1. Cashbook User Guide
  2. Cashbook Setup

2 Cashbook Setup

This section describes the procedure to configure the Cashbook Category and Transaction Codes.

Transaction Codes Setup

The Transaction Codes comprises of two tabs:

  • Pay-In – Receiving Codes

  • Pay-Out – Expenses Codes.

Setting Up Transaction Codes

  1. At the Cashbook context menu, select Setup Transaction Codes.
  2. To add Pay-In Transactions Code, select the Pay-in Code tab and click New.

    Figure 2-1 Cashbook Transaction Codes


    This figure shows the Cashbook Transaction Codes
  3. At the Pay-In code form, Code and Name field, insert a unique transaction code.
  4. You can randomly create the Transactions code as it has an option to link the code to its corresponding general ledger account.
  5. By default, the Enabled checkbox is checked. Deselect the check mark to deactivate the code.
  6. Check the Pay-Out/Pay-In code checkbox to duplicate the code to Pay-Out, or vice versa. This option depends on the Parameter setting “Same Pay-In/Out Codes”.
  7. To delete the Transactions Code, select the code and click the Remove button. You are not allowed to delete a code that transaction linked.
  8. To edit the details, click Edit.

Cashbook Category Setup

You can delete the Cashbook using the Remove option. However, once you have a transaction linked to the Cashbook, deleting or removing is not allowed.

  1. Login to Cashbook module and select Setup Cashbooks from the context menu.

  2. At the Cashbook Setup screen, right-click and select Add New.

  3. Enter a unique Cashbook Code and Description.

  4. At the Min. Balance field, enter the minimum cashbook balance. This value is used to calculate the Balance Differences (Current Balance — Minimum Balance) in Cashbook Transactions.

  5. Choose the Default Currency code for the Cashbook. This code is used to separate the currencies accepted (EUR, USD, SGD, and others) and record the cash available in each currency type.

  6. The Pay-in/Out codes refers to above Transactions Codes. Select the corresponding code from the drop-down list, and then click OK to save.

  7. You can delete the Cashbook using the Remove option. However, once you have a transaction linked to the Cashbook, deleting or removing is not allowed.

Scanning Device

The Cashbook module have a scanning function to stores transaction documents. You would need to install a scanning device in Management module, Options, Hardware setup.

  1. Login to Management module, select Options and then click on Document Scanner tab.
  2. Choose the required scanner from Select Scanner drop-down list.
  3. Check mark the Set as Default checkbox, if this is a default scanner.
  4. Check mark the Enable Manufacturer Default Settings Dialog before Scan checkbox to enable the user to re-configure the scanning settings before the scanning process.
  5. At the Scanner Setting section, select the relevant options from the drop-down list.
  6. Check the Auto Brightness for the scanning effect and Deskew for straightening the image, and then adjust the brightness accordingly.
  7. Click OK to save the setting.
