOVERABLE.
Note: When multiple alerts are present for a given NF, the latest alert is always considered. The timestamp can also be seen in the "Active Since" field of the alert in Prometheus. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7050 |
Metric Used | ocnrf_nfInstance_status_change_total |
Recommended Actions | The alert is cleared automatically after a window of 5
minutes.
Steps:
|
Available in OCI | Yes |
6.3.3.14 OcnrfNFServiceStatusTransitionToUndiscoverable
Table 6-611 OcnrfNFServiceStatusTransitionToUndiscoverable
Field | Details |
---|---|
Description |
'NF service {{$labels.NfServiceName}} and service instance id {{$labels.NfServiceInstanceId}} of NF profile fqdn {{$labels.NfProfileFqdn}} and instance id {{$labels.NfInstanceId}} is UNDISCOVERABLE, previous status was {{$labels.PreviousStatus}}' |
Summary |
'kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}},podname: {{$labels.kubernetes_pod_name}},NfInstanceId: {{$labels.NfInstanceId}},NfServiceName: {{$labels.NfServiceName}},NfServiceInstanceId:{{$labels.NfServiceInstanceId}},NfProfileFqdn: {{$labels.NfProfileFqdn}},NfServiceFqdn: {{$labels.NfServiceFqdn}},PreviousStatus: {{$labels.PreviousStatus}},NewStatus: {{$labels.NewStatus}},timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} NF service is UNDISCOVERABLE.' |
Severity | Info |
Condition | Status of an NF Instance's service transitions to
UNDISCOVERABLE.
Note: When multiple alerts are present for a given NF, the latest alert is always considered. The timestamp can also be seen in the "Active Since" field of the alert in Prometheus. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7051 |
Metric Used | ocnrf_nfService_status_change_total |
Recommended Actions | The alert is cleared automatically after a window of 5
minutes.
Steps:
|
Available in OCI | Yes |
6.3.3.15 OcnrfNFStatusTransitionToDeregistered
Table 6-612 OcnrfNFStatusTransitionToDeregistered
Field | Details |
---|---|
Description | 'NF with NF profile fqdn {{$labels.NfProfileFqdn}} NF instance id {{$labels.NfInstanceId}} NF type {{$labels.NfType}} is DEREGISTERED, previous status was {{$labels.PreviousStatus}}' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}},podname: {{$labels.kubernetes_pod_name}},NfInstanceId: {{$labels.NfInstanceId}},NfProfileFqdn: {{$labels.NfProfileFqdn}},NfType: {{$labels.NfType}},PreviousStatus: {{$labels.PreviousStatus}},NewStatus: {{$labels.NewStatus}},timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} NF is DEREGISTERED.' |
Severity | Info |
Condition | NF Instance's status transitions to DEREGISTERED.
Note: When multiple alerts are present for a given NF, the latest alert is always considered. The timestamp can also be seen in the "Active Since" field of the alert in Prometheus. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7052 |
Metric Used | ocnrf_nfInstance_status_change_total |
Recommended Actions | The alert is cleared automatically after a window of 5
minutes.
Steps:
|
Available in OCI | Yes |
6.3.3.16 OcnrfNFServiceStatusTransitionToDeregistered
Table 6-613 OcnrfNFServiceStatusTransitionToDeregistered
Field | Details |
---|---|
Description | 'NF service {{$labels.NfServiceName}} and service instance id {{$labels.NfServiceInstanceId}} of NF profile fqdn {{$labels.NfProfileFqdn}} and instance id {{$labels.NfInstanceId}} is DEREGISTERED, previous status was {{$labels.PreviousStatus}}' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}},podname: {{$labels.kubernetes_pod_name}},NfInstanceId: {{$labels.NfInstanceId}},NfServiceName: {{$labels.NfServiceName}},NfServiceInstanceId:{{$labels.NfServiceInstanceId}},NfProfileFqdn: {{$labels.NfProfileFqdn}},NfServiceFqdn: {{$labels.NfServiceFqdn}},PreviousStatus: {{$labels.PreviousStatus}},NewStatus: {{$labels.NewStatus}},timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} NF service is DEREGISTERED.' |
Severity | Info |
Condition | Status of an NF Instance's service transitions to
DEREGISTERED.
Note: When multiple alerts are present for a given NF, the latest alert is always considered. The timestamp can also be seen in the "Active Since" field of the alert in Prometheus. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7053 |
Metric Used | ocnrf_nfService_status_change_total |
Recommended Actions | The alert is cleared automatically after a window of 5
minutes.
Steps:
|
Available in OCI | Yes |
6.3.3.17 OcnrfNfProfileSizeAboveThreshold
Table 6-614 OcnrfNfProfileSizeAboveThreshold
Field | Details |
---|---|
Description | 'The size of the NF profile is above the critical threshold. (current value is: {{ $value }})' |
Summary | ''namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: The size of the NF profile is above 12kB threshold' |
Severity | Critical |
Condition | This alert is raised when the size of the NF profile is greater than the configured threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7119 |
Metric Used | ocnrf_nf_profile_size |
Recommended Actions | The alert is cleared when the size of the NF profile is
less than the critical threshold.
Note: The
threshold is configurable in the alert file.
Step:Verify which NF has registered a nfProfile above the
threshold size, using the |
Available in OCI | No |
6.3.3.18 OcnrfDiscoveryResponseSizeAboveThreshold
Table 6-615 OcnrfDiscoveryResponseSizeAboveThreshold
Field | Details |
---|---|
Description | 'The size of nfDiscover response is above the critical threshold. (current value is: {{ $value }})' |
Summary | 'namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: The size of nfDiscover response is above 45kB threshold'' |
Severity | Critical |
Condition | This alert is raised when the size of the nfDiscover response is greater than the configured threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7120 |
Metric Used | ocnrf_nfDiscover_tx_response_size_bytes_max |
Recommended Actions | The alert is cleared when the size of the nfDiscover
response is less than the critical threshold.
Note: The threshold is configurable in the alert file.
Step:
|
Available in OCI | No |
6.3.4 Feature Specific Alerts
This section lists the feature specific alerts.
6.3.4.1 KeyID for AccessToken Feature
This section lists the alerts that are specific to KeyID for AccessToken feature. For more information about the feature, see the Key-ID for Access Token section.
6.3.4.1.1 OcnrfAccessTokenCurrentKeyIdNotConfigured
Table 6-616 OcnrfAccessTokenCurrentKeyIdNotConfigured
Field | Details |
---|---|
Description | 'AccessToken request(s) have been rejected by OCNRF (current value is: {{ $value }})' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} AccessToken Request has been rejected by OCNRF as Current Key Id is not configured.' |
Severity | Critical |
Condition | NRF Access Token Rejected due to CurrentKeyId not configured |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7033 |
Metric Used | 'ocnrf_accessToken_tx_responses_total' |
Recommended Actions | The alert is automatically cleared as it is raised when
NRF receives Access Token Request, and at that point, Current Key Id is
not selected. For more information about configuring
currentKeyID parameter, see Oracle Communications Cloud Native Core, Network Repository Function REST
Specification Guide.
|
Available in OCI | No |
6.3.4.1.2 OcnrfAccessTokenCurrentKeyIdInvalidDetails
Table 6-617 OcnrfAccessTokenCurrentKeyIdInvalidDetails
Field | Details |
---|---|
Description | 'AccessToken request(s) have been rejected by OCNRF (current value is: {{ $value }})' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, KeyType: {{$labels.KeyType}}, RejectionReason: {{$labels.RejectionReason}},timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} AccessToken Request has been rejected by OCNRF as CurrentKeyId details are invalid.' |
Severity | Critical |
Condition | NRF Access Token Rejected due to token signing details corresponding to CurrentKeyId are invalid. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7034 |
Metric Used | 'ocnrf_accessToken_tx_responses_total' |
Recommended Actions | The alert is automatically cleared when NRF receives
Access Token Request, and at that point, Current Key Id details are
invalid. For more information about configuring
currentKeyID parameter, see Oracle Communications Cloud Native Core, Network Repository Function REST
Specification Guide.
|
Available in OCI | No |
6.3.4.1.3 OcnrfOauthCurrentKeyNotConfigured
Table 6-618 OcnrfOauthCurrentKeyNotConfigured
Field | Details |
---|---|
Description | 'OCNRF Oauth Access token Current Key Id is not configured' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} OCNRF Oauth Access token Current Key Id is not configured.' |
Severity | Critical |
Condition | Oauth Current Key ID is not configured |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7035 |
Metric Used | ocnrf_oauth_currentKeyId_configuredStatus |
Recommended Actions | The alert is cleared when the current key ID is
configured.
Steps: Configure
valid current key ID in Access Token Configuration. For more
information about configuring |
Available in OCI | No |
6.3.4.1.4 OcnrfOauthCurrentKeyDataHealthStatus
Table 6-619 OcnrfOauthCurrentKeyDataHealthStatus
Field | Details |
---|---|
Description | 'OCNRF Oauth Access token Current Key Id status is not healthy' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, KeyId: {{$labels.KeyId}}, KeyType: {{$labels.KeyType}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} OCNRF Oauth Access token Current Key Id status is not healthy.' |
Severity | Critical |
Condition | Oauth Current Key ID details health is not good. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7036 |
Metric Used | ocnrf_oauth_keyData_healthStatus |
Recommended Actions |
The alert is cleared when the current key ID status is healthy. Steps: Rectify the condition by checking ErrorCondition For example: For ErrorCondition Invalid_Key_Details, check if the k8SecretName, k8SecretNameSpace, and filename combination exists correctly for both privateKey and certificate. Make sure that the pem file data is not corrupt or the certificate has not expired. |
Available in OCI | No |
6.3.4.1.5 OcnrfOauthNonCurrentKeyDataHealthStatus
Table 6-620 OcnrfOauthNonCurrentKeyDataHealthStatus
Field | Details |
---|---|
Description | 'OCNRF Oauth Access token Non current Key Id status is not healthy' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, KeyId: {{$labels.KeyId}}, KeyType: {{$labels.KeyType}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} OCNRF Oauth Access token non current Key Id status is not healthy.' |
Severity | Info |
Condition | Oauth Non Current Key details health is not good |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7037 |
Metric Used | ocnrf_oauth_keyData_healthStatus |
Recommended Actions |
The alert is cleared when the current key ID status is healthy. Steps: Rectify the condition by checking ErrorCondition For example: For ErrorCondition Invalid_Key_Details, check if the k8SecretName, k8SecretNameSpace, and filename combination exists correctly for both privateKey and certificate. Make sure that the pem file data is not corrupt or the certificate has not expired. |
Available in OCI | No |
6.3.4.1.6 OcnrfOauthCurrentCertificateExpiringIn1Week
Table 6-621 OcnrfOauthCurrentCertificateExpiringIn1Week
Field | Details |
---|---|
Description | 'OCNRF Oauth Access token current Key Id certificate is expiring in less than 1 week' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, KeyId: {{$labels.KeyId}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} OCNRF Oauth Access token current Key Id certificate is expiring in less than 1 week.' |
Severity | Critical |
Condition | Oauth Current Key ID details are expiring in less than 1 week |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7038 |
Metric Used | ocnrf_oauth_keyData_expiryStatus |
Recommended Actions |
The alert is cleared when the key expiry time is more than 1 week. Steps: Replace expiring certificate key pair with new ones. For more information on creating certificate key pair, see Oracle Communications Cloud Native Core, Network Repository Function Installation, Upgrade, and Fault Recovery Guide. |
Available in OCI | No |
6.3.4.1.7 OcnrfOauthNonCurrentCertificateExpiringIn1Week
Table 6-622 OcnrfOauthNonCurrentCertificateExpiringIn1Week
Field | Details |
---|---|
Description | 'OCNRF Oauth Access token non current Key Id certificate is expiring in less than 1 week' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, KeyId: {{$labels.KeyId}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} OCNRF Oauth Access token non current Key Id certificate is expiring in less than 1 week.' |
Severity | Info |
Condition | Oauth Non Current Key ID details are expiring in less than 1 week |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7039 |
Metric Used | ocnrf_oauth_keyData_expiryStatus |
Recommended Actions |
The alert is cleared when the key expiry time is more than 1 week. Steps: Replace expiring certificate key pair with new ones. For more information on creating certificate key pair, see Oracle Communications Cloud Native Core, Network Repository Function Installation, Upgrade, and Fault Recovery Guide. |
Available in OCI | No |
6.3.4.1.8 OcnrfOauthCurrentCertificateExpiringIn30days
Table 6-623 OcnrfOauthCurrentCertificateExpiringIn30days
Field | Details |
---|---|
Description | 'OCNRF Oauth Access token current Key Id certificate is expiring in less than 30 days' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, KeyId: {{$labels.KeyId}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} OCNRF Oauth Access token current Key Id certificate is expiring in less than 30 days.' |
Severity | Major |
Condition | Oauth Current Key ID details are expiring in more than 24 hours and less than 30 days |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7040 |
Metric Used | ocnrf_oauth_keyData_expiryStatus |
Recommended Actions |
The alert is cleared when certificate for the current key id's expiry time is more than 30 days. Steps: Replace expiring certificate key pair with new ones. For more information on creating certificate key pair, see Oracle Communications Cloud Native Core, Network Repository Function Installation, Upgrade, and Fault Recovery Guide. |
Available in OCI | No |
6.3.4.1.9 OcnrfOauthNonCurrentCertificateExpiringIn30days
Table 6-624 OcnrfOauthNonCurrentCertificateExpiringIn30days
Field | Details |
---|---|
Description | 'OCNRF Oauth Access token non current Key Id certificate is expiring in less than 30 days' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, KeyId: {{$labels.KeyId}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} OCNRF Oauth Access token non current Key Id certificate is expiring in less than 30 days.' |
Severity | Info |
Condition | Oauth Non Current Key ID details are expiring in more than 24 hours and less than 30 days |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7041 |
Metric Used | ocnrf_oauth_keyData_expiryStatus |
Recommended Actions |
The alert is cleared when certificate for the non-current key id's certificate expiry time is more than 30 days. Steps: Replace expiring certificate key pair with new ones. For more information on creating certificate key pair, see Oracle Communications Cloud Native Core, Network Repository Function Installation, Upgrade, and Fault Recovery Guide. |
Available in OCI | No |
6.3.4.2 Overload Control Based on Percentage Discards Feature
This section lists the alerts that are specific to Overload Control Based on Percentage Discards feature. For more information about the feature, see the Overload Control section.
6.3.4.2.1 OcnrfMemoryUsageCrossedMinorThreshold
Table 6-625 OcnrfMemoryUsageCrossedMinorThreshold
Field | Details |
---|---|
Description | 'OCNRF Memory Usage for pod <Pod name> has crossed the configured minor threshold (50 %) (value={{ $value }}) of its limit.' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : Memory Usage of pod exceeded 50% of its limit.' |
Severity | Minor |
Condition | A pod has reached the configured minor threshold (50%) of its memory resource limits. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7030 |
Metric Used | 'container_memory_usage_bytes' and
'container_spec_memory_limit_bytes'
Note: This is a Kubernetes metric used for instance availability monitoring. If the metric is not available, use the similar metric as exposed by the monitoring system. |
Recommended Actions | The alert gets cleared when the memory utilization falls
below the minor threshold or crosses the major threshold, in which case
OcnrfMemoryUsageCrossedMajorThreshold alert is raised.
Note: The threshold is configurable in the alerts file. In case the issue persists, capture all the outputs for the above steps and contact My Oracle Support. Note: Use CNC NF Data Collector tool for capturing logs. For more information on how to collect logs using Data Collector tool, see Oracle Communications Cloud Native Core, Network Function Data Collector User Guide. |
Available in OCI | Yes |
6.3.4.2.2 OcnrfMemoryUsageCrossedMajorThreshold
Table 6-626 OcnrfMemoryUsageCrossedMajorThreshold
Field | Details |
---|---|
Description | 'OCNRF Memory Usage for pod <Pod name> has crossed the major threshold (60%) (value = {{ $value }}) of its limit.' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : Memory Usage of pod exceeded 60% of its limit.' |
Severity | Major |
Condition | A pod has reached the configured major threshold (60%) of its memory resource limits. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7031 |
Metric Used | 'container_memory_usage_bytes' and
'container_spec_memory_limit_bytes'
Note: This is a Kubernetes metric used for instance availability monitoring. If the metric is not available, use the similar metric as exposed by the monitoring system. |
Recommended Actions | The alert gets cleared when the memory utilization falls
below the major threshold or crosses the critical threshold, in which
case OcnrfMemoryUsageCrossedCriticalThreshold alert is raised.
Note: The threshold is configurable in the alert file. In case the issue persists, capture all the outputs for the above steps and contact My Oracle Support. Note: Use CNC NF Data Collector tool for capturing logs. For more information on how to collect logs using Data Collector tool, see Oracle Communications Cloud Native Core, Network Function Data Collector User Guide. |
Available in OCI | Yes |
6.3.4.2.3 OcnrfMemoryUsageCrossedCriticalThreshold
Table 6-627 OcnrfMemoryUsageCrossedCriticalThreshold
Field | Details |
---|---|
Description | 'OCNRF Memory Usage for pod <Pod name> has crossed the configured critical threshold (70%) (value = {{ $value }}) of its limit.' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : Memory Usage of pod exceeded 70% of its limit.' |
Severity | Critical |
Condition | A pod has reached the configured critical threshold (70%) of its memory resource limits. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7032 |
Metric Used | 'container_memory_usage_bytes' and
'container_spec_memory_limit_bytes'
Note: This is a Kubernetes metric used for instance availability monitoring. If the metric is not available, use a similar metric as exposed by the monitoring system. |
Recommended Actions | The alert gets cleared when the memory utilization falls
below the critical threshold.
Note: The threshold is configurable in the alert file. In case the issue persists, capture all the outputs for the above steps and contact My Oracle Support. Note: Use CNC NF Data Collector tool for capturing logs. For more information on how to collect logs using Data Collector tool, see Oracle Communications Cloud Native Core, Network Function Data Collector User Guide. |
Available in OCI | Yes |
6.3.4.2.4 OcnrfOverloadThresholdBreachedL1
Table 6-628 OcnrfOverloadThresholdBreachedL1
Field | Details |
---|---|
Description | 'Overload Level of {{$labels.app_kubernetes_io_name}} service is L1' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, podname: {{$labels.kubernetes_pod_name}}: Overload Level of {{$labels.app_kubernetes_io_name}} service is L1' |
Severity | Warning |
Condition | NRF Services have breached its configured threshold of Level L1 for any of the aforementioned metrics. Thresholds are configured for CPU, svc_failure_count, svc_pending_count, and memory. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7059 |
Metric Used | load_level |
Recommended Actions |
The alert is cleared when the Ingress Traffic rate falls below the configured L1 threshold. Note: The thresholds can be configured using REST API. Steps:
|
Available in OCI | Yes |
6.3.4.2.5 OcnrfOverloadThresholdBreachedL2
Table 6-629 OcnrfOverloadThresholdBreachedL2
Field | Details |
---|---|
Description | 'Overload Level of {{$labels.app_kubernetes_io_name}} service is L2' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, podname: {{$labels.kubernetes_pod_name}}: Overload Level of {{$labels.app_kubernetes_io_name}} service is L2' |
Severity | Warning |
Condition | NRF Services have breached its configured threshold of Level L2 for any of the aforementioned metrics. Thresholds are configured for CPU, svc_failure_count, svc_pending_count, and memory. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7060 |
Metric Used | load_level |
Recommended Actions |
The alert is cleared when the Ingress Traffic rate falls below the configured L2 threshold. Note: The thresholds can be configured using REST API. Steps:
|
Available in OCI | Yes |
6.3.4.2.6 OcnrfOverloadThresholdBreachedL3
Table 6-630 OcnrfOverloadThresholdBreachedL3
Field | Details |
---|---|
Description | 'Overload Level of {{$labels.app_kubernetes_io_name}} service is L3' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, podname: {{$labels.kubernetes_pod_name}}: Overload Level of {{$labels.app_kubernetes_io_name}} service is L3' |
Severity | Warning |
Condition | NRF Services have breached its configured threshold of Level L3 for any of the aforementioned metrics. Thresholds are configured for CPU, svc_failure_count, svc_pending_count, and memory. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7061 |
Metric Used | load_level |
Recommended Actions |
The alert is cleared when the Ingress Traffic rate falls below the configured L3 threshold. Note: The thresholds can be configured using REST API. Steps:
|
Available in OCI | Yes |
6.3.4.2.7 OcnrfOverloadThresholdBreachedL4
Table 6-631 OcnrfOverloadThresholdBreachedL4
Field | Details |
---|---|
Description | 'Overload Level of {{$labels.app_kubernetes_io_name}} service is L4' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, podname: {{$labels.kubernetes_pod_name}}: Overload Level of {{$labels.app_kubernetes_io_name}} service is L4' |
Severity | Warning |
Condition | NRF Services have breached its configured threshold of Level L4 for any of the aforementioned metrics. Thresholds are configured for CPU, svc_failure_count, svc_pending_count, and memory. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7062 |
Metric Used | load_level |
Recommended Actions |
The alert is cleared when the Ingress Traffic rate falls below the configured L4 threshold. Note: The thresholds can be configured using REST API. Steps:
|
Available in OCI | Yes |
6.3.4.3 DNS NAPTR Update Feature
This section lists the alerts that are specific to DNS NAPTR Update feature. For more information about the feature, see the DNS NAPTR Update section.
6.3.4.3.1 OcnrfDnsNaptrFailureResponseStatus
Table 6-632 OcnrfDnsNaptrFailureResponseStatus
Field | Details |
---|---|
Description | OCNRF DNS NAPTR Response status is not healthy |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, NfInstanceId: {{$labels.NfInstanceId}}, NfSetFqdn: {{$labels.NfSetFqdn}}, Replacement: {{$labels.Replacement}},timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} OCNRF Dns Naptr Response status is not healthy.' |
Severity | Major |
Condition | The DNS NAPTR response towards DNS Server is not successful. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7063 |
Metric Used | ocnrf_dns_naptr_failure_rx_response |
Recommended Actions | This alert is cleared when DNS NAPTR response is successful either automatic through service operations, or manual trigger for update and delete NAPTR requests. |
6.3.4.3.2 OcnrfAlternateRouteUpstreamDnsRetryExhausted
Table 6-633 OcnrfAlternateRouteUpstreamDnsRetryExhausted
Field | Details |
---|---|
Description | OCNRF alternate route upstream DNS retry exhausted |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, podname: {{$labels.kubernetes_pod_name}}, FQDNS_Name: {{$labels.FQDNS_Name}}, Replacement_Name: {{$labels.Replacement_Name}},timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} OCNRF alternate route upstream dns retry exhausted' |
Severity | Major |
Condition | The DNS NAPTR retry is exhausted. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7064 |
Metric Used | oc_alternate_route_upstream_dns_retry_exhausted |
Recommended Actions | This alert is cleared automatically in 2 minutes. |
Available in OCI | No |
6.3.4.4 Notification Retry Feature
This section lists the alerts that are specific to Notification Retry feature. For more information about the feature, see the Notification Retry section.
6.3.4.4.1 OcnrfNotificationRetryExhausted
Table 6-634 OcnrfNotificationRetryExhausted
Field | Details |
---|---|
Description | 'OCNRF NotificationRetry Exhausted' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, podname: {{$labels.kubernetes_pod_name}}, SubscriptionId: {{$labels.SubscriptionId}}, NotificationHostPort: {{$labels.NotificationHostPort}}' |
Severity | Major |
Condition | This alarm is raised when number of retries are exhausted. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7065 |
Metric Used | ocnrf_nfStatusNotify_rx_responses_total |
Recommended Actions | The alert is cleared automatically after 5 minutes.
Steps: Check logs in NF management pod to check the reason for retry query failures. Note: Use CNC NF Data Collector tool for capturing logs. For more information on how to collect logs using Data Collector tool, see Oracle Communications Cloud Native Core, Network Function Data Collector User Guide. |
Available in OCI | Yes |
6.3.4.4.2 OcnrfNotificationFailureOtherThanRetryExhausted
Table 6-635 OcnrfNotificationFailureOtherThanRetryExhausted
Field | Details |
---|---|
Description | 'OCNRF notification failure other than retry exhausted' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, podname: {{$labels.kubernetes_pod_name}}, SubscriptionId: {{$labels.SubscriptionId}}, NotificationHostPort: {{$labels.NotificationHostPort}}, NumberOfRetriesAttempted: {{$labels.NumberOfRetriesAttempted}}' |
Severity | Major |
Condition | This alarm is raised when notification failure occurs with reason other than retry count exhausted. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7066 |
Metric Used | ocnrf_nfStatusNotify_rx_responses_total |
Recommended Actions | The alert is cleared automatically after 5 minutes.
Steps: Check logs in NF management pod to check the reason for retry query failures. Note: Use CNC NF Data Collector tool for capturing logs. For more information on how to collect logs using Data Collector tool, see Oracle Communications Cloud Native Core, Network Function Data Collector User Guide. |
Available in OCI | Yes |
6.3.4.5 NRF Message Feed Feature
This section lists the alerts that are specific to NRF Message Feed feature. For more information about the feature, see the NRF Message Feed section.
6.3.4.5.1 OcnrfIngressGatewayDDUnreachable
Table 6-636 OcnrfIngressGatewayDDUnreachable
Field | Details |
---|---|
Description | OCNRF Ingress Gateway Data Director unreachable |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} OCNRF Ingress Gateway Data Director unreachable' |
Severity | Major |
Condition | This alarm is raised when data director is not reachable from Ingress Gateway. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7067 |
Metric Used | oc_ingressgateway_dd_unreachable |
Recommended Actions | Alert gets cleared automatically when the connection with data director is established. |
Available in OCI | No |
6.3.4.5.2 OcnrfEgressGatewayDDUnreachable
Table 6-637 OcnrfEgressGatewayDDUnreachable
Field | Details |
---|---|
Description | OCNRF Egress Gateway Data Director unreachable |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} OCNRF Egress Gateway Data Director unreachable' |
Severity | Major |
Condition | This alarm is raised when data director is not reachable from Egress Gateway. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7068 |
Metric Used | oc_egressgateway_dd_unreachable |
Recommended Actions | Alert gets cleared automatically when the connection with data director is established. |
Available in OCI | No |
6.3.4.6 Subscription Limit Feature
This section lists the alerts that are specific to Subscription Limit feature. For more information about the feature, see the Subscription Limit section.
6.3.4.6.1 OcnrfSubscriptionGlobalCountWarnThresholdBreached
Table 6-638 OcnrfSubscriptionGlobalCountWarnThresholdBreached
Field | Details |
---|---|
Description | The total number of subscriptions has breached the configured WARN level threshold. |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}: The total number of subscriptions has breached the configured WARN level threshold' |
Severity | Warning |
Condition | This alarm is raised when the total number of subscriptions has breached the configured WARN level threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7069 |
Metric Used | ocnrf_nfset_limit_level |
Recommended Actions |
The alert is cleared automatically when the count comes down due to unsubscription. Note: The thresholds can be configured using REST API. Steps:
|
Available in OCI | Yes |
6.3.4.6.2 OcnrfSubscriptionGlobalCountMinorThresholdBreached
Table 6-639 OcnrfSubscriptionGlobalCountMinorThresholdBreached
Field | Details |
---|---|
Description | The total number of subscriptions has breached the configured MINOR level threshold |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}: The total number of subscriptions has breached the configured MINOR level threshold' |
Severity | Minor |
Condition | This alarm is raised when the total number of subscriptions has breached the configured MINOR level threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7070 |
Metric Used | ocnrf_nfset_limit_level |
Recommended Actions |
The alert is cleared automatically when the count comes down due to unsubscription. Note: The thresholds can be configured using REST API. Steps:
|
Available in OCI | Yes |
6.3.4.6.3 OcnrfSubscriptionGlobalCountMajorThresholdBreached
Table 6-640 OcnrfSubscriptionGlobalCountMajorThresholdBreached
Field | Details |
---|---|
Description | The total number of subscriptions has breached the configured MAJOR level threshold |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}: The total number of subscriptions has breached the configured MAJOR level threshold' |
Severity | MAJOR |
Condition | This alarm is raised when the total number of subscriptions has breached the configured MAJOR level threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7071 |
Metric Used | ocnrf_nfset_limit_level |
Recommended Actions |
The alert is cleared automatically when the count comes down due to unsubscription. Note: The thresholds can be configured using REST API. Steps:
|
Available in OCI | Yes |
6.3.4.6.4 OcnrfSubscriptionGlobalCountCriticalThresholdBreached
Table 6-641 OcnrfSubscriptionGlobalCountCriticalThresholdBreached
Field | Details |
---|---|
Description | The total number of subscriptions has breached the configured CRITICAL level threshold |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}: The total number of subscriptions has breached the configured CRITICAL level threshold' |
Severity | Critical |
Condition | This alarm is raised when the total number of subscriptions has breached the configured CRITICAL level threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7072 |
Metric Used | ocnrf_nfset_limit_level |
Recommended Actions |
The alert is cleared automatically when the count comes down due to unsubscription. Note: The thresholds can be configured using REST API. Steps:
|
Available in OCI | Yes |
6.3.4.6.5 OcnrfSubscriptionMigrationInProgressWarn
Table 6-642 OcnrfSubscriptionMigrationInProgressWarn
Field | Details |
---|---|
Description | The subscription migration is pending and subscriptionLimit feature is disabled |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, nrflevel:{{$labels.NrfLevel}}, subscriptionLimitFeatureStatus:{{$labels.subscriptionLimitFeatureStatus}}: The subscription migration is pending and subscriptionLimit feature is disabled' |
Severity | Warning |
Condition | The subscription migration is pending and subscriptionLimit feature is disabled. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7073 |
Metric Used | ocnrf_subscription_migration_status |
Recommended Actions | This alert is cleared automatically when the migration is complete. |
Available in OCI | No |
6.3.4.6.6 OcnrfSubscriptionMigrationInProgressCritical
Table 6-643 OcnrfSubscriptionMigrationInProgressCritical
Field | Details |
---|---|
Description | The subscription migration is pending and subscriptionLimit feature is enabled |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, nrflevel:{{$labels.NrfLevel}}, subscriptionLimitFeatureStatus:{{$labels.subscriptionLimitFeatureStatus}}: The subscription migration is pending and subscriptionLimit feature is enabled' |
Severity | Warning |
Condition | The subscription migration is pending and subscriptionLimit feature is enabled. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7074 |
Metric Used | ocnrf_subscription_migration_status |
Recommended Actions |
This alert is cleared automatically when the migration is complete. Steps: Disable the Subscription Limit feature. For more information, see Oracle Communications Cloud Native Core, Network Repository Function REST Specification Guide. |
Available in OCI | No |
6.3.4.7 Pod Protection Support for NRF Subscription Microservice
This section lists the alerts that are specific to Pod Protection Support for NRF Subscription Microservice feature. For more information about the feature, see the Pod Protection Support for NRF Subscription Microservice section.
6.3.4.7.1 OcnrfPodInDangerOfCongestionState
Table 6-644 OcnrfPodInDangerOfCongestionState
Field | Details |
---|---|
Description | 'The pod {{$labels.kubernetes_pod_name}} of service {{$labels.app_kubernetes_io_name}} is in Danger of Congestion state' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : The pod is in Danger of Congestion state' |
Severity | Major |
Condition | A pod of a service is in Danger Of Congestion state.
This could be due to CPU Usage or Pending Message Count above configured
thresholds.
This alert is raised when the Pod Protection feature is enabled for nfSubscription service. Currently this is applicable for NfSubscription service only. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7079 |
Metric Used | ocnrf_pod_congestion_state |
Recommended Actions | The alert is cleared when the CPU or Pending Message
Count goes below the configured thresholds for the Danger of Congested
state.
Note: The thresholds can be viewed using REST API. Reassess if the NRF is receiving additional traffic. If this is unexpected, contact My Oracle Support. Steps:
|
Available in OCI | No |
6.3.4.7.2 OcnrfPodPendingMessageCountInDangerOfCongestionState
Table 6-645 OcnrfPodPendingMessageCountInDangerOfCongestionState
Field | Details |
---|---|
Description | 'The pod {{$labels.kubernetes_pod_name}} of service {{$labels.app_kubernetes_io_name}} is in Danger of Congestion state due to Pending Message Count above threshold' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : The pod is in Danger of Congestion state due to Pending Message Count above threshold' |
Severity | Major |
Condition |
A pod of a service is in Danger Of Congestion state due to its Pending Message Count above configured thresholds. Currently this is applicable for NfSubscription service only. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7081 |
Metric Used | ocnrf_pod_pending_message_count_congestion_state |
Recommended Actions | The alert is cleared when the pending message count goes
below the configured thresholds for the Danger of Congested state.
Note: The thresholds can be viewed using REST API. Steps: Reassess if the NRF is receiving additional traffic. If this is unexpected, contact My Oracle Support.
|
6.3.4.7.3 OcnrfPodInCongestedState
Table 6-646 OcnrfPodInCongestedState
Field | Details |
---|---|
Description | 'The pod {{$labels.kubernetes_pod_name}} of service {{$labels.app_kubernetes_io_name}} is in Congested state' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : The pod is in Congested state' |
Severity | Major |
Condition | One or more pods of a service are in congested state. This could be due to CPU usage or Pending Message Count above configured thresholds. Currently this is applicable for NfSubscription service only. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7082 |
Metric Used | ocnrf_pod_congested_state |
Recommended Actions | The alert is cleared when the CPU usage or Pending
Message Count goes below the configured thresholds for the congested
state.
Note: The thresholds can be viewed using REST API. Steps: Reassess if the NRF is receiving additional traffic. If this is unexpected, contact My Oracle Support.
|
Available in OCI | No |
6.3.4.7.4 OcnrfPodCpuUsageInCongestedState
Table 6-647 OcnrfPodCpuUsageInCongestedState
Field | Details |
---|---|
Description | 'The pod {{$labels.kubernetes_pod_name}} of service {{$labels.app_kubernetes_io_name}} is in Congested state due to CPU usage above threshold' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : The pod is in Congested state due to CPU usage above threshold' |
Severity | Major |
Condition | A pod of a service is in Congested state due to its CPU Usage above configured thresholds. Currently this is applicable for NfSubscription service only. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7083 |
Metric Used | ocnrf_pod_cpu_congestion_state |
Recommended Actions | The alert is cleared when the CPU usage goes below the
configured thresholds for the congested state.
Note: The thresholds can be viewed using REST API. Steps: Reassess if the NRF is receiving additional traffic. If this is unexpected, contact My Oracle Support.
|
Available in OCI | No |
6.3.4.7.5 OcnrfPodCpuUsageInDangerOfCongestionState
Table 6-648 OcnrfPodCpuUsageInDangerOfCongestionState
Field | Details |
---|---|
Description | 'The pod {{$labels.kubernetes_pod_name}} of service {{$labels.app_kubernetes_io_name}} is in Danger of Congestion state due to CPU usage above threshold' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : The pod is in Danger of Congestion state due to CPU usage above threshold' |
Severity | Major |
Condition |
A pod of a service is in Danger Of Congestion state due to its CPU above configured thresholds. This alert is raised when the Pod Pretoectoin feature is enabled for nfSubscription service. Currently this is applicable for NfSubscription service only. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7080 |
Metric Used | ocnrf_pod_cpu_congestion_state |
Recommended Actions | The alert is cleared when the CPU goes below the
configured thresholds for the Danger of Congested state.
Note: The thresholds can be viewed using REST API. Steps: Reassess if the NRF is receiving additional traffic. If this is unexpected, contact My Oracle Support.
|
Available in OCI | No |
6.3.4.7.6 OcnrfPodPendingMessageCountInCongestedState
Table 6-649 OcnrfPodPendingMessageCountInCongestedState
Field | Details |
---|---|
Description | 'The pod {{$labels.kubernetes_pod_name}} of service {{$labels.app_kubernetes_io_name}} is in Congested state due to Pending Message Count above threshold' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : The pod is in Congested state due to Pending Message Count above threshold' |
Severity | Major |
Condition | A pod of a service is in Congested state due to its Pending Message Count above configured thresholds. Currently this is applicable for NfSubscription service only. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7084 |
Metric Used | ocnrf_pod_pending_message_count_congestion_state |
Recommended Actions | The alert is cleared when the pending message count goes
below the configured thresholds for the congested state.
Note: The thresholds can be viewed using REST API. Steps: Reassess if the NRF is receiving additional traffic. If this is unexpected, contact My Oracle Support.
|
Available in OCI | No |
6.3.4.8 Controlled Shutdown of NRF Feature
This section lists the alerts that are specific to Controlled Shutdown of NRF feature. For more information about the feature, see the Controlled Shutdown of NRF section.
6.3.4.8.1 OcnrfOperationalStateCompleteShutdown
Table 6-650 OcnrfOperationalStateCompleteShutdown
Field | Details |
---|---|
Description | 'The operational state of NRF is Complete Shutdown.' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : The Operational state of NRF is Complete Shutdown' |
Severity | Warning |
Condition | The operator has changed the operational state of NRF to Complete Shutdown. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7085 |
Metric Used | ocnrf_operational_state |
Recommended Actions | The alert is cleared when the user changes the
operational state to NORMAL
|
Available in OCI | No |
6.3.4.8.2 OcnrfAuditOperationsPaused
Table 6-651 OcnrfAuditOperationsPaused
Field | Details |
---|---|
Description | 'The Audit procedures at NRF have been paused.' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : The Audit procedures at NRF has been paused' |
Severity | Warning |
Condition | The NrfAuditor microservice has paused all audit
procedures.
This occurs during any of the following scenarios:
|
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7086 |
Metric Used | ocnrf_audit_status |
Recommended Actions | The alert is expected to clear automatically, after the
waiting period, and once all the above conditions are resolved.
|
Notes |
NrfAuditor continues to remain in the paused state for
some time, even after
|
Available in OCI | No |
6.3.4.9 Monitoring the Availability of SCP Using SCP Health APIs Feature
This section lists the alerts that are specific to Monitoring the Availability of SCP Using SCP Health APIs feature. For more information about the feature, see the Monitoring the Availability of SCP Using SCP Health APIs section.
6.3.4.9.1 OcnrfAllSCPsMarkedAsUnavailable
Table 6-652 OcnrfAllSCPsMarkedAsUnavailable
Field | Details |
---|---|
Description | 'All SCPs have been marked unavailable.' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : All SCPs have been marked as unavailable' |
Severity | Critical |
Condition | All SCPs have been marked unavailable. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7088 |
Metric Used | 'oc_egressgateway_peer_count and oc_egressgateway_peer_available_count' |
Recommended Actions | NF clears the critical alarm when atleast 1 SCP peer in a peerset becomes available such that all other SCP peers in the given peerset are still unavailable. |
Available in OCI | Yes |
6.3.4.9.2 OcnrfSCPMarkedAsUnavailable
Table 6-653 OcnrfSCPMarkedAsUnavailable
Field | Details |
---|---|
Description | 'An SCP has been marked unavailable.' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : One of the SCP has been marked unavailable' |
Severity | Major |
Condition | One of the SCPs has been marked unhealthy. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7087 |
Metric Used | oc_egressgateway_peer_health_status |
Recommended Actions | This alert gets cleared when unavailable SCPs become available. |
Available in OCI | Yes |
6.3.4.10 CCA Header Validation in NRF for Access Token Service Operation Feature
This section lists the alerts that are specific to CCA Header Validation in NRF for Access Token Service Operation feature. For more information about the feature, see the CCA Header Validation in NRF for Access Token Service Operation section.
6.3.4.10.1 OcnrfCcaRootCertificateExpiringIn4Hours
Table 6-654 OcnrfCcaRootCertificateExpiringIn4Hours
Field | Details |
---|---|
Description | 'The CCA Root Certificates expiring in 4 hours'. |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : CCA Root Certificate is expiring in 4 Hours' |
Severity | Critical |
Condition | Indicates the expiry dates of the CCA Root certificates that are expiring in four hours. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7091 |
Metric Used | 'oc_ingressgateway_cca_certificate_info' |
Recommended Actions | The alert is cleared when the expiring CCA root
certificates are replaced with new ones.
Steps: Replace expiring certificate key pair with new ones. For more information on creating certificate key pair, see Oracle Communications Cloud Native Core, Network Repository Function Installation, Upgrade, and Fault Recovery Guide. |
Available in OCI | No |
6.3.4.10.2 OcnrfCcaRootCertificateExpiringIn1Day
Table 6-655 OcnrfCcaRootCertificateExpiringIn1Day
Field | Details |
---|---|
Description | 'The CCA Root Certificates expiring in 1 day'. |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : CCA Root Certificate is expiring in 1 Day' |
Severity | Major |
Condition | Indicates the expiry dates of the CCA Root certificates that are expiring in one day. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7090 |
Metric Used | 'oc_ingressgateway_cca_certificate_info' |
Recommended Actions | The alert is cleared when the expiring CCA root
certificates are replaced with new ones.
Steps: Replace expiring certificate key pair with new ones. For more information on creating certificate key pair, see Oracle Communications Cloud Native Core, Network Repository Function Installation, Upgrade, and Fault Recovery Guide. |
Available in OCI | No |
6.3.4.10.3 OcnrfCcaRootCertificateExpiringIn5Days
Table 6-656 OcnrfCcaRootCertificateExpiringIn5Days
Field | Details |
---|---|
Description | 'The CCA Root Certificates expiring in 5 days.' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : CCA Root Certificate is expiring in 5 Days' |
Severity | Minor |
Condition | Indicates the expiry dates of the CCA Root certificates that are expiring in five days. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7089 |
Metric Used | 'oc_ingressgateway_cca_certificate_info' |
Recommended Actions | The alert is cleared when the expiring CCA root
certificates are replaced with new ones.
Steps: Replace expiring certificate key pair with new ones. For more information on creating certificate key pair, see Oracle Communications Cloud Native Core, Network Repository Function Installation, Upgrade, and Fault Recovery Guide. |
Available in OCI | No |
6.3.4.11 NRF Georedundancy Feature
This section lists the alerts that are specific to NRF Georedundancy feature. For more information about the feature, see the NRF Georedundancy section.
6.3.4.11.1 OcnrfDbReplicationStatusInactive
Table 6-657 OcnrfDbReplicationStatusInactive
Field | Details |
---|---|
Description | 'The Database Replication Status is currently INACTIVE.' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, nftype:{{$labels.NfType}}, nrflevel:{{$labels.NrfLevel}}, remoteNrfInstanceId: {{$labels.nrfInstanceId}}, remoteSiteName: {{$labels.siteName}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: The database replication status is INACTIVE.' |
Severity | Critical |
Condition | The database replication channel status between the given site and the georedundant site(s) is inactive. The alert is raised per replication channel. The alarm is raised or cleared only if the georedundancy feature is enabled. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7013 |
Metric Used | 'ocnrf_dbreplication_status' |
Recommended Actions | The alert is cleared when the database channel replication status between the given site and the georedundant site(s) is up. For more information on how to check the database replication status, see Oracle Communications Cloud Native Core, cnDBTier User Guide. |
Notes | The alarm is included only if the georedundancy feature is enabled. |
Available in OCI | No |
6.3.4.11.2 OcnrfReplicationStatusMonitoringInactive
Table 6-658 OcnrfReplicationStatusMonitoringInactive
Field | Details |
---|---|
Description | 'OCNRF Replication Status Monitoring Inactive' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : Pod {{ $labels.kubernetes_pod_name}} are not monitoring the replication status' |
Severity | Critical |
Condition | This alarm is raised when one or more pods are not monitoring the replication status. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7078 |
Metric Used | ocnrf_replication_status_monitoring_inactive |
Recommended Actions | Resolution Steps:
|
6.3.4.12 XFCC Header Validation Feature
This section lists the alert that is specific to XFCC Header Validation feature. For more information about the feature, see the XFCC Header Validation section.
6.3.4.12.1 OcnrfNfAuthenticationFailureRequestsRejected
Table 6-659 OcnrfNfAuthenticationFailureRequestsRejected
Field | Details |
---|---|
Description | 'Service request(s) received from NF have been rejected by OCNRF (current value is: {{ $value }})' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : Request rejected for Nf FQDN based Authentication failure.' |
Severity | Warning |
Condition | NRF rejected a service request due to NF authentication failure |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7015 |
Metric Used | 'ocnrf_nf_authentication_failure_total' |
Recommended Actions | The alert is cleared automatically.
Steps: Filter out nfAccessToken application ERROR logs on Kibana for more details. |
Available in OCI | No |
6.3.4.13 Enhanced NRF Set Based Deployment (NRF Growth) Feature
This section lists the alert that is specific to Enhanced NRF Set Based Deployment (NRF Growth) feature. For more information about the feature, see the Enhanced NRF Set Based Deployment (NRF Growth) section.
6.3.4.13.1 OcnrfRemoteSetNrfSyncFailed
Table 6-660 OcnrfRemoteSetNrfSyncFailed
Field | Details |
---|---|
Description | 'A sync request to the NRF in the remote set has
failed.'
Note: The alert must be configured only if the NRF Growth feature is enabled. |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : A sync request to the NRF in the remote set has failed.' |
Severity | Minor |
Condition | Sync request to the NRF in the remote NRF set has failed. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7098 |
Metric Used | ocnrf_query_remote_cds_responses_total |
Recommended Actions |
The alert is cleared when the synchronization with the remote NRF set is successful. Steps:
|
Available in OCI | No |
6.3.4.13.2 OcnrfSyncFailureFromAllNrfsOfAnyRemoteSet
Table 6-661 OcnrfSyncFailureFromAllNrfsOfAnyRemoteSet
Field | Details |
---|---|
Description | 'Sync requests to all the NRFs of a remote set has
failed.'
Note: The alert must be configured only if the NRF Growth feature is enabled. |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : Sync requests to all the NRFs in any of the remote sets have failed' |
Severity | Major |
Condition | The sync requests to all the NRFs in the remote sets has failed. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7099 |
Metric Used | ocnrf_remote_set_unavailable_total |
Recommended Actions | The alert is cleared when synchronization is successful
with at least one NRF of the remote NRF set.
Steps:
|
Available in OCI | No |
6.3.4.13.3 OcnrfSyncFailureFromAllNrfsOfAllRemoteSets
Table 6-662 OcnrfSyncFailureFromAllNrfsOfAllRemoteSets
Field | Details |
---|---|
Description | 'Sync request to all the NRFs in all the remote sets
have failed.'
Note: The alert must be configured only if the NRF Growth feature is enabled. |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : Sync request to all the NRFs in all the remote sets have failed' |
Severity | critical |
Condition | Sync requests to all the NRFs in all the remote sets have failed. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7100 |
Metric Used | ocnrf_all_remote_sets_unavailable_total |
Recommended Actions |
The alert is cleared when synchronization is successful with at least one NRF of the remote set(s). Steps:
|
Available in OCI | No |
6.3.4.13.4 OcnrfCacheDataServiceDown
Table 6-663 OcnrfCacheDataServiceDown
Field | Details |
---|---|
Description | 'OCNRF NrfCacheData service {{$labels.app_kubernetes_io_name}} is down' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : Cache Data Service is down' |
Severity | Critical |
Condition | Cache Data Service is unavailable. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7101 |
Metric Used | up |
Recommended Actions |
The alert is cleared when the Cache Data Service (CDS) is available. Steps:
Note: Use the CNC NF Data Collector tool for capturing logs. For more information on how to collect logs using the Data Collector tool, see Oracle Communications Cloud Native Core, Network Function Data Collector User Guide. |
Available in OCI | No |
6.3.4.13.5 OcnrfDatabaseFallbackUsed
Table 6-664 OcnrfDatabaseFallbackUsed
Field | Details |
---|---|
Description | 'A service operation is unable to get data from the Cache Data Service, and hence gets the data from the cnDBTier to fulfill the service operation' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : A service Operation is unable to get data from the Cache Data Service, so falling back to DB' |
Severity | Major |
Condition | When a service operation is unable to get data from the Cache Data Service, and hence gets the data from the database to fulfill the service operation. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7102 |
Metric Used | ocnrf_db_fallback_total |
Recommended Actions |
The alert is cleared automatically. Steps:
|
Available in OCI | No |
6.3.4.13.6 OcnrfTotalNFsRegisteredAtSegmentBelowMinorThreshold
Table 6-665 OcnrfTotalNFsRegisteredAtSegmentBelowMinorThreshold
Field | Details |
---|---|
Description | The alert is raised when the number of NFs registered at the segment is below the configured minor threshold. |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : The number of NFs registered at the segment is below minor threshold' |
Severity | Minor |
Condition | The number of NFs registered at the segment is below
minor threshold.
Note: This alert is triggered when the
registered NF count is greater than or equal to 10 and below 20.
This default value can be modified in the
|
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7103 |
Metric Used | ocnrf_nf_registered_count |
Recommended Actions |
The alert is cleared when the number of registered NFs in the segment is above the minor threshold. Steps:
|
Available in OCI | No |
6.3.4.13.7 OcnrfTotalNFsRegisteredAtSegmentBelowMajorThreshold
Table 6-666 OcnrfTotalNFsRegisteredAtSegmentBelowMajorThreshold
Field | Details |
---|---|
Description | The alert is raised when the number of NFs registered at the segment is below the configured major threshold. |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : The number of NFs registered at the segment is below major threshold |
Severity | Major |
Condition | The number of NFs registered at the segment is below
major threshold.
Note: This alert is triggered when the
registered NF count is greater than or equal to 2 and below 10. This
default value can be modified in the
|
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7104 |
Metric Used | ocnrf_nf_registered_count |
Recommended Actions |
The alert is cleared when the number of registered NFs in the segment is above the major threshold. Steps:
|
Available in OCI | No |
6.3.4.13.8 OcnrfTotalNFsRegisteredAtSegmentBelowCriticalThreshold
Table 6-667 OcnrfTotalNFsRegisteredAtSegmentBelowCriticalThreshold
Field | Details |
---|---|
Description | The alert is raised when the number of NFs registered at the segment is below the configured critical threshold. |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : The number of NFs registered at the segment is below critical threshold' |
Severity | Critical |
Condition | The number of NFs registered at the segment is below
critical threshold.
Note: This alert is triggered when the
registered NF count is below 2. This default value can be modified
in the |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7105 |
Metric Used | ocnrf_nf_registered_count |
Recommended Actions |
The alert is cleared when the number of registered NFs in the segment is above the critical threshold. Steps:
|
6.3.4.14 Ingress Gateway Pod Protection Feature
This section lists the alerts that are specific to Ingress Gateway Pod Protection feature. For more information about the feature, see the Ingress Gateway Pod Protection section.
6.3.4.14.1 OcnrfIngressGatewayPodInDangerOfCongestionState
Table 6-668 OcnrfIngressGatewayPodInDangerOfCongestionState
Field | Details |
---|---|
Description | 'The pod {{$labels.kubernetes_pod_name}} is in Danger of Congestion state' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : The pod is in Danger of Congestion state' |
Severity | Major |
Condition |
When Ingress Gateway pod is in Danger Of Congestion state. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7092 |
Metric Used | oc_ingressgateway_pod_congestion_state |
Recommended Actions | The alert is cleared when the pod is out of Danger Of
Congestion (DoC) state.
Note: The thresholds can be viewed using REST API. Steps: Reassess if the NRF is receiving additional traffic. If this is unexpected, contact My Oracle Support.
|
Available in OCI | No |
6.3.4.14.2 OcnrfIngressGatewayPodInCongestedState
Table 6-669 OcnrfIngressGatewayPodInCongestedState
Field | Details |
---|---|
Description | 'The pod {{$labels.kubernetes_pod_name}} is in Congested state' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : The pod is in Congested state' |
Severity | Critical |
Condition |
When Ingress Gateway pod is in Congested state. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7093 |
Metric Used | oc_ingressgateway_pod_congestion_state |
Recommended Actions | The alert is cleared when the pod is out of Congested
state.
Note: The thresholds can be viewed using REST API. Steps: Reassess if the NRF is receiving additional traffic. If this is unexpected, contact My Oracle Support.
|
Available in OCI | No |
6.3.4.14.3 OcnrfIngressGatewayPodCpuUsageInCongestedState
Table 6-670 OcnrfIngressGatewayPodCpuUsageInCongestedState
Field | Details |
---|---|
Description | 'The pod {{$labels.kubernetes_pod_name}} is in Congested state' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : The pod is in Congested state' |
Severity | Critical |
Condition |
Ingress Gateway pod is in Congested state due to CPU consumption above the configured thresholds. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7094 |
Metric Used | oc_ingressgateway_pod_resource_state |
Recommended Actions | The alert is cleared when the CPU consumption goes below
the configured thresholds for the Congested state.
Note: The thresholds can be viewed using REST API. Steps: Reassess if the NRF is receiving additional traffic. If this is unexpected, contact My Oracle Support.
|
Available in OCI | No |
6.3.4.14.4 OcnrfIngressGatewayPodCpuUsageInDangerOfCongestionState
Table 6-671 OcnrfIngressGatewayPodCpuUsageInDangerOfCongestionState
Field | Details |
---|---|
Description | 'The pod {{$labels.kubernetes_pod_name}} is in Danger of Congestion state due to CPU usage above threshold' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : The pod is in Danger of Congestion state due to CPU usage above threshold' |
Severity | Major |
Condition |
Ingress Gateway pod is in Danger of Congestion state due to CPU consumption above the configured thresholds. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7095 |
Metric Used | oc_ingressgateway_pod_resource_state |
Recommended Actions | The alert is cleared when the CPU consumption is not as
per the configured thresholds value for the Danger of Congestion
state.
Note: The thresholds can be viewed using REST API. Steps: Reassess if the NRF is receiving additional traffic. If this is unexpected, contact My Oracle Support.
|
Available in OCI | No |
6.3.4.14.5 OcnrfIngressGatewayPodPendingMessageInCongestedState
Table 6-672 OcnrfIngressGatewayPodPendingMessageInCongestedState
Field | Details |
---|---|
Description | 'The pod {{$labels.kubernetes_pod_name}} is in Congested state' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : The pod is in Congested state' |
Severity | Critical |
Condition |
Ingress Gateway pod is in Congested state due to pending message count above the configured thresholds. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7096 |
Metric Used | oc_ingressgateway_pod_resource_state |
Recommended Actions | The alert is cleared when the pending message count is
not as per the configured thresholds value for the Congested state.
Note: The thresholds can be viewed using REST API. Steps: Reassess if the NRF is receiving additional traffic. If this is unexpected, contact My Oracle Support.
|
Available in OCI | No |
6.3.4.14.6 OcnrfIngressGatewayPodPendingMessageInDangerOfCongestionState
Table 6-673 OcnrfIngressGatewayPodPendingMessageInDangerOfCongestionState
Field | Details |
---|---|
Description | 'The pod {{$labels.kubernetes_pod_name}} is in Danger of Congestion state due to Pending Message above threshold' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}},podname: {{$labels.kubernetes_pod_name}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : The pod is in Danger of Congestion state due to Pending Message above threshold' |
Severity | Major |
Condition |
Ingress Gateway pod is in Danger of Congestion state due to pending message count above the configured thresholds. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7097 |
Metric Used | oc_ingressgateway_pod_resource_state |
Recommended Actions | The alert is cleared when the pending message count is
not as per the configured thresholds value for the Danger of Congestion
state.
Note: The thresholds can be viewed using REST API. Steps: Reassess if the NRF is receiving additional traffic. If this is unexpected, contact My Oracle Support.
|
Available in OCI | No |
6.3.4.15 Subscriber Location Function Feature
This section lists the alert that is specific to Subscriber Location Function feature. For more information about the feature, see the Subscriber Location Function section.
6.3.4.15.1 OcnrfMaxSlfAttemptsExhausted
Table 6-674 OcnrfMaxSlfAttemptsExhausted
Field | Details |
---|---|
Description | 'NF discovery request with fqdn {{$labels.NfProfileFqdn}} NF type {{$labels.NfType}} has exhausted maximum SLF attempts' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, nrflevel:{{$labels.NrfLevel}}, podname: {{$labels.kubernetes_pod_name}}, NfProfileFqdn: {{$labels.NfProfileFqdn}}, NfType: {{$labels.NfType}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: The maximum slf attempts have exhausted.' |
Severity | Critical |
Condition |
NF discovery request with FQDN of the given NFType UDR
has exhausted maximum SLF attempts. This alert is raised when the
Note: This alert is included if SLF selection from registered profiles is enabled. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7054 |
Metric Used | 'ocnrf_max_slf_attempts_exhausted_total' |
Recommended Actions |
The alert is cleared automatically after 5 minutes. Steps:
|
Available in OCI | Yes |
6.3.4.16 EmptyList in Discovery Response Feature
This section lists the alert that is specific to EmptyList in Discovery Response feature. For more information about the feature, see the EmptyList in Discovery Response section.
6.3.4.16.1 OcnrfNFDiscoveryEmptyListObservedNotification
Table 6-675 OcnrfNFDiscoveryEmptyListObservedNotification
Field | Details |
---|---|
Description | 'Empty List observed with received discovery request with NfType $labels.NfType Feature Status $labels.FeatureStatus' |
Summary | 'namespace: $labels.namespace, nrflevel:$labels.NrfLevel, podname: $labels.pod, NfType: $labels.NfType, FeatureStatus: $labels.FeatureStatus: Empty List observed with received discovery request' |
Severity | Critical |
Condition |
This alarm is raised when profiles do not match the discovery request. Also, this alarm is raised when the SUSPENDED profile is in response to incoming request and Empty List feature is enabled. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7055 |
Metric Used | ocnrf_nfDiscover_emptyList_total |
Recommended Actions |
The alert is cleared automatically after a duration of 5 minutes. Steps:
|
Available in OCI | No |
6.3.4.17 Support for TLS
This section lists the alert that is specific to Support for TLS feature. For more information about the feature, see the Support for TLS section.
6.3.4.17.1 OcnrfTLSCertificateExpireMinor
Table 6-676 OcnrfTLSCertificateExpireMinor
Field | Details |
---|---|
Description | 'TLS certificate to expire in 6 months'. |
Summary | 'namespace: {{$labels.namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : TLS certificate to expire in 6 months' |
Severity | Minor |
Condition | This alert is raised when the TLS certificate is about to expire in six months. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7106 |
Metric Used | security_cert_x509_expiration_seconds |
Recommended Actions |
The alert is cleared when the TLS certificate is renewed. For more information about certificate renewal, see "Creating Private Keys and Certificate " section in the Oracle Communications Cloud Native Core, Network Repository Function Installation, Upgrade, and Fault Recovery Guide. |
Available in OCI | No |
6.3.4.17.2 OcnrfTLSCertificateExpireMajor
Table 6-677 OcnrfTLSCertificateExpireMajor
Field | Details |
---|---|
Description | 'TLS certificate to expire in 3 months.' |
Summary | 'namespace: {{$labels.namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : TLS certificate to expire in 3 months' |
Severity | Major |
Condition | This alert is raised when the TLS certificate is about to expire in three months. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7107 |
Metric Used | security_cert_x509_expiration_seconds |
Recommended Actions |
The alert is cleared when the TLS certificate is renewed. For more information about certificate renewal, see "Creating Private Keys and Certificate" section in the Oracle Communications Cloud Native Core, Network Repository Function Installation, Upgrade, and Fault Recovery Guide. |
Available in OCI | No |
6.3.4.17.3 OcnrfTLSCertificateExpireCritical
Table 6-678 OcnrfTLSCertificateExpireCritical
Field | Details |
---|---|
Description | 'TLS certificate to expire in one month.' |
Summary | 'namespace: {{$labels.namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }} : TLS certificate to expire in 1 month' |
Severity | Critical |
Condition | This alert is raised when the TLS certificate is about to expire in one month. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7108 |
Metric Used | security_cert_x509_expiration_seconds |
Recommended Actions |
The alert is cleared when the TLS certificate is renewed. For more information about certificate renewal, see "Creating Private Keys and Certificate" section in the Oracle Communications Cloud Native Core, Network Repository Function Installation, Upgrade, and Fault Recovery Guide. |
Available in OCI | No |
6.3.4.18 Egress Gateway Pod Throttling
6.3.4.18.1 OcnrfEgressPerPodDiscardRateAboveMajorThreshold
Table 6-679 OcnrfEgressPerPodDiscardRateAboveMajorThreshold
Field | Details |
---|---|
Description | 'Egressgateway PerPod Discard Rate is greater than the configured major threshold. (current value is: {{ $value }})' |
Summary | 'kubernetes_namespace: {{$labels.namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Egressgateway PerPod Discard Rate is more than 1 request per second.' |
Severity | Major |
Condition | This alert is raised when the Egress Gateway pods discard traffic due to its request limit is greater than the configured threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7113 |
Metric Used | oc_egressgateway_podlevel_throttling_discarded_total |
Recommended Actions | The alert is cleared when the Egress Gateway pods
discard traffic rate falls below the major threshold.
Note: The threshold is configurable in the alert file.
Reassess why the NRF is receiving additional traffic (for example, Mated
site NRF is unavailable in georedundancy scenario). If this alert is
unexpected, contact My Oracle
Support.
Steps:
|
Available in OCI | No |
6.3.4.18.2 OcnrfEgressPerPodDiscardRateAboveCriticalThreshold
Table 6-680 OcnrfEgressPerPodDiscardRateAboveCriticalThreshold
Field | Details |
---|---|
Description | 'Egressgateway PerPod Discard Rate is greater than the configured critical threshold. (current value is: {{ $value }})' |
Summary | 'kubernetes_namespace: {{$labels.namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Egressgateway PerPod Discard Rate is more than 100 requests per second.’ |
Severity | Critical |
Condition | This alert is raised when the Egress Gateway pods discard traffic due to its request limit is greater than the configured threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7114 |
Metric Used | oc_egressgateway_podlevel_throttling_discarded_total |
Recommended Actions | The alert is cleared when the Egress Gateway pods
discard traffic rate falls below the critical threshold.
Note: The threshold is configurable in the alert file.
Reassess why the NRF is receiving additional traffic (for example, Mated
site NRF is unavailable in georedundancy scenario). If this alert is
unexpected, contact My Oracle
Support.
Steps:
|
Available in OCI | No |
6.3.4.19 Ingress Gateway Pod Protection Using Rate Limiting
6.3.4.19.1 OcnrfIngressDiscardDueToRateLimitMajorThreshold
Table 6-681 OcnrfIngressDiscardDueToRateLimitMajorThreshold
Field | Details |
---|---|
Description | 'Ingress Gateway discards due to rate limit exceeds the configured major threshold. (current value is: {{ $value }})' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Ingressgateway Discard due to Rate Limit is more than or equal to 1 requests per second and less than 100 requests per second.' |
Severity | Major |
Condition | This alert is raised when Ingress Gateway discard requests as rate limit exceeds the configured major threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7129 |
Metric Used | oc_ingressgateway_http_request_ratelimit_denied_count_total |
Recommended Actions |
The alert is cleared when the Ingress Gateway pods discard traffic rate falls below the major threshold or exceeds the critical threshold. Note: The threshold is configurable in the alert file. Reassess why the NRF is receiving additional traffic (for example, Mated site NRF is unavailable in georedundancy scenario). If this alert is unexpected, contact My Oracle Support. Steps:
|
Available in OCI | No |
6.3.4.19.2 OcnrfIngressDiscardDueToRateLimitCriticalThreshold
Table 6-682 OcnrfIngressDiscardDueToRateLimitCriticalThreshold
Field | Details |
---|---|
Description | 'Ingress gateway discards due to rate limit exceeds the configured critical threshold. (current value is: {{ $value }})' |
Summary | 'kubernetes_namespace: {{$labels.kubernetes_namespace}}, timestamp: {{ with query "time()" }}{{ . | first | value | humanizeTimestamp }}{{ end }}: Ingressgateway Discard due to Rate Limit is more than or equal to 100 requests per second.' |
Severity | Critical |
Condition | This alert is raised when Ingress Gateway discard requests as rate limit exceeds the configured critical threshold. |
OID | 1.3.6.1.4.1.323.5.3.36.1.2.7130 |
Metric Used | oc_ingressgateway_http_request_ratelimit_denied_count_total |
Recommended Actions |
The alert is cleared when the Ingress Gateway pods discard traffic rate falls below the critical threshold. Note: The threshold is configurable in the alert file. Reassess why the NRF is receiving additional traffic (for example, Mated site NRF is unavailable in georedundancy scenario). If this alert is unexpected, contact My Oracle Support. Steps:
|
Available in OCI | No |
6.3.5 NRF Alert Configuration
This section describes the measurement based alert rules configuration for NRF. The Alert Manager uses the Prometheus measurements values as reported by microservices in conditions under alert rules to trigger alerts.
Note:
- Alert file is packaged with NRF custom templates. The NRF CSAR package can be downloaded from MOS. Unzip the NRF CSAR package file to get the Alertrules.yaml file.
- Review the Alertrules.yaml file and edit the value of the parameters in the Alertrules.yaml file (if needed to be changed from default values) before configuring the alerts. See below table for details.
- kubernetes_namespace is configured as Kubernetes namespace in which NRF is deployed. Default value is NRF. Update the Alertrules.yaml file to reflect the correct NRF Kubernetes namespace.
Table 6-683 Alerts
Alert Name | Details | Default Value | Notes |
---|---|---|---|
OcnrfTotalIngressTrafficRateAboveMinorThreshold | Traffic Rate is above 80 Percent of Max requests per second | Greater than/equal to 800 and Less than 900 |
Maximum Ingress rate considered is 1000 requests per second. So, here in default value 800 is 80% of 1000 and 900 is 90% of 1000. For example, if value need to be updated then depending upon maximum ingress request rate, set [ 90% of Max Ingress Request Rate] and [ 80% of Max Ingress Request Rate] for this alert |
OcnrfTotalIngressTrafficRateAboveMajorThreshold | Traffic Rate is above 90 Percent of Max requests per second | Greater than/equal to 900 and Less than 950 |
Maximum Ingress rate considered is 1000 requests per second. So, here in default value 900 is 90% of 1000 and 950 is 95% of 1000. For example, if value need to be updated then depending upon maximum ingress request rate, set [ 90% of Max Ingress Request Rate] and [ 95% of Max Ingress Request Rate] for this alert |
OcnrfTotalIngressTrafficRateAboveCriticalThreshold | Traffic Rate is above 95 Percent of Max requests per second | Greater than/equal to 950 |
Maximum Ingress rate considered is 1000 requests per second. So, here in default value 950 is 95% of 1000. For example, if value need to be updated then depending upon maximum ingress request rate, set [ 95% of Max Ingress Request Rate] for this alert |
NRF Alert configuration in Prometheus
Update NRF alerts for CNE 1.8.x and previous versions
The following procedure describes how to update the NRF alerts for CNE version 1.8.x and previous versions:
_NAME_ :- Helm Release of Prometheus
_Namespace_ :- Kubernetes NameSpace in which Prometheus is installed
- Find the config map to configure alerts in Prometheus server
using the following command:
kubectl get configmap -n <Namespace>
where, <Namespace> is the prometheus server namespace used in helm install command. For example, assuming Prometheus server is under occne-infra namespace, run the following command to find the config map:kubectl get configmaps -n occne-infra | grep prometheus-server
- Take backup of current
configuration map of Prometheus:
kubectl get configmaps _NAME_-server -o yaml -n _Namespace_ > /tmp/tempConfig.yaml
- Check if alertsnrf is present in the
tempConfig.yaml file by running the following command:
cat /tmp/tempConfig.yaml | grep alertsnrf
Depending on the outcome of the previous step, perform anyone of the following steps:
- If alertsnrf is present, delete the
alertsnrf entry from the tempConfig.yaml file, by
running the following commands:
sed -i '/etc\/config\/alertsnrf/d' /tmp/tempConfig.yaml
sed -i '/rule_files:/a\ \- /etc/config/alertsnrf' /tmp/tempConfig.yaml
Note:
This command should be run only once. - If alertsnrf is not present, add the
alertsnrf entry in the tempConfig.yaml file by
running the following command:
sed -i '/rule_files:/a\ \- /etc/config/alertsnrf' /tmp/tempConfig.yaml
- If alertsnrf is present, delete the
alertsnrf entry from the tempConfig.yaml file, by
running the following commands:
- Update configuration map with updated file name of
NRF alert file:
kubectl replace configmap _NAME_-server -f /tmp/tempConfig.yaml
- Add NRF
alert rules in configuration map under file name of NRF alert file:
kubectl patch configmap _NAME_-server -n _Namespace_--type merge --patch "$(cat ~/NrfAlertrules.yaml)"
Update NRF alerts for CNE 1.9.x
This section describes the measurement based Alert rules configuration for NRF in Prometheus. Use the ocnrf_alerting_rules_promha_25.1.200.yaml file updated in NRF Alert configuration section.
- Run the following command to apply the prometheusrules
CRD:
$ kubectl apply -f ocnrf_alerting_rules_promha_25.1.200.yaml --namespace <namespace>
Example:$ kubectl apply -f ocnrf_alerting_rules_promha_25.1.200.yaml --namespace ocnrf prometheusrule.monitoring.coreos.com/ocnrf-alerting-rules created
- Run the following command to check NRF
alert file is added to
prometheusrules:
Example:$ kubectl get prometheusrules --namespace <namespace>
$ kubectl get prometheusrules --namespace ocnrf
Sample output:NAME AGE ocnrf-alerting-rules 1m
- Log in to Prometheus GUI and verify the alerts.
The following alert configuration file must be loaded as shown in the figure.
Figure 6-2 Prometheus Alert Manager
Note:
The Prometheus server takes an updated configuration map that is automatically reloaded after approximately 60 seconds. Refresh the Prometheus GUI to confirm that the NRF Alerts have been reloaded.Validating Alerts
After configuring the alerts in Prometheus server, a user can verify the same by following steps:
- Open the Prometheus server from your browser using the <IP>:<Port>
- Navigate to Status and then Rules.
- Search Ocnrf. OcnrfAlerts list will appear.
Note:
If you are unable to see the alerts, it means the alert file is not loaded in a format that Prometheus server accepts. Modify the file and try again.
6.3.5.1 Disable Alerts
- Edit NrfAlertrules-25.1.200.yaml file to remove a specific alert.
- Remove complete content of a specific alert from the
NrfAlertrules-25.1.200.yaml
file.
For example: If you want to remove
OcnrfTrafficRateAboveMinorThreshold
alert, remove the complete content:## ALERT SAMPLE START## - alert: OcnrfTrafficRateAboveMinorThreshold annotations: description: 'Ingress traffic Rate is above minor threshold i.e. 800 mps (current value is: {{ $value }})' summary: 'Traffic Rate is above 80 Percent of Max requests per second(1000)' expr: sum(rate(oc_ingressgateway_http_requests_total{app_kubernetes_io_name="ingressgateway",kubernetes_namespace="ocnrf"}[2m])) >= 800 < 900 labels: severity: Minor ## ALERT SAMPLE END##
- Perform Alert configuration. For more information about configuring alerts, see NRF Alert Configuration section.
6.3.5.2 Configuring SNMP Notifier
This section describes the procedure to configure SNMP Notifier.
- Run the following command to edit the
deployment:
$ kubectl edit deploy <snmp_notifier_deployment_name> -n <namespace>
Example:
$ kubectl edit deploy occne-snmp-notifier -n occne-infra
SNMP deployment yaml file is displayed.
- Edit the SNMP destination in the deployment
yaml file as
follows:
--snmp.destination=<destination_ip>:<destination_port>
Example:
--snmp.destination=10.75.203.94:162
- Save the file.
$ docker logs <trapd_container_id>
2020-04-29 15:34:24 10.75.203.103 [UDP: [10.75.203.103]:2747->[172.17.0.4]:162]:DISMAN-EVENT-MIB::sysUpTimeInstance = Timeticks: (158510800) 18 days, 8:18:28.00 SNMPv2-MIB::snmpTrapOID.0 = OID: SNMPv2-SMI::enterprises.323.5.3.36.1.2.7003 SNMPv2-SMI::enterprises.323.5.3.36.1.2.7003.1 = STRING: "1.3.6.1.4.1.323.5.3.36.1.2.7003[]" SNMPv2-SMI::enterprises.323.5.3.36.1.2.7003.2 = STRING: "critical" SNMPv2-SMI::enterprises.323.5.3.36.1.2.7003.3 = STRING: "Status: critical- Alert: OcnrfActiveSubscribersBelowCriticalThreshold Summary: namespace: ocnrf, nftype:5G_EIR, nrflevel:6faf1bbc-6e4a-4454-a507-a14ef8e1bc5c, podname: ocnrf-nrfauditor-6b459f5db5-4kvt4,
timestamp: 2020-04-29 15:33:24.408 +0000 UTC: Current number of registered NFs detected below critical threshold. Description: The number of registered NFs detected below critical threshold (current value
is: 0)
There are two MIB files which are used to generate the traps. The user need to update these files along with the Alert file in order to fetch the traps in their environment.
- ocnrf_mib_tc_25.1.200.mib
This is considered as NRF top level mib file, where the objects and their data types are defined.
- ocnrf_mib_25.1.200.mib
This file fetches the objects from the top level mib file and based on the alert notification, these objects can be selected for display.
- toplevel_25.1.200.mib: This defines the OIDs for all NFs.
Note:
MIB files are packaged along with the release package. Download the file from MOS. For more information on downloading the release package, see Oracle Communications Cloud Native Core, Network Repository Function Installation, Upgrade, and Fault Recovery Guide.6.3.6 NRF Alert Configuration in OCI
The following procedure describes how to configure the NRF alerts for OCI. The OCI supports metric expressions written in MQL (Metric Query Language) and thus, requires a new NRF alert file for configuring alerts in OCI observability platform.
The following are the steps:
- Run the following command to extract the .zip
file:
Theunzip ocnrf_oci_alertrules_<version>.zip
ocnrf_oci
andocnrf_oci_resources
folders are available in the zip file.Note:
The zip file is available in the Scripts folder of CSAR package. - Open the
ocnrf_oci
folder, in thenotifications.tf file
, update the parameterendpoint
with the email id of the user. - Open the
ocnrf_oci_resources
folder, in thenotifications.tf file
, update the parameterendpoint
with the email id of the user (replace test@gmail.com with the email id of the user). - Log in to the OCI Console.
Note:
For more details about logging in to the OCI, refer to Signing In to the OCI Console. - Open the navigation menu and select Developer Services. The Developer Services window appears in the right pane.
- Under the Developer Services, select Resource Manager.
- Under Resource Manager, select Stacks. The Stacks window appears.
- Click Create Stack.
- Select the default My Configuration radio button.
- Under Stack configuration, select the folder radio button and upload
the
ocnrf_oci
folder. - Enter the Name and Description and select the compartment.
- Select the latest Terraform version from the Terraform version drop-down.
- Click Next. The Edit Stack screen appears.
- Enter the required inputs to create the NRF alerts or alarms and click Save and Run Apply.
- Verify that the alarms are created in the Alarm Definitions screen (OCI
Console> Observability & Management>
Monitoring>Alarm Definitions)
provided.
The required inputs are:
- Alarms Configuration
- Compartment Name - Choose name of compartment from the drop-down
- Metric namespace - Metric namespace that the user provided while deploying OCI Adaptors.
- Topic Name - Any user configurable name. Must contain fewer than 256 characters. Only alphanumeric characters plus hyphens (-) and underscores (_) are allowed.
- Message Format - Keep it as ONS_OPTIMIZED. (This is pre-populated)
- Alarm is_enabled - Keep it as True. (This is pre-populated)
- Alarms Configuration
- The steps 6 to 16 must be repeated for uploading the
ocnrf_oci_resources
folder. Keep Metric namespace as mgmtagent_kubernetes_metrics (This is pre-populated).
